TempoLink Smart Assistant
Operation Manual

TempoLink Smart Assistant
Operation Manual
I2 I
Table of contents
1. Introduction ........................................................................................................................................................................3
1.1 Purpose and use of this manual....................................................................................................................................3
1.2 Used symbols and warnings .........................................................................................................................................3
2. Safety instructions .............................................................................................................................................................3
2.1 Intended use .................................................................................................................................................................3
2.2 Foreseeable misuse.......................................................................................................................................................3
2.3 Installation, commissioning and operation....................................................................................................................4
2.4 Safety instructions for use in explosion-hazardous areas .............................................................................................4
2.5 Warranty .......................................................................................................................................................................4
2.6 Return ...........................................................................................................................................................................4
2.7 Removal from service/dismantling................................................................................................................................4
3. Identification ......................................................................................................................................................................5
4. Package content.................................................................................................................................................................5
5. Connection of TempoLink smart assistant to R-Series Vsensor .....................................................................................6
6. Connection of TempoLink smart assistant to power supply..............................................................................................6
6.1 Using the plug-in power supply with plug adapters .....................................................................................................6
6.2 Using the cable for insertion in an existing sensor power supply with sensor mating connector and barrel connector
(only R-Series VEtherNet/IP™, EtherCAT®, POWERLINK and PROFINET) .........................................................................6
7. Connection of TempoLink smart assistant to smartphone, tablet or computer................................................................7
7.1 Connecting a Wi-Fi enabled device to the integrated Wi-Fi access point 3.....................................................................7
7.2 Connecting a computer via USB connection .................................................................................................................7
8. Establishing a connection via browser..............................................................................................................................7
9. Graphical user interface ....................................................................................................................................................8
9.1 Menu item TempoLink ..................................................................................................................................................8
9.2 Menu item status ..........................................................................................................................................................9
9.3 Menu Item Sensor Info .................................................................................................................................................9
9.4 Menu Item Parameters................................................................................................................................................10
9.5 Menu item interface ....................................................................................................................................................10
10. LEDs of TempoLink smart assistant ................................................................................................11

TempoLink Smart Assistant
Operation Manual
I3 I
1. Introduction
1.1 Purpose and use of this manual
Before starting the operation of TempoLink smart assistant,
read this documentation thoroughly and follow the safety
information. Keep this manual for future reference!
The content of this technical documentation is intended
to provide information on mounting, installation and
commissioning by qualified automation personnel 1 or
instructed service technicians who are familiar with the
project planning and dealing with Temposonics®products.
1.2 Used symbols and warnings
Warnings are intended for your personal safety and for
avoidance of damage to the described product or connected
devices. In this documentation, safety information and
warnings to avoid danger that might affect the life and health
of operating or service personnel or cause material damage
are highlighted by the pictogram, defined below.
Symbol Meaning
This symbol is used to point to situations
that may lead to material damage, but not
to personal injury.
1/ The term “qualified technical personnel” characterizes
persons who
• are familiar with the safety concepts of automation
technology applicable to the particular project
• are competent in the field of electromagnetic compatibility
(EMC) or
• have received adequate training for commissioning and
service operations
• and are familiar with the operation of the device and know the
information required for correct operation provided in the
product documentation
NOTICE
2.1 Intended use
This product may be used only for the applications defined
under item 1 and item 2 and only in conjunction with the
third-party devices and components recommended or
approved by MTS Sensors. As a prerequisite of proper
and safe operation, the product requires correct transport,
storage, mounting and commissioning and must be operated
with utmost care.
2. Safety instructions
Foreseeable misuse Consequence
Wrong sensor connection The sensor and TempoLink smart
assistant will not work
properly or can be damaged
Power supply is out of the
defined range
The TempoLink smart assistant
can be damaged
Cables are damaged Short circuit – the sensor and
TempoLink smart assistant can
be destroyed / sensor does not
respond
Wrong connection
of ground / shield
Signal output is disturbed
The electronics can be damaged
Do not alter the TempoLink smart assistant.
The TempoLink smart assistant might be damaged.
Do not step on the TempoLink smart assistant.
The TempoLink smart assistant might be damaged.
1. The sensor systems of all Temposonics®series are
intended exclusively for measurement tasks encountered
in industrial, commercial and laboratory applications. The
sensors are considered as system accessories and must
be connected to suitable evaluation electronics, e.g. a
PLC, IPC, indicator or other electronic control unit.
2. TempoLink smart assistant is an accessory for
Temposonics®R-Series Vsensors for reading out and
adjusting of sensor parameters as well as monitoring
status values.
2.2 Foreseeable misuse

TempoLink Smart Assistant
Operation Manual
I4 I
2.3 Installation, commissioning and operation
The position sensors and TempoLink smart assistant must
be used only in technically safe conditions. To maintain
this condition and to ensure safe operation, installation,
connection and service, work may be performed only by
qualified technical personnel.
If danger of injury to persons or of damage to operating
equipment is caused by sensor failure or malfunction,
additional safety measures such as plausibility checks, limit
switches, EMERGENCY STOP systems, protective devices
etc. are required. In the event of trouble, shut down the
sensor and protect it against accidental operation.
Safety instructions for commissioning
To maintain the sensor's and TempoLink smart assistant's
operability, it is mandatory to follow the instructions given
below.
1. Protect the sensor and TempoLink smart assistant
against mechanical damage during installation and
operation.
2. Do not open or dismantle the sensor and TempoLink
smart assistant.
3. Connect the sensor and TempoLink smart assistant very
carefully and pay attention to the polarity of connections
and power supply.
4. Use only approved power supplies.
5. Ensure the sensor and TempoLink smart assistant are
operating within the defined limits for supply voltage,
environmental conditions, etc.
6. Check the function of the sensor and TempoLink smart
assistant regularly and provide documentation of the
checks.
7. Before applying power, ensure that nobody’s safety
is jeopardized by starting machines.
2.4 Safety instructions for use in explosion-hazardous
areas
The TempoLink smart assistant is are not suitable for
operation in explosion-hazardous areas.
2.5 Warranty
MTS Sensors grants a warranty period for the Temposonics®
position sensors and supplied accessories relating to
material defects and faults that occur despite correct use in
accordance with the intended application.2The MTS Sensors
obligation is limited to repair or replacement of any defective
part of the unit. No warranty can be provided for defects
that are due to improper use or above average stress of the
product, as well as for wear parts. Under no circumstances
will MTS Sensors accept liability in the event of offense
against the warranty rules, no matter if these have been
assured or expected, even in case of fault or negligence of
the company.
MTS Sensors explicitly excludes any further warranties.
Neither the company’s representatives, agents, dealers nor
employees are authorized to increase or change the scope of
warranty.
2.6 Return
For diagnostic purposes, the TempoLink smart assistant
can be returned to MTS Sensors or a repair facility explicitly
authorized by MTS Sensors. Any shipment cost is the
responsibility of the sender.2
2.7 Removal from service/dismantling
The product contains electronic components and must be
disposed of in accordance with the local regulations.
2/ See also applicable MTS Sensors sales and supply
conditions, e.g. under www.mtssensors.com

TempoLink Smart Assistant
Operation Manual
I5 I
3. Identification
1 2 3 4 5 6 7 8
T L 0
a b c d
a Type
T L TempoLink smart assistant kit
b
Power supply
1Plug-in power supply with plug adapters (AU, CCC, EU, UK, US)
2Cable for insertion in existing sensor power supply with sensor
mating connector and barrel connector
3Barrel connector with pig-tail for connection to an existing
power supply
c
Option
0No options
dAdapter cables for connection to R-Series
V
E M 0 8 Cable with M8 female connector (4 pin)
for connection type D56
(EtherCAT® /EtherNet/IP™/POWERLINK)
(part no. 254 887-1)
E M 1 2 Cable with M12 female connector (4 pin)
for connection type D58
(EtherCAT®/EtherNet/IP™/PROFINET)
(part no. 254 897-1)
S D 7 0 Cable with M16 female connector (7 pin) for
connection type D70 (SSI) (part no. 254 990-1)
A S 0 0 Cable with 6 × terminal clamp for cable connection
type (Analog/SSI) (part no. 255 043-1)
A D 6 0 Cable with M16 female connector (6 pin) for
connection type D60 (Analog) (part no. 254 989-1)
DELIVERY
TempoLink smart assistant kit
• TempoLink smart assistant
• Power supply or cable for
insertion in existing sensor
power supply with sensor
mating connector and
barrel connector
• Adapter cable to connect
TempoLink smart assistant
to R-Series Vsensor
• USB cable for optional
connection of TempoLink
smart assistant to a
computer
Adapter cables to connect
TempoLink smart assistant to
sensors of R-Series Vcan be
ordered separately
TempoLink smart assistant
Plug-in power supply with plug adapters or cable for
insertion in an existing sensor power supply
with sensor mating connector and barrel connector
Power supply with plug adapters
M8 male (D56)*
M12 male (D58)*
Pig-tail (D56, D58, SD70, AS00, AD60)*
Adapter cable for connection of TempoLink smart
assistant to R-Series Vsensor
EM08 (sensor – barrel)*
EM12 (sensor – barrel)*
SD70/AD60 (sensor – barrel)*
* One of the above supplied depending on the congurated
TempoLink kit
Fig. 1: Package content of the TempoLink kit, part 1
4. Package content

TempoLink Smart Assistant
Operation Manual
I6 I
AS00 (sensor – cable)*
USB cable for optional connection of TempoLink smart
assistant to a computer
The TempoLink smart assistant can be connected to all
sensors of the R-Series Vfamily. Depending on the sensor
output, different adapter cables are available to connect the
TempoLink smart assistant to the R-Series Vsensor. Use the
appropriate adapter cable for the sensor output. Connect
the barrel connector of the adapter cable to the connection
point labeled “OUTPUT SENSOR” on the TempoLink smart
assistant. Next, connect the opposite end of the adapter cable
to the power supply at the R-Series Vsensor. The TempoLink
smart assistant also provides the supply power for the sensor.
Fig. 3 shows one possible version as an example. The adapter
cable is available in different versions depending on the sensor
output. See the specific R-Series Voperation manual for more
information.
If the sensor is connected to another power supply
disconnect the power supply before connecting TempoLink
smart assistant to the sensor.
NOTICE
When disconnecting the power supply of the sensor
possibly error messages occur at the connected controller.
Do not exceed the maximum cable length between
TempoLink smart assiant and R-Series Vsensor of 30 m.
OUTPUT
INPUT
SENSOR
24VDC
5. Connection of TempoLink smart assistant to
R-Series Vsensor
OUTPUT
INPUT
SENSOR
24VDC
OUTPUT
INPUT
SENSOR
24VDC
6. Connection of TempoLink smart assistant to power
supply
There are two ways:
6.1 Using the plug-in power supply with plug adapters
Connect the barrel connector to the “INPUT 24 VDC” port
on the TempoLink smart assistant. Next, insert the plug into
the outlet. Additional outlet adapters are supplied to support
regional requirements.
6.2 Using the cable for insertion in an existing sensor
power supply with sensor mating connector and barrel
connector (only R-Series VEtherNet/IP™, EtherCAT®,
POWERLINK and PROFINET)
Connect the supplied sensor mating connector to your
existing power supply connector that was removed from the
sensor. Connect the barrel connector to the “INPUT 24 VDC”
port on the TempoLink smart assistant. Fig. 5 shows one
possible version as an example. The adapter cable is available
in different versions depending on the sensor output. See the
specific R-Series Voperation manual for more information.
Fig. 2: Package content of the TempoLink kit, part 2
Fig. 3: Connection of TempoLink smart assistant to R-SeriesV
sensor
Fig. 4: Connection of TempoLink smart assistant with the plug-in
power supply
Fig. 5: Connection of TempoLink smart assistant with the cable for
insertion in an existing sensor power supply cable for R-Series V
EtherNet/IP™, EtherCAT®, POWERLINK and PROFINET

TempoLink Smart Assistant
Operation Manual
I7 I
NOTICE
If you are using a mobile device, ensure cellular data is off.
Depending on your operation system, message can appear,
that there is no internet access. TempoLink smart assistant
does not need internet access.
Connecting to the user interface may take longer if Wi-Fi
and LAN connections are active.
7. Connection of TempoLink smart assistant to
smartphone, tablet or computer
Connect to a smartphone, tablet or computer to display the
graphical user interface of the TempoLink smart assistant.
7.1 Connecting a Wi-Fi enabled device to the
integrated Wi-Fi access point 3
Activate Wi-Fi on the device and choose the network
“TempoLink_xxxx” (xxxx indicates the last four digits of the
serial number). The default password is the serial number
printed on the label on the bottom of the TempoLink smart
assistant.
Fig. 6: Choose the network “TempoLink_xxxx” in the Wi-Fi
settings of the Wi-Fi-enabled device
7.2 Connecting a computer via USB connection
The TempoLink smart assistant can also be connected via
USB. If the computer is Wi-Fi enabled deactivate Wi-Fi on the
computer before setting up the USB connection.
Connect the USB cable with the micro USB connector to
the port labeled “USB” on the TempoLink smart assistant.
Next, connect the USB type-A connector to a free USB port of
the computer. The USB connection simulates a network card.
In the folder “network connections” on the computer the
connection is shown as “IP-over-USB” or “Remote NDIS”.
3/ The integrated Wi-Fi access point does not provide
internet access
After the connection via Wi-Fi or USB is established, open the
browser and go to the website-URL: tempolink.local
The connection icon in the top right shows the status of the
connection between the TempoLink smart assistant and the
sensor.
Fig. 8: Start page of the graphical user interface
Fig. 9: Connection status
Connection status
Green Information
ON Connection to sensor is established
Red Information
ON Connection to sensor is not established
Blue Information
ON Sensor in command mode
NOTICE
Only one device can be connected to the TempoLink smart
assistant at a time in order to display the graphical user
interface.
NOTICE
Disable all Wi-Fi and LAN connections before connecting
TempoLink smart assistant via USB. Connecting to the user
interface may take longer if Wi-Fi and LAN connections
are active. It may be useful to press CTRL + F5 to delete
cached text and images from prior to launching the
tempolink.local website.
USB connector
Fig. 7: USB port on the TempoLink smart assistant
8. Establishing a connection via browser

TempoLink Smart Assistant
Operation Manual
I8 I
Click the menu symbol in the top left to get to the main
menu of the graphical user interface (GUI) (Fig. 10):
9. Graphical user interface
Fig. 10: Main menu of the graphical user interface
9.1 Menu item TempoLink
This menu item includes information about the TempoLink
smart assistant like its serial number, firmware version and
part number. In addition you can change the password and
update the firmware of your TempoLink smart assistant.
Firmware Update
Firmware updates of the TempoLink smart assistant are
available for download from the MTS Sensors website
www.mtssensors.com. The firmware update is a zip file.
Download the zip file, save it on your computer and unzip
it. To install the firmware update, connect your TempoLink
smart assistant to your computer via USB cable or via Wi-Fi.
A firmware update is not possible when connecting via
smartphone or tablet.
In the TempoLink menu item click the UPDATE button to
open the “Configure TempoLink” window (Fig. 11). Click
the CHOOSE FILE button. Use the dialog to navigate to the
location where you saved the firmware update file and select
the update.tar file. The selected file is displayed. To
execute the update, click the SUBMIT button (Fig. 12).
NOTICE
No action is required from you during the installation of the
update. Do not disconnect the TempoLink smart assistant
from the power supply during the update process.
Fig. 11: Window for the firmware update
Fig. 12: Selected tar-file for the firmware update
During the update process, the TempoLink smart assistant
will automatically shut down and restart. During installation,
a USB drive will appear and disappear at your computer.
The LEDs will also change during the process. Typically, the
three LEDs will turn green before changing to orange. The
installation may take several minutes (typically 3…4 minutes)
even if the LEDs do not change. After successful installation,
the orange LEDs go out. LED A and LED B light up depending
on the connection. LED C lights up green. If you have
connected your computer to the TempoLink smart assistant
via Wi-Fi, restore the Wi-Fi connection after the installation
is complete. The Wi-Fi connection is interrupted during the
update. Refresh your browser and use the TempoLink smart
assistant as usual.

TempoLink Smart Assistant
Operation Manual
I9 I
9.2 Menu item status
The status menu includes current information about the
sensor status (Fig. 13) such as:
Fig. 13: Sensor status
Fig. 14: Graphical display of position values
Fig. 15: Change displayed units
• Magnets Found: Number of magnets detected on the
sensor
• Magnets Set: Number of set magnets. By clicking on the
red arrow on the left the current position of the magnet is
displayed. The magnifying glass on the right of the magnet
provides a graphical display of the magnet's position. Note,
that the output of the position values for the graphical
display is slower than the output of the position values to
the controller (Fig. 14).
• Temperature: Current temperature inside the sensor
electronics housing.
• Input Voltage: Current input voltage of the sensor.
• Sensor Notices: Current error messages
• Lifetime Statistics: By clicking the red arrow in the left
information about the sensor statistics are displayed
(depending on the connected sensor)
Odometer: Total distance travelled by the position magnet
Magnet cycles: Total number of directional changes
of the magnet
Operational Time: Total operational hours of the sensor
Max Temperature: Maximum temperature inside the
sensor electronics housing reached so far
Min Temperature: Minimum temperature inside the
sensor electronics housing reached so far
Temperature Violations: Duration of exceeding or falling
below the permissible operating temperature range
Max Voltage: Maximum input voltage reached so far
Min Voltage: Minimum input voltage reached so far
Voltage Violations: Duration of exceeding or falling
below the permissible power supply range
• Displayed Units: You can change the units of the displayed
values from metric units to imperial units. To do this, click
on the black pencil in this line. The “Change Display Units”
window opens. Select the desired unit and confirm by
clicking OK (Fig. 15).
9.3 Menu Item Sensor Info

TempoLink Smart Assistant
Operation Manual
I10 I
settings, the command mode must be started. In command
mode, the sensor does not output a position value. By
clicking the button ENTER COMMAND MODE the “Enter
Command Mode” window opens. After reading the
information, enter the word COMMAND and confirm by
clicking OK (Fig. 16). After entering the command mode the
connection icon on the top right will turn from green to blue.
By clicking the button FACTORY RESET the sensor is reset to
the factory setting.
After the parameters have been configured or the factory
NOTICE
For information about the parameters, check the
R-SeriesVoperation manual of the sensor connected to
your TempoLink smart assistant.
Fig. 16: Starting the command mode
The Sensor Info menu includes information about the
connected sensor like stroke length, serial number and order
code.
9.4 Menu Item Parameters
The Parameter menu includes information about the
operational settings and the statistics settings of the
connected sensor. The displayed parameters depend on the
sensor output. In addition some operational settings may not
be adjustable.
To change parameters or to reset the sensor to factory
reset has been carried out, click the button EXIT COMMAND
MODE. The “Exit Command Mode” window for exiting the
command mode will open. Click the button SAVE AND EXIT
to exit the command mode and to transfer the changed
parameters to the sensor (Fig. 17). If you click the button
CANCEL, the changed parameters are not transferred to
the sensor. The sensor returns to the normal function and
outputs the current position value. The connection icon on
the top right will turn to green.
Fig. 17: Exiting the command mode
9.5 Menu item interface
The interface menu includes information about the interface
settings of the connected sensor. The displayed information
depends on the sensor output.

TempoLink Smart Assistant
Operation Manual
I11 I
Fig. 18: LED connection status
10. LEDs of TempoLink smart assistant
Three LEDs in the lid of the TempoLink smart assistant
display the current status of the tool:
TempoLink smart assistant LEDs
Status LEDs
LED A
Communication between TempoLink smart assistant and sensor
LED color Information
Green Flashing Data transfer between TempoLink smart
assistant and sensor
Red ON No connection between TempoLink smart
assistant and sensor
LED B
Communication between TempoLink smart assistant and website
LED color Information
Red ON Website not accessed
Green Flashing Data transfer between TempoLink smart
assistant and website
LED C
USB & Wi-Fi connection
LED color (up) Information
Green ON USB connection exists
Red ON USB connection error
– OFF No USB connection
LED color (down) Information
Green ON Wi-Fi activated on TempoLink smart assistant
Red ON Wi-Fi error on TempoLink smart assistant
– OFF Wi-Fi deactivated on TempoLink smart assistant
(USB connection exists)
NOTICE
Initialization of the Wi-Fi connection or USB connection
takes a few seconds. After initialization, the corresponding
LED C lights up.
NOTICE
German version of the operation manual is available on our
homepage: www.mtssensors.com

UNITED STATES
MTS Systems Corporation
Sensors Division
Americas & APAC Region
3001 Sheldon Drive
Cary, N.C. 27513
Phone: [phone]
E-mail: [email protected]
GERMANY
MTS Sensor Technologie
GmbH & Co. KG
EMEA Region & India
Auf dem Schüffel 9
58513 Lüdenscheid
Phone: [phone]
E-mail: [email protected]
ITALY
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
FRANCE
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
UK
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
SCANDINAVIA
Branch Offi ce
Phone: + 46 70 29 91 281
E-mail: [email protected]
CHINA
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
JAPAN
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
www.mtssensors.com
MTS, Temposonics and Level Plus are registered trademarks of MTS Systems Corporation in the United States; MTS SENSORS and the MTS SENSORS logo are trademarks of MTS Systems Corporation within the
United States. These trademarks may be protected in other countries. All other trademarks are the property of their respective owners. Copyright © 2020 MTS Systems Corporation. No license of any intellectual
property rights is granted. MTS reserves the right to change the information within this document, change product designs, or withdraw products from availability for purchase without notice. Typographic and
graphics errors or omissions are unintentional and subject to correction. Visit www.mtssensors.com for the latest product information.
Document Part Number:
551986 Revision C (EN) 05/2020
