Motorola Nextel iDEN i1000plus User manual

MotorolaTM
iDEN®
Digital Multi-Service Data-Capable Phone
i1000plusUser’sGuide
2/4/00

i
Contents
CONTENTS
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Features of Your i1000plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Charging and Attaching the Battery . . . . . . . . . . . . . . . . . . . . . . .10
Turning On Your i1000plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Display Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
About Modes and Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Changing the Display Language . . . . . . . . . . . . . . . . . . . . . . . . .15
Selectable Backlight Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Making Phone Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using Other Dialing Methods . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Emergency Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Last Number Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Turbo Dial® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Plus Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Hands-Free Speakerphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Receiving a Phone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Ending a Phone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Missed Call Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
What Is My Phone Number? . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
VibraCall™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Selecting VibraCall for All Incoming Calls and Messages .22
Selecting VibraCall for Individual Services . . . . . . . . . . . . .22
Setting the Ringer Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Selecting a Ring Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Unconditional Call Forwarding . . . . . . . . . . . . . . . . . . . . . .24
Conditional Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . .25
Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Call Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3-Way Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Alternate Phone Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Setting the Active Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Receiving a Call on Your Alternate Line . . . . . . . . . . . . . . .27
Phone Only Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Creating, Editing, and Using Stored Lists . . . . . . . . . . . . . . . . . .29

ii
i1000plus User’s Guide
Combined Phone Number and Private ID List . . . . . . . . . . .29
Pause Dialing Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Last 10 Calls Received and Sent Lists . . . . . . . . . . . . . . . . .32
Quickstore of Phone Numbers . . . . . . . . . . . . . . . . . . . . . . .33
Making Private Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Receiving a Private Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Private/Group Mode Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Call Alert™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Sending a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Receiving a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Call Alert Queuing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Quickstore of Private IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Storing Your Private ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Making Group Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Receiving a Group Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Adding or Storing a Talkgroup . . . . . . . . . . . . . . . . . . . . . . . . . .41
Area Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Private/Group Mode Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Using Mail Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Net Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Delay Voice Mail Alerts during Phone Call . . . . . . . . . . . . .44
Message Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Saving and Erasing Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Auto Call Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Mail Memory Full . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Using Your Phone as a Modem . . . . . . . . . . . . . . . . . . 47
Setting Programming Menus . . . . . . . . . . . . . . . . . . . . 48
About Status Messages . . . . . . . . . . . . . . . . . . . . . . . . . 55
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Charging the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Battery Operating Instructions . . . . . . . . . . . . . . . . . . . . . . .57
Travel Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Using the Travel Charger . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Travel Charger Operating Specifications . . . . . . . . . . . . . . .58

iii
Contents
Vehicular Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Using the Vehicular Battery Charger . . . . . . . . . . . . . . . . . .59
Removing the Vehicular Battery Charger . . . . . . . . . . . . . . .59
Vehicular Battery Charger Operating Specifications . . . . . .59
Desktop Dual-Pocket Charger . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Audio Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Using the Audio Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Attaching/Detaching the Earpiece Microphone . . . . . . . . . .61
Removing the Audio Adapter . . . . . . . . . . . . . . . . . . . . . . .61
Exposure To Radio Frequency Energy . . . . . . . . . . . . . . . . . . . .62
Safety and General Information . . . . . . . . . . . . . . . . . . 62
Interference to Medical and Personal Electronic Devices . . . . . .63
Pacemakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Hearing Aids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Other Medical Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Interference to Other Electronic Devices . . . . . . . . . . . . . . .64
Safety and General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Use While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
OPERATIONAL
WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Potentially Explosive Atmospheres . . . . . . . . . . . . . . . . . . .65
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Blasting Caps and Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
For Vehicles Equipped with an Air Bag . . . . . . . . . . . . . . . .65
OPERATIONAL CAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Damaged Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Antenna Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Accessory Safety Information . . . . . . . . . . . . . . . . . . . . 67
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . 69
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Motorola Communication Products . . . . . . . . . . . . . . . . . . . . . . .69
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Motorola Communication Products . . . . . . . . . . . . . . . . . . . . . . .73

iv
i1000plus User’s Guide
Owner’s Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Private Number Directory . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Talkgroup Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

v
i1000plus User’s Guide
Patent and Trademark Information
This product is protected under one or more of the following patents:
4817157, 4896361, 4857928, 5041793, 5060294, 5066923, 5134718, 5140156,
5239963, 5257411, 5287387, 5265219, 5289504, 5316168, 5317247, 5338396,
5389927, 5406588, 5424921, 5457376, 5460906, 5551063, 5557079, 5596487,
5615412, 5638403, 5559468, 5469465, 5170413, 5140615, 5519730, 5241544,
5584059, 5574992, 5396656, 5487091, 5533004, 5299199, 5343499, 5369501,
5509031, 5515379, 5528723, 5598417, 5066923, 5241650, 5278833, 5359696,
5548631, 5410632, 5440582, 5457735, 5457818, 5471670, 5477550, 5481537,
5566181, 5229767, 5208804, 5295140, 5381449, 5440590, 5467398, 5490230,
5620242, 5623523, 5655913, 5715240, 5771440, 5854578, 5675281
Additional patents are pending.
, Motorola, iDEN, Turbo Dial, VibraCall, Call Alert, and Message Mail are
trademarks or registered trademarks of Motorola, Inc.
®Reg. U.S. Pat. & Tm. Off.
T9 is a trademark of Tegic Communications, Inc.
All other trademarks mentioned in this manual are trademarks of their respective
companies.
© Copyright 2000, Motorola, Inc. All rights reserved.
Important!
Be sure to read “Safety and General Information”on page 83
before using your i1000plus.

7
Welcome
WELCOME
ongratulations on purchasing your Motorola iDEN i1000plus
data-capable, multi-service, digital portable phone. Superior
features and state-of-the-art technology help to keep you in
constant touch with all your business and personal contacts.
Your i1000plus has so many new and exciting features! With wireless
access to the Internet, you can check on the latest news and weather, get
stock quotes, send and receive e-mail, and download information from
your computer.
A missed-call indicator lets you know that you received calls while you
were away.
And, new ease-of-dialing features, such as Turbo Dial®and the Last 10
Calls Received and Sent lists, help you to quickly make and return
phone calls.
The i1000plus offers:
•Phone Mode—for cellular phone operation.
See page 16.
•Private Mode—for two-way radio use to talk with one person.
See page 35.
•Group Mode—for two-way radio use to talk with several people. See
page 40.
•Net Mode—for accessing the built-in microbrowser.
See the Net Mode User’s Guide.
•Mail Services—for message, voice, and net mail.
See page 43.
•Fax and Data Transfer—for circuit data faxes and file transfers. See
page 48.
•TTY Access—for assisting hearing-impaired users
See the Wireless Data Services User’s Guide for information about data
calls and TTY access.
This manual provides information about how Net Mode works with
various features of your i1000plus. For information on using the
microbrowser and other components of Net Mode, see the Net Mode
User’s Guide.
This manual describes the features of the
i1000plus as they were set up at the factory.
However, your carrier or your organization may
have changed or added features. For more
information, check with your carrier or your
organization.

8
i1000plus User’s Guide
Features of Your i1000plus
Notes:
• Remove the three plastic film lens protectors from
the display and cover before you use your
i1000plus for the first time.
• Some keys have multiple uses. For more
information, see the Net Mode User’s Guide.
•Press any key or button to turn on the keypad
backlight.
1. Antenna
7. Option Keys
2. On/Off Button
3. Status Light LED
4. Speaker Button
8. Cover
(Closed)
6. Push-to-Talk
(PTT) Button
5. Volume/List
Control
Buttons
18. Alphanumeric
Keypad
13. Speakerphone
10. Mode Key
9. Menu Key
8. Cover
(Open)
14. Earpiece
15. Alphanumeric
Display
7. Option Key
7. Option Key
17. Scroll Key
*19. Home Key
16. Send/End Key
20. Microphone
*11. Punctuation
Key
*12. Back Key
*21. Next Word Key
22. Accessory and
Data Cable
Connector
* These features are available in the Net Mode Browser

9
Welcome
1. Antenna Extend for optimal signal.
2. On/Off Button Press and hold to turn your i1000plus on or off.
3. LED (Light
Emitting Diode) Check the phone’s status. See Table 1 on page 11 for more information.
4. Speaker/Home/
Back Button Press to hear incoming calls through the earpiece or the speaker during Private and Group calls. In
Net mode, press to go back; press and hold to go
to the Home menu.
5. Volume Control/
List Buttons Press to adjust volume levels in Phone, Private, and Group modes. Scroll through the phone list
with the cover closed. In mail menus and in Net
mode, press to scroll forward and backward.
6. Push-To-Talk
(PTT) Button Transmit a Private or Group Call, or a Call Alert. Press and hold to talk; release to listen.
7. Option Keys Press the left or right option key to select the
menu option that appears directly above the key.
8. Cover Close to end a phone call.
9. Menu Key Press to scroll through menu options.
10. Mode Key Press to change modes (Phone, Private, Group,
Net).
11. Punctuation
Key Add punctuation in the Net Mode browser (within T9™Text Input).
12. Back Key Return to the previous browser screen.
13. Speaker Listen to Private and Group calls. Listen to Phone
calls in speakerphone mode.
14. Earpiece Listen to calls when the speakerphone is off.
15. Alphanumeric
Display View up to four lines (up to 12 characters per line) or in Net and Mail screens, six lines (up to
16 characters per line) on the display.
16. Send/End Key Press to answer an incoming Phone call. After
entering a phone number, press to dial the call or
to redial the entered phone number. Press to end
Phone calls.
17. Scroll Key Press the left side to scroll backward or the right
side to scroll forward through menu options and
lists. When entering text, press to erase text or
add a space.
18. Alphanumeric
Keypad Enter telephone numbers, Private call IDs, and alphanumeric characters.
19. Home Key Press to return to the browser Home menu.
20. Microphone Use to speak during calls.
21. Next Word Key Press to display the next word choice in the
browser (within T9 Text Input).
22. Accessory
Connector Use to connect accessories, including the battery charger.

10
i1000plus User’s Guide
Charging and Attaching the Battery
Remove the battery from the protective case provided in the original
packaging. When the battery is not attached to the phone or being
charged, store it in this case.
Charging the Battery
To get the maximum use from the battery, charge it for at least three
hours before you use it for the first time.
Attach the charger connector to the i1000plus, then flip open the prongs
and plug the charger into an electrical outlet. For more information
about chargers, see “Accessories”on page 57.
Attaching the Battery
To attach the battery to your i1000plus,
align the battery as shown. Press down
on the battery until you hear a click.
Battery and Charging Status
A low battery is indicated by a short,
chirp-like sound through the speaker.
The battery strength icon shows the
remaining charge in the battery. Three
bars indicate full charge. When you
have less than five minutes of talk time
remaining, the indicator flashes.
Figure 1. Battery Charging Status
Detaching the Battery
To detach the battery, press the latch to release the battery and slide the
battery downward.
Turning On Your i1000plus
Press the On/Off button until a set of icons appears on your
display. Next, a welcome message displays while the i1000plus
connects to your carrier’s network.
Icon
Flashes
Charging Low Battery 0-30% 31-60% 61-90% 91-100%
Discharging Low Battery 0-10% 11-40% 41-70% 71-100%
Latch
