Mocka Brixton User manual

mocka.co.nz I mocka.com.au
Brixton
Desk Drawers
Thank you for purchasing a Mocka . Please follow the Brixton Desk Drawers
manufacturer’s assembly instructions in detail to ensure the safety
features of the not compromised.
d s
rawers i
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an
earthquake. Accordingly, we recommend that all furniture is anchored to a wall. We supply a
free safety wall anchor with all furniture sold and we recommend these are used to prevent
your product tipping. The fixing device provided should fit most wall types, but please note
that different wall materials may require different fixing devices from those supplied.
Phillips&Flatheadscrewdriversrequired
A B C D E
HardwareSupplied
F
I J K M N O
bolt & nut
set x20
PVC sticker
x20
dowel
x8
50mm
s x12
crew slide rail
x3
14mm
s x48
crew
18mm
bolt x3
handle
x3
lock castor
x2
w plug
all
x2
safety strap
x2
25mm
s x2
crew
L
castor
x2
G
18mm
s x6
crew
H
brace
x6
E1 E2
E3
E4

mocka.co.nzImocka.com.au
1 2
Insert the 8 x nut(A) into panel [3] and [4]. Insert the 12 x nut(A) into 3 x panel [7] and 3 x panel [8].
Brixton
Desk Drawers
34
7 8
x3
A
A
A
AA
A
A
A
A
A

mocka.co.nzImocka.com.au
3 4
Attach the 2 x lock castor (L) and 2 x castor (K) with 16 x screw (F).
Tighten with a screwdriver.
Attach slide rails (E1) and (E3) to panels [3] and [4] with 18 x screws (F).Tighten
with a screwdriver.
Brixton
Desk Drawers
2
34
F
F
F
FK
K
L
L
E1
E1
E1 E3
FF
E3
E3

mocka.co.nzImocka.com.au
5 6
Attach panel [3] and [4] to panel [2] with 4 x bolt (A) and 4 x dowel (C). Tighten
with a screwdriver.
Slide panel [5] into the position as shown.
Brixton
Desk Drawers
A
A
A
A
C
C
C
C
2
3
45
3
4

mocka.co.nzImocka.com.au
7
Attach panel [1] to panel [3] and [4] with 4 x bolt (A) and 4 x dowel (C).
Tighten with a screwdriver.
8
Insert 6 x braces (H) into panel[5] with 6 x screws (G).Tighten with a screwdriver.
Brixton
Desk Drawers
1
3
4
5
G
H
A
A
A
AC
C
C
C

mocka.co.nzImocka.com.au
9
Attach panel [7] and [8] to panel [9] with 12 x screw( D). Tighten with a
screwdriver. Then slide panel [10] into the position as shown.
Brixton
Desk Drawers
x3
10
Attach handle (J) to panel [6] with bolt (I). Tighten with a screwdriver.
x3
7
8
9
10 6
D
D
D
D
I
J

mocka.co.nzImocka.com.au
11
Attach panel [6] to panel [7] and [8] with 12x bolt (A). Tighten with a screwdriver.
Brixton
Desk Drawers
12
Attach E2 and E4 to panel [7] and [8] with 12x bolt (F). Tighten with a
screwdriver.
x3 x3
F
F
F
F
7
7
8
10
6
A
A
A
A
E2
E4

mocka.co.nzImocka.com.au
13
Insert the drawers to the cabinet as shown. Then you can stick the PVC sticker
on visible nut (A) to make the cabinet more pretty.
Brixton
Desk Drawers
14
Attach safety strap (O) to panel [1] with 2 x screw(F). Tighten with a
screwdriver.
6
6
6
O
O
F
F
B
1

mocka.co.nzImocka.com.au
15
Move the unit to the desired location against a wall. Attach the other end of the
2 x safety straps (O) to the wall using 2 x wall plugs (N) and 2 x screws (M).
Tighten with a screwdriver.
Brixton
Desk Drawers
16
You're done, enjoy!
M
N
O
