MJ LED LIGHTNING MJ-3325C-200W26D User manual

LED PROFILE SPOT LIGHT
MJ-3325C-200W26D
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED profile spot light. For the sake of your
safety, Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.

OVERVIEW
Thank you for using our product, this unit is designed for indoor using, it’s widely
used for stage, building, disco, etc. as high power led effects lighting, this unit can
be operated as a single unit or multiple units for large applications. Direct input of
DMX512 signal to unit to allow it controlled by any DMX controller, powerful
internal programs and friendly and convenient operation interface allows
customers to program freely to any different lighting project requirements for
installation or showing.
This high power par can has gotten the nice sculpt, efficient, save electricity and
durable。
Technical Parameter:
• Power Supply: AC90V-260V, 50-60Hz
• Power Consumption: Max. 260W
• LED: 200W RGBW 4in1 LED Color
• LED Life time: over 50,000 hours
• Small volume, lightweight
• High quality optical system
• Beam Angel: 26°
• High-quality optical system , Glass reflector
• Control Mode: DMX,Auto run and Master/Slave
• DMX Channels: 4/ 8CH
• Housing: Plastic ,
• Color: Black
• IP Rating: IP20
• Warranty : One year
• N.W.:6 kgs
• G.W.: 8kgs
• Dimensions : 660x285x295mm
•Packing : 700x300x310mm 1

I. Product Introduction
1.1 Product Feature
4 kinds of running mode
External control mode (Slave mode)
DMX 512 controller control(2 kinds of DMX channel modes)
Master/salve model control (auto match the signal from controller and the Master
light, no need to set by menu)
Auto run mode (Master mode)
Different kind of Gradual change & pulse change
Different kind of Strobe：speed change strobe (slow to fast)、mixing strobe( Strobe
+basic color、Strobe +Gradual change)……
static mode (Master mode)
It can fix any color without the controller ,also work this color with strobe
Sound mode (Master mode)
Included 2 kinds of commonly used sound mode
“Software cutting ”
The light would be turn off when the dimmer channel is "0"（procedure would keep
working)
The difference with “BLACKOUT” key(controller keys) &"Software cutting" ：only
work this light , and do not clear up the controller data .
No-liner dimmer &liner dimmer
The Effect get high praise from the professional technologist.
Balance of white light

It can be set 11 kinds of white light with different color temperature and controlled by
the controller.
Screen Protect
It will enter blank screen without any operate on the keyboard in 30 seconds . Press any
keys then it can quit screen protection.
Temperature Protection
It can be set to temperature protection mode
2
APPENDIX
Caution :
﹡Unqualified person involved with installation , operation and maintenance of this
device is prohibited .
﹡If any above mentioned problem happened , or unknown problem happened ,
please contact manufacturer or distributor for assistance
DISCLAIMER
1. The device is with one year warranty . The warranty period appear non-artificial
quality problem, this company is responsible for free maintenance
2. User violate operation caused the machine failure, this is user responsibility.
3. If due to the wrong operation or intense impact caused product destroy even safety
accidents, the manufacturer does not undertake any responsibility
4.
Prohibit replaced product components by any person, therefore caused any
consequences will be whose responsible
Please contact us freely when you need our related products or in
formations...
7

SAFETY WARNING
1. Warning
﹡
Every person involved with the installation , operation and maintenance of this device has
to be qualified .
﹡User must follow the instructions of this manual
﹡Unqualified person can not open the housing cover and operate the device , or the dealer
will not accept liability for any resulting defects or problems.
﹡The device against rain and moisture
2. Waring notes :
﹡Power supply :AC 100V-240V , 50/60Hz
﹡
Make sure the power switch is off , the power plug , outlet and the earth connection is in
well condition before connecting the device with the mains.
﹡Please use qualified power plug and the outlet. Never connect the power cord of this
device with other electrical equipment.
﹡
During move and installation , make sure the device not crashed with metal parts and other
tough materials.
﹡Always disconnect from the mains, when the device is on the installation and dismantled
﹡The minimum distance between light-output and the illuminated surface must be more than
50cm
﹡The device must only be installed on a non-flammable surface . In order to safeguard
sufficient ventilation , leave 50cm of free space around the device . Please note that
heat-sensitive objects may be deformed or damaged by the emitted heat .
﹡
During the operation the housing becomes very hot ! Do not operate the device for 15
minutes after switching off .
﹡The maximum ambient temperature Ta = 45℃must never be exceeded , The maximum
housing temperature Tb = 80℃must never be exceeded .
﹡For indoor use
﹡Replace any visible cracked protective shield , filters and lens .
﹡The protective shiel, filters and lens will require weekly cleaning as smoke “Cfluid tends
to building up residues , reducing the light “Coutput very quickly.
6
Speed of the Fan
The fan will start to work when the working temperature reach 40 degree, and the
speed will be changed according to the change of temperature.
Can support reverse display
1.2 Multi-light working in the same time
When using controller to control multi lights to work in strobe or auto run, the controller just
send the channel data . The strobe and auto run effect will be depend on each light itself . And
please take attention for the follow situation:
1. There will be many situations make the lights are not synchronization in the beginning.
(For example: the different time of opening the light , or different time of them connect to the
controller) .In this case, you can change value of the controller( for example push 20 to 0, and
back to 20), then it can be synchronization.
2. Due to crystal frequency of different lights are not the same exactly, so it may not be
synchronization after long time.
3. If need to keep synchronization for long time, there are two ways to do so:
A. Using the controller to edit program make the strobe, auto run effect, then they must
be synchronization.
B. Using the Maser/Slave model
2. Channel data
2.1 Standard channel model
Channel Data Function
CH1 0~255 Red
CH2 0~255 Green
CH3 0~255 Blue
CH4 0~255 White
3

P
2.2 Basic channel model
Channel Data Function Mark
CH1 0~255 Dimmer
CH2 0~255
Color 1 (R)
CH3 0~255 Color 2 (G)
CH4 0~255
Color 3 (B)
CH5 0~255 Color 4 (W)
CH6
0~30
No effect
31~200 Multi color change
201~205
Color temperature 1 (3200k)
`````` Color temperature 2~10 (each 5
data is a color temperature)
250~255 Color temperature 11 (10000k)
CH7
0~10 No strobe
this channel
control the speed
when running the
build-in program
11~255 The speed of strobe from slow to
fast
CH8
0~20 speed of dimmer 4 (the slowest
and softest)
21~40 speed of dimmer 3
41~60
speed of dimmer 2
61~80 speed of dimmer 1
81~99
speed of dimmer OFF (fastest
and no any delay)
100~109 inner program 1
``````
each 10 data is a program
190~199 inner program 10
200~240
change color by sound control
241~255 strobe by sound control
4
3. Operation
MENU：Switch the main menu
UP/DOWN：Change the value of the current menu item
ENTER：If there are sub menu switch submenu
MEUN SUB MRUN DISPLAY KEY OPERATION
Standard
channel model
（
8 channel
）
DMX(8CH)
Addr:001 UP/DOWN change the address code
Simple channel
model
（
4channel
）
DMX(4CH)
Addr:001 UP/DOWN change the address code
Static mode
Dimmer
：
Color1
（
Red
）
Static >
R :000
UP/DOWN : dimmer
ENTER : switch sub menu
Dimmer
：
Color2 (Green)
Static >
G :000
UP/DOWN :dimmer
ENTER :switch sub menu
Dimmer
：
Color3 (Blue)
Static >
B :000
UP/DOWN :dimmer
ENTER :switch sub menu
Dimmer
：
Color4 (White)
Static >
W :000
UP/DOWN :dimmer
ENTER :switch sub menu
Strobe
Static >
Strob:00
UP/DOWN :strobe
ENTER :switch sub menu
Temperature
control
Display the
current
temperature
Temp >
Curr: 0 ENTER :switch sub menu
Setting the
temperature
protection
Temp >
Top :080 UP/DOWN :temperature value ENTER :switch sub menu
RESET TO
DEFAULT
Reset
After press ENTER, prompted for a
password, as follows
：
Reset
Pwd:
Press the UP/DOWN key to enter the
password, input a password will
display a "*". As follows:
Reset
Pwd:****
Press ENTER to confirm password.
Password correct will reset to default.
Otherwise will remove all the "*", in
order to enter the password again
。
Note:1) If the first line of menu shows”>” , it means there has sub menu can change by
“ENTER”
2) The password is“UP、DOWN、UP、DOWN”.
