Moxa Technologies CCG-1500 Series User manual

P/N: 1802015102011
*1802015102011*
CCG-1500 Series
Quick Installation Guide
Version 1.1, August 2023
Technical Support Contact Information
www.moxa.com/support

2023 Moxa Inc. All rights reserved.

- 2 -
Overview
The CCG-1500 Series is a private 5G gateway that acts as a media and
protocol converter. These gateways support 5G-to-Ethernet and 5G-to-
Serial connections, suitable for both public and private networks. The
CCG-1500 Series can also be used as a protocol converter for Modbus
TCP/RTU communications, as well as a wireless platform for 5G
communications.
Equipped with a Cortex-A7 processor optimized for media conversion,
the CCG-1500 Series can be deployed in a wide variety of industrial
applications. The robust wide-temperature design further makes the
CCG-1500 Series suitable for use in harsh operating environments.
Package Checklist
Your CCG-1500 device is shipped with the following items. If any of
these items are missing or damaged, please contact your customer
service representative for assistance.
•1 CCG-1500 Series gateway
•DIN-rail mounting kit (pre-installed)
•Power jack for power adapter
•2-pin terminal block for power input
•6 antennas (CCG-1510-TW-T, CCG-1510-US-T models)
•4 antennas (CCG-1520-T models)
•Quick installation guide (printed)
•Warranty card
Panel Layouts
CCG-1510 Models
Front View
Rear View

- 3 -
Top View
Bottom View
CCG-1520 Models
Front View Rear View
Top View

- 4 -
Bottom View
Device Dimensions
Mounting the CCG-1500 Series
The CCG-1500 Series can be mounted onto a DIN rail or a wall. The
DIN-rail mounting kit is attached to the device by default. The wall-
mounting kit can be purchased separately.
DIN-rail Mounting
Installation
STEP 1: Using a screwdriver, pull down the slider of the DIN-rail
bracket on the back of the unit.
STEP 2: Insert the top of the DIN rail into the slot just below the upper
hook of the DIN-rail bracket.
STEP 3: Press the device towards the DIN rail until it snaps into place.

- 5 -
Removal
STEP 1: Pull down the latch on the mounting kit with a screwdriver.
STEP 2: Slightly pull the device forward.
STEP 3: Lift the device up to remove it from the DIN rail.
Wall Mounting (Optional)
NOTE
Mounting the CCG-1500 Series onto a wall requires an optional
wall-mounting kit, which is sold separately.
For some applications, it may be more convenient to mount the CCG-
1500 gateway to a wall.
Installation
STEP 1
: Attach the wall mounting kit plates to the side panel of the
CCG
-1500 Series device using four M3 x 6 mm screws.
STEP 2: Use the CCG-1500 Series device with the wall mount plates
attached as a guide to mark the correct location of the four screws. The
heads of the screws should be less than 6.0 mm in diameter, the shafts
should be less than 3.5 mm in diameter, and th
e length should be at
least 10 mm in diameter.
STEP 3: Once the screws are fixed into the wall, insert the four screw
heads through the large opening of the keyhole
-shaped apertures of
the mounting kit. Tighten the four screws for added stability.

- 6 -
Connecting the Power Input
Power Terminal Block
A skilled person for the job should install the wiring for the input
terminal block. The wiring type should be copper (Cu) and only 14-22
AWG wire size and torque value 0.2 N-m should be used.
Power Jack
Connect the power jack (included in the package) to the CCG-1500
Series’ terminal block located on the top panel, then connect the power
adapter. It takes several seconds for the system to boot up. Once the
system is ready, the P/S LED will light up.
NOTE
The product is intended to be supplied by a UL Listed Power
Unit marked "L.P.S." (or "Limited Power Source") and is rated
9
-24 VDC @ 1.33-0.5 A min., Tma = 70°C (min). If you need
assistance
purchasing a power source, please contact Moxa for
more information.
Grounding the CCG-1500 Series
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI) by routing the noise from the metal
chassis to the connected ground.
Connect the grounding wire to the
grounding screw located on
the top panel of the device
. When connected to ground, the
noise is routed directly through the metal chassis.

- 7 -
NOTE
The grounding wire should have a minimum diameter of
3.31 mm
2
.
NOTE
If using a Class I adapter, the power cord must be connected to
an outlet with an earthing connection.
Interface Description
10/100/1000BaseT(X) Ethernet Port
The 10/100/1000BaseT(X) ports located on the front panel of the CCG-
1500 Series device are used to connect to Ethernet-enabled devices.
The pin assignment of the port is as below:
10/100 Mbps
1000 Mbps
Pin
Signal
1
Tx+
2
Tx-
3
Rx+
4
–
5
–
6
Rx-
7
–
8
–
Pin
Definition
1
DA+
2
DA-
3
DB+
4
DB-
5
DD+
6
DD-
7
DC-
8
DC+
Serial Port
The serial port uses terminal block connectors. The serial mode (RS-
232, RS-422, or RS-485) can be configured through software. The pin
assignment of the port is as below:
Pin
Definition
1
RS-232TXD/RS-422T+
2
RS-232RXD/RS-422T-
3
RS-232RTS/RS-422R+/RS-485D+
4
RS-232CTS/RS-422R-/RS-485D-
5
GND
SIM Card Sockets
The CCG-1500 Series comes with two nano-SIM card sockets for
cellular communication. The nano-SIM card sockets are located on the
front panel and are protected by a cover. The left socket is for SIM 1
and the right socket is for SIM 2.

- 8 -
Remove the protective cover to
access the sockets, then insert
the nano-SIM cards into the
sockets directly. You will hear a
click when the cards are in
place.
To remove the cards, push the
cards in then release to unseat
the cards.
Wireless Connectors
Cellular Interface
The CCG-1510 Series is equipped with a built-in cellular module. To use
the cellular function, the antennas must be connected to the SMA
connectors. The CCG-1510 models have six antenna connectors while
CCG-1520 models have four antenna connectors.
GPS
The built-in GPS module of the CCG-1500 Series allows the device to
use GPS satellite geolocation. To use the GPS function, the antennas
must be connected to the SMA connectors.
LED Indicators
The LED indicators are located on the front panel of the CCG-1500. The
function of each LED is described in the table below:
LED Color Behavior Status
Signal
Strength
(Strong)
Green On Indicates a strong 4G/5G signal.
Signal
Strength
(Medium)
Green On Indicates a medium 4G/5G
signal.
Signal
Strength
(Weak)
Green On Indicates a weak 4G/5G signal.
P/S
(Power/System
Status)
Red On The system is booting up or is
not ready yet.
Green On The system is powered on and
ready.
Off Off The system is powered off.
SIM1/2 Amber On A SIM card is enabled in slot 1.

- 9 -
Green On A SIM card is enabled in slot 2.
Off Off No SIM card is inserted.
4G/5G
Amber On A cellular connection is
established to a 4G network.
Green On A cellular connection is
established to a 5G network.
Off Off No cellular network signal.
LAN1, LAN2
Green On
The port is active, and a link is
established at 1000 Mbps.
Green Blinking Data is being transmitted at
1000 Mbps.
Amber On
The port is active, and a link is
established at 10/100 Mbps.
Amber Blinking
Data is being transmitted at
10/100 Mbps.
Off Off The port is inactive, or the link is
down.
Accessing the Web Console
You can log into the web console of the CCG-1500 Series gateway by
connecting a host computer to LAN1 or LAN2 on the device and
navigating to the device’s default IP address in a web browser. Please
ensure the host computer and CCG-1500 gateway are in the same
subnet.
The default web interface address is https://192.168.225.1:443
When prompted, log in using the default credentials:
•Username: admin
•Password: moxa
Certifications
WARNING
1.
為避免電磁干擾，本產品不應安裝或使用於住宅環境。
2.
減少電磁波影響，請妥適使用。
3.
電波功率密度 MPE 標準值： 1 mW/cm²，送測產品實測值：
0.11422 mW/cm²，建議使用時設備天線至少距離人體 20 公
分。
4.
此電信終端設備支援行動寬頻頻段資訊：
LTE 介面支援頻段
: LTE FDD 700/900/1800/2100/2500MHz;
TDD 2600 MHz
5GNR 介面支援頻段: 5GNR FDD 700/1800/2100 MHz; TDD
2500/3500 MHz
