Mocka Maya Bedside Table User manual

*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
x2
washer
Z
Wall
Screw
r/washer
screw
x1
Y
wall
anchor
x1
X
Safety
Strap
W
Wall Strap
WARNING: Any furniture that is not anchored to a wall has the potential to
tip over in certain circumstances, i.e. if a child attempts to climb up on the
furniture or in the event of an earthquake. Accordingly, we recommend that
all furniture is anchored to a wall. We supply a free safety wall anchor with
all furniture sold and we recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall types, but please
note that different wall materials may require different fixing devices from
those supplied.
Phillips & Flathead screwdriver and hammer required
V
A B C D
FG
Hardware Supplied
dowel
x8
screw
x4
bolt
x12
locking
nut x12
screw
x16
H
small
screw x9
bracket
x4
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Maya Bedside Table
1
mocka.co.nz | mocka.com.au
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
E
stopper
x1 x1 x1
I
screw
x1

12
Attach 4x brackets (G) to panel [2] with 16x small screws (F), ensuring
the raised edge of each bracket faces the middle of the table. Tighten
with a screwdriver.
Screw on 4x legs [10] to the brackets on panel [2] until secure.
F x4
F x4
F x4
F x4
G
G
G
G
2
2
10
10
10
10
Maya Bedside Table
2
mocka.co.nz | mocka.com.au
Assembly Instructions
F x4

34
Insert 8x bolts (A) and 8x dowels (C) into the ends of the side panels
[3] and attach to panel [2]. Attach panel [1] to the side panels and
secure all with 8x locking nuts(B). Tighten with a screwdriver. Attach
1xstoppers (E) to panel [2] and secure with screws (I).
Secure panel [4] onto the back of the side drawer with 9x screws (H).
Use 1x screw (W) and 1x washer (Z) to attach the safety strap (V) to the
top panel.
3
3
1
2
A
A
A
A
A
A
A
C
C
C
C
B
B
B
BB
B
B
3
4
HH
H
HHH
H
H
H
V
Z
W
small
screw
strap
Maya Bedside Table
3
mocka.co.nz | mocka.com.au
Assembly Instructions
E
I

56
Insert 4x bolts (A) into panel [5].Tighten with a screwdriver. Attach panel [6] and [7] to front panel [5] using 4x locking nuts (B).
Tighten with a screwdriver.
Drawer
Maya Bedside Table
Assembly Instructions
4
mocka.co.nz | mocka.com.au
Drawer
A
B
A
B
A
AB
B
6
7
5
5

78
Slide panel [9] along the grooves between the side panels [6] and
[7] to form the base of the drawer.
Attach panels [6], [7] and [8] as shown using 4x screws (D).
Tighten with a screwdriver.
Drawer
Maya Bedside Table
Assembly Instructions
5
mocka.co.nz | mocka.com.au
Drawer
D
D
D
D
6
7
9
8
5
6
7
9
5

X
ZY
V
x1
wall
anchor
wall
screw
Washer
Strap
910
Insert the completed drawer and lift the unit to the desired location, do
not drag.
Drawer
Maya Bedside Table
Assembly Instructions
6
mocka.co.nz | mocka.com.au
Use a drill to create a small hole lining up with the top of the safety strap
(V).Fasten to wall using wall anchor (X), washer (Z) and a wall screw(Y).
Ensure unit is balanced and steady before use. You’re done, enjoy!
Wall Strap
