User’s Manual
TDY
PC-Programmable Temperature
Transmitter with Display
No. 235-740-00J
March 2019

Customer Support
Moore Industries is recognized as the industry leader in delivering top quality to its customers in products
and services. We perform a sequence of stringent quality assurance checks on every unit we ship. If any
Moore Industries product fails to perform up to rated specications, call us for help. Our highly skilled sta󰀨 of
trained technicians and engineers pride themselves on their ability to provide timely, accurate, and practical
answers to your process instrumentation questions. Our headquarters and other facilities phone numbers
are listed below.
There are several pieces of information that can be gathered before you call the factory that will help our
sta󰀨 get the answers you need in the shortest time possible. For fastest service, gather the complete model
and serial number(s) of the problem unit(s) and the job number of the original sale.
www.miinet.com
Demand Moore Reliability
Locations
World Headquarters Europe Australia
16650 Schoenborn Street
North Hills, California
91343-6196, U.S.A.
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
TOLL FREE: 1-800-999-2900
www.miinet.com
1 Lloyds Court, Manor Royal, Crawley
W. Sussex RH10-9QU
United Kingdom
Tel: [phone]
Fax: [phone]
FREE PHONE: [phone]
[email protected]
www.miinet.com/uk
Sydney, NSW
3/1 Resolution Drive
Caringbah, New South Wales 2229
Australia
Tel: [phone]
Fax: [phone]
[email protected]
www.miinet.com/au
China Guido Gezellestraat 106
BE-2630 Aartselaar
Belgium
Tel: [phone]
Fax: [phone]
[email protected]
Dutch: www.miinet.com/dbe
French: www.miinet.com/fbe
Perth, WA
6/46 Angove Street
North Perth, Western Australia 6006
Australia
Tel: [phone]
Fax: [phone]
[email protected]
www.miinet.com/au
Room 402, No. 57,
Lane 651, Xipu Road,
Xinqiao Town, Songjiang District,
Shanghai, 201612, P. R. China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.miinet.com/cn
Burg Meslaan 98
4003 CD Tiel
The Netherlands
Tel: [phone]
Fax: [phone]
[email protected]
www.miinet.com/nl
www.miinet.com Moore Industries-International, Inc.

Table of Contents
Introduction..................................................................................................... 5
The TDY...................................................................................................................................................... 5
Specications ........................................................................................................................................ 6
Input Type & Accuracy................................................................................................... 7
Ordering Information ..................................................................................................... 8
Everything You Need is Included ................................................................................. 8
Default Factory Conguration ...................................................................................... 8
Conguring a TDY........................................................................................................................ 9
What is First.................................................................................................................... 9
What is Next.................................................................................................................... 9
Installing the Software................................................................................................. 10
Gathering the Equipment Needed ......................................................................... 10-11
PC Conguration Software Summary........................................................................ 12
Keeping What You’ve Got Safe—Using the “Get Setup” Function ......................... 13
Selecting Input Type, Wiring, etc................................................................................ 14
Scaling the Input (also: Setting Reverse Output) .................................................... 15
Setting the Display....................................................................................................... 16
Scaling the Output ....................................................................................................... 17
Trimming the Input....................................................................................................... 18
Trimming the Output.................................................................................................... 18
Setting Miscellaneous Functions--Engineering Unit Readout, Input Filtering,
Upscale or Downscale Drive, and Broken Wire Detection....................................... 19

Setting Output Damping.............................................................................................. 20
Using the Loop Test..................................................................................................... 20
Creating a Custom Linearization Table.................................................................21-22
Managing Conguration Files..................................................................................................23
Saving the Conguration Files to Disk ...................................................................... 23
Retrieving a Conguration File from Disk ................................................................. 23
Retrieving a Conguration File from a Connected TDY........................................... 23
Installing and Connecting the TDY.......................................................................................24
Connecting the TDY in an Application ....................................................................... 24
Recommended Ground Wiring Practices .................................................................. 24
CE Conformity.............................................................................................................. 24
Dimensions.................................................................................................................................... 25-26
Installation in Hazardous Locations.........................................................................................27
Specic Conditions of Use ............................................................................................................27
Operating the TDY........................................................................................ 29
Maintaining the TDY........................................................................................................................29
Troubleshooting the TDY.............................................................................................................29
Conguration Software Error Messages ................................................................... 29
Contacting Customer Support .................................................................... 30
Intrinsically Safe Diagrams................................................................................................ 31-32
Return Procedures and Warranty Info ..............................................................................33

TDY
Demand Moore Reliability 5
Introduction
The TDY is a 2-wire (loop-powered) temperature
transmitter with a digital display. It is congured using
a personal computer (PC) and the software program
provided by Moore Industries.
The TDY
The TDY is an exceptionally accurate and remarkably
versatile temperature transmitter with display. It
transmits input from a thermocouple, RTD, direct
resistance, millivolt source, or a potentiometer as a
linearized, scaled, and o󰀨set 4-20mA. The output
signal is proportional (or, by user designation,
inversely proportional) to the input.
Available in your choice of explosion-proof or NEMA
4X enclosures, the TDY has certied protection in
even the toughest environments. Combine this with a
20 V/m RFI/EMI immunity, and you have a transmitter
that can accurately read and send temperature
information in some very di󰀩cult environments.
Figure 1. Use the PC-Programmable TDY as an interface between sensors and controllers
2-Wire
(Loop-Powered)
RTD
Thermocouple
Millivolts
Resistance
Potentiometer
4-20mA
Isolated
+PS -PS1 234
TDY
DEG f
705.74
TO SERIAL
(COM) PORT
OF PC
TDY COMMUNICATIONS CABLE
803-040-26 FOR NON-ISOLATED
803-039-26 FOR ISOLATED
804-030-26 FOR USB
TO USB
(COM) PORT
OF PC
or

TDY
6 Demand Moore Reliability
Specications
Input Accuracy:
Refer to Table 2
Output Accuracy: 4.8µA
(0.03% of 4-20mA span)
Overall Accuracy: overall
accuracy of the unit is the
combined input and output
accuracy. It includes the
combined e󰀨ects of linearity,
hysteresis, repeatability
and adjustment resolution.
It does not include ambient
temperature e󰀨ect. For T/C
input only, add the Reference
Junction Compensation error
Reference Junction
Compensation Accuracy:
±0.45°C
Stability: Error % of
Maximum Conformance
range
Power Supply and Load
E󰀨ect: Negligible within
power and load limits
Over-Voltage Protection:
4V max., on Input;
48V max., on Output;
48V Reverse Polarity
protection on output
Output Current Limiting:
3.8mA and 21.4mA for input
under/over range; 25mA,
maximum (hardware limit)
Load Capability:
583Ω @ 24V, typical;
Ω = (Supply Voltage - 10V)
0.024A
Burnout Protection: Total
Sensor Diagnostics
user-selected via Windows
conguration software;
Upscale to 23.6mA or
Downscale to 3.6 mA.
T/C Input Impedance:
40MΩ, nominal
RTD Excitation:
250µA, ±10%
RTD Lead Wire
Resistance Maximum:
RTD resistance + 2 times
the lead wire resistance
must be less than 4000Ω;
Recommended <35Ωper
wire for 3-wire inputs; <5Ω
per wire for 10Ω Cu inputs
Type:
LCD; Top Row, 10.16mm
(0.4 inch) high black digits
on a reective background;
Bottom Row, 5.72mm
(0.225 inch) high black
digits on a reective
background
Format: Two rows of ve
alphanumeric characters
Decimal Points:
Automatically adjusting
decimal point with a two
decimal place maximum
(Analog output display is
always two decimal places)
Range: -99999 to 99999
Minimum Display Span:
1.00
Operating and Storage
Range:
Transmitter: -40°C to 85°C
(-40°F to 185°F);
Display: -20°C to 65°C
(-4°F to 149°F)
Relative Humidity:
0-95%, non-condensing
E󰀨ect of Ambient
Temperature on Accuracy:
±0.015% of span per °C
change, max (+ 0.001% of Ω
reading for RTD inputs)
E󰀨ect of Ambient
Temperature on Reference
Junction Compensation:
±0.015°C/°C change
RFI/EMI Immunity:
20V/m@80-1000MHz, 1kHz
AM, when tested according
to IEC 61326
Common Mode Rejection:
100dB, min, @ 50/60Hz
Normal Mode Rejection:
Refer to Table 1
All settings made using
Windows-based conguration
program, then stored in non-
volatile memory
HP-style housing:
178g (6.3 oz)
2LG housing:
1229g (2 lbs, 11.9 oz)
D2LC housing:
688g (1 lb, 8.3 oz)
Performance Performance
(Continued)
Ambient
Conditions
Display
Specications and information subject to change without notice.
Stability Input to Output
1yr 3yrs 5yrs
T/C, mV 0.11 0.18 0.24
RTD
Ohm 0.13 0.22 0.28
Pot.
Isolation:
500VAC/1000VDC input to
output to case
Measurement Cycle:
Output updates at least 8
times per second
Response Time: 256msec
typical for the output to
change from 10% to 90% for
an input step change of 0%
to 100%
Step Response Time:
500msec typical from the
time an input is applied until
the output reaches 90% of its
nal value.
Ripple: 10mV peak-to-peak,
maximum.
Table 1. Normal Mode Rejection Ratio Table
Sensor Type Max. p-p Voltage Injection for
70dB at 50/60Hz
150mV
80mV
200mV
800mV
150mV
100mV
800mV
200mV
100mV
T/C: J, K, N, C, E
T/C: T, R, S, B
Pt RTD: 100, 200, 300 ohms
Pt RTD: 400, 500, 1000 ohms
Ni: 120 ohms
Cu: 9.03 ohms
mV
250-1000
62.5-250
31.25-62.5
Resistance
1-4kohms
0.25-1kohms
0.125-0.25kohms
Adjustments
Display
(Continued)
Weight

TDY
Demand Moore Reliability 7
RTD
T/C
Table 2. InputTypes,Ranges,MinimumSpanandMaximumRangeSpecications,andAccuracyoftheTDY
0.003750
0.003850
0.003902
0.003911
0.003916
0.003923
0.003926
0.003928
0.000672
0.000427
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
100, 200, 300,
400, 500, 1000
100, 200, 400
500, 1000
100, 500
100
98.129
100, 470,
500
100
120
9.035
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
-100 to 560°C
-148 to 1040°F
-240 to 960°C
-400 to 1760°F
-150 to 720°C
-238 to 1328°F
-235 to 710°C
-391 to 1310°F
-240 to 580°C
-400 to 1076°F
-235 to 680°C
-391 to 1256°F
-235 to 710°C
-391 to 1310°F
-260 to 962°C
-436 to 1763.6°F
-100 to 360°C
-148 to 680°F
-65 to 280°C
-85 to 536°F
n/a
-210 to 770°C
-346 to 1418°F
-270 to 1390°C
-454 to 2534°F
-270 to 1013°C
-454 to 1855.4°F
-270 to 407°C
-454 to 764.6°F
-50 to 1786°C
-58 to 3246.8°F
-50 to 1786°C
-58 to 3246.8°F
200 to 1836°C
392 to 3336.8°F
-270 to 1316°C
-454 to 2400.8°F
0 to 2338°C
32 to 4240.4°F
Direct resistance
or Potentiometer
J
K
E
T
R
S
B
N
C
-50 to 500°C
-58 to 932°F
-200 to 850°C
-328 to 1562°F
-100 to 650°C
-148 to 1202°F
-200 to 630°C
-328 to 1166°F
-200 to 510°C
-328 to 950°F
-200 to 600°C
-328 to 1112°F
-200 to 630°C
-328 to 1166°F
-200 to 850°C
-328 to 1562°F
-80 to 320°C
-112 to 608°F
-50 to 250°C
-58 to 482°F
0-4000Ω
-180 to 770°C
-292 to 1418°F
-150 to 1372°C
-238 to 2501.6°F
-170 to 1000°C
-274 to 1832°F
-200 to 400°C
-328 to 752°F
0 to 1768°C
32 to 3214.4°F
0 to 1768°C
32 to 3214.4°F
400 to 1820°C
752 to 3308°F
-130 to 1300°C
-202 to 2372°F
0 to 2315°C
32 to 4199°F
Input Type α∗ Ohms Conformance
Range
Minimum
Span Input Accuracy Maximum
Range
15°C (27°F) for
100Ωinputs
10°C (18°F) for
200Ωinputs
7.5°C (13.5°F)
for 500 and
1000Ωinputs
10°C (18°F)
100°C (180°F)
30Ω
35°C
63°F
40°C
72°F
35°C
63°F
20°C
36°F
50°C
90°F
50°C
90°F
75°C
135°F
45°C
81°F
100°C
180°F
±0.11°C ±0.2°F
±0.21°C ±0.38°F
±0.15°C ±0.27°F
±0.17°C ±0.31°F
±0.14°C ±0.25°F
±0.16°C ±0.29°F
±0.17°C ±0.31°F
±0.21°C ±0.38°F
±0.16°C ±0.29°F
±1.2°C ±2.16°F
±0.4Ω −
±0.28°C ±0.5°F
±0.3°C ±0.54°F
±0.26°C ±0.47°F
±0.24°C ±0.43°F
±0.71°C ±1.28°F
±0.71°C ±1.28°F
±0.43°C ±0.77°F
±1.33°C ±2.39°F
±1.16°C ±2.09°F
* α values with both 32 and 128-point linearization curves are available. (lower resolution values provided for compatibility with older units.)
Ohms
Millivolts DC n/a n/a -50 to 1000mV 4mV ±0.04mV -50 to 1000mV
Platinum
Nickel
Copper
1000

TDY
8 Demand Moore Reliability
Model and Serial Numbers Moore Industries uses
a system of model and serial numbers to keep track
of all of the information on every unit it sells and
services. If a problem occurs with a TDY, check
for a tag a󰀩xed to the unit listing these numbers.
Supply the Customer Support representative with this
information when calling.
If additional units are needed, use the information
printed in bold text in the table above to “build” a
model number for the type of transmitter required.
Each TDY order comes with one copy of our Interface
Solution Conguration Tools and Installation Manuals
CD.
To order additional copies of the Interface Solution
Conguration Tools and Installation Manuals CD,
specify Moore Industries’ part number
750-75E05-01.
To order cables, specify Moore Industries’ part number
803-040-26, or 803-039-26 for the special cable
equipped with its own, self-powered input-to-output
isolation circuit for operation in areas of high ground
potentials. Use Moore Industries’ part number 804-
030-26 for Fuse Protected USB cable.
Ordering Information
Unit
TDY
PC-Programmable
Temperature
Transmitter with
Display
Input
PRG
Programmable
with supplied
Conguration
Software (see
Table 1 for
descriptions of
available input
types; Factory
Conguration
available)
Output
4-20 MA
User
scaleable
with
supplied
software
Housings
BH2NG* 2-Hub, explosion-proof enclosure with two, ½-inch
entry ports and a glass cover
BH2TG* 2-Hub, explosion-proof enclosure with two, ¾-inch
entry ports and a glass cover
BH2MG* 2-Hub, explosion-proof enclosure with two, M20 x 1.5
entry ports and a glass cover
BH3NG 3-Hub, explosion-proof enclosure with three, ½-inch
entry ports
BH3TG 3-Hub, explosion-proof enclosure with two, ¾-inch side-
entry ports, one ½-inch bottom-entry port, and a glass cover
BH3MG 3-Hub, explosion-proof enclosure with two, M20 x 1.5
side-entry ports, one ½-inch bottom-entry port, and a glass cover
D2LC 2-Hub, low base, clear cover, NEMA 4X (IP66) enclosure
HP Hockey puck housing and spring clips
DN Snap-in mounting for HP case on TS-32 DIN rail
FL Mounting anges on HP suitable for relay track or screw
mounting
FLD Mounting anges on HP suitable for 3½” relay track
mounting
A su󰀩x indicates ANZEx (TestSafe) Ex d approval (i.e. BH2NGA).
E su󰀩x indicates ATEX (ISSeP) Ex d and Ex tD approval (i.e. BH2NGE).
2-inch pipe mount standard for A or E su󰀩x.
P su󰀩x indicates enclosure comes equipped with base and U-bolts for mounting on a
2-inch pipe (i.e. BH2NGP)
To order, specify: Unit / Input/ Output / Power [Housing]
Model Number Example: TDY / PRG / 4-20MA / 10-42DC [BH2NGP]
Default Factory Conguration
for TDY
The following are the factory default conguration
settings for your TDY unit:
Input:
RTD 4W Pt3850 100 Ohms 0-100degC
Display:
Input
Settings:
Input Trim OFF
Broken wire:
ON
Filter:
60Hz
Sensor Failure:
Up 24mA
Output:
4-20mA
Damping:
0s
Options
-IS Option
(cFMus,
ATEX and
IECEx
Intrinsically
Safe ap-
proval)
Power
10-42DC
10-30DC
for -IS
option

TDY
Demand Moore Reliability 9
Conguring a TDY
One of the benets of the TDY transmitter is its easy-
to-use PC program; there are no internal or external
controls to adjust or settings to change. All operating
parameters are set using the PC program included
with each shipment. These settings are “downloaded”
in the form of a Conguration File into nonvolatile unit
memory over a connection between the PC’s serial
(COM) port (or USB port when using cable
804-030-26) and a COM port on the transmitter.
This section of the manual contains instructions for
conguring the TDY:
• Installing the Software
• Saving the Default Conguration
(Keeping What You’ve Got Safe)
• Selecting Input Type, Wiring Conguration,
etc.
• Scaling the Input/Setting Reverse Output
• Setting the Display
• Scaling the Output
• Trimming the Input
• Trimming the Output
• Setting Miscellaneous Parameters,
including Readout Engineering Units in °F
or °C, Input Filtering, Upscale or Downscale
Drive on Sensor Failure, and Broken Input
Wire Detection
• Setting Output Damping, Using the Loop Test
• Creating Custom Linearization Tables
• Managing Conguration Files
What is First
First, it is necessary to install the TDY Conguration
Program on a PC. Once the program is loaded and
running, nearly all of the operating parameters for the
connected transmitter are shown on a single screen
(see Figure 3). This makes it easy to determine which
aspects of transmitter operation need to be changed
to suit the application requirements.
What is Next
Once the Conguration Program is installed on the
PC, the TDY can be connected to equipment to
simulate input and monitor output, and with the PC
program, the user can view and/or change its
operating parameters.
No Transmitter Needed
It is not necessary to connect the TDY to a PC to
create Conguration Files. The Conguration
Program can be run without connecting a transmitter,
and most operating parameters can be set without
benet of input from a sensor or from a transmitter.
This makes it easy to create a set of operating
parameters, save them to disk, and download them to
one or more transmitters at a later time.
Note, however, that not all parameters can be set
without a transmitter. In some cases, a source of
input is also required.
The TDY must be connected to the PC in order to:
• Trim Input
• Trim Output
• Assign a Tag
• Perform a Loop Test
• Receive (via download) a Conguration File
And, perhaps most importantly...
• SAVE THE CONFIGURATION FILE ALREADY IN
THE TRANSMITTER’S MEMORY (refer to
“Keeping What You’ve Got Safe—Using ‘Get
Setup’”)

TDY
10 Demand Moore Reliability
Installing the Conguration
Software
Refer to Table 5 for the equipment needed.
1. Insert the Moore Industries Interface Solution
PCCongurationSoftware CD into the CD
drive of the PC. Access the CD and open
the SDY SIY TDY TRX TRY 64 bit PC
Congurationsoftware folder.
2. Double-click the installation program located
in the folder. Follow the prompts to correctly
install the program.
Once the Conguration Program is installed on the
PC, the TDY can be connected to equipment to
simulate input and monitor output. You can then
change the transmitter’s operating parameter
Gathering the Equipment Needed
It is possible to create a Conguration File for a TDY
without ever connecting the transmitter to a PC.
Most TDY operating parameters can be setup, saved
in a Conguration File, and stored on disk entirely
within the Conguration Program—without ever
communicating with a transmitter.
It is not possible to trim the transmitter input or
output without a transmitter, a source of input,
and a meter (for output trimming). Likewise, it is
not possible to use the Loop Test function of the
transmitter unless everything is setup as shown in
Figure 2, and it is not possible to store a tag name in
the memory of a transmitter without connecting that
transmitter to the Conguration Program.
Table 3 lists the things needed to setup the TDY as
shown in Figure 2.
Device Specications
Note:
Be sure to use calibrated test equipment when
performing any trimming operations on the TDY.
Moore Industries uses equipment rated 5:1 over the
rated accuracy of the unit under test.
We recommend the use of equipment
rated at least 3:1.
Table 3. Equipment Needed for Setting Up the TDY
Thermocouple, RTD, Millivolt,
Potentiometer Simulator, or
Decade Resistance Box
Power Supply
Precision Load Resistor (Optional)
Multimeter
Thermocouple or RTD
Temperature vs. Resistance Tables
Personal Computer
Moore Industries’
TRX/TRY/ TDY/SIY/SDY
Conguration Software
Moore Industries’
Communication Cable
Accurate to ±0.05% of unit span
10-42Vdc, ±0.01%
250 ohms ±0.01%
Accurate to ±0.025%,
e.g. Fluke Model 87
ITS68 and ITS90, or equivalent
Microsoft Windows based PC;
16Mb free RAM; 20MB free
disk space on hard drive
Microsoft Windows XP, 7 or 10
and 1 (one) serial port
or one available USB port
Version 4.0 or greater, success-
fully installed on the hard disk of the
specicied PC
Non- isolating (PN 803-040-26)
Isolating (PN 803-039-26)
USB Cable (PN 208-236-00)
Fuse protected USB Cable
(PN 804-030-26)

TDY
Demand Moore Reliability 11
+PS -PS1 234
TDY
DEG C
327.64
–
+
–+
POWER
SOURCE
10-42Vdc
CURRENT
METER
0-50mA
–+
CALIBRATED
INPUT
SIMULATOR
2-WIRE RTD, W,
THERMOCOUPLE,
or MILLIVOLTS
TO SERIAL
(COM) PORT
OF PC
TDY COMM CABLE
803-040-26 FOR NON-ISOLATED
803-039-26 FOR ISOLATED
804-030-26 FOR USB
Thermocouple
& Millivolts
Inputs
–+
2-Wire RTD
& Direct Resistance
Inputs
3-Wire RTD
& Direct Resistance
Inputs
4-Wire RTD
& Direct Resistance
Inputs
Potentiometer
Inputs
+PS -PS1 234
+PS -PS1 234 +PS -PS1 234 +PS -PS1 234
+PS -PS1 234
TO USB
(COM) PORT
OF PC
or
Figure 2.UsethePCCongurationSoftwaretoprogramtheTDY

TDY
12 Demand Moore Reliability
1. TDY HP Status The left column of the screen
displays the input, output, and settings of the TDY.
This column will change to reect the values on the
rest of the screen when you program the TDY with its
new values.
2. Calibration Use these radio buttons to change
from “Measurement Mode”, the mode that you will be
doing all your work from the PC in, and “Calibration
Mode”, the mode that you will select when using a
handheld calibrator to simulate input to the unit.
3. “Help” Buttons The “Help” and “About” buttons
both provide information on the TDY Conguration
Software. The “CustTable” button allows you to set up
a custom linearization table for your TDY.
4. File Management Buttons This set of nine
buttons are essential to all the functions of the
Conguration Software, and will be used often. The
names and functions of the individual command
buttons may change when you press a button.
5. Output These scroll bars control the scaling and
damping values of the TDY. When certain options are
selected, these scroll bars are renamed to adjust the
reverse output and the loop test.
6. Input Range and Setup Options Use this section
to congure the TDY’s range of input and parameters
of its display options.
7. Input Type The top pull-down menu of this section
selects the type of input that the TDY will accept:
Millivolt, Ohms, RTD, Thermocouple, or Potentiometer.
The pull-down menus below it change to provide only
the options for the input type you have selected.
8. Communication The communication menu
displays the status of the TDY: if it is connected, and
to which COM port it’s connected to. The yellow light
in the upper right corner of this section will ash if the
TDY is connected.
Figure 3. PCCongurationSoftwareScreenSummary
3
1
2
8
7
6
5
4

TDY
Demand Moore Reliability 13
Keeping What You’ve Got Safe—
Using “Get Setup”
Every TDY is shipped from the factory with a
Conguration File already installed in its memory.
This le is comprised of either the factory default set
of operating parameters, or of the set of parameters
specied by the customer at the time of order.
CAUTION:
AnytimeaconnectedTDYis“programmed”
bydownloadingaCongurationFileintomemory,
ALLofthecongurationparameters
resident in the transmitter memory
at the time of the download are OVERWRITTEN
with whatever parameters are showing
ontheCongurationProgramScreen.Allprevious
parameters are then unrecoverable.
This includes things like, input type, tag name,
calibration date, input and/or output trim values, etc.
IMPORTANT:
To safeguard against the accidental loss of a
CongurationFile,alwaysusethe“GetSetup”button
andtheFileManagementfacilitiesunderthe“File”
button, located at the bottom-center of the
CongurationProgramMainScreen.
To save the Conguration File already resident in the
transmitter’s memory:
1. Start the PC Conguration Program, making
sure that the TDY is connected as shown in
Figure 2.
2. Click on the “Get Setup” button at the bottom-
center of the Conguration Program Main
Screen (see Figure 3).
The screen will icker once, and the settings
shown on the left area of the screen will match
those showing on the right.
3. Click on the “File” button. This brings up an
Explorer-like set of windows on the left area of
the screen.
4. Enter a name for the current Conguration File
(the one already in the transmitter’s memory),
and click on the “Save” button.
Note:
FilenamesmustfollowtheDOSconvention;Eight-
charactermaximum,alllowercase,nosux.
TheCongurationProgramadds
asuxtothelenameautomatically.
5. Answer “Yes” to save the named le to disk.
The left side of the screen will now show the
name of the le entered in Step 4. The
“starting point” of the TDY Conguration
Process is now saved on the PC disk. If you
decide to abort the conguration, this le can
always be downloaded back to the transmitter.
6. Click on “QuitFile” to return to the Main
Conguration Screen.

TDY
14 Demand Moore Reliability
Selecting Input Type, Wiring, etc.
Use the selection tools in the Input Type box to
choose the sensor type that the TDY will be reading.
Moore Industries suggests saving the initial settings
resident in the transmitter before making any changes
(refer to “Keeping What You’ve Got Safe”, page 9).
1. After saving, select the appropriate Input Type
values as shown in Figure 4. Continue to change
the remaining areas in Input Type (such as
ohms, linearization, custom table, or # wires,
depending on your sensor type).
Figure 4. Choosing the Input Type for the TDY .
IMPORTANT:
SettingsontheCongurationProgramScreendo
nottakeeectintheunituntiltheCongurationFile
is downloaded. Skip to Step 6 for instructions on
getting the settings programmed
into TDY nonvolatile memory.
2. Select one of these options:
a. Download the current settings into the
connected transmitter’s memory (Go to Step
3),
b. Continue creating a Conguration File by
setting other parameters, or
c. Save the current settings into a le on disk for
later downloading to a transmitter(s). Refer to
“Keeping What You’ve Got Safe”, starting with
Step 3 on page 9.
3. To start the Download Process, click on
the “Stop” button at the bottom-center of
the screen, then on the “Prog” button. This
transfers the settings from the software to the
memory of the connected transmitter.
CAUTION:
AnytimeaconnectedTDYis“programmed”
bydownloadingaCongurationFileintomemory,
ALLofthecongurationparametersresident
in the transmitter memory at the time of the
downloadareOVERWRITTEN.Theseprevious
parameters are unrecoverable. This includes things
like tag name, calibration date, trim values, etc.
The Status Bar in the upper-left corner of the
Conguration Program screen will display the
progress of the download of the Conguration
File to the connected transmitter.
When the download is complete, the
Conguration Program will emit a faint, yet
distinctly audible “beep” to indicate that the
download was successful.
4. Click on the “Start” button to re-enable the
Conguration Program’s monitoring of the
connected transmitter.
The status area of the Conguration Program
screen will display the “Measurement ON”
message, and will show the trimmed values
resident in memory.
Note:
TheTDYCustomInputLinearizationTablefacilityis
available only with the “Millivolts” input selection.
RTDinputselectionsdistinguishedbythe“E”suxed
alphavalueselectionsuse128-bitlinearizationcurves.
RTDselectionswithoutthe“E”suxusestandard,
32-bit curves. 128-bit curves are only available with a
TDY connected to the PC.

TDY
Demand Moore Reliability 15
Scaling the Input
(also: Setting Reverse Output)
This parameter allows the user to set the TDY to
scale its output in response to a portion of the total
range of the selected input type. In a reverse output
application, the TDY output drops in proportion to a
rise on the input, and rises in proportion to a drop on
the input.
The instructions assume that the Conguration
Program has been loaded successfully (page 6).
To set the scaling for the Input to the TDY:
1. Start the PC Conguration program and
connect a transmitter.
Note:
It is not necessary to connect a unit to the PC in
order to scale the input.
2. With the Conguration Program Main Screen
showing (Figure 3, page 8), select the “Input
Zero” box in the upper right corner of the
screen.
Figure 5.TheInputZero/Fullmenu.
3. Enter the value for the desired percentage
Input Zero value from the application where the
TDY is to be employed. Press Enter (return).
4. Access the “Input Full” box in the same fashion
to set the desired 100% input value.
IMPORTANT:
SettingsontheCongurationProgramScreen
donottakeeectintheunituntiltheConguration
Fileisdownloaded.SkiptoStep6forinstructions
on getting the settings programmed into TDY
nonvolatile memory.
5. Select one of these options:
a. Download the current settings into the
connected transmitter’s memory (Go to Step
6), or
b. Continue setting other parameters, or
c. Save the existing settings into a le on disk.
Refer to “Keeping What You’ve Got Safe”,
starting with Step 3 on page 9.
6. To start the Download Process, click on the
“Stop” button at the bottom-center of the
screen. This will enable the “Prog” button.
7. Click on the “Prog” button (Program), to
download the settings (specically, the input
type and conguration) from the PC software
into the memory of the connected transmitter.
CAUTION:
DownloadingaCongurationFileintomemory
OVERWRITESallpreviousparameters.
8. Click on the “Start” button to re-enable the
Conguration Program’s monitoring of the
connected transmitter.
Setting Reverse Output
a. Select the “Input Zero” box (Figure 5).
b. Enter a value GREATERTHANTHE
INTENDEDFULLSCALEINPUT.
c. Select the “Input Full” box.
d. Enter a value LESSTHANTHEZEROSCALE
INPUT entered in Step b.
The Conguration Program will display a
message in the output section of the screen to
indicate that a Reverse Output situation exists
(see Figure 6).
Figure 6.SettheReversedOutputusingthebarsinthebottom
rightoftheCongurationSoftwareMenu.

TDY
16 Demand Moore Reliability
Setting the Display
The TDY has numerous settings for its display, all
of which are controlled using the “Input Range and
Setup Options” box. You can set the customizable
display to display the input, output, or toggle between
the two every two seconds. The display will even
scale to display any type of engineering units you
desire.
Input, Output, and Toggle
The pull-down menu shown below is used to adjust
what the TDY displays. There are three settings:
“Input”, which causes the TDY to display the input
it is receiving, “Output”, which causes the TDY to
display the 4-20mA output it is emitting, and “Toggle”,
which causes the TDY to switch between displaying
Input to Output every two seconds. To switch
between these, simply click on the pull-down menu,
select the appropriate function, and program the
transmitter as described on page 9, starting with step
3.
Figure 7. The pull-down menu lets you select what the TDY displays.
Display Zero & Display Full
The display zero and display full show what values will
actually be displayed. If the pull-down menu in Figure
7 and the radio button on Figure 8 both have “Input”
selected, then Display Zero will match Input Zero
and Display Full will match Input Full. The Display
columns then cannot be changed except by changing
the display value.
Figure 8. Use the Display radio button to switch from standard
input display to a scaleble display of any engineering unit type.
Scaling the Display
The TDY can scale its display. This feature is useful
when you need to limit, expand, or manipulate the
numbers the TDY displays. Doing this also gives you
the option of changing the engineering units
being displayed to any engineering unit type.
Scaling the input display is a simple procedure. First,
click “Scale” on the radio button in Figure 8. (Note
that if you have the pull-down menu in
Figure 7 set to “Output”, the Display radio button will
not be available.) You can then enter values into
the “Display Zero”, “Display Full”, and “Display EGU”
boxes. When you have entered the appropriate
values, program the TDY with the new information by
using the steps on page 9, starting with Step 3.

TDY
Demand Moore Reliability 17
Scaling the Output
The TDY can be congured to scale its 4-20mA
output to o󰀨set the performance or calibration of other
instruments in the process loop.
The instructions assume that the Conguration
Program has been loaded successfully (page 6).
Moore Industries also suggests saving the initial
settings resident in the transmitter before making any
changes (refer to “Keeping What You’ve Got Safe”,
page 9).
To set the output scaling for the Input to the TDY:
1. Start the PC Conguration program and
connect a TDY as shown in Figure 2.
Note:
It is not necessary to connect a unit to the PC in
order to scale the output.
2. Enter the desired 0% output value (between
3.800mA and 17.400mA) in the “Zero Scale
Output” box at the lower right corner of the
screen (see Figure 5), or click and drag the
slide bar, adjacent to the box, to adjust the
value for 0% as desired.
3. Enter the desired 100% output value (between
7.800mA and 21.400mA) in the “Full Scale
Output” box, or click and drag the slide bar to
adjust the value.
Note:
Theminimumdierencebetween
0%outputand100%outputis4.000mA.
IMPORTANT:
SettingsontheCongurationProgramScreen
donottakeeectintheunituntiltheConguration
Fileisdownloaded.SkiptoStep5forinstructionson
getting the settings programmed
into TDY nonvolatile memory.
4. Choose from one of these options:
a. Download the current settings into the
connected transmitter’s memory (Go to Step
5),
b. Continue creating a Conguration File by
setting other parameters, or
c. Save the current settings to a le on disk for
later downloading to a transmitter. Refer to
“Keeping What You’ve Got Safe”, starting with
Step 3 on page 9.
5. To start the Download Process, click on the
“Stop” button at the bottom-center of the
screen. This will enable the “Prog” button.
6. Click on the “Prog” button (Program), to
download the settings (specically, the input
type and conguration) into the memory of the
connected transmitter.
CAUTION:
AnytimeaconnectedTDYis“programmed”
bydownloadingaCongurationFileintomemory,
ALLofthecongurationparametersresident
in the transmitter memory at the time of the
download are OVERWRITTEN.
This includes things like, tag name,
calibration date, trim values, etc.
7. Click on the “Start” button to re-enable the
Conguration Program’s monitoring of the
connected transmitter. The status area of the
Conguration Program screen will display the
“Measurement ON” message, and will show the
trimmed values resident in memory.

TDY
18 Demand Moore Reliability
Trimming the Input
Use this feature of the TDY to enhance the accuracy
of the transmitter by precisely matching its actual
reading of the input to its scaling of the either one
or two input points. Trim the output by following the
directions below:
1. Connect the transmitter to your PC using the
setup shown in Figure 2.
2. Click the radio button labeled “Input Trim On”.
3. Click “Start”, then “InpTrim”.
4. Select whether you will trim two points (upper
and lower) or just one point by clicking on the
appropriate radio button in the “Trim Pnts”
section.
5. In the “Trim Lower” and “Trim Upper” boxes,
type in the sensor’s value that you are
trimming.
6. Attach the sensor that you wish to trim to the
transmitter and place the sensor in a calibration
bath. Adjust the bath until its temperature
matches the “Trim Lower” value you have
chosen. Click “Trim Lower” and wait for it to
capture the value.
7. Attach the sensor that you wish to trim to the
transmitter and place the sensor in a calibration
bath. Adjust the bath until its temperature
matches the “Trim Upper” value you have
chosen. Click “Trim Upper” and wait for it to
capture the value.
8. Click on the button labelled “QuiInTrim”, then
the “Stop” button, and nally the “Prog” button
to send the trim values to the transmitter.
Trimming the Output
The TDY has a function that allows precise control
over its output. Note that to activate this function, a
unit must be connected in the setup to current meter,
as shown in Figure 2.
To trim TDY output:
1. Set all unit parameters on the TDY Conguration
Screen as required for your intended application.
When the Conguration File shown on the screen
has been modied for your application, click “Stop”
to stop measurement.
2. Click “OutTrim”.
3. Select and move the “Zero Scale Output” or the
“Full Scale Output” slide bar to adjust the TDY
output.
Monitor the output with a calibrated current meter
or with a voltmeter measuring the drop across a
precision, 250 Ohm resistor (see Figure 2).
4. When both zero and full scale have been adjusted
to satisfaction, press “QuitTrim”, then “Prog” to
program the SIY with the new trim values.
Note:
Changing the settings shown on the screen
in “Trim”modeDOESNOTCHANGETHE
UNIT’SOPERATINGPARAMETERS,itonly
updates the screen. The settings are saved
to non-volatile memory by using the “Prog”
function.
The “TDY Status” area of the Conguration Screen
will reect the new output settings.
Figure 9. Trim Capture Box

TDY
Demand Moore Reliability 19
Disabling Broken Wire Detection
One of the premier features of many of Moore
Industries’ temperature transmitters is our Total
Sensor Diagnostics® system. During operation, the
TDY sends random micro-amp pulses through input
wiring to check for broken wiring or a burned out
sensor.
Working with a Millivolt Input
When the transmitter is connected to a PC, the “TDY
Status” section of the Main Conguration screen
displays the message “Broken Wire” whenever
problems are detected on the input, and the
transmitter itself drives its output upscale or
downscale.
This can cause problems for some types of millivolt
calibrators and input sources. To permanently
disable this feature when the TDY is working in a
millivolt input conguration, set the “Broken Wire”
radio button in the center-right section of the
Conguration Screen to OFF.
Working with a Thermocouple or RTD Input
Total Sensor Diagnostics can also cause problems
with some types of temperature calibrators. It is not
possible to disable the feature by setting the “Broken
Wire” radio button to OFF, as with millivolt inputs.
Instead, when working with thermocouple or RTD
inputs, set the “Calibration” radio button in the lower-
left area of the Conguration Screen to “Calibration
Mode”. This temporarily disables Total Sensor
Diagnostics.
Note:
It is not possible to set a TDY transmitter into
CalibrationMode(SensorDiagnosticsOFF)
permanently. The “Calibration Mode” setting remains
ineectonlyuntilaCongurationFileisdownloaded
to the transmitter.
Working with a Conguration File
Also, when working with a Conguration File, it may
be necessary to turn o󰀨 Total Sensor Diagnostics
in order to complete the settings for one or another
aspect of transmitter operation. To do this, click on the
“Stop BW” (Stop Broken Wire Detection) button when
it is active on the bottom of the screen.
Setting Miscellaneous Functions—
Engineering Unit Readout, Input
Filtering, Upscale or Downscale
Drive, and Broken Wire Detection
There are several “radio buttons” on the TDY
Conguration Program Main Screen that control
ancillary transmitter functions. It is not necessary to
have a transmitter hooked up to the PC in order to set
these parameters and save them in a Conguration
File.
Setting Engineering Unit Readout
When a temperature sensor is designated as the input
to the transmitter, the radio buttons for “Degree” are
enabled.
Use this setting to have the Conguration Program
calculate the Centigrade or Fahrenheit temperature for
readout in the “Status” area of the screen whenever
the PC is being used to monitor the input from the
connected sensor and from the display if the
“Input” option in the “Display” section is selected.
Setting Input Filtering
Use this radio button setting to lter out noise on the
power to the transmitter.
Choosing Between
Upscale and Downscale Drive
The TDY transmitter can be congured to provide a
special warning, using its output, of a breakdown in
its connected sensor or sensor wiring. Use this radio
button setting to congure the transmitter to drive its
output either up to 24mA or down to 3.3mA when a
sensor or sensor wiring failure is detected.
Note:
Thereisadierencebetweentheavailable
FullScaleoutputsettingandtheUpscaleDrive,
andbetweentheavailablezeroscaleoutputsetting
and the Downscale Drive:
TheTDYtransmitterwillonlyoutput24mAor3.3mA
(ascongured)intheeventofasensororsensor
wiringfailure(upscale/downscaledrive).
If sensor input drops below the rated range, output
dropstoaminimumof3.8mA.Ifsensorinputrises
abovetheratedrange,outputrisesto21.4mA.
This allows the user to distinguish between an input
failure and an input over or under-range condition.

TDY
20 Demand Moore Reliability
Setting Output Damping
The Output Damping function of the TDY allows the
user to introduce a delay into the response of the
transmitter in order to minimize the e󰀨ect of any
input oscillations on the output. The higher the
damping value (set in seconds), the longer the TDY
will take to respond to trends on the input.
Note:
It is not necessary to connect an input device to the
PCinordertoselectandconguretheDamping
Value.
To set the damping value, either adjust the position of
the slider bar in the lower-right area of the
Conguration Program Main Screen, or enter a value
directly into the space provided.
The default damping value is 0 seconds. The
maximum allowable damping value is 5.056 seconds.
Using the Loop Test
The TDY Loop Test feature allows the user to employ
the transmitter’s output to “trim” other instruments in
the loop.
To use the Loop Test feature, the connected TDY must
stop measuring input.
1. Click on the “Stop” button.
2. Click on the “Loop Test” button.
This enables a slide bar in the lower-right area
of the Conguration Screen.
3. Use the slide bar to adjust the output of
the connected TDY to a percentage of the
congured scale. Monitor the e󰀨ect of this
on other instruments in the loop, and adjust
accordingly.
4. Click on “Quit Loop” to stop using the Loop Test
feature.
Figure 10.TheOutputLoopTestscrollbars.
