Motorola RZ100 User manual

MOTOROLA SMART
CONTROLLER

1
Check it out
here’s what you can do
No need to get off the couch. Use the touchpad and
buttons on your Motorola Smart Controller remote to
control your phone or tablet, or flip it over for handsfree
calls.
Go ahead, check it out:
At a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connect & go. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Want more?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Caution: Please read the important safety, regulatory
and legal information at the back of this guide.

2At a glance
At a glance
the important bits, quick and easy
Note: Your battery is designed to last the life of your product. It
should only be removed by a recycling facility. Any attempt to
remove or replace your battery will damage your remote.
Menu
Home
Back
Search
Call Button
Microphone
Speaker
Remote
Calls (Phone Only)
Android Buttons
Touchpad
(works like a
laptop computer
touchpad)
Power Switch
Charge
(MicroUSB)
On Off
Status Light
Volume & Mute
+
-
Phone
Tablet
Connections
Mouse
Buttons
Green full charge
Yellow mediumcharge
Red low charge
Charge Level (when
connected to power)

3Connect & go
Connect & go
let’s get you connected
Tip: For daily use, just make sure your remote is on, and
your device’s Bluetooth feature is on. Your remote and
device connect automatically.
Turn Bluetooth on.
T
1
On
2
Status Light - Blue
Turn remote on.
On
3
Enter “0000”
if prompted
Enter passcode.
Complete.
C
4
Status Light - Purple flash
(5 times)
Status Light - Purple pulse
(30 seconds)
Status Light

4Basics
Basics
standard features, advanced quality
Touchpad
Scroll list
on screen.
Zoomout.
Rotate image
clockwise.
Custom
(based on application).
Mouse* Multi-touch gestures*
Tap
Press right mouse
button.
Display and
move pointer.
Touch & slide
Select item
under pointer.
Click & hold
Move (drag) item
under pointer.
-- Screen itemunderneath pointer.
-- No screen itemunderneath
pointer.
Rotate image
counterclockwise.
Zoomin.
Tap or Click
Click & move
Display menu options,
or add a shortcut or
widget to screen.
* Multi-touch gestures are supported by
selected Motorola devices only. Scan
the QR code below to find out if yours
does.
Gestures may also behave differently
in some applications, such as
Google Maps™.
* Cursor speed can be adjusted.
See TROUBLESHOOTING on page 7 for
details.

5Basics
Android Buttons
Calls
Note: Some features are phone/network dependent.
To…
answer a call Press the Call button .
reject a call Press and hold a Volume button until
you hear a tone.
redial last call Press and hold the Call
button until you hear a tone.
mute or
unmute
Press the Mute button .
end a call Press the Call button .
Display item’s menu
Return to home
Go back a step
Press = Google search
Press & hold = Voice search
Note: For voice search, there
are third-party apps you can
download and use fromthe
Android Market™. Google
Voice Search will not work
with your device (it does not
support Bluetooth).

6Advanced
Advanced
more clever stuff
Status light
An easy way to check your remote.
Note: After 30 seconds of inactivity, the light stops
flashing to save battery power, but the remote stays on.
If status light is… remote is…
steady blue pairing mode
rapid blue/purple
flashes
connecting to your device
slow blue flash connected (remote or call audio
connected but not in use)
slow purple flash connected (remote and call
audio connected but not in use)
slow red flash idle (not connected to a device)
quick red flash in a low battery state

7Want more?
Want more?
we’re here to help
Troubleshooting
A few frequently asked questions—with answers of
course. Find more at www.motorola.com/support.
My remote won’t go into pairingmode. Make sure
that any previously paired devices are turned off. Also,
the status light should show steady blue (pairing
mode)—if not, turn off the remote, then turn back on
while holding the Volume Up (+) and buttons
until the light turns blue.
My device doesn't find my remote when searching.
Make sure the status light shows steady blue when your
device is searching for devices. If not, turn off the
remote, then turn back on while holding the Volume Up
(+) and buttons until the light turns blue.
My remote worked before, but now it's not working.
Make sure your device is on and its Bluetooth feature is
on. You may need to pair your device and remote again
(see “Connect & go” on page 3).
The touchpad cursor is slow on the screen. You can
adjust the speed as follows:
•For Android 3.2 tablet devices, touch Settings
>Language&Input > Mouse and Trackpad Settings
>Pointer Speed.

8Want more?
•For Motorola phones, select Settings
>Wireless&Networks > Bluetooth Settings then
press and hold the Motorola RZ100 device. Adjust the
speed in the popup window.
For other devices, check mouse system settings for
adjustments.
• If your device is not working, plug into the charger
as it may need recharging (device works while
plugged into charger).

9Want more?
Connect with Motorola
Get what you need:
• Answers: User guides, online help and more at
www.motorola.com/support.
• Bluetooth: If you have questions or need assistance,
contact us at 1-877-MOTOBLU, or visit
www.motorola.com/bluetoothsupport or
www.motorola.com/bluetoothconnect.
• Accessories: Find more accessories at
www.motorola.com/products.
• Social: The latest news, tips & tricks, videos and so
much more—join us on:
YouTube™ www.youtube.com/motorola
Facebook™ www.facebook.com/motorola
Twitter www.twitter.com/motomobile

10
Safety, Regulatory & Legal
Battery Use & Safety
DON’Ts
• Don’t let the product come in contact with liquids.* Liquids can get into the
product’s circuits, leading to corrosion.
• Don’t place your product near a heat source.* High temperatures can cause the
battery to swell, leak, or malfunction.
• Don’t dry a wet or damp product with an appliance or heat source , such as a hair
dryer or microwave oven.
DOs
• Do avoid leaving your product in your car in high temperatures.*
• Do avoid dropping the product.*
Dropping your product, especially on a hard surface,
can potentially cause damage.*
• Do contact your retailer or Motorola if your product has been damaged by
dropping, liquids or high temperatures.
Warning:
Never dispose of battery powered products in a fire because they may explode.
Battery Charging
Battery Charging
Notes for charging your product’s battery:
•
During charging, keep your battery and charger near room temperature for efficient
battery charging.
• New batteries are not fully charged.
• New batteries or batteries stored for a long time may take more time to charge.
• Motorola batteries and charging systems have circuitry that protects the battery from
damage from overcharging.
Third Party Accessories
Use of third party accessories, including but not limited to batteries, chargers, headsets,
covers, cases, screen protectors and memory cards, may impact your product’s performance.
In some circumstances, third party accessories can be dangerous and may void your product
warranty. For a list of Motorola accessories, visit
www.motorola.com/products

11
Children
Keep your product and its accessories away from small children. These products are
not toys and may be hazardous to small children. For example:
• A choking hazard may exist for small, detachable parts.
• Improper use could result in loud sounds, possibly causing hearing injury.
• Improperly handled batteries could overheat and cause a burn.
Caution About High Volume Usage
Warning: Exposure to loud noise from any source for extended periods of
time may affect your hearing. The louder the volume sound level, the less
time is required before your hearing could be affected. To protect your
hearing:
• Limit the amount of time you use headsets or headphones at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in your
ears, ringing in your ears, or muffled speech, you should stop listening to the device through
your headset or headphones and have your hearing checked.
For more information about hearing, see our website at
direct.motorola.com/hellomoto/nss/AcousticSafety.asp (in English only).
Symbol Key
Your battery, charger, or accessory product may contain symbols, defined as follows:
Symbol Definition
Important safety information follows.
Do not dispose of your product or battery in a fire.
032374o
032376o

12
European Union Directives Conformance
Statement
EU Conformance
The following CE compliance information is applicable to Motorola products that carry one of
the following CE marks:
Hereby, Motorola declares that this product is in compliance with:
• The essential requirements and other relevant provisions of Directive 1999/5/EC
• All other relevant EU Directives
Your product or battery may require recycling in accordance with
local laws. Contact your local regulatory authorities for more
information.
Do not dispose of your product or battery with your household waste.
See “Recycling” for more information.
Do not use tools.
For indoor use only.
Symbol Definition
032375o

13
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to
R&TTE Directive) at
www.motorola.com/rtte (in English only). To find your DoC, enter
the Product Approval Number from your product’s label in the “Search” bar on the website.
FCC Notice to Users
FCCNotice
The following statement applies to all products that bear the FCC logo on the
product label.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b). These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
See 47 CFR Sec. 15.19(a)(3).
Motorola has not approved any changes or modifications to this device by the user. Any
changes or modifications could void the user’s authority to operate the equipment. See 47
CFR Sec. 15.21.
Product
Approval
Number

14
For products that support Wi-Fi 802.11a (as defined in the product specifications available at
www.motorola.com ), the following information applies. This equipment has the
capability to operate Wi-Fi in the 5 GHz Unlicensed National Information Infrastructure
(U-NII) band. Because this band is shared with MSS (Mobile Satellite Service), the FCC has
restricted such devices to indoor use only (see 47 CFR 15.407(e)). Since wireless hot spots
operating in this band have the same restriction, outdoor services are not offered.
Nevertheless, please do not operate this device in Wi-Fi mode when outdoors.
Industry Canada Notice to Users
IndustryCanada Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) This device may not cause interference and (2)
This device must accept any interference, including interference that may cause undesired
operation of the device. See RSS-GEN 7.1.5. This Class B digital apparatus complies with
Canadian ICES-003.
Use & Care
Use & Care
To care for your Motorola product, please keep it away from:
liquids of any kind
Don’t expose your product to water, rain, extreme humidity, sweat, or other
moisture. If it does get wet, don’t try to accelerate drying with the use of an
oven or dryer, as this may damage the product.
extreme heat or cold
Avoid temperatures below -10°C (14°F) or above 60°C (140°F). For battery
powered accessories, do not recharge your accessory in temperatures below
0°C (32°F) or above 45°C (113°F).
microwaves
Don’t try to dry your product in a microwave oven.
dust and dirt
Don’t expose your product to dust, dirt, sand, food, or other inappropriate
materials.

15
cleaning solutions
To clean your product, use only a dry soft cloth. Don’t use alcohol or other
cleaning solutions.
shock and vibration
Don’t drop your product.
Recycling
Recycli ng
Products & Accessories
Please do not dispose of products or electrical accessories (such as chargers,
headsets, or batteries) with your household waste, or in a fire. These items
should be disposed of in accordance with the national collection and recycling
schemes operated by your local or regional authority. Alternatively, you may
return unwanted products and electrical accessories to any Motorola Approved Service
Center in your region. Details of Motorola approved national recycling schemes, and further
information on Motorola recycling activities can be found at:
www.motorola.com/recycling
Packaging & Product Guides
Product packaging and product guides should only be disposed of in accordance with national
collection and recycling requirements. Please contact your regional authorities for more
details.
Software Copyright Notice
Motorola products may include copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United States and other countries
preserve for Motorola and third-party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted
software. Accordingly, any copyrighted software contained in Motorola products may not be
modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed
by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either
directly or by implication, estoppel, or otherwise, any license under the copyrights, patents,
or patent applications of Motorola or any third-party software provider, except for the normal,

16
non-exclusive, royalty-free license to use that arises by operation of law in the sale of a
product.
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United States of America and
Canada. The Governments of the United States of America and Canada may restrict the
exportation or re-exportation of this product to certain destinations. For further information
contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and
International Trade.
Product Registration
Registration
Online Product Registration:
www.motorola.com/us/productregistration (in English only)
Product registration is an important step toward enjoying your new Motorola product.
Registering permits us to contact you for product or software updates and allows you to
subscribe to updates on new products or special promotions. Registration is not required for
warranty coverage.
Please retain your original dated sales receipt for your records. For warranty service of your
Motorola Personal Communications Product you will need to provide a copy of your dated
sales receipt to confirm warranty status.
Thank you for choosing a Motorola product.
Motorola Limited Warranty for the United
States and Canada
Warranty
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola Mobility, Inc. warrants its mobile
telephones (“Products”), Motorola-branded or certified accessories sold for use with these
Products (“Accessories”), and Motorola software contained on CD-ROMs or other tangible
media and sold for use with these Products (“Software”) to be free from defects in materials
and workmanship under normal consumer usage for the period(s) outlined below. This limited
warranty is a consumer's exclusive remedy, and applies as follows to new Motorola
Products, Accessories, and Software purchased by consumers in the United States or
Canada, which are accompanied by this written warranty:

17
Products and Accessories
Exclusions (Products and Accessories)
Normal Wear and Tear. Periodic maintenance, repair and replacement of parts due to
normal wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of their rated
capacity and batteries that leak are covered by this limited warranty.
Abuse & Misuse. Defects or damage that result from: (a) improper operation, storage,
misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the
surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the
Products or Accessories for commercial purposes or subjecting the Product or Accessory to
abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are
excluded from coverage.
Use of Non-Motorola Products and Accessories. Defects or damage that result from
the use of non-Motorola branded or certified Products, Accessories, Software or other
peripheral equipment are excluded from coverage.
Products Covered Length of Coverage
Products and Accessories
as
defined above, unless otherwise
provided for below.
One (1) year from the date of purchase by the
first consumer purchaser of the product unless
otherwise provided for below.
Decorative Accessories and
Cases. Decorative covers, bezels,
PhoneWrap™ covers and cases.
Limited lifetime warranty for the lifetime of
ownership by the first consumer purchaser of
the product.
Monaural Headsets. Ear buds
and boom headsets that transmit
mono sound through a wired
connection.
Limited lifetime warranty for the lifetime of
ownership by the first consumer purchaser of
the product.
Products and Accessories that
are Repaired or Replaced. The balance of the original warranty or for ninety (90) days
from the date returned to
the consumer, whichever is longer.

18
Unauthorized Service or Modification. Defects or damages resulting from service,
testing, adjustment, installation, maintenance, alteration, or modification in any way by
someone other than Motorola, or its authorized service centers, are excluded from coverage.
Altered Products. Products or Accessories with (a) serial numbers or date tags that have
been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c)
mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts,
are excluded from coverage.
Communication Services. Defects, damages, or the failure of Products, Accessories or
Software due to any communication service or signal you may subscribe to or use with the
Products Accessories or Software is excluded from coverage.
Software
Exclusions (Software)
Software Embodied in Physical Media. No warranty is made that the software will meet
your requirements or will work in combination with any hardware or software applications
provided by third parties, that the operation of the software products will be uninterrupted or
error free, or that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media. Software that is not embodied in physical
media (e.g. software that is downloaded from the Internet), is provided “as is” and without
warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the purchase price of any
Products, Accessories or Software that does not conform to this warranty. We may use
functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories
or parts. No data, software or applications added to your Product, Accessory or Software,
including but not limited to personal contacts, games and ringer tones, will be reinstalled. To
Products Covered Length of Coverage
Software.
Applies only to physical defects in the
media that embodies the copy of the software (e.g.
CD-ROM, or floppy disk).
Ninety (90) days from the
date of purchase.
