Mocka Hudson Bar Stool User manual

Hudson Bar Stool
1
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Once fully assembled please ensure all legs are sitting flush against
the stools underside to ensure stability. Do not over-tighten screws.
To ensure longevity of the wood please use a damp cloth only for
cleaning. Avoid use of household cleaners
F
Socket Screw
25mm x4
G H
Socket Screw
35mm x12
Socket Screw
30mm x2
IJ
Socket Nut
x6
Allen key
x1
Thank you for your purchase.
Please follow the instructions below for correct assembly.

12
Hudson Bar Stool
2
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Find all four stool legs and position them on the underside of the seat
(A). Legs (C) are positioned at the front and Legs (B) at the back. Using
the 12x screws (F) and the allen key (J) attach each leg to the seat.
Fasten the back rest (D) to the back legs using 4x Socket Nuts (I) and
4x Socket Screws (G). Tighten the nuts and screws using the Allen Key
F x12
J
A
B B C C
I x4
G x4
J
D

3
3
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach the Support (E) to the front legs using the remaining 2x Socket
Nuts (I) and Socket Screws (H).
Fasten all screws and ensure all legs are sitting flush on the ground to
ensure stability. All done! Regularly check all screws are secure but not
overly tightened. You’re done, enjoy!
Hudson Bar Stool
4
H x2
J
E
I x2
