TECHNICAL & SERVICE MANUAL
OUTDOOR UNIT
HFC
utilized
R410A
November 2020
<Outdoor unit>
[Model Name]
PARTS CATALOG (OCB668)
Salt proof model
[Service Ref.]
CONTENTS
TECHNICAL CHANGES································· 2
1. SAFETY PRECAUTION....................................3
2. OVERVIEW OF UNITS......................................6
3. SPECIFICATIONS........................................... 10
4. DATA................................................................12
5. OUTLINES AND DIMENSIONS...................... 27
6. WIRING DIAGRAM......................................... 28
7. NECESSARY CONDITIONS FOR SYSTEM CONSTRUCTION..... 30
8. TROUBLESHOOTING.................................... 46
9. ELECTRICAL WIRING...................................122
10. REFRIGERANT PIPING TASKS....................128
11. DISASSEMBLY PROCEDURE.......................135
12. REMOTE CONTROLLER.............................. 142
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
No. OCH668
REVISED EDITION-G
OCH668 REVISED
EDITION-F is void.
PUMY-SP112VKM.TH PUMY-SP112VKMR1.TH PUMY-SP112VKMR2.TH
PUMY-SP112VKM-ETR2.TH PUMY-SP112VKM-ERR2.TH
PUMY-SP125VKM.TH PUMY-SP125VKMR1.TH PUMY-SP125VKMR2.TH
PUMY-SP125VKM-ETR2.TH PUMY-SP125VKM-ERR2.TH
PUMY-SP140VKM.TH PUMY-SP140VKMR1.TH PUMY-SP140VKMR2.TH
PUMY-SP140VKM-ETR2.TH PUMY-SP140VKM-ERR2.TH
PUMY-SP112YKM.TH PUMY-SP112YKMR1.TH PUMY-SP112YKMR2.TH
PUMY-SP112YKM-ETR2.TH PUMY-SP112YKM-ERR2.TH
PUMY-SP125YKM.TH PUMY-SP125YKMR1.TH PUMY-SP125YKMR2.TH
PUMY-SP125YKM-ETR2.TH PUMY-SP125YKM-ERR2.TH
PUMY-SP140YKM.TH PUMY-SP140YKMR1.TH PUMY-SP140YKMR2.TH
PUMY-SP140YKM-ETR2.TH PUMY-SP140YKM-ERR2.TH
PUMY-SP112VKM.TH-BS PUMY-SP112VKMR1.TH-BS PUMY-SP112VKM-BSR2.TH
PUMY-SP112VKM-ET-BSR2.TH PUMY-SP112VKM-ER-BSR2.TH
PUMY-SP125VKM.TH-BS PUMY-SP125VKMR1.TH-BS PUMY-SP125VKM-BSR2.TH
PUMY-SP125VKM-ET-BSR2.TH PUMY-SP125VKM-ER-BSR2.TH
PUMY-SP140VKM.TH-BS PUMY-SP140VKMR1.TH-BS PUMY-SP140VKM-BSR2.TH
PUMY-SP140VKM-ET-BSR2.TH PUMY-SP140VKM-ER-BSR2.TH
PUMY-SP112YKM.TH-BS PUMY-SP112YKMR1.TH-BS PUMY-SP112YKM-BSR2.TH
PUMY-SP112YKM-ET-BSR2.TH PUMY-SP112YKM-ER-BSR2.TH
PUMY-SP125YKM.TH-BS PUMY-SP125YKMR1.TH-BS PUMY-SP125YKM-BSR2.TH
PUMY-SP125YKM-ET-BSR2.TH PUMY-SP125YKM-ER-BSR2.TH
PUMY-SP140YKM.TH-BS PUMY-SP140YKMR1.TH-BS PUMY-SP140YKM-BSR2.TH
PUMY-SP140YKM-ET-BSR2.TH PUMY-SP140YKM-ER-BSR2.TH
PUMY-SP112VKM
PUMY-SP112VKM-ET/ER
PUMY-SP125VKM
PUMY-SP125VKM-ET/ER
PUMY-SP140VKM
PUMY-SP140VKM-ET/ER
PUMY-SP112YKM
PUMY-SP112YKM-ET/ER
PUMY-SP125YKM
PUMY-SP125YKM-ET/ER
PUMY-SP140YKM
PUMY-SP140YKM-ET/ER
PUMY-SP112VKM-BS
PUMY-SP112VKM-ET/ER-BS
PUMY-SP125VKM-BS
PUMY-SP125VKM-ET/ER-BS
PUMY-SP140VKM-BS
PUMY-SP140VKM-ET/ER-BS
PUMY-SP112YKM-BS
PUMY-SP112YKM-ET/ER-BS
PUMY-SP125YKM-BS
PUMY-SP125YKM-ET/ER-BS
PUMY-SP140YKM-BS
PUMY-SP140YKM-ET/ER-BS
Revision:
• PUMY-SP112VKM-ER(-BS)R2.TH,
PUMY-SP125VKM-ER(-BS)R2.TH,
PUMY-SP140VKM-ER(-BS)R2.TH,
PUMY-SP112YKM-ER(-BS)R2.TH,
PUMY-SP125YKM-ER(-BS)R2.TH, and
PUMY-SP140YKM-ER(-BS)R2.TH have
been added in REVISED EDITION-G.

2
OCH668G
TECHNICAL CHANGES
PUMY-SP112VKMR1.TH PUMY-SP112VKMR2.TH
PUMY-SP125VKMR1.TH PUMY-SP125VKMR2.TH
PUMY-SP140VKMR1.TH PUMY-SP140VKMR2.TH
PUMY-SP112YKMR1.TH PUMY-SP112YKMR2.TH
PUMY-SP125YKMR1.TH PUMY-SP125YKMR2.TH
PUMY-SP140YKMR1.TH PUMY-SP140YKMR2.TH
PUMY-SP112VKMR1.TH-BS PUMY-SP112VKM-BSR2.TH
PUMY-SP125VKMR1.TH-BS PUMY-SP125VKM-BSR2.TH
PUMY-SP140VKMR1.TH-BS PUMY-SP140VKM-BSR2.TH
PUMY-SP112YKMR1.TH-BS PUMY-SP112YKM-BSR2.TH
PUMY-SP125YKMR1.TH-BS PUMY-SP125YKM-BSR2.TH
PUMY-SP140YKMR1.TH-BS PUMY-SP140YKM-BSR2.TH
• Some connectable indoor units have been added.
PUMY-SP112VKM.TH PUMY-SP112VKMR1.TH
PUMY-SP125VKM.TH PUMY-SP125VKMR1.TH
PUMY-SP140VKM.TH PUMY-SP140VKMR1.TH
PUMY-SP112YKM.TH PUMY-SP112YKMR1.TH
PUMY-SP125YKM.TH PUMY-SP125YKMR1.TH
PUMY-SP140YKM.TH PUMY-SP140YKMR1.TH
PUMY-SP112VKM.TH-BS PUMY-SP112VKMR1.TH-BS
PUMY-SP125VKM.TH-BS PUMY-SP125VKMR1.TH-BS
PUMY-SP140VKM.TH-BS PUMY-SP140VKMR1.TH-BS
PUMY-SP112YKM.TH-BS PUMY-SP112YKMR1.TH-BS
PUMY-SP125YKM.TH-BS PUMY-SP125YKMR1.TH-BS
PUMY-SP140YKM.TH-BS PUMY-SP140YKMR1.TH-BS
• Some connectable indoor units have been added.
Service ref. have been changed as follows.

3
OCH668G
Cautions for units utilizing refrigerant R410A
1-1. CAUTIONS RELATED TO NEW REFRIGERANT
1SAFETY PRECAUTION
Use new refrigerant pipes.
Avoid using thin pipes.
Use a vacuum pump with a reverse ow check
valve.
Vacuum pump oil may ow back into refrigerant cycle and
that can cause deterioration of refrigerant oil, etc.
Handle tools with care.
If dirt, dust or moisture enters into refrigerant cycle, that
can cause deterioration of refrigerant oil or malfunction of
compressor.
Do not use a charging cylinder.
If a charging cylinder is used, the composition of refrigera-
nt will change and the e󰀩ciency will be lowered.
Use the specied refrigerant only.
Never use any refrigerant other than that specied.
Doing so may cause a burst, an explosion, or re when
the unit is being used, serviced, or disposed of.
Correct refrigerant is specied in the manuals and on the
spec labels provided with our products.
We will not be held responsible for mechanical failure,
system malfunction, unit breakdown or accidents caused
by failure to follow the instructions.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a ame, poisonous gases will be released.
Use the following tools specically designed for
use with R410A refrigerant.
The following tools are necessary to use R410A
refrigerant.
Tools for R410A
Gauge manifold Flare tool
Charge hose Size adjustment gauge
Gas leak detector Vacuum pump adaptor
Torque wrench Electronic refrigerant
charging scale
Make sure that the inside and outside of refrige-
rant piping is clean and it has no contaminants
such as sulfur, oxides, dirt, shaving particles,
etc.,
which are hazard to refrigerant cycle.
In addition, use pipes with specied thickness.
Contamination inside refrigerant piping can cause deterio-
ration of refrigerant oil, etc.
Store the piping indoors, and keep both ends of
the piping sealed until just before brazing.
(Leave elbow joints, etc. in their packaging.)
If dirt, dust or moisture enters into refrigerant cycle, that
can cause deterioration of refrigerant oil or malfunction of
compressor.
The refrigerant oil applied to are and ange
connections must be ester oil, ether oil or
alkylbenzene oil in a small amount.
If large amount of mineral oil enters, that can cause
deterioration of refrigerant oil, etc.
Charge refrigerant from liquid phase of gas
cylinder.
If the refrigerant is charged from gas phase, composition
change may occur in refrigerant and the e󰀩ciency will be
lowered.
Do not use refrigerant other than R410A.
If other refrigerant (R22, etc.) is used, chlorine in refrige-
rant can cause deterioration of refrigerant oil, etc.
Precautions during the repair service
• Do not perform the work involving the electric parts
with wet hands.
• Do not pour water into the electric parts.
• Do not touch the refrigerant.
•
Do not touch the hot or cold areas in the refrigerating cycle.
• When the repair or the inspection of the circuit needs
to be done without turning o󰀨 the power, exercise great
caution not to touch the live parts.
Preparation before the repair service
• Prepare the proper tools.
• Prepare the proper protectors.
• Provide adequate ventilation.
• After stopping the operation of the air conditioner, turn
o󰀨 the power-supply breaker.
• Discharge the condenser before the work involving the
electric parts.

4
OCH668G
Unit
Electronic weighing scale
[3] Service tools
Use the below service tools as exclusive tools for R410A refrigerant.
[1] Cautions for service
(1) Perform service after recovering the refrigerant left in unit completely.
(2) Do not release refrigerant in the air.
(3) After completing service, charge the cycle with specified amount of refrigerant.
(4) If moisture or foreign matter might have entered the refrigerant piping during service, ensure to remove them.
[2] Additional refrigerant charge
When charging directly from cylinder
(1) Check that cylinder for R410A on the market is a syphon type.
(2) Charging should be performed with the cylinder of syphon stood vertically. (Refrigerant is charged from liquid phase.)
Although "-BS" model has been designed to be resistant to salt damage, observe the following precautions to maintain the
performance of the unit.
(1) Avoid installing the unit in a location where it will be exposed directly to seawater or sea breeze.
(2) If the cover panel may become covered with salt, be sure to install the unit in a location where the salt will be washed away
by rainwater. (If a sunshade is installed, rainwater may not clean the panel.)
(3) To ensure that water does not collect in the base of the outdoor unit, make sure that the base is level, not at angle. Water
collecting in the base of the outdoor unit could cause rust.
(4) If the unit is installed in a coastal area, clean the unit with water regularly to remove any salt build-up.
(5) If the unit is damaged during installation or maintenance, be sure to repair it.
(6) Be sure to check the condition of the unit regularly.
(7) Be sure to install the unit in a location with good drainage.
1-2. PRECAUTIONS FOR SALT PROOF TYPE "-BS" MODEL
No. Tool name Specifications
1Gauge manifold · Only for R410A
· Use the existing fitting specifications. (UNF1/2)
· Use high-tension side pressure of 5.3MPa·G or over.
2Charge hose · Only for R410A
· Use pressure performance of 5.09MPa·G or over.
3Electronic weighing scale —
4Gas leak detector · Use the detector for R134a, R407C or R410A.
5Adaptor for reverse flow check · Attach on vacuum pump.
6Refrigerant charge base —
7Refrigerant cylinder · Only for R410A · Top of cylinder (Pink)
· Cylinder with syphon
8Refrigerant recovery equipment —

5
OCH668G
Cautions for refrigerant piping work
New refrigerant R410A is adopted for replacement inverter series. Although the refrigerant piping work for R410A is the
same as for R22, exclusive tools are necessary so as not to mix with different kind of refrigerant. Furthermore as the work-
ing pressure of R410A is 1.6 times higher than that of R22, their sizes of flared sections and flare nuts are different.
1 Thickness of pipes
Because the working pressure of R410A is higher compared to R22, be sure to use refrigerant piping with thickness shown
below. (Never use pipes of 0.7 mm or below.)
2 Dimensions of flare cutting and flare nut
The component molecules in HFC refrigerant are smaller compared to conventional refrigerants. In addition to that, R410A
is a refrigerant, which has higher risk of leakage because its working pressure is higher than that of other refrigerants.
Therefore, to enhance airtightness and strength, flare cutting dimension of copper pipe for R410A has been specified sepa-
rately from the dimensions for other refrigerants as shown below. The dimension B of flare nut for R410A also has partly
been changed to increase strength as shown below. Set copper pipe correctly referring to copper pipe flaring dimensions for
R410A below. For 1/2 and 5/8 inch pipes, the dimension B changes.
Use torque wrench corresponding to each dimension.
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
0.8
0.8
0.8
1.0
—
0.8
0.8
0.8
1.0
1.0
Nominal
dimensions (in)
Diagram below: Piping diameter and thickness
Outside
diameter (mm)
Thickness (mm)
R410A R22
Dimension A
Dimension B
Flare cutting dimensions Flare nut dimensions
Nominal
dimensions (in)
Outside
diameter (mm)
Dimension A
(
+0
-0.4
)
(mm) Nominal
dimensions (in)
Outside
diameter (mm)
Dimension B (mm)
R410A R22 R410A R22
1/4 6.35 9.1 9.0 1/4 6.35 17.0 17.0
3/8 9.52 13.2 13.0 3/8 9.52 22.0 22.0
1/2 12.70 16.6 16.2 1/2 12.70 26.0 24.0
5/8 15.88 19.7 19.4 5/8 15.88 29.0 27.0
3/4 19.05 — 23.3 3/4 19.05 — 36.0
3 Tools for R410A (The following table shows whether conventional tools can be used or not.)
Tools and materials Use R410A tools Can R22 tools be used? Can R407C tools be used?
Gauge manifold Air purge, refrigerant charge
and operation check
Tool exclusive for R410A × ×
Charge hose Tool exclusive for R410A × ×
Gas leak detector Gas leak check Tool for HFC refrigerant ×○
Refrigerant recovery equipment Refrigerant recovery Tool exclusive for R410A × ×
Refrigerant cylinder Refrigerant charge Tool exclusive for R410A × ×
Applied oil Apply to ared section Ester oil, ether oil and alkylbenzene
oil (minimum amount)
×Ester oil, ether oil: ○
Alkylbenzene oil: minimum amount
Safety charger Prevent compressor malfunction
when charging refrigerant by
spraying liquid refrigerant
Tool exclusive for R410A × ×
Charge valve Prevent gas from blowing out
when detaching charge hose
Tool exclusive for R410A × ×
Vacuum pump Vacuum drying and air purge Tools for other refrigerants
can be used if equipped with
adapter for reverse ow check
( Usable if equipped
with adapter for
reverse flow)
( Usable if equipped with
adapter for reverse flow)
Flare tool Flaring work of piping
Tools for other refrigerants can be
used by adjusting aring dimension
(Usable by
adjusting aring
dimension)
( Usable by adjusting
aring dimension)
Bender Bend the pipes
Tools for other refrigerants can be used
○ ○
Pipe cutter Cut the pipes Tools for other refrigerants can be used
○ ○
Welder and nitrogen gas
cylinder
Weld the pipes Tools for other refrigerants can be used
○ ○
Refrigerant charging scale Refrigerant charge Tools for other refrigerants can be used
○ ○
Vacuum gauge or thermistor
vacuum gauge and vacuum
valve
Check the degree of vacuum. (Vacuum
valve prevents back ow of oil and refri-
gerant to thermistor vacuum gauge)
Tools for other refrigerants can be used
○ ○
Charging cylinder Refrigerant charge Tool exclusive for R410A ×-
×: Prepare a new tool. (Use the new tool as the tool exclusive for R410A.)
: Tools for other refrigerants can be used under certain conditions.
○: Tools for other refrigerants can be used.

6
OCH668G
2
2-1. SYSTEM CONSTRUCTION
Remote
controller
Name
Model number
Functions
M-NET remote controller
PAR-F27MEA-E, PAR-U02MEDA
• A handy remote controller for use in
conjunction
with the Melans centralized
management system.
• Addresses must be set.
• Addresses setting is not necessary.
MA remote controller
PAR-4xMAA, PAR-3xMAA ("x" represents 0 or later)
*1
When the indoor unit of Fresh Air type is connected with the outdoor unit, the maximum connectable total indoor unit capacity is 110%.
*2
For the PLFY-EP/VEM-E, up to 2 units can be connected . Other indoor units (Excluding the PEFY-P/ VMA3-E, PEFY-P/ VMH-E-F, and
PEFY-P･VMHS-E-F) can be connected within the total rated capacity and maximum number of connected units.
*3
PUMY is connectable to Fresh Air type indoor unit.
It is possible to connect 1 Fresh Air type indoor unit to 1 outdoor unit. (1:1 system)
Operating temperature range (outdoor temperature) for fresh air type indoor units differ from other indoor units.
Refer to "2-4-(3). Operating temperature range".
*4
Do not connect Lossnay remote controller(s). (PZ-61DR-E, PZ-60DR-E, PZ-52SF-E, PZ-43SMF-E)
*5
Authorized connectable indoor units are as follows;
PUMY-SP112:PEFY-P25VMA3-E×2 + PEFY-P32VMA3-E×2
PUMY-SP125: PEFY-P25VMA3-E×1 + PEFY-P32VMA3-E×3
PUMY-SP140: PEFY-P32VMA3-E×2 + PEFY-P40VMA3-E×2
*6
When connecting the CONNECTION KIT (PAC-LV11M-J) and an M-series indoor unit, refer to the installation manual for the CONNECTION KIT.
*7
Connectable only for PUMY-SP▪VKMR1/R2.TH(-BS),PUMY-SP▪YKMR1/R2.TH(-BS).
*8
Only for R2 models: PEFY-P·VMHS-E-F
OVERVIEW OF UNITS
Outdoor unit 4.5HP 5HP 6HP
SP112 SP125 SP140
Applicable
indoor unit
Capacity Type 10 to Type 140
Number of units 1 to 12 units 1 to 12 units 1 to 12 units
Total system capacity range 50 to 130% of outdoor unit capacity *1
Branching pipe
components Branch header
(2 branches)
Branch header
(4 branches)
Branch header
(8 branches)
CMY-Y62-G-E CMY-Y64-G-E CMY-Y68-G-E
M series remote
controller
Model
Capacity
Cassette Ceiling Ceiling
concealed
Wall
Mounted
Ceiling
Suspended
Floor standing Ceiling concealed Lossnay
CONNECTION KIT
2 by 2 4-way ow 2-way ow
1-way ow
Exposed Concealed Fresh air
*3
Built-in PAC-LV11M-J
PLFY-P PLFY-P PLFY-EP
*2
PLFY-M PLFY-P PMFY-P PEFY-P PEFY-M PKFY-P PCFY-P PFFY-P PFFY-P PEFY-P PDFY-P GUF
*4
10 – – – – – – – – 10VLM-E/ET – – – – – –
15 15VFM-E1 – – – – – 15VMS1(L)-E –15VBM-E
15VLM-E/ET – – – – – –
20 20VFM-E1 20VBM-E
20VEM-E – 20VEM-E/ET 20VLMD-E 20VBM-E
20VMS1(L)-E
20VMA(L)-E(2/3)
20VMR-E-L/R
20VMA(L)-A 20VBM-E
20VLM-E/ET –
20VLEM-E
20VKM-E(2)
20VLRM-E
20VLRMM-E
20VCM-E
– 20VM-E –
25 25VFM-E1 25VBM-E
25VEM-E – 25VEM-E/ET 25VLMD-E 25VBM-E
25VMS1(L)-E
25VMA(L)-E(2/3)
25VMR-E-L/R
25VMA3-E
*5
25VMA(L)-A 25VBM-E
25VLM-E/ET –
25VLEM-E
25VKM-E(2)
25VLRM-E
25VLRMM-E
25VCM-E
– 25VM-E –
32 32VFM-E1 32VBM-E
32VEM-E – 32VEM-E/ET 32VLMD-E 32VBM-E
32VMS1(L)-E
32VMA(L)-E(2/3)
32VMR-E-L/R
32VMA3-E
*5
32VMA(L)-A 32VHM-E
32VLM-E/ET –
32VLEM-E
32VKM-E(2)
32VLRM-E
32VLRMM-E
32VCM-E
– 32VM-E –
40 40VFM-E1 40VBM-E
40VEM-E – 40VEM-E/ET 40VLMD-E 40VBM-E
40VMS1(L)-E
40VMA(L)-E(2/3)
40VMH(S)-E
40VMA3-E
*5
40VMA(L)-A 40VHM-E
40VLM-E/ET 40VKM-E
40VLEM-E
40VKM-E(2)
40VLRM-E
40VLRMM-E
40VCM-E
– 40VM-E –
50 50VFM-E1 50VBM-E
50VEM-E 50VEM-E 50VEM-E/ET 50VLMD-E –
50VMS1(L)-E
50VMA(L)-E(2/3)
50VMH(S)-E
50VMA(L)-A 50VHM-E
50VLM-E/ET – 50VLEM-E
50VLRM-E
50VLRMM-E
50VCM-E
– 50VM-E 50RD(H)4
63 – 63VBM-E
63VEM-E 63VEM-E 63VEM-E/ET 63VLMD-E –
63VMS1(L)-E
63VMA(L)-E(2/3)
63VMH(S)-E
63VMA(L)-A 63VKM-E 63VKM-E 63VLEM-E
63VLRM-E
63VLRMM-E
63VCM-E
– 63VM-E –
71 – – – – – – 71VMA(L)-E(2/3)
71VMH(S)-E 71VMA(L)-A – – – – – 71VM-E –
80 – 80VBM-E
80VEM-E 80VEM-E 80VEM-E/ET 80VLMD-E – 80VMA(L)-E(2/3)
80VMH(S)-E 80VMA(L)-A – – – – 80VMH-E-F 80VM-E –
100 – 100VBM-E
100VEM-E –
100VEM-E/ET 100VLMD-E –100VMA(L)-E(2/3)
100VMH(S)-E 100VMA(L)-A 100VKM-E 100VKM-E – – – 100VM-E 100RD(H)4
125 –
125VBM-E
125VEM-E
– 125VEM-E/ET 125VLMD-E –
125VMA(L)-E (2/3)
125VMH (S) -E
125VMA(L)-A
–
125VKM-E – –125VMHS-E-F
*8
125VM-E –
140 – –
– – – –
140VMA(L)-E (2/3)
140VMH (S) -E
140VMA(L)-A
–– –
– 140VMH-E-F
–
–
M series indoor unit
*6
MSZ-GE Series
MSZ-SF Series
MSZ-EF Series
MSZ-FH Series
MSZ-LN Series
MFZ-KT Series
MSZ-AP Series
*7

7
OCH668G
*changes such as 1, 2...
Branch box
5-branches
(MAX. 5 units)
Number of branches
Indoor unit that
can be connected
( )
Note:
A maximum of 2 branch boxes can be connected to 1 outdoor unit.
PUMY-SP•VKM.TH(-BS),PUMY-SP•YKM.TH(-BS)
cannot connect 32/33/52/53 series.
PUMY-SP•VKMR1/R2.TH(-BS),PUMY-SP•YKMR1/R2.TH(-BS)
cannot connect 31/32/51/52 series.
Select a model according to the connection method.
2-branch pipe (joint): Optional parts
In the case of using 1- branch box
In the case of using 2- branch boxes
No need
Model name Connection method
flare
brazing
MSDD-50AR-E
MSDD-50BR-E
Option Optional accessories of indoor units and outdoor units are available.
PAC-MK5*BC
3-branches
(MAX. 3 units)
PAC-MK3*BC
2-2. SYSTEM CONSTRUCTION (BRANCH BOX SYSTEM)
Outdoor unit 4.5HP 5HP 6HP
SP112 SP125 SP140
Applicable
indoor unit
Capacity kW unit: Type 15 to Type 100
Number of units 2 to 8 units
Total system capacity
range
50 to 130% of outdoor unit capacity
(6.3 to 16.2 kW) o
50 to 130% of outdoor unit capacity
(7.1 to 18.2 kW) o
50 to 130% of outdoor unit capacity
(8.0 to 20.2 kW) o
Branch box that
can be connected
Number of units 1 to 2 units
Model
Capacity
[kW type]
Wall Mounted
1-way
ceiling
cassette
4-way
ceiling cassette
2 by 2 type Standard
MSZ-FH MSZ-LN MSZ-GE MSZ-GF MSZ-EF MSZ-SF MSZ-AP
*1
MLZ-KA MLZ-KP
*1
SLZ-KF SLZ-M
*1
PLA-RP PLA-M
15
- - - - - 15VA 15VF
15VG(K) -
- - 15FA - -
18
- - - - 18VE
18VG(K) -
- - - - - - -
20
- - - - - 20VA 20VF
20VG(K) -
- - - - -
22
- - 22VA - 22VE
22VG(K) -
- - - - - - -
25
25VE2 25VG
25VG2 25VA - 25VE 25VG(K) 25VE3 25VG(K) 25VA 25VF
25VA2 25FA - -
35
35VE2 35VG
35VG2 35VA - 35VE 35VG(K) 35VE3 35VG(K) 35VA 35VF
35VA2 35FA 35EA 35EA
42
- - 42VA - 42VE
42VG(K) 42VE3 42VG(K) -
- - - - -
50
50VE2 50VG
50VG2 50VA - 50VE 50VG(K) 50VE3 50VG(K) 50VA 50VF
50VA2 50FA 50EA 50EA
60
- - 60VA 60VE - - - - - - - 60EA 60EA
71
- - 71VA 71VE - - - - - - - 71EA 71EA
80
- - 80VA - - - - - - - - - -
100
- - - - - - - - - - - 100EA 100EA
Model
Capacity
[kW type]
Ceiling
concealed Ceiling
suspended Floor standing
Low static pressure Middle static
pressure
SEZ-KD
SEZ-M
*1PEAD-RP
PEAD-M PCA-RP PCA-M MFZ-KJ
*1
MFZ-KT
15 - - - - - - - -
18 - - - - - - - -
20 - - - - - - - -
22 - - - - - - - -
25
25VAQ(L) 25DA - - - - 25VE 25VG
35
35VAQ(L) 35DA - - 35KAQ 35KA 35VE 35VG
42 - - - - - - - -
50
50VAQ(L) 50DA 50JAQ(L) 50JA(L) 50KAQ 50KA 50VE 50VG
60
60VAQ(L) 60DA 60JAQ(L) 60JA(L) 60KAQ 60KA - -
71
71VAQ(L) 71DA 71JAQ(L) 71JA(L) 71KAQ 71KA - -
80 - - - - - - - -
100 - -
100JAQ(L) 100JA(L) 100KAQ 100KA - -
*1
Connectable for only PUMY-SP▪VKMR1/R2.TH(-BS),PUMY-SP▪YKMR1/R2.TH(-BS)T
Note: The lineup of a connectable indoor unit depends on a district/areas/country.

8
OCH668G
PUMY-SP•VKM.TH(-BS),PUMY-SP•YKM.TH(-BS) cannot
connect 32/33/52/53 series.
PUMY-SP•VKMR1/R2.TH(-BS),PUMY-SP•YKMR1/R2.TH
(-BS) cannot connect 31/32/51/52 series.
PAC-MK5*BC
5-branches
(MAX. 5 units)
Branch box
Number of branches
Branching pipe
components
CMY-Y62-G-E
Branch header
(2-branches)
CMY-Y64-G-E
Branch header
(4-branches)
CMY-Y68-G-E
Branch header
(8-branches)
CITY MULTI
indoor units*1
CONNECTION KIT
PAC-LV11M-J
M series indoor unit
*changes such as 1, 2...
MA
remote
controller
M series
remote
controller
M series
S series
P series
indoor units*1
MA
remote
controller
*1Refer to “2-1. SYSTEM CONSTRUCTION” or “2-2. SYSTEM CONSTRUCTION (BRANCH BOX SYSTEM)”, for more detail.
PAC-MK3*BC
3-branches
(MAX. 3 units)
2-3. SYSTEM CONSTRUCTION (MIXED SYSTEM)
Outdoor unit 4.5HP 5HP 6HP
SP112 SP125 SP140
Applicable
indoor unit
Capacity
CITY MULTI indoor unit
Type 10 to Type 140
Via branch box kW unit: Type 15 to Type 100
Number
of units
Via branch box CITY MULTI indoor Via branch box CITY MULTI indoor Via branch box CITY MULTI indoor
1 branch box- 5 5 5 5 5 5
2 branch boxes 8 3 8 3 8 3
Total system capacity range 6.3 to 16.2 kW 7.1 to 18.2 kW 8.0 to 20.2 kW

9
OCH668G
2-4. SYSTEM SPECIFICATIONS
(2) Method for identifying MULTI-S model
(1) Outdoor Unit
Outdoor unit <When using model 125 >
PU M Y - SP 125 Y K M - BS
Refrigerant
R410A
Indicates equivalent
to Cooling capacity
Power supply
V: Single phase
220-230-240 V, 50 Hz
220 V, 60 Hz
Y: 3-phase
380-400-415 V, 50 Hz
380 V, 60 Hz
Outdoor unit
model type
M-NET
control
Frequency
conversion
controller
Outdoor unit
MULTI-S
(kcal/ h)
Salt proof
type
Cooling capacity indicates the maximum value at operation under the following condition.
*Cooling Indoor : D.B. 27°C/W.B. 19°C
Outdoor : D.B. 35°C
*Heating Indoor : D.B. 20°C
Outdoor : D.B. 7°C/W.B. 6°C
Outdoor unit SP112 SP125 SP140
Capacity
Cooling (kW) 12.5 14.0 15.5
Heating (kW) 14.0 16.0 16.5
(3) Operating temperature range
Cooling Heating
Indoor intake air temperature W.B. 15 to 24°C D.B. 15 to 27°C
Outdoor intake air temperature D.B. −5 to 52°C*1 W.B. −20 to 15°C
Notes: D.B.: Dry Bulb Temperature
W.B.: Wet Bulb Temperature
*1 10 to 52°C D.B.: When connecting PKFY-P15/P20/P25VBM, PKFY-P10/15/20/25/32VLM, PFFY-P20/25/32VKM, PFFY-P20/25/32VCM,
PFFY-P20/25/32VLE(R)M(M) and; M series, S series, and P series type indoor unit.
■ When connecting fresh air type indoor unit
• PEFY-P·VMH-E-F
Cooling Heating
Indoor and Outdoor intake air temperature
D.B. 21 to 43ºC*2
W.B. 15.5 to 35ºC D.B. −10 to 20ºC*3
D.B. 21 to 43ºC*2
W.B. 15.5 to 35ºC D.B. −5 to 20ºC*3
*2Thermo-OFF (FAN-mode) automatically starts if the outdoor temperature is lower than 21ºC D.B.
*3Thermo-OFF (FAN-mode) automatically starts if the outdoor temperature is higher than 20ºC D.B.
• PEFY-P·VMHS-E-F
Cooling Heating
Indoor and Outdoor intake air temperature D.B. 17 to 43ºC*4
W.B. 15.5 to 35ºC D.B. −5 to 20ºC*5
*4Thermo-OFF (FAN-mode) automatically starts if the outdoor temp. is lower than 17°C D.B..
*5Thermo-OFF (FAN-mode) automatically starts if the outdoor temp. is higher than 21°C D.B..

10
OCH668G
3SPECIFICATIONS
Model PUMY-SP112VKM(-BS)
PUMY-SP112VKM-ET(-BS)
PUMY-SP112VKM-ER(-BS)
PUMY-SP125VKM(-BS)
PUMY-SP125VKM-ET(-BS)
PUMY-SP125VKM-ER(-BS)
PUMY-SP140VKM(-BS)
PUMY-SP140VKM-ET(-BS)
PUMY-SP140VKM-ER(-BS)
Power source 1-phase 220-230-240 V, 50 Hz; 1-phase 220 V, 60 Hz
Cooling capacity
(Nominal)
kW *1 12.5 14.0 15.5
kcal/h *1 10,750 12,040 13,330
Btu/h *1 42,650 47,768 52,886
Power input kW 3.10 3.84 4.70
Current input A 14.38 13.75 13.18 17.81 17.04 16.33 21.80 20.85 19.98
COP kW/kW 4.03 3.65 3.30
Temp. range of cooling Indoor temp. W.B. 15 to 24°C
Outdoor temp. D.B. -5 to 52°C *3,*4
Heating capacity
(Nominal)
kW *2 14.0 16.0 16.5
kcal/h *2 12,040 13,760 14,190
Btu/h *2 47,768 54,592 56,298
Power input kW 3.17 3.90 4.02
Current input A 14.70 14.06 13.48 18.09 17.30 16.58 18.65 17.83 17.09
COP kW/kW 4.42 4.10 4.10
Temp. range of heating Indoor temp. D.B. 15 to 27°C
Outdoor temp. W.B. -20 to 15°C
Indoor unit
connectable
Total capacity 50 to 130% of outdoor unit capacity
Model/ Quantity CITY MULTI P10-P140/12 P10-P140/12 P10-P140/12
Branch box *5 P15-P100/8 P15-P100/8 P15-P100/8
Mixed
system
Branch box
1 unit*5
CITY MULTI P10-P140/5 P10-P140/5 P10-P140/5
Branch box P15-P100/5 P15-P100/5 P15-P100/5
Branch box
2 units*5
CITY MULTI P10-P140/3 P10-P140/3 P10-P140/3
Branch box P15-P100/8 P15-P100/8 P15-P100/8
Sound pressure level
(measured in anechoic room)
dB <A> 52/54 53/56 54/56
Power pressure level
(measured in anechoic room)
dB <A> 72/74 73/76 74/76
Refrigerant piping
diameter
Liquid pipe mm (inch) 9.52 (3/8)
Gas pipe mm (inch) 15.88 (5/8)
Fan*2 Type × Quantity Propeller Fan × 1
Airow rate m³/min 77 83 83
L/s 1283 1383 1383
cfm 2719 2931 2931
Control, Driving mechanism DC control
Motor output kW 0.20 × 1
External static press. 0 Pa/30 Pa*6
Compressor Type × Quantity Twin rotary hermetic compressor × 1
Manufacturer Mitsubishi Electric Corporation
Starting method Inverter
Capacity control %Cooling 26 to 100
Heating 20 to 100
Cooling 24 to 100
Heating 18 to 100
Cooling 21 to 100
Heating 17 to 100
Motor output kW 3.1 3.5 3.7
Case heater kW 0
Lubricant FV50S (1.4 litter)
External nish Galvanized Steel Sheet Munsell No. 3Y 7.8/1.1
External dimension H × W × D mm 981 × 1,050 × 330 (+40)
inch 38-5/8 × 41-3/8 × 13 (+1-37/64)
Protection devices High pressure protection High pressure Switch
Inverter circuit (COMP./FAN) Overcurrent detection, Overheat detection(Heat sink thermistor)
Compressor Compressor thermistor, Overcurrent detection
Fan motor Overheating, Voltage protection
Refrigerant Type × original charge R410A 3.5 kg
Control Linear expansion valve
Net weight kg (lb) 93 (205)*7
Heat exchanger Cross Fin and Copper tube
HIC circuit (HIC: Heat Inter-Changer) HIC circuit
Defrosting method Reversed refrigerant circuit
Drawing External RK01B171
Wiring BH79J995
Standard
attachment
Document Installation Manual
Accessory Grounded lead wire
Optional parts Joint: CMY-Y62-G-E
Header: CMY-Y64/68-G-E
Remarks *1 Nominal cooling conditions *2 Nominal heating conditions Unit converter
Indoor:
Outdoor:
Pipe length:
Level
di󰀨erence:
27°C D.B./19°C W.B. [81°F D.B/66°F W.B.]
35°C D.B. [95°F D.B.]
7.5 m [24-9/16 ft]
0 m [0 ft]
20°C D.B. [68°F D.B.]
7°C DB/6°C W.B. [45°F D.B./43°F W.B.]
7.5 m [24-9/16 ft]
0 m [0 ft]
kcal/h = kW × 860
Btu/h = kW × 3,412
cfm = m³/min × 35.31
lb = kg/0.4536
Above specication data is
subject to rounding variation.
*3
10 to 52°C(D.B): When connecting PFFY-P20/25/32VCM, PKFY-P15/20/25VBM, PKFY-P10/15/20/25/32VLM, PFFY-P20/25/32VKM,
PFFY-P20/25/32VLE(R)M(M), and M series, S series, and P series type indoor unit.
*4
−15 to 52°C(D.B): When using an optional air protect guide [PAC-SH95AG-E]. However, this condition does not apply to the indoor unit listed in *3.
*5 At least two indoors must be connected when using branch box.
*6 It is possible to set the External static pressure to 30 Pa by Dip Switch
.
*7 94 (207), for PUMY-SP112/125/140VKM(R1/R2).TH-BS.
Notes :1. Nominal conditions *1, *2 are subject to ISO 15042.
2. Due to continuing improvement, above specications may be subject to change without notice.
