Temposonics
®
Magnetostrictive, Absolute, Non-contact
Linear-Position Sensors
R-Series Models RP and RH
Profinet Interface
Data Sheet
SENS
O
RS
®
Document Part Number
551451 Revision A
FEATURES
Linear, Absolute Measurement
LEDs For Sensor Diagnostics
Superior Accuracy, Resolution down to 1 µm
Non-Contact Sensing Technology
Linearity Deviation Less Than 0.01%
Repeatability Within 0.001%
Intergrated Pronet IRT switch
BENEFITS
Rugged Industrial Sensor
Position + Velocity Measurements For Up to 19 Magnets
APPLICATIONS
Continuous Operation In Harsh Industrial Conditions
High Pressure Conditions
For Accurate, Simultaneous Multi-Position
and Velocity Measurements
TYPICAL INDUSTRIES
Factory Automation
Fluid Power
Plastic Injection and Blow Molding
Material Handling and Packaging
All specifications are subject to change. Contact MTS for specifications and
engineering drawings that are critical to your application. Drawings contained
in this document are for reference only. Go to http://www.mtssensors.com for
the latest support documentation and related media.
Time-based Magnetostrictive position sensing principle
Movable position magnet
Magnetic field from
position magnet
Interaction of magnetic
fields causes waveguide to
generate a strain pulse
Magnetic field encompasses
entire waveguide - generated
by the interrogation pulse
Bias magnet
Strain-Pulse detector
Interrogation
Return wire
Waveguide
Benefits of Magnetostriction
Temposonics linear-position sensors use the time-based magneto-
strictive position sensing principle developed by MTS. Within the
sensing element, a sonic-strain pulse is induced in a specially designed
magnetostrictive waveguide by the momentary interaction of two
magnetic fields. One field comes from a movable permanent magnet
that passes along the outside of the sensor. The other field comes
from an “interrogation” current pulse applied along the waveguide.
The resulting strain pulse travels at sonic speed along the waveguide
and is detected at the head of the sensing element.
The position of the magnet is determined with high precision and
speed by accurately measuring the elapsed time between the applica-
tion of the interrogation pulse and the arrival of the resulting strain
pulse with a high-speed counter. The elapsed time measurement is
directly proportional to the position of the permanent magnet and is
an absolute value. Therefore, the sensor's output signal corresponds
to absolute position, instead of incremental, and never requires
recalibration or re-homing after a power loss. Absolute, non-contact
sensing eliminates wear, and guarantees the best durability and output
repeatability.

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.: 551451, Revision A 08/13 2
Product specifications
Product overview
Parameters Specifications
OUTPUT
Measured output
variables: Simultaneous multi-position or velocity
measurements up to 19 magnets.
Resolution: 1 to 100 µm selectable
Update time: Dependent on stroke length
Motion control
cycle time: Minimum 1 ms
Linearity
deviation: < ± 0.01% full stroke (minimum ± 50 µm)
Repeatability: < ± 0.001% full stroke
(minimum ± 2.5 µm)
Hysteresis: < 4 µm
Outputs: Interface: Profinet IO RT
Data transmission rate: 100 Mbit/s max.
Stroke length: Range (Profile style):
25 mm to 5080 mm (1 in. to 200 in.)
Range (Rod style):
25 mm to 7620 mm (1 in. to 300 in.)
ELECTRONICS
Operating
voltage: +24 Vdc nominal: -15% or +20%
Polarity protection: up to -30 Vdc
Over voltage protection: up to 36 Vdc
Current drain: 110 mA typical
Dielectric withstand voltage:
500 Vdc (DC ground to machine ground)
Product Overview and Specifications
Parameters Specifications
ENVIRONMENTAL
Operating
conditions: Operating temperature:
0 °C (32 °F) to +75 °C (+167 °F)
Relative humidity: 90% no condensation
Temperature coefficient: < 15 ppm/ °C
EMC test: Electromagnetic emission:
EN 61000-6-4 (for industrial environments)
Electromagnetic immunity:
EN 61000-6-2
(The sensor meets the requirements of the EC
directives and is marked with CE)
Shock rating: 100 g (single hit)/IEC standard 60068-2-27
(survivability)
Vibration rating: 15 g / 10 to 2000 Hz / IEC standard 60068-2-6
(resonance frequencies excluded)
WIRING
Connection type: D58 option: Two female 4-pin (M12-D) plus
one 4-pin male (M12-A) connector
PROFILE STYLE SENSOR (MODEL RP)
Electronic head: Aluminum housing with diagnostic LED display
(LEDs located beside connectors)
Sealing: IP 65
Sensor extrusion: Aluminum (Temposonics profile style)
Mounting: Any orientation. Adjustable mounting feet or
T-slot nut (M5 threads) in bottom groove
Magnet types: Captive-sliding magnet or open-ring magnet
ROD STYLE SENSOR (MODEL RH)
Electronic head: Aluminum housing with diagnostic LED display
(LEDs located beside connectors)
Sealing: IP 67
Sensor rod: 304L stainless steel
Operating
pressure:
350 bar static, 690 bar peak
(5000 psi static, 10,000 psi peak)
Mounting: Any orientation. Threaded flange M18 x 1.5 or
3/4 - 16 UNF-3A
Typical
mounting torque: 45 N-m (33 ft. - lbs.)
Magnet types: Ring magnet, open-ring magnet, or magnet
float
The sensor meets the requirements of the Profinet IO industrial Ethernet standards and can be directly operating in a network with
decentralized peripherals. Profinet is characterized by a high data transfer and high real-time capability. It´s officially certified by
the PNO (Profinet user organization).

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.: 551451, Revision A 08/13
3
Profinet Output Options, Programmability
Enhanced Monitoring and Diagnostics
Enhanced monitoring and diagnostics
SENSOR STATUS AND DIAGNOSTIC DISPLAY
Integrated LED (green/red) provides basic visual feed-
back for normal sensor operation and troubleshooting.
Figure 1. R-Series sensor Integrated diagnostic LEDs
Green Red Description
ON OFF Normal function
ON ON No master contact
ON Flashing Parametrization failed
Table 1. Diagnostic display indicator modes
Profinet interface
Pronet versions
The sensor can be ordered in following versions:
a) Encoder Profile 4.1: PNO standardized profile
b) MTS Communication Profile: It allows a simultaneous position measure-
ment up to 19 positions. The configuration
is similar to the sequence of Temposonics®
Profibus sensors
Operation modes and output
Single and Multi-magnet position and velocity:
Up to 19 simultaneous magnet measurements are possible when using
multiple magnets. The minimum allowed distance between magnets
is 75 mm (3 in.) to maintain proper sensor output (see ‘Figure 2’).
Single magnet
Measurement M1 M1a
Position / Velocity
Temposonics
®
R-Series
R
®
U401
Figure 2.
1 to 19 magnet
Measurement M1 M2 M19
75 mm
(3 in.) min.
M3
Position / Velocity
Temposonics®
R-Series
R
®
U402
Single and multi-magnet output diagram

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.:551451, Revision A 08/13 4
Model RP profile-style sensor dimension references
MODEL RP, PROFILE-STYLE SENSOR WITH CAPTIVE-SLIDING MAGNET
Drawing is for reference only, contact applications engineering for tolerance specific information.
49 mm
(1.92 in.)
9 mm
(0.36 in.)
50 mm (1.97 in.)
68 mm (2.68 in.)
5.5 mm
(0.21 in.) dia.
M5 or #10 screw
2 mm
(0.07 in.)
45 mm
(1.77 in.)
12 mm (0.47 in.)
124.5 mm
(4.9 in.)
Stroke length
82 mm (3.2 in.)
Dead zone
End of stroke
‘Span’ position
Beginning of stroke ‘Null’ position
Mounting foot, moveable
(part no.: 400802)
Electronics
housing
Captive-sliding magnet
D58
integral connector option
15.5 mm
Figure 3. R-Series Model RP Profile-style sensor dimension reference (Shown with the D58 connector option)
MODEL RP, PROFILE-STYLE SENSOR WITH OPEN-RING MAGNET
Drawing is for reference only, contact applications engineering for tolerance specific information.
28 mm
(1.10 in.)
Null
zone Open-ring magnet Style M
(part no. 251416-2)
Dead Zone
66 mm (2.6 in.)
Stroke length
Non-ferrous mounting
support and screws
124.5 mm
(4.9 in.)
15.5 mm (0.61 in.)
28 mm
(1.10 in.)
D58
integral connector option
Electronics
Housing
End of stroke
‘Span’ position
Beginning of stroke ‘Null’ position
Figure 4. R-Series Model RP Profile-style sensor dimension reference (Shown with the D58 connector option)
Model RP Profile-Style Sensor
Sensor Dimension References

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.:551451, Revision A 08/135
Model RP Profile-Style Sensor
Standard Magnet Selections
Standard magnet selections (Model RP)
SELECTION OF POSITION MAGNETS
A choice of two magnet mounting configurations are available with the profile-style sensor; A ‘captive-sliding’ magnet, Styles Sor Vor an
‘open-ring’ magnet, Style M. Captive-sliding magnets utilize slide bearings of special material that reduce friction, and if required, help mitigate
dirt build up. The slide bearings are designed to operate dry, requiring no external lubrication or maintenance.
The Style M ‘open-ring’ magnet mounts on the moving machine part and travels just above the sensor’s profile extrusion. The open-ring
magnet requires a minimum distance away from ferrous metals to allow proper sensor output. It must be mounted using non-ferrous screws
and a non-ferrous support bracket, or utilize a non-ferrous spacer of at least 5 mm (0.2 in.) thickness.
POSITION MAGNET SELECTIONS (Drawing dimensions are for reference only)
Magnet dimensions and mounted magnet dimensions Description Part number
Captive-sliding magnet, Style S
For Model RP profile-style sensor 252182
40 mm
(1.58 in.)
25 mm
(1 in.)
9 mm
(0.35 in.)
57 mm
(2.24 in.)
14 mm
(0.55 in.)
Rotation:
Vertical: 18°
Ball-jointed arm
(M5 thread)
Captive-sliding magnet, Style V
For Model RP profile-style sensor 252184
21 mm
(0.81 in.)
25 mm
(0.97 in.)
14 mm
(0.55 in.)
2 Holes
Each 4.3 mm
(0.17 in.) dia. on
24 mm (0.94 in.) dia.
60°
Open-ring magnet, Style M
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.29 in.)
Thickness: 8 mm (0.31 in.)
Operating temperature:
- 40 °C to 100 °C
This magnet may influence the
sensor performance specifications
for some applications.
251416-2
40 mm
(1.58 in.)
25 mm
(1 in.)
20 mm
(0.79 in.)
43 mm
(1.69 in.)
14 mm
(0.55 in.)
Rotation:
Vertical: 18°
Horizontal: 360°
Ball-jointed arm
(M5 thread)
45 mm
(1.77 in.)
52 mm
(2.05 in.)
36 mm
(1.41 in.)
21 mm
(0.81 in.)
Max gap
3 mm ± 1 mm
(0.12 in. ± 0.04 in.)
29 mm
(1.14 in.)
Non-ferrous mounting support and screws
Open-ring magnet Style ‘M’

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.: 551451, Revision A 08/13 6
Sensor mounting
Model RP profile-style sensor mounting flexible installation in any position!
Temposonics Model RP profile-style sensors offer two basic mounting methods; side grooves for use with mounting feet or a bottom groove
that accepts special T-Slot nuts. Both the mounting feet and T-Slot nuts can be positioned along the sensor extrusion to best secure the sensor
for each particular application.
Notes:
1. Model RP sensors include two mounting feet (part no. 400802) for sensors stroke lengths up to 1250 mm (50 in.)
2. One additional mounting foot is included for stroke lengths over 1250 mm (50 in.) and for each additional 500 mm (20 in.),
thereafter.
3. MTS recommends using 10-32 cap screws (customer supplied) at a maximum torque of 44 in. lbs. when fastening mounting feet.
Profile-Style sensor mounting and installation reference Mounting method Part number
(Width = 14.5 mm (0.57 in.)
Mounting feet, standard (304 SS)
Profile-style sensor mounting for
sensor model RP
400802
10 - 32 Cap screws
Recommended
(Customer supplied) Mounting feet and screws
Profile-style sensor foot installation
See Mounting
Feet
part number:
400802
T-Slot nut
Nut for mounting model RP sensor.
M5 thread
(Optional, ordered separately)
401602
4 Holes
5.3 mm
(0.21 in.) dia.
28 mm
(1.1 in.) 9 mm
(0.36 in.)
50 mm
(1.97 in.)
2 mm
(0.08 in.) 68 mm
(2.68 in.)
9 mm
(0.36 in.)
Mounting foot
(Customer supplied)10-32 cap screws
M5 threaded T-Slot nut
T-Slot nut (M5 threaded)
5 mm
(0.20 in.)
M5 Threaded stud and nut
(customer supplied)
Model RP Profile-Style Sensor
Sensor Mounting Reference

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.: 551451, Revision A 08/137
Model RH Rod-Style Sensor
Dimension References
Model RH rod-style sensor dimension reference
The Temposonics R-Series rod-style sensor (Model RH) offers modular construction, flexible mounting configurations, and easy installation.
The Model RH sensor is designed for mounting in applications where high pressure conditions exist (5000 psi continuous, 10,000 psi spike)
such as inside hydraulic cylinders. The Model RH sensor (see 'Figure 5') may also be mounted externally in many applications.
Stroke-dependent Dead Zones:
Stroke length:
25 mm (1 in.) - 5000 mm (197 in.)
5005 mm (197 in.) - 7620 mm (300 in.)
Dead zone:
63.5 mm (2.5 in.)
66 mm (2.6 in.)
MODEL RH, ROD-STYLE SENSOR WITH RING MAGNET (MAGNET ORDERED SEPARATELY)
Drawing is for reference only, contact applications engineering for tolerance specific information.
Figure 5. Model RH Rod-style sensor dimension reference (shown with D58 integral connector options
15.5 mm (0.61 in.)
129 mm (5.1 in.) 51 mm (2 in.)
Beginning of stroke ‘Null’ position End of stroke ‘Span’ position
Electronics
housing
Null zone
Stroke length
Flat-faced hex flange type ‘S’
Sensor Rod
10 mm (0.39 in.) dia.
25 mm
(0.98 in.)
O-Ring
Ring magnet
Dead zone
(refer to Notes
‘Stroke dependent
dead zones’)
Refer to ‘Table 2’ for
(A) Flange threads
D58
Integral connector option
)
MODEL RH, ROD-STYLE SENSOR WITH RING MAGNET (MAGNET ORDERED SEPARATELY)
Drawing is for reference only, contact applications engineering for tolerance specific information.
Figure 6.
D58
Integral connector option
25.4 mm
(1 in.)
O-Ring
Beginning of stroke ‘Null’ position
Null
51 mm (2 in.)
Electronics
housing
2.5 mm (0.10 in.)
Raised-faced flange, Type ‘T’
Refer to ‘Table 2’
25 mm
(0.98 in.)
Ring Magnet
part no.: 201542-2
Refer to ‘Table 2’
(A) Flange Threads
B
C
Refer to ‘Table 2’
(B) dimensions and (C) dimensions
Model RH Rod-style sensor dimension reference (Shown with the D58 Integral cable connection type option)
Housing style
Flange type Description (A) Flange threads (B) Dimensions (C) Dimensions
TUS customary threads with raised-face flange 3/4" - 16 UNF-3A 1.75 in. 2 in.
SUS customary threads with flat-faced flange 3/4" - 16 UNF-3A 1.75 in. 2 in.
M Metric threads with flat-faced flange M18 x 1.5 46 mm 53 mm
Table 2. Model RH Rod-style sensor housing style and flange type references

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.: 551451, Revision A 08/13 8
Model RH Rod-Style Sensor
Standard Magnet Selections
Standard magnet selections (Model RH)
Magnets must be ordered separately with Model RH position sensors. The standard ring magnet (part number 201542-2) is suitable for most
applications.
POSITION MAGNET SELECTIONS (Magnet must be ordered separately) (Drawing dimensions are for reference only)
Magnet and magnet dimensions Description Part number
Standard ring magnet
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
201542-2
Magnet spacer
(Non-ferrous, use with ring magnet
Part number: 201542-2)
I.D.: 14 mm (0.56 in.)
O.D.: 32 mm (1.25 in.)
Thickness: 3.2 mm (0.125 in.)
400633
Ring magnet
I.D.: 13.5 mm (0.53 in.)
O.D.: 25.4 mm (1 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
400533
Open-ring magnet, Style M
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
This magnet may influence the
sensor performance specifica-
tions for some applications.
251416-2
MAGNET FLOAT SELECTION (Drawing dimensions are for reference only)
Magnet float
(Level sensing applications)
Specific gravity: 0.70 maximum
Pressure: 870 psi maximum
(This float is used with Model RH rod-style
sensors for hydraulic fluid or fresh water
applications only). Collar (part no.: 560777)
is recommended for end of stroke stops.
251447
4 Holes
Each 4.3 mm (0.17 in.) dia.
90° apart on
24 mm (0.94 in.) dia.
4 Holes
Each 4.3 mm (0.17 in.) dia.
90° apart on
24 mm (0.94 in.) dia.
21 mm
(0.81 in.)
25 mm
(0.97 in.)
14 mm
(0.55 in.)
2 Holes
Each 4.3 mm
(0.17 in.) dia. on
24 mm (0.94 in.) dia.
60°
14 mm (0.55 in.) Min. I.D.
51 mm (2 in.)
Spherical O.D.
3.4 mm (0.13 in.)
C
L
53 mm
(2.1 in.)

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors -Profinet Industrial Profinet
Interface Product Data Sheet, Part No.: 551451, Revision A 08/139
Model RH Rod-Style Sensor Mounting
Cylinder Installation and Connections
Model RH Rod-Style sensor mounting
The position magnet requires minimum distances away from ferrous
metals to allow proper sensor output. The minimum distance from the
front of the magnet to the cylinder end cap is 15 mm (0.6 in.).
The minimum distance from the back of the magnet to the piston head
is 3.2 mm (0.125 in.). However, a minimum distance of at least 5 mm
(0.197 in.) is preferred for added performance margin.The non-ferrous
spacer (part no.: 400633) provides this minimum distance when used
along with the standard ring magnet (part no.: 201542-2), as shown
in 'Figure 7'.
Figure 7.
Non ferrous
spacer
> 15 mm
(0.6 in.)
Min. 3.2 mm
(0.125 in.)
Ring magnet
n fer
cer
m
m
mm
.)
(0
.125 in.)
magne
t
Ring
m
Non
spa
Min. 3.2 mm
m
ag
net
Ring
m
Cylinder end cap
Piston head
Temposonics®
R-Series
R
®
Model RH rod-style mounting
Cylinder installation
When used for direct-stroke measurement in fluid cylinders, the sen-
sor's high pressure, stainless steel rod installs into a bore in the piston
head/rod assembly as shown in 'Figure 8'. This method guarantees a
long-life and trouble-free operation.
The sensor cartridge can be removed from the flange and rod hous-
ing while still installed in the cylinder. This procedure allows quick
and easy sensor cartridge replacement without the loss of hydraulic
pressure.
The sensor’s rod housing and flange can remain
permanently installed in the cylinder
Ring magnet
The sensor cartridge consist of the electronics housing
and sensing element and is easy to replace by removing
(2) M4 thread 2.5 mm hex socket head screws
Figure 8. Fluid cylinder installation
Connections and wiring
(D58) BUS CONNECTOR OPTION
D58 connector option for 'daisy chain' topologies. A separate cable
is used for the supply voltage. Unused connectors should be covered
by a protective cap (part no.: 370537).
BUS CONNECTIONS PORTS 1 AND 2
4
3
2
1
Female, 4-pin (M12-D) Integral connector
pin-out as viewed from the end of the sensor
Pin number Cable color Function
1 Yellow Tx+
2 White Rx+
3 Orange Tx-
4 Blue Rx-
INPUT VOLTAGE
Input voltage, male, 4-pin (M12-A) integral
connector pin-out as viewed from the end of
the sensor
Pin number Cable color Supply voltage
1 Brown +24 Vdc (-15/+20%)
2 White No connection
3 Blue DC ground (for supply)
4 Black No connection

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.: 551451, Revision A 08/13 10
Model RP and RH Sensors
Ordering Information; Connector and Cable Assembly Options
(D58) CABLE CONNECTOR OPTIONS (Drawing dimensions are for reference only)
Connector and connector dimensions Description Part number
Bus Cable Connector, Male 4-pin
(M12), D-coded with insulation
displacement technology
370523
Female cable connector,
straight exit
(Field installable)
5-Pin (M12-A) connector for
power supply
Termination:
Screw terminals
Cable gland:
for 4 to 8 mm dia cable
370677
Connector end cap
(Unused connectors should be
covered by this protective cap)
370537
BUS CABLE WITH CONNECTORS (Drawing dimensions are for reference only)
Bus cable and connector assemblies Description Part number
Ethernet cable
2 - Male, (M12)
4-pin connectors
47 mm
(1.85 in.)
16 mm
(0.63 in.) dia.
1
2
3
4
Industrial Ethernet Bus Cable,
5 m length (Cat 5e ES)
Assembly Includes two 4-pin
(M12) connectors (D-coded)
and PUR cable jacket (green)
530064
Ethernet cable
Male, (M12)
4-pin connector
47 mm
(1.85 in.)
16 mm
(0.63 in.) dia.
1
2
3
4M12 x 1
RJ45 Connector
55 mm
(2.17 in.)
Industrial Ethernet Bus Cable,
5 m length (Cat 5e ES)
Assembly Includes one RJ45
connector and one 4-pin (M12)
connector (D-coded) with PUR
cable jacket (green) Cables using
the RJ45 connector provide
convenient sensor connection to
a PC for setup and programming
but are not recommended for
factory floor installations.
530065
SW17/ width across flats 17
M12x1
Ø19.5 mm
(0.77 in.)
52 mm (2.05 in.)
SW13/ width across flats 13

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profinet Industrial Profinet
Interface Product Data Sheet, Part No.: 551451, Revision A 08/1311
Model RP and RH Sensors
Ordering Information
R D 5 8 1 U 4 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
SENSOR MODEL =R1-2
RP = Profile style RH = Hydraulic rod style
HOUSING STYLE =3
Model RP profile-style sensor (includes one magnet):
S=
Captive-sliding magnet with ball joint
at top (part no. 252182)
V
=
Captive-sliding magnet with ball
joint at front (part no. 252184)
M
=
Open-ring magnet (part no. 251416-2)
Model RH rod-style sensor (magnet(s) must be ordered separately):
T=
US customary threads, raised-faced
flange and pressure tube, standard
U
=
Same as option “T”, except uses
fluoroelastomer seals for the
electronics housing
B
=
Sensor cartridge only (no flange or
pressure tube, stroke length
< 1830 mm (72 in.))
S=
US customary threads, flat-faced
flange and pressure tube, standard
H
=
Same as option “S”, except uses
fluoroelastomer seals for the
electronics housing
M= Metric threads, flat-faced flange and
pressure tube, standard
V= Same as option “M”, except uses
fluoroelastomer seals for the
electronics housing
STROKE LENGTH = 4-8
— — — — M
=
Millimeters
(Encode in 5 mm increments)
Stroke Length Notes:
———.—U
=
Inches and tenths
(Encode in 0.1 in.
increments)
1. Profile-style sensor (model RP) stroke range = 25 mm (1 in.) - 5080 mm. (200 in.)
2. Rod-style sensor (model RH) stroke range = 25 mm (1 in.) - 7620 mm (300 in.)
CONNECTION TYPE =D 5 8 9-11
Integral connector:
D58 =Two 4-pin female (M12-D), plus one 4-pin male (M12-A)
INPUT VOLTAGE =112
1= +24 Vdc (+20% - 15%)
OUTPUT = U 4 0 13-16
U401 =Profinet RT, Encoder profile, 1 magnet
U402 =Profinet RT, MTS profile, 1 to 19 magnets
NUMBER OF MAGNETS =Z
17-19
For multi-position measurement only (Order additional magnets separately).
Z— — = Number of magnets for output U402 (range 02 to 19)

MTS and Temposonics are registered trademarks of MTS Systems Corporation.
All other trademarks are the property of their respective owners.
Printed in USA. Copyright © 2013 MTS Systems Corporation. All Rights Reserved in all media.
Document Part Number: 551451 Revision A, 08/13
MTS Sensor Technologie
GmbH & Co. KG
Auf dem Schüffel 9
D - 58513 Lüdenscheid, Germany
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
http://www.mtssensor.de
MTS Systems Corporation
Sensors Division
3001 Sheldon Drive
Cary, North Carolina,
27513, USA
Tel.: [phone]
Fax: [phone]
[phone]
e-mail: [email protected]
http://www.mtssensors.com
SENS
O
RS
®
MTS Sensors Technology
Corporation
737 Aihara-cho, Machida-shi
Tokyo 194-0211, Japan
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
http://www.mtssensor.co.jp
