MJ LED LIGHTNING MJ-1029A User manual

Zoom LED Moving Head Light
MJ-1029A
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED zoom moving head light. For the sake of your safety, Please
read and follow these instructions carefully and keep this manual in a safe place for future
reference.

2
Catalogue
Chapter Page
Safe Usage Of The Product -----------------------------------------------------------------------------------------3
Install The Equipment ------------------------------------------------------------------------------------------------4
Power Code Connection ---------------------------------------------------------------------------------------------4
DMX Connection ------------------------------------------------------------------------------------------------------4
DMX Terminator -------------------------------------------------------------------------------------------------------5
Function Set --------------------------------------------------------------------------------------------------------------5
Operation Menu ---------------------------------------------------------------------------------------------------------6
Control panel of LED display information ----------------------------------------------------------------------9
Maintenance --------------------------------------------------------------------------------------------------------------9
Keeping The Product Clean ------------------------------------------------------------------------------------------9
Trouble Shooting--------------------------------------------------------------------------------------------------------10
Equipment and Appendix---------------------------------------------------------------------------------------------10
Channel List --------------------------------------------------------------------------------------------------------------10
Technical Parameters---------------------------------------------------------------------------------------------------12
☆Important notice:
·In this instruction for use contains about the installment and the use aspect important information of the LED moving
head. When installing and using, you need to look this usage instruction strictly.
·Before open the LED moving head and if you want to do the repair work, please make sure the power source is at the
separation condition.
·Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and the unit are
in good condition before installation and use. Should there be any damage caused by transportation, consult your dealer
and do not use the unit. Any damage caused by improper use will not be assumed by the manufacturer or dealer.
Attention: Unceasingly carries on the product improvement about our company the policy, in this instruction booklet
carries the data will have the possibility to be able to change in the future, when no longer separate notice change matters
concerned. Our company retains when the product improvement changes the related specification the authority. This
instruction booklet publisher cannot be responsible regarding this instruction booklet in information accuracy, also cannot
the related consequence which causes regarding these information be responsible.

3
SAFE USAGE OF THE PRODUCT
When unpacking and before disposing of the carton, check there is no transportation damage before
using the product. Should there be any damage caused by transportation, consult your dealer and do
not use the apparatus.
The product is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain
and moisture, excessive heat, humidity and dust. Do not allow contact with water or any other
liquids.
The product is not designed or intended to be mounted directly on to inflammable surfaces
The product is only intended for installation, operation and maintenance by professional person.
The product must be installed in a location with adequate ventilation, at least 50cm from adjacent
wall surfaces. Be sure that no ventilation slots are blocked.
Do not product the beam onto inflammable surfaces, minimum distance is 5m.
Avoid direct exposure to the light from the lamp. The light is harmful to the eye.
Do not attempt to dismantle or modify the projector in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power
requirements of the projector.
It is essential that each projector is correctly earthed and that electrical installation conforms to all
relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the
power-cord come into contact with other cables. Only handle the power-cord by the plug. Never pull
out the plug by tugging the power-cord.
Keep the optical system clean. Do not touch the LED lens with bare hands.
The product should always be installed with a secondary safety fixing. On the projector base brink,
there is a hole for the safety cord provided. It should be attached as shown in “installing the projector”
section.
LED lens shall be changed if they have become visibly damaged to such an extent that their
effectiveness is impaired, for example by cracks or deep scratches.
Exterior surface temperatures of the luminaire after 5 minutes operation is 40°C，when steady state is
achieved 50°C.
There is no user serviceable parts inside the projector, do not open the housing and never operate the
product with the covers removed.
If you have any questions, don’t hesitate to consult your dealer or manufacturer.
★Always disconnect from the mains, when the device is not in use or before cleaning it or
before attempting any maintenance work !

4
Install The Equipment:
Use 2pcs clamp and safety cord(need to purchase).Use clamp fix with light hook which in the
packing box with light, then use screw install to the bottom of lamp. Hang the fixture on the structure
and fasten the screws attached to each clamp. Make sure the light is installed reliable, and confirm
the light which you fixed is strong enough for hanging the light. Base on safety reason, please
according to the above picture using safety wire cross the light to make it strong enough again.
Warning!
1．Hook and clamp only use for hanging the light. Do not use clamp as a tool to move fixtures.
2．Base on safety reason, please use the safety cord which can afford the weight ten times of lamp
through Insurance hole for auxiliary hanging.
3．Don't use the handle of the moving head light to fixed or lift!
Power Code Connection:
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Use the plug provided to connect the mains power to the projector paying attention to the voltage and
frequency marked on the panel of the projector. It is recommended that each projector be supplied
separately so that they may be individually switched on and off.
★It is essential that each projector is correctly earthed and the electrical installation conforms
to all relevant standards.
DMX Connection:

5
Connection between the controller and a projector and between one projector and another must be
made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Connection to
and from the projector is via cannon 3 pin (which are included with the projector) XLR plugs and
sockets. The XLR's are connected as shown in the figure above.
Note: Care should be taken to ensure that none of the pins touch the metallic body of the plug or each
other. The body of the plug is not connected in any way. The XLED 590 accepts digital control
signals in protocol DMX512 (1990).
Connect the controller’s output to the first fixture’s input, and connect the first fixture’s output to the
second fixture’s input and connect the rest fixtures in the same way. Eventually connect the last
fixture’s output to a DMX terminator.
DMX Terminator:
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a
DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control
signals.
The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins
2 and 3, which is then plugged into the output socket on the last projector in the chain. The
connections are illustrated below.
Function Set:
Picture 1 picture 2
Menu
Up
Down
Enter
Run Mode Address Set Language
Set Up Test Mode Sys Info

6
Press MENU into the main menu, when the LCD is off.
When the LCD display the main menu,Press the menu into sub menu.(as picture 1)
Use button switch and LCD display, can set the address code and function code easily.
Check or modify lighting function settings, Press the MENU display panel. LCD display panel will
display function menu of lighting. Function operation menu all have corresponding submenu(as
picture 2) . Each menu all represent the specific functions of lamps, specific see below "operation
menu" section.
Set or browse function setting of lamp, Press UP or DOWN key.
Press ENTER key to save your changes or to ENTER submenu, Touch UP or DOWN can change
value(Plus or reduce number).
According to the Return key to return to the last menu.
Operation Menu:
Menu Structure chart
Main Menu Sub Menu
DMX Address Set(001-512)
Address
Test Mode
Pan test
Tilt
Green
Red
White
Blue
Focus
0
－
255
0
－
255
0
－
255
0
－
255
0
－
255
0
－
255
0
－
255
Run Mode
DMX Mode
Auto Mode
Sound Mode
14/22CH
Auto1
－
Auto8
Language
Chinese
English

7
Set Up
ID Code
Pan Reverse
Tilt Reverse
Pan Calibration
Tilt Calibration
Temp Switch Set
Reset
Screen Protect
LOGO
Factory Set
Red Current
On Time
（
The time of now
）
Sys Info
Run Time
（
Total time of using
）
Soft ver
Running Mode
Dmx Address
Temperature Set
Temperature(Display current temperature）
0
－
25
ON/OFF
ON/OFF
ON/OFF
0
－
255
0
－
255
ON/OFF
50°C - 85°C
Green Current
Handspike Delay
ON/OFF
ON/OFF
ON/OFF
Blue Current
ON/OFF
200(20-255)
200(20-255)
200(20-255)
XF03
**H**M**S
*****H**M
Signal Link
ON/OFF
Focus Calibration
0
－
255
Code Wheel
ON/OFF
Screen Rot
ON/OFF
White Current
200(20-255)

8
Main Menu
Touch the menu to into setting.
Sub Menu
Sub menu include address, run mode, test mode, language , Setup and sys info. Press the main menu to do each
setting.
Run mode, “√” is mean to the currently run mode. At the same time, only running one mode. When you
select DMX mode and auto mode, Press “ ENTER”, also can choose different DMX mode and auto mode.
DMX mode,When the light in the DMX mode, then also can be slave mode. If the light connect to
the DMX control signal, then it is DMX mode. If you connect the light is Master signal, then it is
running slave mode.
Auto mode, auto mode also can be master mode.
Sound mode,When the light in sound mode, it can’t be master mode.
Address setting,after you finished the setting, then you need to press “ ENTER” button to keep the address
code and return to main menu.
Language,menu language can choose Chinese or English.
Setup mode,
Pan reverse set
Tilt reverse set
Pan Calibration
Tilt Calibration
Focus Calibration
Code wheel: If off, ID code will failure in reset and running mode, can’t record correct position of
pan and tilt. Will recover from wrong running operation. Reset can be max travel reset from code
wheel reset.
Signal link:When turn on signal link, cut off control signal will be remain disconnected before the
control signals
Handspike delay, when switch on handspike delay, the controller handspike can achieve soft
dimming effect. Handspike delay can be chosen ON/OFF on the controller.
ID code, ID code is using for DMX mode in the channel16th,when the value of channel 16th over
number 9,only ID code corresponding to the front two value which in 16th channel, then other
channel value are available now.(This model have no this function)
Temperature: Protect temperature, when start temp protect function, if test temperature over protect
temperature, then brightness will be reduce a half.
Temp Switch: Temperature protect switch.
Screen protect: It can be set turn off,mode1 and mode 2.When it’s OFF, then won’t enter screen
protect condition. When in mode 1,it will clear the screen. When in mode 2,after you into screen
protection, big letter display current address code. Touch the screen, you can exit screen protect
condition, and return main menu.
Screen Rot: this menu can let the screen inversion 180 degree.
Logo: if display logo
Reset: reset function
Red Current: Red current adjust
Green Current: Green current adjust
Blue Current: Blue current adjust

9
White Current: White current adjust
Factory set: you can set all parameters to factory set.
Test mode,test mode is a special mode, only can be used when it is in test mode interface, exit interface,
then return to previous running mode. In the test mode, you can adjust Pan, tilt and focus motor’s
position, also can adjust intensity of RGBW color. The RGBW color of test mode can be used by the 6th
channel in the DMX mode.
Sys info : display related information on system
DMX address
Running mode: System running mode currently
ON time: The current time when you power on it
Run time: Total time of using this light
Temperature: Display current temperature
Ver: current verson of software
Control panel of LED display information:
Green
On
DMX signal ok
Off
No DMX signal
Flash
DMX signal error
Red
On
Err
Maintenance:
To prolong the life of the projector, some maintenance work has to be done to ensure the LED
optical system in good condition. If the projector does not function, check the fuses on the power
socket of the projector, they should only be replaced by fuses of the same specification. Should
these be damaged, call a qualified technician before replacement. The projector has thermal
protection device that will switch off the projector in case of overheating. Should either of these
operate, check that the fans are not blocked, and if they are dirty, clean them before switching on the
projector again. Check that the fans are operational, if not, call a qualified technician.
☆Any maintenance work should only be carried out by qualified technicians.
Keeping The Product Clean:
To ensure the reliability of the projector, it should be kept clean. It is recommended that the fans
should be cleaned every 15 days. LED lens should also be regularly cleaned to maintain an optimum
light output.
Cleaning frequency depends on the environment in which the fixture operates: damp, smoke or
particularly dirty surroundings can cause greater accumulation of dirt on the unit's optics. A soft cloth
and typical glass cleaning products should be used for cleaning. It is recommended to clean the
external optics at least once every 15 days.
☆Do not use any organic solvent, e.g. alcohol, to clean housing of the apparatus.

10
Trouble Shooting:
Problem
Answer
The LED moving head light doesn’t switch
on.
Check the fuse the power socket
Although shines, but the LED moving head
lamp doesn’t accept the instruction of the
controller.
Check the digital start address and
also check the connection situation of
the communication control line
LED moving head lamp only can work
intermittently.
Inspect the power supply and voltage
is whether normal.
Do not receive the DMX512 signal.
Whether the signal lines do contact
well or broken.
The light beam appears gloomily.
Check that the heat dissipation
system is running normally or Inspect
the optics part is whether clean.
☆Other maintain work should by the specialist which has the experience to carry on.
Equipment and Appendix:
The packing list of this light as follows:
☆Led zoom moving head light 1pcs
☆Power Cable 1pcs
☆XLR connector 1unit
☆Light Hook 2pcs
☆The Product of Instruction 1pcs
Channel List:
STAN
(22CH)
SMAL
(14CH)
DMX
Value
Function
1 1 0－255 Pan moving
2 2 0－255 Tilt moving
3 3 0－255 Zoom moving
4 4 0－255 Pan fine(16Bit)
5 5 0－255 Tilt fine(16Bit)
6 6 0－255 XY motor speed from quick to slow
7 7 0－255 Main dimming
8 8 0 Strobe from slow to quick
1-255

11
* 9 0－255 Red dimmer from dark to bright
* 10 0－255 Green dimmer from dark to bright
* 11 0－255 Blue dimmer from dark to bright
* 12 0－255 White dimmer from dark to bright
9 * 0－255 R1 dimmer from dark to bright
10 * 0－255 G1 dimmer from dark to bright
11 * 0－255 B1 dimmer from dark to bright
12 * 0－255 W1 dimmer from dark to bright
13 * 0－255 R2 dimmer from dark to bright
14 * 0－255 G2 dimmer from dark to bright
15 * 0－255 B2 dimmer from dark to bright
16 * 0－255 W2 dimmer from dark to bright
17 * 0－255 R3 dimmer from dark to bright
18 * 0－255 G3 dimmer from dark to bright
19 * 0－255 B3 dimmer from dark to bright
20 * 0－255 W3 dimmer from dark to bright
0-5 Do not use macro function
6-20 Choice color（Motor is control by DMX512）
21-40 Color jumping change（Motor is control by DMX512）
41-60 Color fading change（Motor is control by DMX512）
61-80 Color pulsing change（Motor is control by DMX512）
21 13 81-100 Sound control 1（Motor is control by DMX512）
101-120 Sound control 2（Motor is control by DMX512）
121-140 Choice color（Motor auto running）
141-160 Color jumping change（Motor auto running）
161-180 Color fading change（Motor auto running）
181-200 Color pulsing change（Motor auto running）
201-220 Sound control 1（Motor auto running）
221-255 Sound control 2（Motor auto running）
22 14 0－255
Color choice, jumping
，
fading
，
pulsing speed is from slow to
fast

12
Technical Parameters:
Construction: Composite plastic, die-casting aluminum,
Voltage: AC100V-240V; 50/60Hz
Power Consumption: 300W (220V)
LED Bulbs: 4IN1*19LEDs
LED Current: 700mA
LED Lifetime: 50000Hours
Colors: RGBW color mixing
Adjusts the light: 0-100 electron adjusts the light, various colors may alone move also may mix the
color tone
Strobe: 1-25/second high speed strobe, but single color Mixes the color strobe
Head Movement: Pan 540°, Tilt 270°, with auto position correction and electronic replacement
function.
Beam Angle: 15-60°
Control mode: DMX 512, Stand –alone mode, Sound, Master/slave
DMX Channel: 14/22CH
Control Panel: LCD display panel
IP Grade: IP20
Work Environment Temperature:-20°C~40°C
Other Functions: Pan and Tilt speed adjustable; LCD Display and light use time; Menu inversion,
Screen protection and so on
Net weight:7.5KG
Gross Weight:8.8 kg
Package Size: 360 x 250x 460cm
