MiTAC Tyan S5542 User manual

http://www.tyan.com
1
S5542
Version 1.0b
Copyright
Copyright © 2017 MiTAC International Corporation. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
MiTAC International Corporation.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
TYAN®is a trademark of MiTAC International Corporation.
Intel®is a trademark of Intel®Corporation.
AMI, AMI BIOS are trademarks of AMI Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
Nuvoton®is a trademark of Nuvoton Technology Corporation.
Notice
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN®products including liability or
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MiTAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.

http://www.tyan.com
2

http://www.tyan.com
3
Contents
Before you begin…....................................................................................4
Chapter 1: Instruction ................................................................................ 5
1.1 Congratulations .................................................................................5
1.2 Hardware Specifications....................................................................5
1.3 Software Specifications...................................................................14
Chapter 2: Board Installation................................................................... 15
2.1 Board Image....................................................................................16
2.2 Block Diagram.................................................................................17
2.3 Mainboard Mechanical Drawing......................................................18
2.4 Board Parts, Jumpers and Connectors...........................................19
2.5 LED Definitions................................................................................26
2.6 Installing the Processor and Heat sink............................................29
2.7 Thermal Interface Material ..............................................................33
2.8 Tips on Installing Motherboard in Chassis ......................................34
2.9 Installing the Memory ......................................................................36
2.10 Attaching Drive Cables..................................................................39
2.11 Installing Add-In Cards..................................................................40
2.12 Connecting External Devices ........................................................41
2.13 Installing the Power Supply...........................................................42
2.14 Finishing Up...................................................................................42
Chapter 3: BIOS Setup ............................................................................. 43
3.1 About the BIOS................................................................................43
3.2 Main Menu.......................................................................................45
3.3 Advanced Menu...............................................................................46
3.4 Chipset Menu ..................................................................................72
3.5 Security............................................................................................79
3.6 Server Management........................................................................80
3.7 Boot .................................................................................................85
3.8 Save & Exit......................................................................................87
Chapter 4: Diagnostics............................................................................. 89
4.1 Flash Utility......................................................................................89
4.2 AMIBIOS Post Code (Aptio)............................................................90
Appendix: Fan and Temp Sensors.......................................................... 97
Glossary................................................................................................... 101
Technical Support .................................................................................. 107

http://www.tyan.com
4
Before you begin…
Check the box contents!
The retail motherboard package should contain the following:
1 x S5542 Motherboard
2 x SATA Cable
1 x Rear IO Shield
1 x S5542 Quick reference guide
1 x TYAN®Driver’s and Utilities DVD
IMPORTANT NOTE:
Sales sample may not come with the accessory listed above.
Please contact your sales representative to help order accessory for your
evaluation.

http://www.tyan.com
5
Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN® S5542 motherboard, based on the
Intel®C232 chipset. The S5542 is designed to support single Intel®Xeon E3-
1200 v5 series processor, and up to 64GB of un-buffered ECC UDIMM DDR4
2133MHz memory. Leveraging advanced technology from Intel®, the S5542 is
capable of offering scalable 32 and 64-bit computing, high-bandwidth memory
design, and lightning-fast PCI-E bus implementation.
The S5542 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provides the S5542 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN® website at http://www.tyan.com. There you can
find all the information on all TYAN®products as well as all the supporting
documentation, FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
TYAN S5542 (S5542WGM2NR)
Processor
Supported CPU
Series Intel Xeon E3-1200 v5 series processors
Socket Type / Q'ty LGA1151 / (1)
Thermal Design
Power (TDP)
wattage Max up to 80W
Chipset PCH Intel C232
Memory
Supported DIMM
Qty (4) DIMM slots
DIMM Type / Speed Unbuffered ECC UDIMM DDR4 2133
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V
Expansion
Slots PCI-E (1) PCI-E Gen.3 x16 slot (w/ x8 link) / (2) PCI-E Gen.3 x1 slot
LAN
Port Q'ty (2) GbE ports + (1) dedicated for IPMI
Controller Intel I210
PHY Broadcom BCM5221 PHY (dedicated for IPMI
connection)
Storage SAS Connector (2) Mini-SAS HD connectors (totally support 8 ports)

http://www.tyan.com
6
Controller LSI SAS3008
Speed 12.0 Gb/s
RAID RAID 0/1/1E/10 (LSI Integrated RAID)
SATA
Connector (6) SATA
Controller Intel C232
Speed 6.0 Gb/s
RAID RAID 0/1/10/5 (Intel RST)
Graphic
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Chipset Aspeed AST2400
Input /Output
USB (3) USB2.0 ports (2 via cable, 1 Type-A) / (6) USB3.0
ports (4 at rear, 2 via cable)
COM (2) ports (1 at rear, 1 via cable)
SAS (2) Mini-SAS HD (4-in-1) connectors
VGA (1) D-Sub 15-pin VGA port
RJ-45 (2) GbE ports, (1) Dedicated for IPMI
PSMI (1) 1x5-pin header
Others (1) Reset button/ (1) Power button
SATA (6) SATA-III connectors
System
Monitoring
Chipset Aspeed AST2400
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (4) 4-pin headers
Temperature Monitors temperature for CPU & memory & system
environment
LED Over temperature warning indicator / Fan & PSU fail
LED indicator
Others Watchdog timer support
Server
Management
Onboard Chipset Onboard Aspeed AST2400
AST2400 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
AST2400 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s MAC interface
BIOS
Brand / ROM size AMI / 16MB
Feature
Hardware Monitor / ACPI 5.0 / SMBIOS
3.0/PnP/Wake on LAN / ACPI sleeping states
S3,S4,S5 / Boot from USB device ,PXE via
LAN ,Storage / User Configurable FAN PWM Duty
Cycle / Console Redirection
Physical
Dimension
Form Factor ATX
Board Dimension 12"x9.6" (305x243.8mm)
Operating
System OS supported list Please refer to our Intel OS supported list.

http://www.tyan.com
7
Regulation FCC (DoC) Class A
CE (DoC) Yes
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Package
Contains
Motherboard (1) S5542 Motherboard
Manual (1) Web User's manual / (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
TYAN S5542 (S5542GM2NR)
Processor
Supported CPU
Series Intel Xeon E3-1200 v5 series processors
Socket Type / Q'ty LGA1151 / (1)
Thermal Design
Power (TDP)
wattage Max up to 80W
Chipset PCH Intel C232
Memory
Supported DIMM
Qty (4) DIMM slots
DIMM Type / Speed Unbuffered ECC UDIMM DDR4 2133
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V
Expansion
Slots PCI-E (1) PCI-E Gen.3 x16 slot (w/ x8 link) / (1) PCI-E Gen.3 x8 slot / (2) PCI-E Gen.3 x1 slot
LAN
Port Q'ty (2) GbE ports + (1) dedicated for IPMI
Controller Intel I210
PHY Broadcom BCM5221 PHY (dedicated for IPMI
connection)
Storage SATA
Connector (6) SATA
Controller Intel C232
Speed 6.0 Gb/s
RAID RAID 0/1/10/5 (Intel RST)
Graphic
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Chipset Aspeed AST2400
Input /Output USB (3) USB2.0 ports (2 via cable, 1 Type-A) / (6) USB3.0
ports (4 at rear, 2 via cable)
COM (2) ports (1 at rear, 1 via cable)

http://www.tyan.com
8
VGA (1) D-Sub 15-pin VGA port
RJ-45 (2) GbE ports, (1) Dedicated for IPMI
PSMI (1) 1x5-pin header
Others (1) Reset button/ (1) Power button
SATA (6) SATA-III connectors
System
Monitoring
Chipset Aspeed AST2400
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (4) 4-pin headers
Temperature Monitors temperature for CPU & memory & system
environment
LED Over temperature warning indicator / Fan & PSU fail
LED indicator
Others Watchdog timer support
Server
Management
Onboard Chipset Onboard Aspeed AST2400
AST2400 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
AST2400 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s MAC interface
BIOS
Brand / ROM size AMI / 16MB
Feature
Hardware Monitor / ACPI 5.0 / SMBIOS
3.0/PnP/Wake on LAN / ACPI sleeping states
S3,S4,S5 / Boot from USB device ,PXE via
LAN ,Storage / User Configurable FAN PWM Duty
Cycle / Console Redirection
Physical
Dimension
Form Factor ATX
Board Dimension 12"x9.6" (305x243.8mm)
Operating
System OS supported list Please refer to our Intel OS supported list.
Regulation FCC (DoC) Class A
CE (DoC) Yes
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Package
Contains
Motherboard (1) S5542 Motherboard
Manual (1) Web User's manual / (1) Quick Installation Guide
Installation CD (1) TYAN installation CD

http://www.tyan.com
9
TYAN S5542 (S5542GM4NR)
Processor
Supported CPU
Series Intel Xeon E3-1200 v5 series processors
Socket Type / Q'ty LGA1151 / (1)
Thermal Design
Power (TDP)
wattage Max up to 80W
Chipset PCH Intel C232
Memory
Supported DIMM
Qty (4) DIMM slots
DIMM Type / Speed Unbuffered ECC UDIMM DDR4 2133
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V
Expansion
Slots PCI-E (1) PCI-E Gen.3 x16 slot (w/ x8 link) / (1) PCI-E Gen.3 x8 slot / (2) PCI-E Gen.3 x1 slot
LAN
Port Q'ty (4) ports + (1) dedicated for IPMI
Controller Intel I210
PHY Broadcom BCM5221 PHY (dedicated for IPMI
connection)
Storage SATA
Connector (6) SATA
Controller Intel C232
Speed 6.0 Gb/s
RAID RAID 0/1/10/5 (Intel RST)
Graphic
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Chipset Aspeed AST2400
Input /Output
USB (3) USB2.0 ports (2 via cable, 1 Type-A) / (6) USB3.0
ports (4 at rear, 2 via cable)
COM (2) ports (1 at rear, 1 via cable)
VGA (1) D-Sub 15-pin VGA port
RJ-45 (4) GbE ports, (1) Dedicated for IPMI
PSMI (1) 1x5-pin header
Others (1) Reset button/ (1) Power button
SATA (6) SATA-III connectors
System
Monitoring
Chipset Aspeed AST2400
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (4) 4-pin headers
Temperature Monitors temperature for CPU & memory & system
environment
LED Over temperature warning indicator / Fan & PSU fail
LED indicator

http://www.tyan.com
10
Others Watchdog timer support
Server
Management
Onboard Chipset Onboard Aspeed AST2400
AST2400 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
AST2400 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s MAC interface
BIOS
Brand / ROM size AMI / 16MB
Feature
Hardware Monitor / ACPI 5.0 / SMBIOS
3.0/PnP/Wake on LAN / ACPI sleeping states
S3,S4,S5 / Boot from USB device ,PXE via
LAN ,Storage / User Configurable FAN PWM Duty
Cycle / Console Redirection
Physical
Dimension
Form Factor ATX
Board Dimension 12"x9.6" (305x243.8mm)
Operating
System OS supported list Please refer to our Intel OS supported list.
Regulation FCC (DoC) Class A
CE (DoC) Yes
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Package
Contains
Motherboard (1) S5542 Motherboard
Manual (1) Web User's manual / (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
TYAN S5542-UHE (S5542G2NR-UHE)
Processor
Supported CPU
Series Intel Xeon E3-1200 v5 series processors
Socket Type / Q'ty LGA1151 / (1)
Thermal Design
Power (TDP)
wattage Max up to 80W
Chipset PCH Intel C236
Memory
Supported DIMM
Qty (4) DIMM slots
DIMM Type / Speed Unbuffered ECC UDIMM DDR4 2133
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V

http://www.tyan.com
11
Expansion
Slots PCI-E (1) PCI-E Gen.3 x16 slot (w/ x8 link) / (1) PCI-E Gen3
x8 slot ( w/ x4 link) / (1) PCI-E Gen.3 x8 slot / (2) PCI-
E Gen.3 x1 slot
LAN Port Q'ty (2) GbE ports
Controller Intel I210
Storage SATA
Connector (8) SATA
Controller Intel C236
Speed 6.0 Gb/s
RAID RAID 0/1/10/5 (Intel RST)
Graphic Connector type D-Sub 15-pin
Chipset Intel Processor Graphics(pGFX)
Input /Output
USB (3) USB2.0 ports (2 via cable, 1 Type-A) / (6) USB3.0
ports (4 at rear, 2 via cable)
COM (2) ports (1 at rear, 1 via cable)
VGA (1) D-Sub 15-pin VGA port
RJ-45 (2) GbE ports
PSMI (1) 1x5-pin header
Others (1) Reset button/ (1) Power button
SATA (8) SATA-III connectors
System
Monitoring
Chipset Aspeed AST1400
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (4) 4-pin headers
Temperature Monitors temperature for CPU & system environment
LED Over temperature warning indicator / Fan & PSU fail
LED indicator
Others Watchdog timer support
BIOS
Brand / ROM size AMI / 16MB
Feature
Hardware Monitor / ACPI 5.0 / SMBIOS
3.0/PnP/Wake on LAN / ACPI sleeping states
S3,S4,S5 / Boot from USB device ,PXE via
LAN ,Storage / User Configurable FAN PWM Duty
Cycle / Console Redirection
Physical
Dimension
Form Factor ATX
Board Dimension 12"x9.6" (305x243.8mm)
Operating
System OS supported list Please refer to our Intel OS supported list.
Regulation FCC (DoC) Class A
CE (DoC) Yes
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C

http://www.tyan.com
12
RoHS RoHS 6/6 Compliant Yes
Package
Contains
Motherboard (1) S5542 Motherboard
Manual (1) Web User's manual / (1) Quick Installation Guide
Installation CD (1) TYAN installation CD
TYAN S5542-UHE (S5542G2NR-UHE-M2)
Processor
Supported CPU
Series Intel Xeon E3-1200 v5 series processors
Socket Type / Q'ty LGA1151 / (1)
Thermal Design
Power (TDP)
wattage Max up to 80W
Chipset PCH Intel C236
Memory
Supported DIMM
Qty (4) DIMM slots
DIMM Type / Speed Unbuffered ECC UDIMM DDR4 2133
Capacity Up to 64GB
Memory channel 2 Channels
Memory voltage 1.2V
Expansion
Slots PCI-E (1) PCI-E Gen.3 x16 slot (w/ x8 link) / (1) PCI-E Gen3
x8 slot ( w/ x4 link) / (1) PCI-E Gen.3 x8 slot / (2) PCI-
E Gen.3 x1 slot
LAN Port Q'ty (2) GbE ports
Controller Intel I210
SATA
Connector (7) SATA
Storage Controller Intel C236
Speed 6.0 Gb/s
RAID RAID 0/1/10/5 (Intel RST)
M.2 connector (1) M.2 connector (2242 only)
Graphic Connector type D-Sub 15-pin
Chipset Intel Processor Graphics(pGFX)
Input /Output
USB (3) USB2.0 ports (2 via cable, 1 Type-A) / (6) USB3.0
ports (4 at rear, 2 via cable)
COM (2) ports (1 at rear, 1 via cable)
VGA (1) D-Sub 15-pin VGA port
RJ-45 (2) GbE ports
PSMI (1) 1x5-pin header
Others (1) Reset button/ (1) Power button/ (1) M.2 NGFF
connector
SATA (7) SATA-III connectors
System
Monitoring
Chipset Aspeed AST1400
Voltage Monitors voltage for CPU, memory, chipset & power

http://www.tyan.com
13
supply
Fan Total (4) 4-pin headers
Temperature Monitors temperature for CPU & system environment
LED Over temperature warning indicator / Fan & PSU fail
LED indicator
Others Watchdog timer support
BIOS
Brand / ROM size AMI / 16MB
Feature
Hardware Monitor / ACPI 5.0 / SMBIOS
3.0/PnP/Wake on LAN / ACPI sleeping states
S3,S4,S5 / Boot from USB device ,PXE via
LAN ,Storage / User Configurable FAN PWM Duty
Cycle / Console Redirection
Physical
Dimension
Form Factor ATX
Board Dimension 12"x9.6" (305x243.8mm)
Operating
System OS supported list Please refer to our Intel OS supported list.
Regulation FCC (DoC) Class A
CE (DoC) Yes
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Package
Contains
Motherboard (1) S5542 Motherboard
Manual (1) Web User's manual / (1) Quick Installation Guide
Installation CD (1) TYAN installation CD

http://www.tyan.com
14
5 SKU Comparison Table
Part Number BMC PCH
Expand. slot SAS
12
Gb/s
SAS
Raid
SATA
6
Gb/s
1G
LAN
USB
3.0
M.2
(NGFF)
X16 / X8 / X4
/ x1
S5542GM2NR Yes C232 1 / 1 / 0 / 2 0No 62 4 0
S5542WGM2NR Yes C232 1 / 0 / 0 / 2 8Yes 62 4 0
S5542GM4NR Yes C232 1 / 1 / 0 / 2 0No 64 4 0
S5542G2NR-
UHE No C236 1 / 2 / 0 / 2 0No 82 4 0
S5542G2NR-
UHE-M2 No C236 1 / 2 / 0 / 2 0No 72 4 1
1.3 Software Specifications
For OS (operation system) support, please check with TYAN®support for latest
information.

http://www.tyan.com
15
Chapter 2: Board Installation
You are now ready to install your motherboard.
How to install our products right… the first time
The first thing you should do is reading this user’s manual. It contains important
information that will make configuration and setup much easier. Here are some
precautions you should take when installing your motherboard:
(1) Ground yourself properly before removing your motherboard from the
antistatic bag. Unplug the power from your computer power supply and
then touch a safely grounded object to release static charge (i.e. power
supply case). For the safest conditions, MiTAC recommends wearing a
static safety wrist strap.
(2) Hold the motherboard by its edges and do not touch the bottom of the
board, or flex the board in any way.
(3) Avoid touching the motherboard components, IC chips, connectors,
memory modules, and leads.
(4) Place the motherboard on a grounded antistatic surface or on the antistatic
bag that the board was shipped in.
(5) Inspect the board for damage.
The following pages include details on how to install your motherboard into your
chassis, as well as installing the processor, memory, disk drives and cables.
NOTE: Do not apply power to the board if it has been damaged.

http://www.tyan.com
16
2.1 Board Image
S5542
This picture is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above picture.

http://www.tyan.com
17
2.2 Block Diagram
S5542 Block Diagram

http://www.tyan.com
18
2.3 Mainboard Mechanical Drawing

http://www.tyan.com
19
2.4 Board Parts, Jumpers and Connectors
This diagram is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above diagram. But
for the DIMM number please refer to the above placement for memory installation.
For the latest board revision, please visit our web site at http://www.tyan.com.

http://www.tyan.com
20
Connectors/Slots
1 ID LED Button (ID_BTN) 16 SATA Port (SATA 3.0, 6 Gbit/s)
(SATA6, J40)
2 LAN5 Port / USB Port (USB 3.0)*2 (J2) 17 SATA Port (SATA 3.0, 6 Gbit/s)
(SATA5, J41)
3 VGA Port (D-Sub) / COM Port (RS-232)
(J10) 18 SATA Port (SATA 3.0, 6 Gbit/s) (SATA4, J42)
4 USB Port (USB 3.0)*2 (J5) 19 SATA Port (SATA 3.0, 6 Gbit/s)
(SATA3, J43)
5 LAN3, LAN4 Port (RJ-45)*2 (J8) 20 SATA Port (SATA 3.0, 6 Gbit/s)
(SATA2, J44)
6 LAN1, LAN2 Port (RJ-45)*2 (J7) 21 SATA Port (SATA 3.0, 6 Gbit/s)
(SATA1, J45)
7 PCI Express Slot (x16 Slot, w/x8 link)
(PCIE1) 22 SATA Port (SATA 3.0, 6 Gbit/s) (SATA0, J46)
8 PCI Express Slot (x8 Slot, w/x4 link)
(J12) 23 M.2 (SATA 3.0, 6 Gbit/s, NGFF) (U57)
9 PCI Express Slot (x8 Slot, w/x8 link)
(J11) 24 8-Pin CPU Power Suppiy Connector (PWRCONN1, PW2)
10 PCI Express Slot (x1 Slot, w/x1 link)
(J18) 25 DIMM_A0 (DDR4, Blue, Address:0xA0) (J8C1)
11 PCI Express Slot (x1 Slot, w/x1 link)
(J17) 26 DIMM_A1 (DDR4, Black, Address:0xA2) (J8C2)
12 SAS Port (LSI SAS3008, MINI SAS, 2
Port, 12 Gbit/s) (J28) 27 DIMM_B0 (DDR4, Blue, Address:0xA4) (J8C3)
13 SAS Port (LSI SAS3008, MINI SAS, 2
Port, 12 Gbit/s) (J29) 28 DIMM_B1 (DDR4, Black, Address:0xA6) (J8C4)
14 USB Port (USB2.0, Type-A, 480M/s)
(J33) 29 ATX 24-Pin Power Supply Connector (J32, PW1)
15 SATA Port (SATA 3.0, 6 Gbit/s)
(SATA7, J39)
Headers
A PSMI Pin Header (J16) K Reset button (J36)
B System FAN5 Pin Header (J15) L Power button (J37)
C CPU Fan, PIN Header (J14) M System FAN4 Pin Header (J47)
D RS-232_DB-9_COM-Port_2 Pin
Header (J9) N System FAN3 Pin Header (J48)
E TPM, Debug PIN Header (J13) O System FAN2 Pin Header (J49)
F System FAN Board Pin Header (J19) P System FAN1 Pin Header (J50)
G SSI FP I/O PIN Header (J20) Q IPMB Pin Header (J51)
H USB Header (USB 2.0, 480M/s)* 2
(FP_USB_1) R LAN2 LED (J23)
I USB Header (USB 3.0, ,5G/s)* 2 (J35) S LAN3 LED (J24)
J SATA SGPIO Pin Header (HBA) (J34)
