Mocka Olsen Entertainment Unit User manual

WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
Phillips & Flathead screwdrivers required
Olsen Entertainment Unit
1
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
A B C D E F
IJ
dowel
x24
screw
x12
bolt
x28
locking
nut x28
small
x30
long
screw
x24
KL
CL
runner
tracks x3
CR
runner
tracks x3
DL
runners
x3
DR
runners
x3
G
wedge
x4
H
screw
x4
M
allen
key
x1
N
cover
x8
screw
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1

12
Insert 8x bolts (A) and 8x dowels (C) into panel [1]. Insert 4x bolts
(A) into panel [6]. Tighten with a screwdriver.
Olsen Entertainment Unit
2
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Attach 1x CL runner track (I) to panel [2] and secure with 3x small
screws (F). Attach 1x CR runner track (J) to panel [3] and secure
with 3x small screws (F). Insert 4x bolts (A) and 4x dowels (C) into
panels [2] and [3]. Tighten with a screwdriver.
A
A
1
A
A
A
A
A
A
6A
A
A
A
3
2
A
A
A
A
C
C
CC
C
C
C
C
C
C
C
C
J
F
F
F
F
F
F
F
I
CL
F
J
CR
I

Attach 1x CL runner tracks (I) to each panel [7] and secure with
3x small screws (F). Flip panels [7] over, attach 1x CR runner
tracks (J) to each panel [7], and secure with 3x small screws (F).
Tighten with a screwdriver.
34
Attach panels [2] and [3] to panel [6] and secure with 4x locking nuts
(B) and tighten with a screwdriver.
Olsen Entertainment Unit
3
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
B
B
B
B
2
3
6
F
F
F
F
F
F
B
F
I
CL
F
J
CR
x2
7
I
J
7

Attach 2x panels [5] to panel [6] with 4x dowels (C) and secure with
4x long screws (D) and tighten with a screwdriver.
5
Attach top panel [1] to the rest of the unit and secure with 8x locking nuts
(B) and tighten with a screwdriver. Seal the holes with 8x covers (N).
Olsen Entertainment Unit
Assembly Instructions
4
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
C
C
6
B
B
B
6
5
5
5
5
1
D
D
D
D
L
L
L
B
N
BL
2
3

Slide the completed drawers into the unit, ensuring they slide smoothly
and easily.
B
B
7
7
6
2
3
6
B
8
B
B
Attach 2x panels [7] to panel [6] and secure with 4x locking nuts
(B) and tighten with a screwdriver.
7
Slide panel [8] between the grooves of panels [2] ,[3] and [6] to form
the back of the unit, as shown.
Olsen Entertainment Unit
Assembly Instructions
5
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
8

Jolt Wardrobe
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
9
Attach bottom panel [4] to the rest of the unit with 8x dowels (C) and
secure with 8x long screws (D) and tighten with a screwdriver.
Olsen Entertainment Unit
Assembly Instructions
6
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
C
C
C
10
Attach 4x legs [14] to the bottom panel [4] with 12x screws (E), and
tighten with an Allen key (M).
2
3
7
7
4
4
E
C
C
D
D
D
D
D
D
D
D
E
E
E
14
14
14
14
M
E

A
A
A
A
Jolt Wardrobe
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
11
Insert 4x bolt (A) into panel [9]. Tighten with a screwdriver.
Olsen Entertainment Unit
Assembly Instructions
7
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
12
Attach panels [10] and [11] to panel [9] with 4x locking nuts (B).
Tighten with a screwdriver.
Drawers x3Drawers x3
B
B
B
B
11
10
B
99

Jolt Wardrobe
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
13
Slide panel [12] along the grooves between the side panels [10] and
[11] to form the base of the drawer.
Olsen Entertainment Unit
Assembly Instructions
8
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
14
Attach panels [10], [11] and [13] with 4x screws (D). Tighten with a
screwdriver.
Drawers x3Drawers x3
12
11 D
D
D
D
13
11
10 10
9

Jolt Wardrobe
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
15
Attach DL runner (K) to panel [10] and DR runner (L) to panel [11] with
4x small screws (F). Tighten with a screwdriver. Complete the other
two drawers.
Olsen Entertainment Unit
Assembly Instructions
9
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
16
Insert the completed drawer into the main unit as shown, ensuring
they slide easily along the rails.
Drawers x3
F
F
F
F
K
L
11
10

Jolt Wardrobe
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
17
Attach 4x wedges (G) to the corners of the back [8] as shown, and
secure with 4x small screws (H).Attach 1x safety strap (V) to the
top of the back side of the unit as shown using 1x washer (Z) and
1x screw (W). Tighten with a screwdriver.
Olsen Entertainment Unit
Assembly Instructions
10
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
18
Once assembled lift furniture into place, do not drag. Use a drill
to create a small hole lining up with the top of the safety strap (V).
Fasten to the wall using 1x washer (Z), 1x wall plug (X) and 1x
screw (Y). Ensure unit is balanced and steady before use. You’re
done, enjoy!
H
G
H
G
8
V
W
Z
V
Z
W
X
Y
Z
X
Y
Z
