  9. Mocka Aspen Six Drawer User manual

Mocka Aspen Six Drawer User manual

Phillips & Flathead screwdrivers and hammer required
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
1
X
Z
Y
W
safety
strap
x1
screw
x1
long
screw
x1
wall
anchor
x1
washer
x1
mocka.co.nz | mocka.com.au
B
ACDEF
GH
12 mm
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
WARNING: Any furniture that is not anchored to a wall has the potential
to tip over in certain circumstances, i.e. if a child attempts to climb up on
the furniture or in the event of an earthquake. Accordingly, we
recommend that all furniture is anchored to a wall. We supply a free
safety wall anchor with all furniture sold and we recommend these are
used to prevent your product tipping. The fixing device provided should
fit most wall types, but please note that different wall materials
may require different fixing devices from those supplied.
bolt
x48
locking
nut x 48
dowel
x20
small
screw x48
I
L + R
slide rail
x12
L + R
slide rail
x12
screw x 30
Aspen Six Drawer
40 mm
long
screw x 18
handle
x 6
30 mm
medium
JKL
nut
x4
long
screw x4
cover
x 24
M
N
long
screw x1
shelf
plug x1
O
wedge
x12
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
2
mocka.co.nz | mocka.com.au
Aspen Six Drawer
12
A
1
Insert 10 x bolts (A) into panel [1]. Tighten with a screwdriver.
Attach 1 x wall strap (W) to panel [1] using 1x screw(Y).
G
Attach 3 x left slide rails (G) to panel [3] and secure with 6 x small screws (E).
Attach 3 x right slide rails (G) to panel [4] and secure with 6 x small screws (E).
AA
EE
EE
EE
G
GG
GGG
A
A
EE
EE
EE
3
4
Tighten with a screwdriver.Insert 4 x bolts (A) into panels [3] and [4].
A
A
AA
A
A
A
A
A
A
17
18
17
18 L
L
KK
KK
L
L
K
Insert 4 x nuts (K) into panels [17]. Attach panels [17] to panels [18] and secure
with 4 x screws (L).
YW
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
3
mocka.co.nz | mocka.com.au
Aspen Six Drawer
34
180o
5
4
6
6
B
B
C
C
C
C
B
B
Insert 4 x dowels (C) into panels[6]. Attach panels [6] to panels [4] and [5]
and secure with 4 x locking nuts (B). Tighten with a screwdriver.
B
Attach 3 x left slide rails (G) to panel [5] and secure with 6 x small screws (E).
Attach 3 x right slide rails (G) to panel [5] and secure with 6 x small screws (E).
Tighten with a screwdriver.Insert 4 x bolts (A) into panel [5].
E
E
EE
EE
AA
G
GG
5
5
EE
E
E
E
E
AA
GG
G
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
4
mocka.co.nz | mocka.com.au
Aspen Six Drawer
56
5
4
6
6
B
B
C
C
C
C
B
B
B
3
Insert 4 x dowels(C) into panels[6]. Attach panels[6] to panels [3] and [5]
and secure with 4 x locking nuts (B). Tighten with a screwdriver.
7
7
2
3
4
5
D
D
DD
D
D
DD
D
D
C
C
C
C
C
C
Insert 6 x dowels (C) into panels [3], [4] and [5] .Attach panels [3],
[4], [5] and [7] to panel [2] and secure with 10 x long screws (D).
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
5
mocka.co.nz | mocka.com.au
Aspen Six Drawer
78
10
10
7
5
3
4
9
Slide panels [9] and [10] between the grooves on panels [3] and [4] and [7]
to form theback of the unit as shown.
2
D
D
D
D
D
D
D
D
N
M
Attach panels [17] and [18] to panel [2] and secure with 8 x long
screws (D). Attach 1 x long screw (M) to centre support (N) as shown.
Tighten with a screwdriver.
3
4
17
18
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
6
mocka.co.nz | mocka.com.au
Aspen Six Drawer
910
Drawers (x6)
BB
B
B
A
AA
A
11
12
13
Tighten with a screwdriver.
Insert 24 xbolts (A) into panels [11]. Attach panels [12] and [13] to panels
[11] secure with 24 xlocking nuts (B).
I
II
O
3
5
4
1
7
7B
B
C
C
C
C
BB
B
B
BB
CC
Insert 6 x dowels(C) into panel [1]. Attach panel [1] to panels [3], [4] and [7]
and secure with 10 x locking nuts (B). Tighten with a screwdriver.
Cover locking nuts (B) with 24 x covers (O).
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
7
mocka.co.nz | mocka.com.au
Aspen Six Drawer
11 12
Drawers (x6)
I
E
I
13
E
H
H
E
B
A12
13
14
15
11
F
F
F
F
F
12
15 14
16
13
Insert 6 x bolts (A) into panels [11] .Slide panels [15] between the
Attach panels [14] to panels [11] and secure with 6 x locking nuts (B).
grooves on panels [12] and [13] to form the base of the drawer as shown.
Tighten with a screwdriver.
Attach panels [16] to panels [12], [13] and [14] secure with 30 x medium
screws (F).
Attach 12 x slide rails (H) to panels [12] and [13] and secure with 24 x small
screws (E).Insert 6 x handles (I) into panel [11] .
Drawers (x6)
11
12
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
8
mocka.co.nz | mocka.com.au
Aspen Six Drawer
13 14
Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (W). Fasten to wall
using wall anchor (X), washer (Z) and screw. Ensure the unit is balaced
and steady before use. You’re done, enjoy!
X
Z
x1
wall
screw
wall
anchor
wall
screw
Washer
Strap
J
J
J
JJ
J
J
J
J
J
JJ
J
10
10
9
Attach 12x wedges (J) to panels [9] and
[10].
Tighten with a screwdriver.
