MTS Sensors Temposonics R Series User manual

Model RH Rod-style position sensor
Model RP Prole-style position sensor
All specifications are subject to change. Contact MTS for specifications and
engineering drawings that are critical to your application. Drawings contained
in this document are for reference only. Go to http://www.mtssensors.com for
the latest support documentation and related media.
Time-based Magnetostrictive position sensing principle
Movable position magnet
Magnetic field from
position magnet
Interaction of magnetic
fields causes waveguide to
generate a strain pulse
Magnetic field encompasses
entire waveguide - generated
by the interrogation pulse
Bias magnet
Strain-Pulse detector
Interrogation
Return wire
Waveguide
Benefits of Magnetostriction
Temposonics linear-position sensors use the time-based magneto-
strictive position sensing principle developed by MTS. Within the
sensing element, a sonic-strain pulse is induced in a specially designed
magnetostrictive waveguide by the momentary interaction of two
magnetic fields. One field comes from a moveable permanent magnet
that passes along the outside of the sensor. The other field comes
from an “interrogation” current pulse applied along the waveguide.
The resulting strain pulse travels at sonic speed along the waveguide
and is detected at the head of the sensing element.
The position of the magnet is determined with high precision and
speed by accurately measuring the elapsed time between the applica-
tion of the interrogation pulse and the arrival of the resulting strain
pulse with a high-speed counter. The elapsed time measurement is
directly proportional to the position of the permanent magnet and is
an absolute value. Therefore, the sensor's output signal corresponds
to absolute position, instead of incremental, and never requires
recalibration or re-homing after a power loss. Absolute, non-contact
sensing eliminates wear, and guarantees the best durability and output
repeatability.
Temposonics
®
Magnetostrictive, Absolute, Non-contact
Linear-Position Sensors
R-Series Models RP and RH
Profibus-DP Output
Data Sheet
SENS
O
RS
®
Document Part Number
550990 Revision C
FEATURES
Linear, Absolute Measurement
LEDs For Sensor Diagnostics
Superior Accuracy, Resolution down to 1 µm
Non-Contact Sensing Technology
Linearity Deviation Less Than 0.01%
Repeatability Within 0.001%
Direct Probus-DP Output (Position +Velocity)
Standard and Multi-magnet position measurements
(up to 20 positions per sensor)
BENEFITS
Rugged Industrial Sensor
Fulllls All Requirements of Probus-DP
(EN 50170) Protocol
Probus-DP Provides Powerful Functions for
Diagnostics and Conguration
Linearity Correction Options
APPLICATIONS
Continuous Operation In Harsh Industrial Conditions
High Pressure Conditions
For Accurate, Multi-Magnet Position Measurement
(up to 20 positions per sensor)
TYPICAL INDUSTRIES
Factory Automation
Fluid Power
Plastic Injection and Blow Molding
Material Handling and Packaging

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014 2
Product specifications
Product overview
Parameters Specifications
OUTPUT
Measured output
variables: Position, up to 20 magnet positions simultane-
ously
Position + Velocity, up to 5 magnets simultane-
ously
Resolution: 1 µm, other values are selectable when using
the .gsd file
Update times: 0.5 ms at 500 mm, 1 ms at 2000 mm,
2 ms at 4500 mm, 3.1 ms at 7600 mm stroke
length. For each additional magnet add 0.05
ms,. Add 0.03 ms for approximate values for
velocity measurements.
Linearity
deviation: < ± 0.01% full stroke (minimum ± 50 µm)
(Linearity Correction Option (LCO) available)
Repeatability: < ± 0.001% full stroke (minimum ± 2.5 µm)
Hysteresis: < 4 µm
Outputs: Interface:
Profibus-DP system ISO 74498
Data format:
Profibus-DP (EN 50 170)
Data
transmission
rates: 12 MBd 1.5 MBd 500 kBd 187.5 kBd ≤93.75 kBd
Cable length, m: <100 <200 <400 <1000 <1200
Stroke length: Range (Profile style):
25 mm to 5080 mm (1 in. to 200 in.)
Range (Rod style):
25 mm to 7620 mm (1 in. to 300 in.)
ELECTRONICS
Operating
voltage: +24 Vdc nominal: -15% or +20%*
Polarity protection: up to -30 Vdc
Over voltage protection: up to 36 Vdc
Current drain: 90 mA typical
Dielectric withstand voltage: 500 Vdc
(DC ground to machine ground)
R-Series Models RP/RH Sensors with Profibus-DP Output
Product Overview and Specifications
Parameters Specifications
ENVIRONMENTAL
Operating
conditions: Operating temperature:
-40 °C (-40 °F) to 75 °C (167 °F)
Relative humidity:
90% no condensation
Temperature coefficient: < 15 ppm/ °C
EMC test: Electromagnetic emission:
IEC/EN 50081-1
Electromagnetic susceptibility:
IEC/EN 50082-2, IEC/EN 61000-4-2/3/4/6, level
3/4 criterium A, CE qualified
Shock rating: 100 g (single hit)/IEC standard 68-2-27
(survivability)
Vibration rating: 15 g / 10 to 2000 Hz / IEC standard 68-2-6
WIRING
Connection type: D63 option: Two 6-pin (M16) connectors one
male and one female
D53 option: Two 5-pin (M12) connectors one
male and one female. plus one 4-pin connector
(M8) male
PROFILE STYLE SENSOR (MODEL RP)
Electronic head: Aluminum housing with diagnostic LED display
(LEDs located beside connectors)
Sealing: IP 65**
Sensor
extrusion: Aluminum (Temposonics profile style)
Mounting: Any orientation. Adjustable mounting feet or
T-Slot nut (M5 threads) in bottom groove
Magnet types: Captive-sliding magnet or open-ring magnet
ROD STYLE SENSOR (MODEL RH)
Electronic head: Aluminum housing with diagnostic LED display
(LEDs located beside connectors)
Sealing: IP 67**
Sensor rod: 304L stainless steel
Operating
pressure: 350 bar static, 690 bar peak
(5000 psi static, 10,000 psi peak)
Mounting: Any orientation. Threaded flange M18x1.5 or
3/4-16 UNF-3A
Typical
mounting torque: 45 N-m (33 ft. - lbs.)
Magnet types: Ring magnet, open-ring magnet, or magnet
float
R-Series model RH and RP sensors are extremely robust and are
ideal for continuous operation under harsh industrial conditions.
MTS offers two standard sensor housings, rod and profile extrusion.
The rod housing is capable of withstanding high pressures such as
those found in hydraulic cylinders. The profile extrusion housing
provides convenient mounting options and captive sliding magnets
which utilize slide bearings of special material that reduce friction, and
help mitigate dirt build up. The sensor head contains the active signal
conditioning and a complete integrated electronics interface. Double
shielding is used to ensure EMI protection for unsurpassed reliability
and operating safety.
Temposonics R-Series models RP and RH linear-position sensors
fulfill all requirements of Profibus-DP (EN 50170) protocol. They also
provide absolute position data to Profibus control units by using a
serial, bit synchronous, RS-485 format at a baud rate up to 12 Mbps
maximum.
In addition to data transmission, Profibus-DP provides powerful func-
tionality for diagnostics and configuration, which is loaded into the
bus using the GSD electronic device data sheet file. The download-
able .gsd file for Temposonics Profibus model sensors is available at
http://www.mtssensors.com.
* UL Recognition requires an approved power supply with energy limitation UL 61010-
1), or Class 2 rating according to the National Electrical Code (USA) / Canadian
Electrical Code.
** The IP rating is not part of the UL Recognition.

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014
3
R-Series Models RP/RH Sensors with Profibus-DP Output
Enhanced Monitoring and Diagnostics, Output Parameters
Enhanced monitoring and diagnostics
SENSOR STATUS AND DIAGNOSTIC DISPLAY
Integrated diagnostic LEDs (green/red), located beside sensor con-
nectors (see ‘Figure 1’), provide basic visual monitoring for normal
sensor operation and troubleshooting. diagnostic display LEDs
indicate four modes described in ‘Table 1’.
Figure 1. R-Series sensor Integrated diagnostic LEDs
Profibus-DP output parameters
When using multiple magnets, the minimum allowed distance
between magnets is 75 mm (3. in.) to maintain proper sensor output
(see ‘Figure 2’).
Figure 2.
Temposonics®
R-Series
R
®
Single-magnet sensor
Multi-magnet sensor
M1
M1A
Active stroke range
Position / Velocity
M0 M1 M3
M4
Position / Velocity
75 mm
(3 in.) min.
M2
Temposonics®
R-Series
R
®
Single and multi-magnet output diagram
Green Red Operation status/mode
ON OFF Normal function (operation mode)
ON ON Magnet not detected or wrong
quantity of magnets
Flashing OFF Waiting for master parameters
Flashing ON Programming mode
Table 1. Diagnostic display indicator modes
R-Series sensors with Profibus-DP output are compliant with Profibus
DP slave class 2 and have the following features:
Selectable outputs:
• Absolute position measurement
• Velocity measurement
• Sensor Status
• Error detection (e.g. magnet status)
Selectable parameters:
• Offset / preset for each magnet
• Measuring direction; forward and reverse acting
• Intel®and Motorola®data format transfers
OPERATION MODES
R-Series sensors with Profibus-DP protocol provide the following
single or multi-magnet measurements:
Standard measurement (P102 output code):
• Position (using one magnet)
Multi-magnet measurement (P101 output code):
• Position (using up to 20 magnets simultaneously)
Multi-magnet measurement (P103 output code):
• Position + velocity (using up to 5 magnets simultaneously)
Profibus-DP communication and functionality
DATA EXCHANGE
For multi-magnet measurement, 1 status byte and 3 bytes of position
data for each position are transmitted. The status byte contains an
error bit and the position number for the following measurement
value. Dependent on sensor parameters, sensor data can be trans-
ferred in different data formats, (e.g. Intel®or Motorola®)
LINEARITY CORRECTION OPTION (LCO)
The Linearity Correction Option (LCO) provides improved sensor
output accuracy. For most stroke lengths linearity accuracy is im-
proved up to a factor of 5, resulting in deviations from actual position
of less than ± 20 microns (0.0008 in.). For stroke lengths over 5000
mm (197 in.) the linearity accuracy is improved up to a factor of 10.
Selecting the sensor style and magnet is important (both must be
matched together). Contact the factory for assistance when design-
ing for the LCO in your application.

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014 4
Models RP and RH Programming Accessories
Model RP Profile-Style Sensor Dimension References
The Profibus-DP Handheld Address Programmer (see ‘Figure 3’) is offered as an acces-
sory used to setup the Slave Address via the Profibus-DP interface. Addressing is usu-
ally performed by the Profibus-DP SetSlaveAddress command. If the master system or
controller does not support this service, connecting the Profibus-DP Handheld Address
Programmer to the sensor will bypass the service and allow direct setup.
When ordering the Profibus-DP Node and Field Address Programmer accessory, for
D53 and D63 style connections, order part no.: 280640. The Profibus-DP Node and
Address Programmer Installation instructions (document part no.: 551193) is available
in PDF format at http://www.mtssensors.com. Figure 3. R-Series Profibus-DP Handheld Address
Programmer, part no.: 280640
Model RP profile-style sensor dimension references
MODEL RP, PROFILE-STYLE SENSOR WITH STYLE S CAPTIVE-SLIDING MAGNET
Drawing is for reference only, contact applications engineering for tolerance specific information.
Electronics
Housing
Beginning of stroke 'Null' position End of stroke 'Span' position
Captive-sliding magnet
Style 'S'
Mounting foot, moveable
(part no.: 400802)
D53 Connector option
28 mm
(1.10 in.)
82 mm (3.2 in.)
Dead zone
12 mm
(0.47 in.)
Null zone
Stroke length
100 mm
(3.9 in.) 14.5 mm
(0.57 in.)
19 mm
(0.75 in.)
5.5 mm (0.21 in.) dia.
for M5 or #10 screw (2 ea.)
45 mm
(1.77 in.)
2 mm
(0.07 in.)
9 mm
(0.36 in.)
49 mm
(1.92 in.)
50 mm
(1.97 in.)
68 mm (2.68 in.)
Figure 4. R-Series Model RP Profile-style sensor dimension reference (Shown with the D53 connector option)
MODEL RP, PROFILE-STYLE SENSOR WITH STYLE M OPEN-RING MAGNET
Drawing is for reference only, contact applications engineering for tolerance specific information.
Electronics
Housing
Open-ring magnet Style 'M'
Mounting support
(non-ferrous material)
D63 Connector option
Mounting foot, moveable
(part no.: 400802)
Beginning of stroke 'Null' position
End of stroke 'Span' position
28 mm
(1.10 in.)
66 mm (2.6 in.)
Dead zone
28 mm
(1.10 in.)
Null zone
Stroke length
5.5 mm (0.21 in.) dia.
for M5 or #10 screw (2 ea.)
45 mm
(1.77 in.)
2 mm
(0.07 in.)
9 mm
(0.36 in.)
49 mm
(1.92 in.)
50 mm
(1.97 in.)
68 mm (2.68 in.)
14.5 mm
(0.57 in.)
95 mm
(3.7 in.)
14 mm
(0.55 in.)
Figure 5. R-Series Model RP Profile-style sensor dimension reference (Shown with the D63 connector option)
Programming accessory Function Part number
Profibus handheld address programmer For sensors with the D63 connection type 280640
Profibus handheld address programmer For sensors with the D53 connection type 280640
Profibus master simulator Check sensor operation using Bihl + Wiedemann, Model 1131 401727
Master simulator cable For sensors with the D63 connection type 401726
Master simulator cable For sensors with the D53 connection type 252383
Profibus noise filter box Junction box with noise filter for connecting 24 Vdc input power on to the bus when using
the hybrid Profibus cable, (D63 connection type). 252916
Profibus-DP handheld address programmer

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014
5
Model RP Profile-Style Sensor Dimensions
Standard Magnet Selections
MODEL RP, PROFILE-STYLE SENSOR WITH STYLE V CAPTIVE-SLIDING MAGNET Drawing is for reference only, contact applications
engineering for tolerance specific information.
Electronics
Housing
Captive-sliding magnet
Style 'V'
A05 Integral cable option
Mounting foot, moveable
(part no.: 400802)
5.5 mm (0.21 in.) dia.
for M5 or #10 screw (2 ea.)
45 mm
(1.77 in.)
2 mm
(0.07 in.)
9 mm
(0.36 in.)
49 mm
(1.92 in.)
50 mm
(1.97 in.)
68 mm (2.68 in.)
Beginning of stroke 'Null' position End of stroke 'Span' position
82 mm (3.2 in.)
Dead zone
12 mm (0.47 in.)
Null zone
Stroke length
30 mm
(1.2 in.)
111 mm (4.4 in.)
Figure 6. R-Series Model RP Profile-style sensor dimension reference (Shown with the A05 integral cable option)
Standard magnet selections (Model RP)
SELECTION OF POSITION MAGNETS (ONE MAGNET INCLUDED WITH MODEL RP SENSOR)
A choice of two magnet mounting configurations are available with the profile-style sensor; A ‘captive-sliding’ magnet, Styles S
or Vor an ‘open-ring’ magnet, Style M. Captive-sliding magnets utilize slide bearings of special material that reduce friction, and
if required, help mitigate dirt build up. The slide bearings are designed to operate dry, requiring no external lubrication or maintenance.
The Style M ‘open-ring’ magnet mounts on the moving machine part and travels just above the sensor’s profile extrusion. The open-ring
magnet requires a minimum distance away from ferrous metals to allow proper sensor output. It must be mounted using non-ferrous screws
and a non-ferrous support bracket, or utilize a non-ferrous spacer of at least 5 mm (0.2 in.) thickness.
POSITION MAGNET SELECTIONS (Drawing dimensions are for reference only)
Magnet dimensions and mounted magnet dimensions Description Part number
40 mm
(1.58 in.)
25 mm
(1 in.)
20 mm
(0.79 in.)
43 mm
(1.69 in.)
14 mm
(0.55 in.)
Rotation:
Vertical: 18°
Horizontal: 360°
Ball-jointed arm
(M5 thread)
Captive-sliding magnet, Style S
For Model RP profile-style sensor 252182
40 mm
(1.58 in.)
25 mm
(1 in.)
9 mm
(0.35 in.)
57 mm
(2.24 in.)
14 mm
(0.55 in.)
Rotation:
Vertical: 18°
Ball-jointed arm
(M5 thread)
Captive-sliding magnet,
Style V
For Model RP profile-style sensor
252184
21 mm
(0.81 in.)
25 mm
(0.97 in.)
14 mm
(0.55 in.)
2 Holes
Each 4.3 mm
(0.17 in.) dia. on
24 mm (0.94 in.) dia.
60°
Open-ring magnet,
Style M
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.31 in.)
Operating temperature:
- 40 °C to 100 °C
This magnet may influence the
sensor performance specifications
for some applications.
251416-2
45 mm
(1.77 in.)
52 mm
(2.05 in.)
36 mm
(1.41 in.)
21 mm
(0.81 in.)
29 mm
(1.14 in.)
Max gap
3 mm ± 1 mm
(0.12 in. ± 0.04 in.)
Non-ferrous mounting support
and screws
Open-ring magnet Style ‘M’

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014 6
Model RP Profile-Style Sensor
Mounting
Model RP Sensor mounting
MODEL RP PROFILE-STYLE SENSOR MOUNTING flexible installation in any position!
Temposonics Model RP profile-style sensors offer two basic mounting methods; side grooves for use with mounting feet or a bottom groove
that accepts special T-Slot nuts. Both the mounting feet and T-Slot nuts can be positioned along the sensor extrusion to best secure the sensor
for each particular application.
Notes:
1. Model RP sensors include two mounting feet (part no. 400802) for sensors stroke lengths up to 1250 mm (50 in.)
2. One additional mounting foot is included for stroke lengths over 1250 mm (50 in.) and for each additional 500 mm (20 in.),
thereafter.
3. MTS recommends using 10-32 cap screws (customer supplied) at a maximum torque of 44 in. lbs. when fastening mounting feet.
Profile-Style sensor mounting and installation reference Mounting method Part number
(Width = 14.5 mm (0.57 in.)
Mounting feet, standard (304 SS)
Profile-style sensor mounting for sen-
sor model RP
400802
10 - 32 Cap screws
Recommended
(Customer supplied)
Mounting feet and screws
Profile-style sensor foot installation
See Mounting
Feet
part number:
400802
T-Slot nut
Nut for mounting model RP sensor
M5 thread
(Optional, ordered separately)
401602
4 Holes
5.3 mm
(0.21 in.) dia.
28 mm
(1.1 in.) 9 mm
(0.36 in.)
50 mm
(1.97 in.)
2 mm
(0.08 in.) 68 mm
(2.68 in.)
9 mm
(0.36 in.)
Mounting foot and screws
5 mm (0.20 in.)
T-Slot nut, M5 thread
Detail
M5 Threaded
stud and nut

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014
7
Model RH Rod-Style Sensor
Dimension References
Model RH rod-style sensor dimension reference
The Temposonics R-Series rod-style sensor (Model RH) offers modular con-
struction, flexible mounting configurations, and easy installation. The Model RH
sensor is designed for mounting in applications where high pressure conditions
exist (5000 psi continuous, 10,000 psi spike), such as inside hydraulic cylinders.
The Model RH sensor (see Figures 7, 8 and 9) may also be mounted externally
in many applications.
Stroke-dependent Dead Zones:
Stroke length:
25 mm (1 in.) - 5000 mm (197 in.)
5005 mm (197 in.) - 7620 mm (300 in.)
Dead zone:
63.5 mm (2.5 in.)
66 mm (2.6 in.)
MODEL RH, ROD-STYLE SENSOR DIMENSION REFERENCE
Drawing is for reference only, contact applications engineering for tolerance specific information.
Figure 7. Model RH Rod-style sensor dimension reference (shown with D63 connector option
Electronics
Housing
D63 Connector option
Beginning of stroke 'Null'
position
End of stroke 'Span'
position
Dead Zone
63.5 mm (2.5 in)
66 mm (2.6 in.)‡
Stroke length
45 mm
(1.77 in.)
49 mm
(1.92 in.)
99 mm
(3.9 in.)
Position magnet
Flat-faced hex
flange Type 'S'
(see 'Table 2)
Sensor rod
10 mm (0.39 in.) dia.
10 mm
(0.39 in.)
14 mm
(0.55 in.)
51 mm (2 in.)
Null zone
25 mm (0.98 in.)
O-Ring ‡ For stroke lengths > 5000 mm (197 in.
)
)
MODEL RH, ROD-STYLE SENSOR WITH RING MAGNET (MAGNET ORDERED SEPARATELY)
Drawing is for reference only, contact applications engineering for tolerance specific information.
Figure 8.
Electronics
Housing
Beginning of stroke 'Null'
position
End of stroke 'Span'
position
D53 Connector option
51 mm (2 in.)
Null zone Stroke length
104 mm
(4.09 in.)
19 mm
(0.75 in.)
45 mm
(1.77 in.)
49 mm
(1.92 in.)
Raised-faced hex
flange Type 'T'
(see 'Table 2')
Sensor rod 10 mm (0.39 in.) dia.
10 mm
(0.39 in.)
25 mm (0.98 in.) Position magnet
O-Ring
Dead Zone
63.5 mm (2.5 in)
66 mm (2.6 in.)‡
‡ For stroke lengths > 5000 mm (197 in.
)
25 mm (1 in.)
2.5 mm (0.10 in.)
Model RH Rod-style sensor dimension reference (shown with D53 connector option)
MODEL RH, ROD-STYLE SENSOR WITH RING MAGNET (MAGNET ORDERED SEPARATELY)
Drawing is for reference only, contact applications engineering for tolerance specific information.
Figure 9.
Electronics
Housing
A05 Integral cable option
45 mm
(1.77 in.)
49 mm
(1.92 in.)
85 mm
(3.3 in.)
Beginning of stroke 'Null'
position
End of stroke 'Span'
position
Stroke length
Flat-faced hex
flange Type 'S'
(see 'Table 2')
10 mm
(0.39 in.)
51 mm (2 in.)
Null zone
25 mm (0.98 in.) Position magnet
30 mm
(1.2 in.)
O-Ring
Dead Zone
63.5 mm (2.5 in)
66 mm (2.6 in.)‡
Sensor rod
10 mm (0.39 in.) dia.
‡ For stroke lengths > 5000 mm (197 in.
)
Model RH Rod-style sensor dimension reference (Shown with the A05 Integral cable connection type option)
Housing style
Flange type Description
(A)
Flange threads
(B)
Dimensions
(C)
Dimensions
B
C
A
TUS customary threads with raised-face flange 3/4" - 16 UNF-3A 1.75 in. 2 in.
SUS customary threads with flat-faced flange 3/4" - 16 UNF-3A 1.75 in. 2 in.
MMetric threads with flat-faced flange M18 x 1.5 46 mm 53 mm
Table 2. Model RH Rod-style sensor housing style and flange type references

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014 8
Model RH Rod-Style Sensor
Standard Magnet Selections
Standard magnet options (Model RH)
Magnets must be ordered separately with Model RH position sensors. The standard ring magnet (part number 201542-2) is suitable for most
applications.
POSITION MAGNET SELECTIONS (Magnet must be ordered separately) (Drawing dimensions are for reference only)
Magnet and magnet dimensions Description Part number
Standard ring magnet
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
201542-2
Magnet spacer
(Non-ferrous, use with ring magnet
Part number: 201542-2)
I.D.: 14 mm (0.56 in.)
O.D.: 32 mm (1.25 in.)
Thickness: 3.2 mm (0.125 in.)
400633
Ring magnet
I.D.: 13.5 mm (0.53 in.)
O.D.: 25.4 mm (1 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
400533
Open-ring magnet, Style M
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
This magnet may influence the sensor perfor-
mance specifications for some applications.
251416-2
MAGNET FLOAT SELECTION (Drawing dimensions are for reference only)
Magnet float
(Level sensing applications)
Specific gravity: 0.70 maximum
Pressure: 870 psi maximum
(This float is used with Model RH rod-style
sensors for hydraulic fluid or fresh water
applications only). Collar (part no.: 560777)
is recommended for end of stroke stops.
251447
4 Holes
Each 4.3 mm (0.17 in.) dia.
90° apart on
24 mm (0.94 in.) dia.
4 Holes
Each 4.3 mm (0.17 in.) dia.
90° apart on
24 mm (0.94 in.) dia.
21 mm
(0.81 in.)
25 mm
(0.97 in.)
14 mm
(0.55 in.)
2 Holes
Each 4.3 mm
(0.17 in.) dia. on
24 mm (0.94 in.) dia.
60°
14 mm (0.55 in.) Min. I.D.
51 mm (2 in.)
Spherical O.D.
3.4 mm (0.13 in.)
C
L
53 mm
(2.1 in.)

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014
9
Model RH Rod-Style Sensors
Mounting, Connections and Wiring
Connections and wiring
BUS / INPUT VOLTAGE CONNECTION OPTIONS (DAISY-CHAIN TOPOLOGIES)
(D63) CONNECTOR OPTION
The shielded hybrid cable (5 wires; two bus, two power supply and 1
machine ground, part no.: 530040) is used for both bus and supply
voltage (D63) connections. This provides convenient daisy-chain
connections for applications with multiple Profibus-DP sensors.
Profibus
24 Vdc
RxD/TxD-N
RxD/TxD-P
DGND
VP
220 Ohms
390 Ohms
390 Ohms
1
6
2
3
4
5
Probus Terminator
(D53) CONNECTOR OPTION
For (D53) connection types, a separate 4-pin connector and cable is
used for the supply voltage.
Probus Terminator
Profibus
24 Vdc
male
female
(D53) CONNECTOR OPTION WITH THE 'T' CONNECTOR
A 'T' connector is used with the separate bus cable to enable the
bus to remain active when a sensor is disconnected.
24 Vdc
Profibus
Probus Terminator
Model RH Rod-Style sensor mounting
The position magnet requires minimum distances away from ferrous
metals to allow proper sensor output. The minimum distance from
the front of the magnet to the cylinder end cap is 15 mm (0.6 in.).
The minimum distance from the back of the magnet to the piston
head is 3.2 mm (0.125 in.). However, a minimum distance of at
least 5 mm (0.197 in.) is preferred for added performance margin.
The non-ferrous spacer part no.: 400633) provides this minimum
distance when used along with the standard ring magnet (part no.:
201542-2) as shown in Figure 10.
Figure 10.
Non ferrous
spacer
> 15 mm
(0.6 in.)
Min. 3.2 mm
(0.125 in.)
Ring magnet
n fer
cer
mm
mm
.)
(0.125 in.)
magnet
Ring m
No
n
sp
a
Min. 3.2 mm
magnet
Ring m
Cylinder end cap
Piston head
Temposonics®
R-Series
R
®
Model RH rod-style mounting
Cylinder installation
When used for direct-stroke measurement in fluid cylinders,
the sensor's high pressure, stainless steel rod installs into a bore in
the piston head/rod assembly as shown in Figure 11. This method
guarantees a long-life and trouble-free operation.
The sensor cartridge can be removed from the flange and rod hous-
ing while still installed in the cylinder. This procedure allows quick
and easy sensor cartridge replacement, without the loss of hydraulic
pressure.
The sensor’s rod housing and flange can remain
permanently installed in the cylinder
Ring magnet
The sensor cartridge consist of the electronics housing
and sensing element and is easy to replace by removing
(2) M4 thread 2.5 mm hex socket head screws
Figure 11. Fluid cylinder installation

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014 10
Model RP and RH Sensors
Connections and Wiring
Connections and wiring (D63)
(D63) BUS CONNECTOR OPTION PINOUTS/FUNCTIONS
D63 Male
6-pin outlet
D63 Female
6-pin outlet
MALE/FEMALE, 6-PIN (D63) INTEGRAL CONNECTOR
OPTION FOR SHIELDED HYBRID CABLE FOR BUS AND
INPUT VOLTAGE
1
23
64
5
1
2
3
6
4
5
Male, 6-pin (M16) integral connector pin-out
as viewed from the end of the sensor
1
23
64
5
1
2
3
6
4
5
Female, 6-pin (M16) integral connector pin-out
as viewed from the end of the sensor
Pin number
Cable
wire color Function
1 Green RxD/TxD-N (Bus)
2 Red RxD/TxD-P (Bus)
3 N/A DGnd (Bus termination)
female connector only
4 N/A VP (Bus termination) female
connector only
5 Black +24 Vdc (-15/+20%)
6 Blue DC ground (for supply)
N/A Yellow/
Green
Shielding, machine ground
Connections and wiring (D53)
(D53) BUS CONNECTOR OPTION PINOUTS/FUNCTIONS
D53
Male
5-pin outlet
D53
Female
5-pin outlet
D53
Male, 4-pin
Input voltage
MALE/FEMALE, 5-PIN (D53) INTEGRAL CONNECTOR
OPTION
1
2
3
54
53
4
1
2
Male, 5-pin (M12) integral connector pin-out
as viewed from the end of the sensor
1
2
3
54
53
4
1
2
Female, 5-pin (M12) integral connector pin-out
as viewed from the end of the sensor
Pin number
Cable
wire color Function
1 N/A VP+5 (Bus termination)
female connector only
2 Green RxD/TxD-N (Bus)
3 N/A. DGnd (Bus termination)
female connector only
4 Red RxxD / TxD-P (Bus)
5 Shield Shield
(D53) INPUT VOLTAGE INTEGRAL CONNECTOR OPTION
3
4
2
1
Input voltage, male, 4-pin (M8) integral
connector pin-out as viewed from the end of
the sensor
Pin number Wire color Function
1 Brown +24 Vdc (-15/+20%)
2 White No connection
3 Blue DC ground (for supply)
4 Black No connection

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014
11
(D63) CABLE CONNECTOR OPTIONS (FIELD INSTALLABLE) (Drawing dimensions are for reference only)
Connector and connector dimensions Description Part number
Cable connector, female,
straight exit (field installation)
6-pin DIN (M16) PG9 size strain relief
370423
Cable connector, male,
straight exit (field installation)
6-pin DIN (M16) PG9 size strain relief
370427
Profibus Bus terminator, male 6-pin
DIN (M16) 252347
(D53) CABLE CONNECTOR OPTIONS (FIELD INSTALLABLE)
Cable connectors and dimension references Description Part number
5-pin Profibus (M12) T connector
(D53 field installable) 560887
5-pin Profibus female connector
(M12)
(D53 field installable)
560885
5-pin Profibus male connector
(M12)
(D53 field installable)
560884
5-pin Profibus bus terminator (M12)
(D53 field installable) 560888
5-pin male connector (M12)
90° exit
(Field installable)
370515
54 mm
(2.1 in.)
18 mm
(0.7 in.)
58 mm
(2.28 in.)
18 mm
(0.7 in.) dia.
48 mm
(1.9 in.)
18 mm
(0.7 in.) dia.
70 mm
(2.75 in.)
40 mm
(1.58 in.)
41 mm
(1.6 in.)
9 mm
(0.36 in.)
29 mm
(1.15 in.)
19 mm
(0.74 in.) dia.
20 mm
(0.77 in.)
57 mm
(2.24 in.)
20 mm
(0.77 in.)
62 mm
(2.44 in.)
16 mm
(0.64 in.)
43 mm
(1.69 in.) 22 mm
(0.87 in)
14 mm
(0.55 in.)
54 mm
(1.12 in.)
40 mm
(1.57 in.)
Models RP and RH Sensors
Cable Connector Options

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014
Cable connectors and dimension references Description Part number
5-pin female connector (M12)
90° exit
(Field installable)
370514
4-pin (M8) female connector
straight exit
(Field installable)
370504
4-pin (M8) female cable connector
90°exit, Adjustable
(Field installable)
560886
EXTENSION CABLE WITH CONNECTORS FOR (D63) CONNECTION TYPES
Extension cable and connector assemblies Description Connection type
Hybrid Profibus Bus Cable, straight exit, 6-pin DIN female connec-
tor, with PG9 strain relief for (D63) sensor connection types
(Assembly Includes D63 Connector, Part no.: 370423 and Cable, Part
no.:530040)
Type DF
Hybrid Profibus Bus Cable, straight exit, 6-pin DIN male connector
with PG9 strain relief for (D63) sensor connection types
(Assembly Includes D63 Connector, Part no.: 370427 and Cable, Part
no.:530040)
Type DG
ORDERING INFORMATION - EXTENSION CABLE WITH CONNECTORS FOR (D63) CONNECTION TYPE
D
1 2 3 4 5 6 7 8
SENSOR CONNECTION TYPES =
D
1 - 2
DF =Female connector, straight exit (part no. 370423), and Profibus cable (part no.: 530040) with (D63) type connector
DG =
Female connector, 90° exit (part no. 560778), and Profibus cable (part no.: 530040) with (D63) type connector
CABLE LENGTHS =3 - 5
For standard length cables up to 100 ft.
005
=
5 ft.
015
=
15 ft.
025
=
25 ft.
050
=
50 ft.
100
=
100 ft.
For custom length cables over 100 ft.
— — — = Cable length (maximum cable length is dependent on baud rate).
CABLE TERMINATION =6 - 8
P0 =
Pigtail cable without connector
DFM =
Male connector, (Straight exit). For daisy-chain connections of Profibus sensors with D63 connector.
DGM =
Male connector, (90° exit). For daisy-chain connections of Profibus sensors with D63 connector.
54 mm
(2.12 in.)
38 mm
(1.5 in.)
40 mm
(1.58 in.)
12 mm
(0.58 in.) dia.
12 mm
(0.47 in)
28 mm
(1.1 in.) 12.5 mm
(0.49 in.)
12
Model RP and RH Sensors
Cable connector options

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - Profibus-DP Output
Product Data Sheet, Document Part No.: 550990 Revision C (EN) 05/2014
R 1 P
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
SENSOR MODEL =R1-2
RP =
Profile style
RH
= Hydraulic rod style
HOUSING STYLE =3
Model RP profile-style sensor (includes one magnet):
S=
Captive-sliding magnet with ball joint
at top (Part no. 252182)
V
=
Captive-sliding magnet with ball
joint at front (Part no. 252184)
M
=
Open-ring magnet
(Part no. 251416-2)
Model RH rod-style sensor (magnet(s) must be ordered separately):
T=
US customary threads, raised-faced
flange and pressure tube, standard
U
=
Same as option “T”, except uses
fluoroelastomer seals for the
electronics housing
B
=
Sensor cartridge only (no
flange and pressure tube,
stroke length
< 1830 mm (72 in.))
S=
US customary threads, flat-faced
flange and pressure tube, standard
H
=
Same as option “S”, except uses
fluoroelastomer seals for the
electronics housing
M=
Metric threads, flat-faced flange and
pressure tube, standard
V
=
Same as option “M”, except uses
fluoroelastomer seals for the
electronics housing
STROKE LENGTH
=
4-8
— — — — M
=
Millimeters
(Encode in 5 mm increments)
Stroke Length Notes:
— — — . — U
=
Inches and tenths
(Encode in 0.1 in. increments) 1. Profile-style sensor (model RP) stroke range = 25 mm (1 in.) - 5080 mm. (200 in.)
2. Rod-style sensor (model RH) stroke range = 25 mm (1 in.) - 7620 mm (300 in.)
CONNECTION TYPES =9-11
Integral connector:
D63
=
Two 6-pin DIN (M16), male/female, standard
D53
=
Two 5-pin DIN (M12), male/female plus one 4-pin (M8) male
Integral cable:
Cable Length Note:
A — —
=
Integral cable, Hybrid Profibus with pigtail termination
MTS recommends the maximum integral
cable length to be 10 meters (33 ft.). Cables
greater than 10 m (33 ft.) in length are
available, however, proper care must be taken
during handling and installation.
Cable length:
Encode in feet if using US customary stroke length
Encode in meters if using metric stroke length
>——=3 (03) to 98 (98) ft. or 1 (01) to 30 (30) meters.
INPUT VOLTAGE =12
1=
+24 Vdc (+20% - 15%)
13
Models RP and RH Sensors
Ordering Information
OUTPUT (13 - 16) =P13-16
P — — —
[1] [2] [3] = Profibus-DP protocol - Enter the 3 digit output code (1-3) defined by the following selections
[1] [2] [3] Protocol
101
=
Multi-magnet (multi-position measurement) max. 20 positions
102
=
Single magnet measurement (standard)
103
=
Position, velocity (max. 5 positions and 5 velocities)
202L
=
Multi-magnet, up to 20 magnets with Linearity Correction Option (LCO)
NUMBER OF MAGNETS (17- 19) FOR MULTI-POSITION MEASUREMENT ONLY
Z+ Enter a 2 digit code
= Z17-19
Z — —
[1] [2] =
If output
P101 or P202L is entered, enter a number between (02 - 20).
If output
P103 is entered, enter a number between (02 - 05)
(For multi-position measurements, additional magnets are ordered separately.)

Document Part number:
550990 Revision C (EN) 05/2014
MTS, Temposonics and Level Plus are registered trademarks of MTS Systems Corporation. All
other trademarks are the property of their respective owners. Printed in USA. Copyright © 2014
MTS Systems Corporation. All Rights Reserved in all media.
All specifications are subject to change. Contact MTS for specifications and engineering
drawings that are critical to your application. Drawings contained in this document are for
reference only. Go to http://www.mtssensors.com for the latest product information.
LOCATIONS
LEGAL NOTICES
USA
MTS Systems Corporation
Sensors Division
3001 Sheldon Drive
Cary, N.C. 27513, USA
Tel. [phone]
Fax [phone]
[email protected]
www.mtssensors.com
GERMANY
MTS Sensor Technologie
GmbH & Co. KG
Auf dem Schüffel 9
58513 Lüdenscheid, Germany
Tel. + 49 2351 9587-0
Fax + 49 2351 56491
[email protected]
www.mtssensor.de
JAPAN
MTS Sensors Technology Corp.
737 Aihara-machi,
Machida-shi,
Tokyo 194-0211, Japan
Tel. + 81 42 775-3838
Fax [phone]
[email protected]
www.mtssensor.co.jp
FRANCE
MTS Systems SAS
Zone EUROPARC Bâtiment EXA 16
16/18, rue Eugène Dupuis
94046 Creteil, France
Tel. + 33 1 58 4390-28
Fax [phone]
[email protected]
www.mtssensor.com
ITALY
MTS Systems Srl.Sensor Division
Via Diaz,4
25050 Provaglio d‘Iseo (BS), Italy
Tel. + 39 030 988 3819
Fax [phone]
[email protected]
www.mtssensor.com
CHINA
MTS Sensors
Room 504, Huajing Commercial Center,
No. 188, North Qinzhou Road
200233 Shanghai, China
Tel. [phone]
Fax [phone]
[email protected]
www.mtssensors.cn
