WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
Boston Three Drawer
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
1
Screw
x12 Handle
x6
Screw
x30
E P
Locking Nut
x9
A B C D
G H
Bolt
x9 Screw
x4 Dowel
x18
Nut
x24
F
Screw
x1
Q
R
Screw
x1
Washer
x2
S
Wall Plug
x1
T
Safety Strap
x1
Wall Strap
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
Phillips & Flathead screwdrivers
Hardware Supplied
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Left Slide Rail
x3
J
Left Slide Rail
x3
K
Right Slide Rail
x3
L
Right Slide Rail
x3
M
Screw
x36
N
Foot Pads
x6
U
Allen Key
x1
O
1
Attach 3 x slide rails (J) to panel [1] and secure with 9 x scews (N).
Attach 3 x foot pads (U) to panel [1]. Attach 3 x slide rails (L) to panel
[2] and secure with 9 x scews (N). Tighten with a screwdriver. Attach 3
x foot pads (U) to panel [2].
2 x 3
Attach 1 x left slide rail (K) to panel [9] and secure with 3 x screws (N).
Attach 1 x right slide rail (M) to panel [12] and secure with 3 x screws
(N). Tighten with a screwdriver.
Boston Three Drawer
2
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
U
U
U
J
J
J
J
N
N
N
N
N
M
K
N
N
N
N
N
1
9
12
UU
U
L
L
L
N
N
N
2
4
Insert 2 x dowels (D) into panel [3]. Connect panels [3] and [4] and
secure with 3 x locking nuts (A). Tighten with a screwdriver.
4
3
Boston Three Drawer
3
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
3
Insert 9 x bolts (B) into panels [1], [2] and [3]. Tighten with a screwdriver.
1
3
2
6
Boston Three Drawer
4
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Slide panel [6] between the grooves on panels [4] and [5] to form the
back of the unit as shown.
5
4
6
5
Insert 5x dowels (D) into panels [3], [4] and [5]. Connect panels [1], [3],
[4] and [5] and secure with 3x locking nuts (A). Tighten with a
screwdriver. Secure panels [4] and [5] to panel [1] with 2x screws (C).
Tighten with an allen key (O).
1
5
4
3
8
Boston Three Drawer
5
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Connect panel [7] to panels [1] and [2] and secure with 6 x screws (E).
Tighten with an allen key (O).
1
2
7
7
7
7
Insert 5x dowels (D) into panels [3], [4] and [5]. Connect panels [2], [3],
[4] and [5] and secure with 3x locking nuts (A). Tighten with a
screwdriver. Secure panels [4] and [5] to panel [2] with 2x screws (C).
Tighten with an allen key (O).
6
5
4
3
1
2
10 Drawer x 3
Boston Three Drawer
6
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Slide panel [11] between the grooves on panels [9] and [12] to form the
base of the drawer as shown.
9
12
11
9 Drawer x 3
Connect panels [9] and [12] to panel [10] and secure with 4x screws (E)
and 4x nuts (F). Tighten with an allen key (O).
9
10
12
12 Drawer x 3
Boston Three Drawer
7
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Connect 2 x handles (H) to panel [8] and secure with 4 x screws (G).
Tighten with a screwdriver.
8
11 Drawer x 3
Connect panel [8] to panels [9] and [12] and secure with 4x screws (E)
and 4x nuts (F). Tighten with an allen key (O).
8
11
9
12
14
Boston Three Drawer
8
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Fasten to the wall and the back of the unit using 1 x safety strap (T),
1x wall plug (S), 2x washers (R), 1x screw (P) and 1x screw (Q). Ensure
the unit is balanced and steady before use. You’re done, enjoy!
13
Insert each drawer into the unit as shown, ensuring they slide
smoothly and easily along the rails. Once assembled, lift furniture
into place, do not drag.
