Mocka Hamptons User manual

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
1
X
Z
Y
W
safety
strap
x2
screw
x2
long
screw
x2
wall
anchor
x2
washer
x2
mocka.co.nz | mocka.com.au
WARNING: Any furniture that is not anchored to a wall has the potential
to tip over in certain circumstances, i.e. if a child attempts to climb up on
the furniture or in the event of an earthquake. Accordingly, we
recommend that all furniture is anchored to a wall. We supply a free
safety wall anchor with all furniture sold and we recommend these are
used to prevent your product tipping. The fixing device provided should
fit most wall types, but please note that different wall materials
may require different fixing devices from those supplied.
WARNING: Never leave a child unattended on the change table.
Hamptons Bookcase
Phillips & Flathead screwdrivers and hammer required
B
ACDEF
GH
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
bolt
x 28
locking
nut x 28
dowel
x 30
screw
x 24
I
screw x 8
40 mm
long
screw x 14
25 mm
medium
J
4
hinge
x 4
shelf plug
x 8
handle
x 2
K
shelf
plug x 1
long
screw x 1

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
2
12
mocka.co.nz | mocka.com.au
A
Insert 8 x bolts(A) into panels [3]. Tighten with a screwdriver.
3
A
A
A
A
5
5
3
B
B
CB
C
B
Side panel x 2
B
Insert 2 x dowels(C) into panels[5]. Attach panels [3] to panels [5]
and secure with 4 x locking nuts (B). Tighten with a screwdriver.

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
3
34
mocka.co.nz | mocka.com.au
5
5
3
6
5
5
3
3
C
C
B
B
B
B
Slide panel [6] between the grooves on panels [3] and [5]
to form the back of the unit as shown.
Insert 2 x dowels (C) into panels [5]. Attach panels [3] to panels [5] and [6]
and secure with 4 x locking nuts (B). Tighten with a screwdriver.

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
4
56
mocka.co.nz | mocka.com.au
5
5
3
3
6
6
8
2
A
A
A
A
A
A
Slide panels [6] between the grooves on panels [3] and [5]
to form the back of the unit as shown.
F
F
F
F
Insert 16 x bolts (A) into panels [2] and [9]. Attach panel [2] to panel [8] with 4
x medium screws (F). Tighten with a screwdriver.
9
AA
AA
A
A
A
A
AA

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
5
78
mocka.co.nz | mocka.com.au
1
1
8
Y
YW
W
1
3
3
D
D
D
D
C
C
F
F
F
F
Attach 2 x wall straps (W) to panel [1] using 2 x screws (Y).
Attach panel [8] to panel [1] with 4 x medium screws (F).
Tighten with a screwdriver.
Insert 2 x dowels (C) into panels [1] and [3]. Attach panel [1]
to panels [3] and secure with 4 x long screws (D).

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
6
910
mocka.co.nz | mocka.com.au
3
3
2
D
D
D
D
C
C
Insert 2 x dowels (C) into panels [2] and [3]. Attach panel [2]
to panels [3] and secure with 4 x long screws (D).
B
B
B
BB
B
C
C
C
C
C
C
2
10
11
12
Attach 6 x dowels (C) to panels [10] , [11] and [12]. Attach panel [2] to panels [10],
[11] and [12] and secure with 6 x locking nuts (B).

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
7
11 12
mocka.co.nz | mocka.com.au
12
10
11
9
C
CC
C
C
C
D
D
D
D
D
D
10
12
11
K
KJ
Slide panels [7] between the grooves on panels [10], [11] and [12]
to form the back of the unit as shown.
Attach 6 x dowels (C) to panels [10], [11] and [12]. Attach panel [9] to panels [10],
[11] and [12] and secure with 6 x long screws (D). Attach 1 x long screw (K) to
centre support (J) as shown.
7777
777
7

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
8
13 14
mocka.co.nz | mocka.com.au
A
13
A
A
x2
13
13
14
14
C
C
C
C
B
B
B
B
Attach 4 x bolts (A) into panels [13]. Attach 4 x dowels (C) to panels [13] and [14].
Insert 4 x locking nuts (B) into panels [14]. Tighten with a screwdriver.
13
13
14
14
BBB
B
B
B
B
B
C
B
B
C
C
C
C
C
Insert 6 x dowels (C) into panels [9], [13] and [14]. Attach panels [9], [13]
and [14] and secure with 10 x locking nuts (B). Tighten with a screwdriver.
9

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
9
15
mocka.co.nz | mocka.com.au
16
16
15
Attach 4 x hinges (G) to panels[15] and [16] and secure with 8 x small screws (E).
G
G
EE
EE
E
G
G
G
EE
EE
Attach panels [15] and [16] to panels [10] and [11] as shown. Secure
with 16 x screws(E). Insert 2 x handles (I) into panels [15] and [16].
E x4
E x4
E x4
E x4
II
I15
16
10
11

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hamptons Bookcase
10
17
mocka.co.nz | mocka.com.au
18
4
12
11
10
H x4
H x4
Insert 8 x shelf plugs (H) to panels [10], [11] and [12]. Place panels [4]
on to shelf plugs (H).
1
H
11
X
Z
wall
screw
x2
wall
anchor
wall
screw
Washer
Strap
X
Z
wall
screw
Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (W). Fasten to wall
using wall anchor (X), washer (Z) and screw. Ensure the unit is balaced
and steady before use. You’re done, enjoy!
