Temposonics
®
Magnetostrictive, Absolute, Non-contact
Linear-Position Sensors
R-Series Models RP and RH
DeviceNet Output
Data Sheet
SENS
O
RS
®
Document Part Number
550651 Revision F
Time-based Magnetostrictive position sensing principle
Movable position magnet
Magnetic field from
position magnet
Interaction of magnetic
fields causes waveguide to
generate a strain pulse
Magnetic field encompasses
entire waveguide - generated
by the interrogation pulse
Bias magnet
Strain-Pulse detector
Interrogation
Return wire
Waveguide
Benefits of Magnetostriction
Temposonics linear-position sensors use the time-based
magnetostrictive position sensing principle developed by MTS.
Within the sensing element, a sonic-strain pulse is induced in a
specially designed magnetostrictive waveguide by the momentary
interaction of two magnetic fields. One field comes from a moveable
permanent magnet that passes along the outside of the sensor. The
other field comes from an “interrogation” current pulse applied along
the waveguide. The resulting strain pulse travels at sonic speed along
the waveguide and is detected at the head of the sensing element.
The position of the magnet is determined with high precision and
speed by accurately measuring the elapsed time between the applica-
tion of the interrogation pulse and the arrival of the resulting strain
pulse with a high-speed counter. The elapsed time measurement is
directly proportional to the position of the permanent magnet and is
an absolute value. Therefore, the sensor's output signal corresponds
to absolute position, instead of incremental, and never requires
recalibration or re-homing after a power loss. Absolute, non-contact
sensing eliminates wear, and guarantees the best durability and
output repeatability.
FEATURES
Linear, Absolute Measurement
LEDs For Sensor Diagnostics
Superior Accuracy, Resolution down to 2 µm
Non-Contact Sensing Technology
Linearity Deviation Less Than 0.01%
Repeatability Within 0.001%
Direct DeviceNet Output
BENEFITS
Rugged Industrial Sensor
Cost-effective Communications Network linking Industrial
Measurement and Control Devices
Interface Up to 64 Devices using one cable
APPLICATIONS
Continuous Operation In Harsh Industrial Conditions
High Pressure Conditions
TYPICAL INDUSTRIES
Factory Automation
Fluid Power
Plastic Injection and Blow Molding
Material Handling and Packaging

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - DeviceNet Output
Product Data Sheet, Document Part No.: 550651 Revision F (EN) 05/2014 2
Product specifications
Product overview
Parameters Specifications
OUTPUT
Measured output
variable: Position
Resolution: 2 µm or 5 µm
Update times: 0.5 ms up to 1200 mm,
1.0 ms up to 2400 mm,
2.0 ms up to 4800 mm,
4.0 ms up to 7600 mm stroke length
Linearity
deviation: < ± 0.01% full stroke (minimum ± 40 µm)
Repeatability: < ± 0.001% full stroke
(minimum ± 2.5 µm)
Hysteresis: < 4 µm
Output: Interface:
CAN-Fieldbus system ISO DIS 11898
Data protocol DeviceNet release 2.0
Baud rate, kBit/s: 500 250 125
Cable length, m: <100 <250 <500
Sensors will be supplied with ordered Baud rate
which can be changed by the customer.
Stroke length: Range (Profile style):
25 mm to 5080 mm (1 in. to 200 in.)
Range (Rod style):
25 mm to 7620 mm (1 in. to 300 in.)
ELECTRONICS
Operating voltage: +24 Vdc nominal: -15% or +20%*
Polarity protection: up to -30 Vdc
Overvoltage protection: up to 36 Vdc
Current drain: 90 mA typical
Dielectric withstand voltage: 500 Vdc
(DC ground to machine ground)
Product Overview and Specifications
Parameters Specifications
ENVIRONMENTAL
Operating
conditions: Operating temperature:
-40 °C (-40 °F) to +75 °C (+167 °F)
Relative humidity: 90% no condensation
Temperature coefficient: 15 ppm/ °C
EMC test: Electromagnetic emission:
IEC/EN 50081-1
Electromagnetic susceptibility:
IEC/EN 50082-2, IEC/EN 61000-4-2/3/4/6,
level 3/4 criterium A, CE qualified
Shock rating: 100 g (single hit)/IEC standard 68-2-27
(survivability)
Vibration rating: 15 g / 10 to 2000 Hz / IEC standard 68-2-6
WIRING
Connection type: 5-pin male D51 DeviceNet connector
PROFILE STYLE SENSOR (MODEL RP)
Electronic head: Aluminum housing with diagnostic LED
display (LEDs located beside connector/
cable exit)
Sealing: IP 65**
Sensor extrusion: Aluminum (Temposonics profile style)
Mounting: Any orientation. Adjustable mounting
feet or T-slot nut (M5 threads) in bottom
groove
Magnet types: Captive-sliding magnet or open-ring
magnet
ROD STYLE SENSOR (MODEL RH)
Electronic head: Aluminum housing with diagnostic LED
display (LEDs located beside connector/
cable exit)
Sealing: IP 67 or IP 68 for integral cable models**
Sensor rod: 304L stainless steel
Operating
pressure:
350 bar static, 690 bar peak
(5000 psi static, 10,000 psi peak)
Mounting: Any orientation. Threaded flange M18 x 1.5
or 3/4 - 16 UNF-3A
Typical
mounting torque: 45 N-m (33 ft. - lbs.)
Magnet types: Ring magnet, open-ring magnet, or
magnet float
R-Series model RH and RP sensors are extremely robust and are
ideal for continuous operation under harsh industrial conditions.
MTS offers two standard sensor housings, rod and profile extrusion.
The rod housing is capable of withstanding high pressures such as
those found in hydraulic cylinders.
The profile extrusion housing provides convenient mounting options
and captive sliding magnets which utilize slide bearings of special
material that reduce friction, and help mitigate dirt build up. The
sensor head contains the active signal conditioning and a complete
integrated electronics interface. Double shielding is used to ensure
EMI protection for unsurpassed reliability and operating safety.
Controller Area Network (CAN) is a standard for device level com-
munications and the foundation of fieldbus systems like DeviceNet,
CANopen and CANbus.These fieldbus systems can provide high
speed transmission appropriate for position indication and for mo-
tion control in industrial applications.
DeviceNet allows users to interface up to 64 devices using a single
cable, thus eliminating the need for conventional methods of multiple
wire runs. DeviceNet provides a way to define how, and in which
priority, data will be transmitted over the network. The result is a
lower complexity, cost-effective communications network linking
industrial measurement and control devices. Together, the open
DeviceNet protocol and the MTS “smart” R-Series sensors offer an
effective, high-precision data transfer system that is well suited for
industrial automation.
* UL Recognition requires an approved power supply with energy limitation UL 61010-
1), or Class 2 rating according to the National Electrical Code (USA) / Canadian
Electrical Code.
** The IP rating is not part of the UL Recognition.

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - DeviceNet Output
Product Data Sheet, Document Part No.: 550651 Revision F (EN) 05/2014
3
DeviceNet Protocol, Programmability, Enhanced Monitoring,
Diagnostics and Model RP sensor dimension references
Enhanced monitoring and diagnostics
SENSOR STATUS AND DIAGNOSTIC DISPLAY
Integrated diagnostic LEDs (green/red), located beside sen-
sor connector (see ‘Figure 1’), provide basic visual monitoring
for normal sensor operation and DeviceNet communications.
Diagnostic display LEDs indicate two modes, Network and Module
status as described in ‘Table 1’.
Figure 1. R-Series sensor Integrated diagnostic LEDs
DeviceNet protocol
Network Status LED Operation status/mode
Green Normal function (operation mode)
Green Flashing Waiting for instructions from
DeviceNet master
Red Initialization error
Red Flashing No answer from DeviceNet master
Module Status LED Operation status/mode
Green Normal function (operation mode)
Red Magnet not detected
Table 1. Diagnostic display indicator modes
R-Series models RP and RH linear-position sensors as slave devices
fulfill all requirements of the CANbus (ISO 11898) standard. The sen-
sors electronics and integrated software implement the DeviceNet
protocol to convert the displacement measurements into bus
oriented outputs and transfer this data directly to the controller.The
DeviceNet protocol is appropriate for serial data transfer up to 500
kBit/sec.
When using the DeviceNet protocol with R-series sensors, function-
ality always includes but is not limited to the following:
• Position
• Error Detection
• Polling & bit-strobe communications modes
PLUG AND PLAY
R-Series sensors with DeviceNet output can be directly connected
to a DeviceNet network. The plug and play design makes installation
quick and easy. The sensor acts as a “slave” device that transmits
its position and status data upon request to the “master” device
such as a PLC or IPC. After initial system configuration, the user is
not required to have extensive knowledge concerning network tim-
ing and sensor technology to execute operations within DeviceNet
environment. Sensor-specific parameters are installed into the
network using the Electronic Data Sheet (EDS). To obtain the EDS,
go to www.mtssensors.com.
There are only two programmable parameters, which are, the node
identifier and the baud rate. If desired, a PC programming tool,
such as DeviceNet Manager offered by Allen Bradley, can be used
to change their values. The node identifier is factory set at node 63.
The selected baud rate is shown in the sensor's model number.
Note that the sensor will only be recognized on a network running
at the same baud rate.
Model RP profile-style sensor dimension references
MODEL RP, PROFILE-STYLE SENSOR WITH CAPTIVE-SLIDING MAGNET
Drawing is for reference only, contact applications engineering for tolerance specific information.
Beginning of stroke - ‘Null’ position
14.5 mm
(0.57 in.)
18 mm
(0.7 in.)
81 mm
(3.2 in.)
12 mm (0.47 in.)
49 mm
(1.9 in.)
45 mm (1.77 in.)
2 mm (0.07 in.)
9 mm
(0.36 in.)
5.5 mm (0.21 in.)
for M5 or #10 screw
68 mm (2.68 in.)
50 mm (1.97 in.)
82 mm
(3.2 in.)
Dead zone
Sensor head
63 mm
(2.5 in.)
Metal connector
Stroke length End of stroke
‘Span’ position
Mounting foot, moveable
(part no.: 400802)
Captive-sliding magnet
D51
integral connector option
Figure 2. R-Series Model RP Profile-style sensor dimension reference (Shown with the D51 integral connector option)

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - DeviceNet Output
Product Data Sheet, Document Part No.: 550651 Revision F (EN) 05/2014 4
MODEL RP, PROFILE-STYLE SENSOR WITH OPEN-RING MAGNET
Drawing is for reference only, contact applications engineering for tolerance specific information.
Mounting support
(non-ferrous material)
Open-ring magnet
Beginning of stroke ‘Null’ Position
Stroke length
66 mm
(2.6 in.)
Mounting foot, moveable
(part no.: 400802)
28 mm
(1.1 in.)
28 mm
(1.1 in.)
Dead zone
Electronics
housing
End of stroke
‘Span’ Position
63 mm
(2.5 in.)
Figure 3. R-Series Model RP Profile-style sensor dimension reference (Shown with the D51 integral connector option)
Standard magnet selections (Model RP)
SELECTION OF POSITION MAGNETS (ONE MAGNET INCLUDED WITH MODEL RP SENSOR)
A choice of two magnet mounting configurations are available with the profile-style sensor; A ‘captive-sliding’ magnet, Styles Sor Vor
an ‘open-ring’ magnet, Style M. Captive-sliding magnets utilize slide bearings of special material that reduce friction, and if required, help
mitigate dirt build up. The slide bearings are designed to operate dry, requiring no external lubrication or maintenance.
The Style M ‘open-ring’ magnet mounts on the moving machine part and travels just above the sensor’s profile extrusion. The open-ring
magnet requires a minimum distance away from ferrous metals to allow proper sensor output. It must be mounted using non-ferrous
screws and a non-ferrous support bracket, or utilize a non-ferrous spacer of at least 5 mm (0.2 in.) thickness.
POSITION MAGNET SELECTIONS (ONE MAGNET INCLUDED WITH EACH MODEL RP SENSOR)
(Drawing dimensions are for reference only)
Magnet dimensions and mounted magnet dimensions Description Part number
Captive-sliding magnet, Style S
For Model RP profile-style sensor 252182
40 mm
(1.58 in.)
25 mm
(1 in.)
9 mm
(0.35 in.)
57 mm
(2.24 in.)
14 mm
(0.55 in.)
Rotation:
Vertical: 18°
Ball-jointed arm
(M5 thread)
Captive-sliding magnet, Style V
For Model RP profile-style sensor 252184
21 mm
(0.81 in.)
25 mm
(0.97 in.)
14 mm
(0.55 in.)
2 Holes
Each 4.3 mm
(0.17 in.) dia. on
24 mm (0.94 in.) dia.
60°
Open-ring magnet, Style M
I.D.: 13.5 mm (.53 in.)
O.D.: 33 mm (1.29 in.)
Thickness: 8 mm (0.31 in.)
Operating temperature:
- 40 °C to 100 °C
This magnet may influence the
sensor performance specifica-
tions for some applications.
251416-2
40 mm
(1.58 in.)
25 mm
(1 in.)
20 mm
(0.79 in.)
43 mm
(1.69 in.)
14 mm
(0.55 in.)
Rotation:
Vertical: 18°
Horizontal: 360°
Ball-jointed arm
(M5 thread)
45 mm
(1.77 in.)
52 mm
(2.05 in.)
36 mm
(1.41 in.)
21 mm
(0.81 in.)
29 mm
(1.14 in.)
Max gap
3 mm ± 1 mm
(0.12 in. ± 0.04 in.)
Non-ferrous mounting support
and screws
Open-ring magnet Style ‘M’
Model RP Profile-Style Sensor Dimensions
and Standard Magnet Selections

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - DeviceNet Output
Product Data Sheet, Document Part No.: 550651 Revision F (EN) 05/20145
Model RP Profile-Style Sensor
Mounting and Installation Reference
Sensor mounting
Model RP profile-style sensor mounting flexible installation in any position!
Temposonics Model RP profile-style sensors offer two basic mounting methods; side grooves for use with mounting feet or a bottom groove
that accepts special T-Slot nuts. Both the mounting feet and T-Slot nuts can be positioned along the sensor extrusion to best secure the
sensor for each particular application.
Notes:
1. Model RP sensors include two mounting feet, (part no. 400802) for sensors stroke lengths up to 1250 mm (50 in.)
2. One additional mounting foot is included for stroke lengths over 1250 mm (50 in.) and for each additional 500 mm (20 in.),
thereafter.
3. MTS recommends using 10-32 cap screws (customer supplied) at a maximum torque of 44 in. lbs. when fastening mounting feet.
Profile-Style sensor mounting and installation reference Mounting method Part number
(Width = 14.5 mm (0.57 in.)
Mounting feet, standard (304 SS)
Profile-style sensor mounting for
sensor model RP
400802
(10 - 32 Cap screws)
Recommended
(Customer supplied)
Mounting feet and screws
Profile-style sensor foot installation
See Mounting
Feet
part number:
400802
T-Slot nut
Nut for mounting model RP sensor.
(M5 threaded) using bottom groove
401602
4 Holes
5.3 mm
(0.21 in.) dia.
28 mm
(1.1 in.) 9 mm
(0.36 in.)
50 mm
(1.97 in.)
2 mm
(0.08 in.)
68 mm
(2.68 in.)
9 mm
(0.36 in.)
Mounting foot and screws
5 mm (0.20 in.)
T-Slot nut, M5 thread
Detail
M5 Threaded
stud and nut

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - DeviceNet Output
Product Data Sheet, Document Part No.: 550651 Revision F (EN) 05/2014 6
Model RH rod-style sensor dimension reference
The Temposonics R-Series rod-style sensor (Model RH) offers modular construction, flexible mounting configurations, and easy installation.
The Model RH sensor is designed for mounting in applications where high pressure conditions exist, (5000 psi continuous, 10,000 psi spike),
such as inside hydraulic cylinders. The Model RH sensor (see Figure 4) may also be mounted externally in many applications.
Stroke-dependent Dead Zones:
Stroke length:
25 mm (1 in.) - 5000 mm (197 in.)
5005 mm (197 in.) - 7620 mm (300 in.)
Dead zone:
63.5 mm (2.5 in.)
66 mm (2.6 in.)
MODEL RH, ROD-STYLE SENSOR WITH RING MAGNET (MAGNET ORDERED SEPARATELY)
Drawing is for reference only, contact applications engineering for tolerance specific information.
Figure 4. Model RH Rod-style sensor dimension reference (shown with D51 integral connector options
Stroke length
63.5 mm (2.5 in.)
66 mm (2.6 in.)‡
Sensor Rod
10 mm (0.394 in.) dia.
Beginning of stroke ’Null’ position
Dead zone
51 mm
(2 in.)
Electronics
housing
49 mm
(1.9 in.)
44 mm (1.7 in.)
Metal connector
63 mm
(2.5 in.)
18 mm
(0.7 in.)
86 mm
(3.4 in.)
25 mm
(0.98 in.)
(A) Flange Threads
Refer to ‘Table 2’
End of stroke
‘Span’ position
O-Ring
‡For stroke lengths > 5000 mm (197 in.)
Flat-faced flange, Type ‘S’
Refer to ‘Table 2’
Ring Magnet
part no.: 201542-2
)
MODEL RH, ROD-STYLE SENSOR WITH RING MAGNET (MAGNET ORDERED SEPARATELY)
Drawing is for reference only, contact applications engineering for tolerance specific information.
Figure 5.
25.4 mm
(1 in.)
O-Ring
Beginning of stroke ‘Null’ position
Null
51 mm (2 in.)
Electronics
housing
2.5 mm (0.10 in.)
Raised-faced flange, Type ‘T’
Refer to ‘Table 2’
25 mm
(0.98 in.)
Ring Magnet
part no.: 201542-2
Refer to ‘Table 2’
‘(A) Flange Threads’
B
C
Refer to ‘Table 2’
‘(B) dimensions’ and ‘(C) dimensions’
Model RH Rod-style sensor dimension reference (shown with D51 integral connector option)
Housing style
Flange type Description (A) Flange threads (B) Dimensions (C) Dimensions
TUS customary threads with raised-face flange 3/4" - 16 UNF-3A 1.75 in. 2 in.
SUS customary threads with flat-faced flange 3/4" - 16 UNF-3A 1.75 in. 2 in.
MMetric threads with flat-faced flange M18 x 1.5 46 mm 53 mm
Table 2. Model RH Rod-style sensor housing style and flange type references
Model RH Rod-Style Sensor
Dimension References

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - DeviceNet Output
Product Data Sheet, Document Part No.: 550651 Revision F (EN) 05/20147
Model RH Rod-Style Sensor
Standard Magnets and Float Selection
Standard magnet selections (Model RH)
Magnets must be ordered separately with Model RH position sensors. The standard ring magnet (part number 201542-2) is suitable for most
applications.
POSITION MAGNET SELECTIONS (Magnet must be ordered separately)
(Drawing dimensions are for reference only)
Magnet and magnet dimensions Description Part number
Standard ring magnet
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
201542-2
Ring magnet
I.D.: 13.5 mm (0.53 in.)
O.D.: 25.4 mm (1 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
400533
Open-ring magnet, Style M
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
This magnet may influence the sensor
performance specifications for some
applications.
251416-2
Magnet spacer
(Non-ferrous, use with ring magnet
Order number: 201542-2)
I.D.: 14 mm (0.56 in.)
O.D.: 32 mm (1.25 in.)
Thickness: 3.2 mm (0.125 in.)
400633
MAGNET FLOAT SELECTION (Drawing dimensions are for reference only)
Magnet float
(Level sensing applications)
Specific gravity: 0.70 maximum
Pressure: 870 psi maximum
(This float is used with the Model RH
Rod-style sensors for hydraulic fluid or
fresh water applications only)
251447
4 Holes
Each 4.3 mm (0.17 in.) dia.
90° apart on
24 mm (0.94 in.) dia.
21 mm
(0.81 in.)
25 mm
(0.97 in.)
14 mm
(0.55 in.)
2 Holes
Each 4.3 mm
(0.17 in.) dia. on
24 mm (0.94 in.) dia.
60°
4 Holes
Each 4.3 mm (0.17 in.) dia.
90° apart on
24 mm (0.94 in.) dia.
14 mm (0.55 in.) Min. I.D.
51 mm (2 in.)
Spherical O.D.
3.4 mm (0.13 in.)
C
L
53 mm
(2.1 in.)

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - DeviceNet Output
Product Data Sheet, Document Part No.: 550651 Revision F (EN) 05/2014 8
Model RH Rod-Style Sensor Mounting, Cylinder Installation,
Wiring and Cable Connector Options
Model RH Rod-Style sensor mounting
The position magnet requires minimum distances away from ferrous
metals to allow proper sensor output. The minimum distance from
the front of the magnet to the cylinder end cap is 15 mm (0.6 in.).
The minimum distance from the back of the magnet to the piston
head is 3.2 mm (0.125 in.). However, a minimum distance of at
least 5 mm (0.197 in.) is preferred for added performance margin.
The non-ferrous spacer (part no. 400633), provides this minimum
distance when used along with the standard ring magnet (part no.:
201542-2) as shown in Figure 6.
Figure 6.
Non ferrous
spacer
> 15 mm
(0.6 in.)
Min. 3.2 mm
(0.125 in.)
Ring magnet
n fer
cer
m
m
mm
.)
(0.125 in.
)
magnet
Ring m
Non
spa
Min. 3.2 mm
magnet
Ring m
Cylinder end cap
Piston head
Temposonics®
R-Series
R
®
Model RH rod-style mounting
Connections and wiring
Cylinder installation
When used for direct-stroke measurement in fluid cylinders, the
sensor's high pressure, stainless steel rod installs into a bore in
the piston head/rod assembly as shown in Figure 7. This method
guarantees a long-life and trouble-free operation.
The sensor cartridge can be removed from the flange and rod hous-
ing while still installed in the cylinder. This procedure allows quick
and easy sensor cartridge replacement, without the loss of hydraulic
pressure.
The sensor’s rod housing and flange can remain
permanently installed in the cylinder
Ring magnet
The sensor cartridge, consisting of the electronics housing
and sensing element, is easy to replace by removing
(2) M4 thread 2.5 mm hex socket head screws
Figure 7. Fluid cylinder installation
CABLE CONNECTOR (FIELD INSTALLED FEMALE MICRO DEVICENET)
21
34
5Male, 5-pin (DeviceNet micro connector )pin-out as viewed from the end of the sensor
Pin number Function / DeviceNet outputs
1 Shield
2 +24 Vdc (+20% / -15%)
3 DC ground (for supply)
4 CAN (+)
5 CAN (-)
CABLE CONNECTOR OPTIONS (FIELD INSTALLABLE) 5-PIN DIN (D51) MALE (Drawing dimensions are for reference only)
Appropriate grounding of cable shield is required at the controller end. Molded extenssion cables are available from third-party vendors.
Connector and connector dimensions Description Part number
Female Cable Connector, Straight
Exit (D51) (Field installable)
5-Pin micro DeviceNet connector
mates with male (D51) connection
type
370375
Female Cable Connector, 90°exit,
(D51) (Field installable)
5-Pin micro DeviceNet connector mates
with male (D51) connection type
370376
55 mm
(2.2 in.)
20 mm
(0.8 in.) dia.
41 mm
(1.6 in.)
37 mm
(1.5 in)

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - DeviceNet Output
Product Data Sheet, Document Part No.: 550651 Revision F (EN) 05/20149
Models RP and RH Sensors
Ordering Information
SENSOR MODEL =
R
1-2
RP =
Profile style
RH
= Hydraulic rod style
HOUSING STYLE = 3
Model RP profile-style sensor (includes one magnet):
S=
Captive-sliding magnet with ball joint
at top (Part no. 252182)
V
=
Captive-sliding magnet with ball
joint at front (Part no. 252184)
M
=
Open-ring magnet
(Part no. 251416-2)
Model RH rod-style sensor (magnet(s) must be ordered separately):
T=
US customary threads, raised-faced
flange and pressure tube, standard
U
=
Same as option 'T', except uses
fluoroelastomer seals for the
electronics housing
B
=
Sensor cartridge only (no flange
and pressure tube, stroke length
< 1830 mm (72 in.))
S=
US customary threads, flat-faced
flange and pressure tube, standard
H
=
Same as option 'S', except uses
fluoroelastomer seals for the
electronics housing
M=
Metric threads, flat-faced flange and
pressure tube, standard
V
=
Same as option 'M', except uses
fluoroelastomer seals for the
electronics housing
STROKE LENGTH
=
4-8
— — — — M
=
Millimeters
(Encode in 5 mm increments)
Stroke Length Notes:
— — — . — U
=
Inches and tenths
(Encode in 0.1 in. increments) 1. Profile-style sensor (model RP) stroke range = 25 mm (1 in.) - 5080 mm. (200 in.)
2. Rod-style sensor (model RH) stroke range = 25 mm (1 in.) - 7620 mm (300 in.)
CONNECTION TYPE =D 5 1
Integral connector:
D51
=
5-pin Micro DeviceNet, male, standard
INPUT VOLTAGE =112
1=
+24 Vdc (+20% - 15%)
R D 5 1 1 C 2 0 2 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
OUTPUT (13 - 19) =C13-19
C — — — — — —
[1] [2] [3] [4] [5] [6] = CANbus output - Enter the 6 digit output code (1-6) defined by the following selections
[1] [2] [3] Protocol
[4] Baud rate
{5] Resolution
{6] Type
202
=
DeviceNet 2
=
500 kBit/s 1
=
5 µm (0.0002 in.) 1= Standard
3
=
250 kBit/s 2
=
2 µm (0.00008 in.)
4
=
125 kBit/s

Document Part number:
550651 Revision F (EN) 05/2014
MTS, Temposonics and Level Plus are registered trademarks of MTS Systems Corporation. All
other trademarks are the property of their respective owners. Printed in USA. Copyright © 2014
MTS Systems Corporation. All Rights Reserved in all media.
All specifications are subject to change. Contact MTS for specifications and engineering
drawings that are critical to your application. Drawings contained in this document are for
reference only. Go to http://www.mtssensors.com for the latest product information.
LOCATIONS
LEGAL NOTICES
USA
MTS Systems Corporation
Sensors Division
3001 Sheldon Drive
Cary, N.C. 27513, USA
Tel. [phone]
Fax [phone]
[email protected]
www.mtssensors.com
GERMANY
MTS Sensor Technologie
GmbH & Co. KG
Auf dem Schüffel 9
58513 Lüdenscheid, Germany
Tel. + 49 2351 9587-0
Fax + 49 2351 56491
[email protected]
www.mtssensor.de
JAPAN
MTS Sensors Technology Corp.
737 Aihara-machi,
Machida-shi,
Tokyo 194-0211, Japan
Tel. [phone]
Fax + 81 42 775-5512
[email protected]
www.mtssensor.co.jp
FRANCE
MTS Systems SAS
Zone EUROPARC Bâtiment EXA 16
16/18, rue Eugène Dupuis
94046 Creteil, France
Tel. [phone]
Fax + 33 1 58 4390-03
[email protected]
www.mtssensor.com
ITALY
MTS Systems Srl.Sensor Division
Via Diaz,4
25050 Provaglio d‘Iseo (BS), Italy
Tel. [phone]
Fax + 39 030 982 3359
[email protected]
www.mtssensor.com
CHINA
MTS Sensors
Room 504, Huajing Commercial Center,
No. 188, North Qinzhou Road
200233 Shanghai, China
Tel. [phone]
Fax [phone]
[email protected]
www.mtssensors.cn
