MJ LED LIGHTNING MJ-1005 User manual

MINI LED MOVING HEAD WASH
MJ-1005
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our Mini LED moving head wash light. For the sake of
your safety, Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.

Catalogue
Chapter Page
1. Product Illustration --------------------------------------------------------------1
2. Installation--------------------------------------------------------------------------1
3. DMX connection ------------------------------------------------------------------1
4. Maintaining-------------------------------------------------------------------------2
5. Precautions ------------------------------------------------------------------------2
6. Warning -----------------------------------------------------------------------------2
7. Difficult processing----------------------------------------------------------------3
8. Declaration -------------------------------------------------------------------------3
9. Equipment and appendix--------------------------------------------------------3
10. Technical parameters ----------------------------------------------------------4
11. Menu display function-----------------------------------------------------------4
12. DMX function----------------------------------------------------------------------5
Before open the LED moving head and if you want to do the repair work,
please make sure the power source is at the separation condition.
Unceasingly carries on the product improvement about our company the
policy, in this instruction booklet carries the data will have the possibility to
be able to change in the future, when no longer separate notice change
matters concerned. Our company retains when the product improvement
changes the related specification the authority. This instruction booklet
publisher cannot be responsible regarding this instruction booklet in
information accuracy, also cannot the related consequence which causes
regarding these information be responsible.

16
1. Product Illustration
Our product adopt semiconductor to produce radiation, LED as light origin. With
advantage of operation quietly, less power waste, high brightness, gaily-colored,
astigmatic, high longevity (60-100 thousands hours), non-calorific etc. Our
product use 3W*18 LED, synthesize turn colors under election, can create effect
of auto gradual change/skip change color, frequent blinking. Can accept control
by DMX512, real save power, no pollution green lighting tool.
2. Installation
Use the four bolts with M6 size by the clip of the LED moving head to install it.
Should guarantee the reliability of the install, this way is to prevent the LED
moving head occurs swings and skids when it’s working. The weight is about
3Kg of each LED moving head, before install, you should confirm the structure
whether can support this weight of the LED moving head light. In order to
guarantee the security, you also need to install a safety chain in the lamp body
side handle.
3. DMX connection
The connection of controller between the led moving head lamp or respectively
led moving head lamp should use the twin core shielded cable, and the diameter
of each core at least be 0.3mm.
When installing, uses the DMX signal terminal is much better. It can avoid the
digital control signal breached by the electrical noise. Generally speaking, the
DMX terminal is Cannon plug coupling, it has a 120 ohm resistances between
the 2 feet and 3 feet, it will connected on the last led moving head lamp’s digital
plug of the led moving head lamp chain.
6. channel 6 control red dimming（R）
CH6：0 off。1-255 red dimming from dark to bright；
7. channel 7 control green dimming（G）
CH7：0 off。1-255green dimming from dark to bright；
8. channel 8 control blue dimming（B）
CH8：0 off。1-255blue dimming from dark to bright；
9. channel 9 control RGBW color mixture
CH9：0-9 off。10-255 32 colors adjusting；
10. channel 10 control strobe
CH10：0-9 no strobe。10-255 strobe adjusting from slowly to quickly；
11. channel control the voice of controller
CH11：0-127 voice of controller OFF，128-255 voice of controller ON；oller
OFF，128-255 voice of controller ON；
6Channel
1. channel 1 control X motor（PAN）
CH1：0 stop，1-255 adjusting X motor rotation；
2. channel 2 control Y motor（TILT）
CH2：0 stop，1-255 adjusting Y motor rotation；
3. channel 3 control main dimming
CH3：0 off。1-255 main dimming from dark to bright；
4. channel 4 control red dimming（R）
CH4：0 off。1-255 red dimming from dark to bright；
5. channel 5 control green dimming（G）
CH5：0 off。1-255green dimming from dark to bright；
6. channel 6 control blue dimming（B）
CH6：0 off。1-255blue dimming from dark to bright；

5 2
5. STBY (opening stop mode)：NO/ YES
6. PAN (X)：NO/ YES
7. TILT (Y)：NO/ YES
8. LED (digital display on/off setting)：ON/OFF
9. DISP (digital display direction setting)
10. TEST (function test)
11. HOUR (fixture use’s time)
12. RSET (reset)
Note：
Start the machine, it will rolling display ：******LED-RGB******
White balance adjusting：
1. Press MENU enter the menu selection mode.
2. Press ENTER remain 5 seconds, then into white balance adjusting menu
（BALA）。 Display will showing twinkling state.
3. Then press ENTER one time, going to the white balance adjustment directly.
RED(0-255)GREE(0-255)BLUK(0-255)
12. DMX function
11Channel
1. channel 1 control X motor（PAN）
CH1：0 stop，1-255 adjusting X motor rotation；
2. channel 2 control X bit（PAN）
CH2：0 stop，1-255 adjusting X motor bit；
3. channel 3 control Y motor（TILT）
CH3：0 stop，1-255 adjusting Y motor rotation；
4. channel 4 control Y bit（TILT）
CH4：0 stop，1-255 adjusting Y motor bit；
5. channel 5 control main dimming
CH5：0 off。1-255 main dimming from dark to bright；
4. Maintaining
1. The fixture should be kept dry to avoid working in wet conditions.
2. Intermittent use will effectively prolong the life of this fixture.
3. For a good ventilation and lighting effects, please clean the
fans ,fan nets and lens usually .
4. To avoid damage this fixture, please don't use alcoholic or other
organic solvents to clean the fixture shell.
5. Precautions
1. In order to ensure the life of this fixture, please don't place this fixture where
is moisture or leakage, and don't operate the fixture at temperatures higher
than 40°please!
2. Don't place the fixture where is easy to loose or vibration-prone
3. To avoid risk of electric shock, please ask the professionals to maintain this
fixture.
4. When connect the fixture to power, the changes of power voltage should
be at-10% ~+10%,if higher, will reduce the life of the fixture, but if lower, will
effect the lightness.
5. Should need 20 Min. to fulling cool the light before re-use.
6. In order to ensure the normal use of this product, please read this manual
carefully.
6. Warning
·Don’t disassemble and assemble the LED moving head.
·Please Do not put the led moving head lamp in water or other any types liquids
and the metal (IP20).
·Do not install the led moving head lamp in the humidity environment.
·Should maintain the minimum 0.5 meter distance between the led moving head
lamp and other neighboring object surface.

3 4
7. Difficult processing
Question Answer
The LED moving head lamp can not
start.
Inspects the fuse on the rear panel.
Although shines, but the LED moving
head lamp can not accept the instruction
of the controller.
Check the digital start address (sees
09th) and also check the connection
situation of the communication control
line the (to see 03rd).
LED moving head lamp only can work
intermittently.
Inspect the power supply and voltage is
whether normal.
Do not receive the DMX512 signal Whether the signal lines do contact
good or broken.
The light beam appears gloomily. Inspect the optics part is whether clean.
Other maintain work should by the specialist which has the
experience to carry on.
8. Declaration
Before delivery, this fixture have the performance intact, packaging integrity, and
all users should strictly observe the above warnings and operating instructions
for the matter, with any damage caused by misuse is not guaranteed within the
company, for damages caused by ignoring the manual instruction is not within
the scope of the distributors or dealers. Thank you for your cooperation!!
9. Equipment and appendix
1. Led moving head light ----------------------------------1pcs
2. The Product of Instruction------------------------------1pcs
3. Power Cable ----------------------------------------------1pcs
4. XLR connector--------------------------------------------1unit
5. Bracket------------------------------------------------------1pcs
6. M6mm Screw----------------------------------------------2pcs
10. Technical parameters
Voltage:AC100-240V, 50Hz/60Hz
Power Consumption: 70 Watts
LED: 3W*18LED (Red:6pcs, Green:6pcs, Blue:6pcs)
LED Power: 3 Watts (x 18pcs)
LED Current: 750mA / 1 pc
LED Beam Angle: 25°
Pan:540°
Titl:180°
Operation Modes: DMX512, Manual, Sound, Master-Slave
DMX Control: 6/11 Channels
Control Panel: Digital 4 CharacterAlphanumeric
Maximum Ambient Temperature: 40° C
Gross Weight: 3.8 kg
Package Size: 25 x 22 x 29.5cm
11. Menu display function
Enter Menu down up
1. ADDR (address code setting) ：A001-A512
2. SLND (master/从slave1/slave2 setting)：NAST,SL 1,SL 2
3. SOUN（sound control）： 0-100
4. AUTO (auto mode)：NO/ YES
