miseno MNO621A User manual

SAFETY TIPS
• Cover your drain to avoid losing parts.
• The fittings should be installed by a licensed
plumber in your State.
• When installing flexible hose, Please note there
should be no torsion or deformation; do not fold
into Shape V or L; do not use if there are any cracks
or deformation
Questions, problems, missing parts?
Before returning to your retailer, please contact Customer Service at 1-855-480-2915 or [email protected]
BEFORE INSTALLATION:
If you contact Customer Service, you will need the Model#, Serial Number
and Date Code. Please locate the Product ID tag and Serial number tag.
Please record the serial number and date code here BEFORE YOU INSTALL:
__________________ ____________
Serial Number Date Code
Please attach your receipt for proof of purchase.
TOOLS YOU WILL NEED
Phillips screwdriver
Adjustable wrench
Pipe tape
Groove joint plier
Silicone Sealant
Model
MNO621 CP/SS/ORB
MNO621A
Single-Handle Pull-Down Kitchen Faucet

FAUCET INSTALLATION PROCEDURE
To avoid over tightening inlet port to spout shank, use a second wrench to prevent inlet port from turning while attaching water hose, as seen in diagram.
SHUT OFF MAIN WATER SUPPLIES BEFORE INSTALLATION
!CAUTION
1. Shut off water supplies. Remove old faucet. Clean
sink surface in preparation for new faucet.
2. Remove locknut and install faucet through center
hole.
3. Unscrew screws on lock nut. Slide rubber washer
and metal washer onto shank. Secure shank with
locknut.
4. Apply pipe tape onto threads of the copper inlet
tube.
5. Remove the plastic seal cover from the outlet port
prior to pushing the hose adapter onto the same port.
You will hear a “click” sound once they are joined
properly.

TROUBLESHOOTING
If you've followed the instructions carefully and your faucet still does not work properly, take these corrective steps.
Problem Cause Action
Locking nut has come loose. O-ring
on cartridge is dirty or damaged.
Metal weight is not installed in the
appropriate position.
Hose and spray head connection may
be loose.
Tighten the locking nut. Clean or
replace O-ring.
Reinstall rubber weight (step 6).
Tighten the connection between the
spray head and hose.
Leaks underneath handle.
Hose does not retract.
There are leaks from the hose
underneath the deck.
6. Locate lowest point of the hose on the spout side
and attach the rubber-coated weight.
7. After installing faucet, remove the aerator and turn on
water to remove any leftover debris. Then reassemble the
aerator.

REPLACEMENT PARTS
Maintenance Your new faucet is designed for years of trouble-free performance. Keep it looking new by cleaning it periodically
with a soft cloth. Avoid abrasive cleaners, steel wool and harsh chemicals as these will dull the finish and void your warranty.
1 Handle Cap Assembly A66D558
(RW/OB/RL) A603595
2 Handle A069456
3 Trim Cap A103016
4 Locking Nut A104207
5 Ceramic Disc Cartridge A507348N
6 O-Ring A004074N
7 Pattern clip A012357
8 Hose Guide A126048GR
9 Hand Spray w/Check Valve A528030N-54
10 Trim Ring A667360
11 Cover Plate Assembly A667003
12 Mounting Hardware Assembly A66D477
13 Hose adaptor Assembly A66G142N
14 Spray Hose A514001WGR
15 Weight A504713
16 Aerator Wrench A031237GR
