Mocka Avoca User manual

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
WARNING: Any furniture that is not anchored to a wall has the
potential to tip over in certain circumstances, ie. if a child attempts
to climb on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall.
We supply a free safety wall anchor with all furniture sold and we
recommend these are used to prevent your product tipping. The
fixing device provided should fit most wall types, but please note
that dierent wall materials may require dierent fixing devices from
those supplied.
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
A B CD
34x 34x 24x 10x
E F GH
3x 3x 4x 2x
I J KL
36x 14x 14x 12x
nutbolt dowel 4”35 screw
spacerclip hinge hinge
bracket4”14 screw 3”14 screw support
M
6x
3.5”12 screw
Avoca
Entertainment Unit

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
Avoca
Entertainment Unit

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
1 2
Attach 12 x bolts (A) to panel {2}, {3} and {8}. Attach 4 x hinge (G) to panel {10},
secure with 8 x screws (I). Tighten with a screwdriver.
Attach 14 x bolts (A) to panel {6}. Attach 2 x hinge (H) to panel {10}, secure
with 4 x screws (I). Tighten with a screwdriver.
I
I
G
H
I
H
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
I
G
A
A
Avoca
Entertainment Unit

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
3 4
Attach 8 x bolts (A), 3 x spacer (F), 3 x clip (E) to panel {1}. secure
with 6 x screws (M). Tighten with a screwdriver.
Attach panel {7} to panel {2} , secure with 2 x nut {B}. Tighten with a screwdriver.
A
E
B
E
A
A
A
A
A
A
A
E
E
BACK!
M
x3 x3
E
F
Avoca
Entertainment Unit
B

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
5 6
Attach assembled frame as show to panel {3}, secure with 2 x nut {B}. Tighten
with a screwdriver.
Attach panels {4} and {5} to assemble part as shown, secure with 2 x screws {D}.
Tighten with a screwdriver.
B
D
D
Avoca
Entertainment Unit
B

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
7 8
Slide panel {13} into position as shown Attach panel {6} to assembled frame together as shown and secure with 8 x
screws (D) and 8x dowels {C}. Tighten with a screwdriver.
D
D
D
D
D
D
D
C
C
C
C
Avoca
Entertainment Unit

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
9
Attach panels (8} and {9} together as shown.Secure with 8x nuts{B} and 8x
dowels {C} as shown. Tighten with a screwdriver.
10
Attach assembled frames as shown and secure with
14x nuts {B}. Tighten with a screwdriver.
B
B
B
B
C
C
C
C
C
C
C
C
B
B
B
B
B
Avoca
Entertainment Unit
B
B

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
11 12
Slide panel {13} into position as shown
180
B
B
BB
C
C
C
C
Attach panel {1} to assembled frame, secure with 8 x nuts (B) and 8x dowels {C}.
Tighten with a screwdriver.
Avoca
Entertainment Unit
B

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
13
Attach 14 x bracket (J) as shown and secure with 14 x screws (K).
Tighten with a screwdriver.
14
Slide panels {11} and {12} into position as shown.
J
K
J
x14
J
J
J
J
J
J
J
J
J
L
Avoca
Entertainment Unit
L
L
LL
L

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
15
Attach panels [10] to assembled frame as shown and secure with 24 x
screws (I). Tighten with a screwdriver.
16
You’re done, enjoy!
x4
G
H
H
GI
I
x2
G
H
G
G
Avoca
Entertainment Unit
