Mitsubishi Lossnay Ventilator
MODEL
VL-50SR2-E (Remote Controller Model)
Installation Manual For Dealer and Contractor
Please ensure that the separate “Operating
Instructions” are handed over to the customer. Please
ensure that it is delivered to the customer.
■ProperinstallationisnecessaryfortheLossnayto
performatfullpotentialandtoensuresafety.Before
proceeding with the installation work, be sure to
read through these instructions.
■Theinstallationworkmustbedonebyanauthorized
dealerorqualiedcontractor.Errorsininstallation
can lead to breakdowns and accidents.
■Installationbythecustomercanleadtobreakdowns
and accidents.
■Electricalworkmustbedonebyaqualiedand
licensed electrician employed by the dealer or
contractor.
TheexplanationinthisInstallationManualismainly
forhorizontalmountingoftheproductbuttheunitcan
be mounted vertically as well.
Contents Page
1.Safetyprecautions.............................. 1
2. Dimensional outline drawing............... 3
3.Listofincludedparts........................... 3
4.Beforeinstallation............................... 4
5. Mounting instructions.......................... 5
5.1. Wall-hole construction.................. 5
5.2.Preparationbeforeinstallation..... 5
5.2.1Forhorizontalmounting ........ 5
5.2.2 For vertical mounting............. 7
5.3. Attaching the main unit ................ 9
5.4.Electricalwork.............................. 10
5.5. Attaching the panel ...................... 10
5.6. Preparing the remote controller ... 11
5.7.
Installing the remote controller case ... 11
5.8. Outdoor construction ................... 12
6.Checksaftermounting........................ 13
7.Testrun............................................... 13
Hazards created by mishandling and their
severity are indicated by the following
markers.
Warning:
This applies to mishandling or misoperation
of the product which could lead to a fatal or
serious injury.
Caution:
This applies to mishandling or misoperation
of the product which will lead to an injury or
damage to your home, household effects, etc.
1. Safety precautions
Warning
- Do not install the unit in
excessively hot areas (40°C or
more), near open ames, in areas
prone to oily smoke, or where it
could come in contact with organic
solvents.
- Fire could result.
- Do not disassemble the unit more
than necessary or modify it.
- Fire, electric shock or injury could
result.
- Do not let the unit get wet.
- Fire or electric shock could result.
Prohibited
DoNOT
disassemble.
Donotexpose
to water

Eng-2
- Do not install the unit and wall
switch in a bathroom or other
highly humid location.
- Electricshockorshortcircuitscould
result.
- Use at the rated voltage.
- Fire or electric shock could result.
- Make sure the outside air intake
opening is positioned so that it
will not take in combustion gases
or other exhaust. Position the unit
so that it will not become covered
with snow.
- Ifintakeairisnotfresh,oxygen
could become depleted in the room.
- Install the unit securely to a
sufciently strong wall surface.
- Injuriescouldresultiftheunitfalls.
- Connect wires securely to terminal
block connections so they do not
come out.
- Poorconnectionscouldresultinre.
- Electrical work must be done by
an electrical contractor (a licensed
electrician) in accordance with
the technical standards of the
equipment and local regulations to
ensure safety.
- Badwiringandmistakesinelectrical
work could result in electric shocks
orre.
- Install an all-pole power supply
isolator at the power supply side
as per local electrical regulations.
All supply circuits must be
disconnected before obtaining
access to the terminal devices.
Use the specied cable size and
connect the cables securely to
prevent disconnection when they
are pulled.
- Ifthereisadefectintheconnection,
thereisapossibilityofre.
- Be sure to shut off circuit breakers
if the Lossnay will not be used for
a long period after installation.
- Failure to do so could result in
electricshockfromdeteriorated
insulation,orrefromashortcircuit.
- Always place a cover on the
terminal block after construction
work is complete.
- Dust, humidity and the like could
causeshortcircuitsorre.
Cannot be
installed in a
bathroom
You must
followthe
instructions
given.
Caution
- Install the unit only on a wall. Do
not install it on a ceiling.
- Injurycouldresultiftheunitfalls.
- Because this product is designed
to be installed at a higher location,
install the product at least 1.8 m
above the oor.
- Failure to heed this warning may
result in injury.
- Wear gloves when attaching the
unit.
- Failure to wear gloves could result in
injury.
- Attach the air supply/exhaust pipe
in a downward slope toward the
outdoor side and make sure to
apply thermal insulation treatment.
- Rainwater entering the unit could
resultinelectricshock,reorindoor
items getting wet.
- Make sure to perform drain
discharge in accordance with the
Installation Manual.
- Failure to heed this warning could
causeelectricshock/reorwater
damage to household property due
to water leaks.
- Install the provided weather
covers.
- Rainwater entering the unit could
resultinelectricshock,reorindoor
items getting wet.
- To prevent freezing or damage to
the Lossnay Core, stop the unit if
the outside temperature falls below
-20°C and the room’s humidity
rises above 40%.
Note
- In mid-rise and high-rise buildings or in
coastal and other areas prone to strong
winds, wind could blow into the unit when it
is not operating. Install the Lossnay where it
will not be directly subject to wind.
- Do not use the Lossnay in areas prone to
damage from salt or hot springs.
Prohibited
You must
followthe
instructions
given.

Eng-3
English
198.5
φ180
108
109
96.5
40 198.5
28
φ
180
108
109
168
2°
522
φ114
245
2. Dimensional outline drawing
Air supply /
exhausthole
Air supply
hole
Air
supply
hole
Weather cover
Mounting plate
Mounting plate
Weather cover
Attachthetwistedpartof
the vertical mounting joint C
toward the indoor side.
Airsupply/exhaust
pipe
JointpipeB
Pipe mounting plate
Pipe mounting plate
Airsupply/exhaust
pipe
Shutter knob
Shutter
knob
Indoor air
exhausthole
Indoor air
exhausthole
Indoor air
exhausthole
Indoor air
exhausthole
Wall thickness
50 to 650
Wall
thickness
120 to 730
Unit (mm)
Unit (mm)
For horizontal mounting
For vertical mounting
* For vertical mounting, the
display part comes to the
lowerside.(Theunitcannot
be mounted upside down.)
3. List of included parts
Pipe mounting plate (1)
Packing (1)
Airsupply/exhaustpipesA(2) Weather cover (1)
Hoodxingscrews(2)
Vertical mounting joint C (1) JointpipeB(1) Weather cover mounting plate (1)
Aluminium tapes (large) (3) Aluminium tapes (small) (1) Remote controller (1)
Remote controller holder (1)
Woodscrews(6)(forattaching
the mounting plate)
Unit mounting screws (5)
*Ascrewdriverwithanaxislengthof150mm
or longer is required.
Remote controller lithium battery (CR2025) (1)
Remote controller holder mounting screws (2)

Eng-4
3. Remove the terminal block cover.
Terminalblockcover
4. Before installation
■ Mounting position diagram (seen from inside)
1. Remove the mounting plate.
Removethetapeonthebackoftheunitand
then remove the mounting plate.
- In order to protect the drain pan end, lay the
underlayasshowninthegurebelow.(Usea
package pad.)
- Topreventscratchingoftheunit,laydowna
material such as cardboard.
2. Remove the panel.
Asshowninthegurebelow,holdbothendsof
the panel and pull toward you.
- Afterremovingthepanel,makesurescrews
or other items do not get inside the unit.
Drain pan endUnderlay
Panel
50 mm or more
Unit (mm)
151.5
223.5
216
245
40.539.5
21 11.5
26.5
20×8＝160
300
200
184
210.5 522
182 193
310 360
125
Mounting plate
Center line
Air
supply /exhaust
hole
(ø120 wall hole)
Mountingplatetemporaryxinghole
position(Forhorizontalmounting)
Unit hanging screw
position
(For vertical mounting)
Unit hanging screw position
(Forhorizontalmounting)
Mounting plate
temporaryxinghole
position
(For vertical mounting)
Edgeofmainunit Mounting hole 53 – ø6
Power and connection
cable pullout area
min. min.
(min.) (min.)

Eng-5
English
5. Mounting instructions
5.1. Wall-hole construction
5.1.1.Determine the installation
position.
1. Check the necessary space distance.
Unit (mm)
ABC D
Horizontalmounting 193 182 310 360
Vertical mounting 310 360 182 193
-Check the position so that unpleasant odors
arenotpickedupfromoutside.
-Checkthatthereinforcement(insidewall)is
positioned properly to secure the mounting
plate.(Ifthereisnoreinforcement,buildina
supporting structure.)
-Maintenancecannotbeperformedifthe
requireddimensionsarenotfollowed.
2. Mark the center of the wall hole position.
Note
- Make sure that the mounting surface of the
mounting plate is at.
- Ifitisnot,Lossnayoperationcouldgenerate
noise or the shutter could not operate properly.
5.1.2.Drill the wall hole.
Drillthewallholeofø120mm.
Note
- Make the holes so they slope down as they
exit the outside wall.
- Thisisnecessarytopreventtheinltrationof
rainwater.
* Nothing should obstruct
thefrontoftheunit.
(Do not place anything
blockingairowinfront
oftheLossnay.)
Diameterofwall
hole ø120 mm 2°
Wall hole
Wall
OutsideInside
5.1.3.Pull out the power and
connection cables.
1. Determine the power and connection cable
pull-out location and make a hole. (See the
mounting position diagram on page 4.)
2. Pull out the power and connection cables on
the indoor side.
5.2. Preparation before installation
5.2.1. For horizontal mounting
1. Attach the packing to the pipe mounting
plate.
Put the packing (included in the package) in the
grooveofthepipeconnectionsideofthepipe
mounting plate.
-Thispackingisusedtoprovideaslopetothe
pipe.Therefore,putthepackingatthe>PP<
mark side.
2. Apply caulking compound.
Apply caulking compound on the pipe mounting
plate.
Note
- Apply caulking higher than the ange end.
- Without caulking, rainwater comes in.
- Before caulking hardens, proceed to the
next procedure.
Power and
connection cables
Pull-out position
Power and connection
cables
“シタ” mark
Packing
>PP<markside
“B”mark
Pipe mounting plate
Caulking compound
Flange end part
Caulking compound
Packing
At least A
AtleastB
At least C
At least D

Eng-6
5. Cutting air supply/exhaust pipes
Measurethewallthickness.(Ifthewallismore
than 300 mm thick, use the provided air supply/
exhaustpipeB).(Seepage3,section3,for
mounting instructions.)
Note
- Check that each air supply/exhaust pipe
A catches on all four prongs of its pipe
mounting plate. (If a prong has not caught,
the pipe will press against the back of
the Lossnay unit and the shutter may not
operate properly.)
6. If the wall is more than 300 mm thick
Cutairsupply/exhaustpipesA2inkeepingwith
thecuttingdimensionsofstep2(wallthickness+
30 mm).
7. Secure the air supply/exhaust pipe to the
mounting plate.
(a)Inserttheairsupply/exhaustpipeAtothe
mounting plate.
(b)Turnthepipecounterclockwisetohookthe
pipe mounting plate with the tab.
Cut perpendicular to the
pipe
Wall
thickness
OutsideInside
(Dimensionattopofpipe)
90°
Cut length
Air supply/
exhaustpipeA
Cut on this side
30 mm
Alminium tape
Air supply/
exhaustpipeA2
Airsupply/exhaust
pipe A2
Air supply/
exhaustpipeA1
Airsupply/exhaustpipeA1
Caulking
Caulking
Alminium tape
Alminium tape
JointpipeB
3. Attach the pipe mounting plate to the air
supply/exhaust pipe A.
(a)Makesuretoinserttheairsupply/exhaust
pipeAdeeplytothegrooveofthepipe
mounting plate.
(b)Use the included aluminum tape (large) to
wrap around the connection section between
the pipe mounting plate and air supply/
exhaustpipeAtoproperlysecureit.Ifitis
not properly secured, drain water may leak.
4. Apply caulking between the pipe mounting
plate and pipe connection section.
Apply caulking on the connection section
between the pipe mounting plate and air supply/
exhaustpipefrominside.
Note
- Without caulking, rainwater comes in.
- After applying the caulking compound,
atten the surface.
- Do not apply caulking compound thicker
than the pipe mounting plate. (Otherwise,
drain water is not discharged.)
Aluminum tape (large)
Airsupply/exhaust
pipe A
Pipe mounting plate
Caulking compound
Caulking compound
Pipe mounting
plate
Pipe partition
Pipe partition
Pipe mounting plate

Eng-7
English
Note
- Secure the plate in an even position at the
four corners.
- For a concrete wall, use concrete screws
(commercially available) to secure the plate.
- Accurately nd the position between
the power and connection cable takeout
position and the mounting plate position.
(If the position of the mounting plate is
displaced, the power and connection cable
takeout hole will protrude from the unit.)
5.2.2. For vertical mounting
1. Attach the packing to the pipe mounting
plate.
Put the packing (included in the package) in the
grooveofthepipeconnectionsideofthepipe
mounting plate.
-Thispackingisusedtoprovideaslopetothe
pipe.
2. Apply caulking compound.
Apply caulking compound on the pipe mounting
plate.
Note
- Apply caulking higher than the ange end.
- Without caulking, rainwater comes in.
- Before caulking hardens, proceed to the
next procedure.
3. Attach the vertical mounting joint C to the
air supply/exhaust pipe.
(a)Attach the vertical mounting joint C to the air
supply/exhaustpipetoapplycaulking.
Packing
“B”mark
“シタ” mark
>PP<markside
Caulking compound
Flange end part
Caulking compound
Packing
(c)Checkthattheairsupply/exhaustpipeA
is downward toward the outdoor side, as
showninthefollowinggure.
Note
- Check that all four tabs catch the ange.
(Otherwise, the back of the product is
pushed, causing shutter operation failure.)
- Attach the pipe in such a way that the “B”
mark on the mounting plate matches the “B”
mark on the ange part.
- If the air supply/exhaust pipe is not
downward slanted, drain water may reux or
rainwater may come in.
8. Attach the mounting plate.
(a)Puttheairsupply/exhaustpipethroughthe
wall hole.
(b)Use one wood screw to temporarily secure
themountingplate.(Tightenthescrewatthe
end.)
(c)Attachoneunitxingscrewtothemounting
plateforhangingtheunit.
(d)Hangaweightandcheckthelevelofthe
mountingplate(slopewithin1°).(Iftheunit
isinclined,watermayspillfromthedrain
pan.
(e)Usefourwoodscrewstosecurethe
mounting plate to the position where
reinforcementisprovidedinsidethewall.
(f)Useawoodscrewtosecurethecenterof
line A
BB
Airsupply/exhaustpipeA
Mounting plate
Pipe mounting plate “B”mark
Tab
Mounting plate Airsupply/exhaustpipe
2°
A
Unitxingscrew
Wood screw
(temporaryxing)
Weight
Wood
screw

Eng-8
(b)Use the included aluminum tape (large) to
wrap around the connection section between
the vertical mounting joint C and air supply/
exhaustpipetoproperlysecureit.Ifitisnot
properly secured, drain water may leak.
4. Attach the pipe mounting plate to the air
supply/exhaust pipe.
(a)Makesuretoinserttheairsupply/exhaust
pipedeeplytothegrooveofthepipe
mounting plate.
(b)Use the included aluminum tape (large) to
wrap around the connection section between
the pipe mounting plate and air supply/
exhaustpipetoproperlysecureit.Ifitisnot
properly secured, drain water may leak.
Note
- Always insert in such a way that the vertical
mounting joint comes to the indoor side.
5. Apply caulking between the pipe mounting
plate and pipe connection section.
Apply caulking to the connection section between
thepipemountingplateandairsupply/exhaust
pipefrominside.
Note
- Without caulking, rainwater comes in.
- After applying the caulking compound,
atten the surface.
- Do not apply caulking compound thicker
than the pipe mounting plate. (Otherwise,
drain water is not discharged.)
Airsupply/exhaust
pipe
Vertical mounting
joint
Aluminum tape (large)
Airsupply/exhaustpipe
Vertical mounting
joint
Pipe mounting plate
Aluminum tape (large)
Caulking compound
Caulking compound
Pipe mounting
plate
Pipe partition
Pipe partition
Pipe mounting plate
6. Afxing aluminum tape.
Afxtheincludedaluminumtape(small)as
showninthegure.
-Thistapeisafxedtofacilitateowingofwater
fromthedrainpanend.
7. Cutting air supply/exhaust pipes
Measurethewallthickness.(Ifthewallismore
than 300 mm thick, use the provided air supply/
exhaustpipeB).(Seepage4,section4,for
mounting instructions.)
Note
- Check that each air supply/exhaust pipe
A catches on all four prongs of its pipe
mounting plate. (If a prong has not caught,
the pipe will press against the back of
the Lossnay unit and the shutter may not
operate properly.)
8. If the wall is more than 300 mm thick
Cutairsupply/exhaustpipesA2inkeepingwith
thecuttingdimensionsofstep2(wallthickness+
30 mm).
Aluminum tape (small)
Pipe mounting
plate Unit (mm)
85
50
Cut perpendicular to the
pipe
Wall
thickness
OutsideInside
(Dimensionattopofpipe)
90°
Cut length
Air supply/
exhaustpipeA
Cut on this side
30 mm
Alminium tape
Air supply/
exhaustpipeA2
Airsupply/exhaust
pipe A2
Air supply/
exhaustpipeA1
Airsupply/exhaustpipeA1
Caulking
Caulking
Alminium tape
Alminium tape
JointpipeB

Eng-9
English
9. Secure the air supply/exhaust pipe to the
mounting plate.
(a)Inserttheairsupply/exhaustpipetothe
mounting plate.
(b)Turnthepipecounterclockwisetohookthe
pipe mounting plate with the tab.
(c)Checkthattheairsupply/exhaustpipe
is downward toward the outdoor side, as
showninthefollowinggure.
Note
- Check that all four tabs catch the ange.
(Otherwise, the back of the product is
pushed, causing shutter operation failure.)
- Attach the pipe in such a way that the “B”
mark on the mounting plate matches the “B”
mark on the pipe mounting plate.
- If the air supply/exhaust pipe is not
downward slanted, drain water may reux or
rainwater may come in.
10. Attach the mounting plate.
(a)Puttheairsupply/exhaustpipethroughthe
wall hole.
(b)Use one wood screw to temporarily secure
themountingplate.(Tightenthescrewatthe
end.)
(c)Attachoneunitxingscrewtothemounting
plateforhangingtheunit.
(d)Hangaweightandcheckthelevelofthe
mountingplate(slopewithin1°).(Iftheunit
isinclined,watermayspillfromthedrain
pan.)
(e)Usefourwoodscrewstosecurethe
mounting plate to the position where
reinforcementisprovidedinsidethewall.
BB
Airsupply/exhaustpipeA
Mounting plate
Pipe mounting plate
“B”mark
Tab
Mounting plate Airsupply/exhaust
pipe
2°
(f)Useawoodscrewtosecurethecenterof
line A.
Note
- Secure the plate in an even position at the
four corners.
- For a concrete wall, use concrete screws
(commercially available) to secure the plate.
- Attach so that the B mark comes to the
bottom side.
- Accurately nd the power and connection
cable takeout position and the mounting
plate position. (If the position of the
mounting plate is displaced, the power and
connection cable takeout hole will protrude
from the unit.)
5.3 Attaching the main unit
1. Pull the power and connection cables
through the hole in the rear of the unit.
-Besurethatthecableisnotcaughtbetween
the unit and mounting plate.
2. Pull the power and connection cable
through the lead-in opening and the bush.
3. Hook the unit to the unit xing screw at the
center of the mounting plate.
-Insert while paying attention not to push in
thecushionoftheairsupply/exhaustpipeby
the drain pan end.
A
Unitxing
screw
Wood screw
(temporary
xing)
Weight
Wood
screw
“B”mark
Power and connection cable
Lead-in opening
Bush

Eng-10
4. Press the main unit into the wall and attach
it with the four screws provided.
-Useascrewdriverwithanaxislengthof150
mm or longer.
Note
- Be aware that the unit xing screw on which
the main unit is hung has been temporarily
secured, thus always support the main unit
with your hand and tighten the screw.
5.4 Electrical work
Warning
-Use at the rated voltage.
- Fire or electric shock could result.
-Connect wires securely to terminal block
connections so they do not come out.
- Poorconnectionscouldresultinre.
-Electrical work must be done by an electrical
contractor (a licensed electrician) in
accordance with the technical standards of
the equipment and local regulations to ensure
safety.
- Badwiringandmistakesinelectricalworkcould
resultinelectricshocksorre.
Note
- Check that the unit operates correctly.
- Malfunctionsmayoccurwhenelectronic
switches,includingforspeedswitchesand
timers controlled by semiconductor, are used.
Mounting
plate
Unitxingscrew
Unitxing
screw
Unit
Cushion
Drain pan end
L
Terminalblock
Bush
Ground cable
Ground screw
Cord clamp
Lead-in opening
Power and connection
cable
Operation requires a control switch. Have a
control switch ready and connect the wiring
shown in bold on the connection diagram below.
Suitable cables: ø0.5 to ø2.0 mm diameter
(1)Removethecoveringfromthenal10mmof
the power and connection cables and screw
the ends in place on the terminal block.
Note
- Cannot operate multiple products.
(2)Attachagroundcabletotheattachingpartfor
ground with a ground screw to ensure the unit
is grounded.
(3)Fixthepowerandgroundingwiresinplace
with the cord clamp.
(4) Make sure that the wires have not come
loosefromtheterminalblock.
(5) Screw on terminal block cover at its original
position.
(6) Attach the terminal block cover.
5.5 Attaching the panel
1. Attach the wire of the panel (fall prevention)
to the hook of the unit.
N
L
Isolator
Terminalblockcover
Wire
Hook
Panel
Unit
