MTS Sensors TempoLink Smart Assistant User manual

TempoLink Smart Assistant
Operation Manual
Temposonics®
Magnetostrictive Linear Position Sensors
GENERATION
I AM
V
THE NEW

TempoLink Smart Assistant
Operation Manual
I2 I
Table of contents
1. Introduction............................................................................................................................... 3
2. Safety instructions....................................................................................................................... 4
2.1 Intended use ..................................................................................................................................................................4
2.2 Foreseeable misuse........................................................................................................................................................4
2.3 Installation, commissioning and operation ....................................................................................................................5
2.4 Safety instructions for use in explosion-hazardous areas ..............................................................................................5
2.5 Warranty ........................................................................................................................................................................5
2.6 Return............................................................................................................................................................................5
2.7 Removal.........................................................................................................................................................................5
3. Package content ......................................................................................................................... 6
4. Connection of TempoLink smart assistant to R-Series Vsensor................................................................. 6
5. Connection of TempoLink smart assistant to power supply ....................................................................... 7
5.1 Using the plug-in power supply with plug adapters ......................................................................................................7
5.2 Using the cable for insertion in an existing sensor power supply with sensor mating connector and barrel connector.7
6. Connection of TempoLink smart assistant to smartphone, tablet or computer................................................. 7
6.1 Connecting a Wi-Fi enabled device to the integrated Wi-Fi access point........................................................................7
6.2 Connecting a computer via USB connection ..................................................................................................................7
7. Establishing a connection via browser ............................................................................................... 8
8. Graphical user interface ................................................................................................................ 8
9. LEDs of TempoLink smart assistant................................................................................................... 9

TempoLink Smart Assistant
Operation Manual
I3 I
1. Introduction
1.1 Purpose and use of this manual
Before starting the operation of TempoLink smart assistant,
read this documentation thoroughly and follow the safety
information. Keep this manual for future reference!
The content of this technical documentation is intended
to provide information on mounting, installation and
commissioning by qualified automation personnel 1 or
instructed service technicians who are familiar with the
project planning and dealing with Temposonics®products.
1.2 Used symbols and warnings
Warnings are intended for your personal safety and for
avoidance of damage to the described product or connected
devices. In this documentation, safety information and
warnings to avoid danger that might affect the life and health
of operating or service personnel or cause material damage
are highlighted by the pictogram, defined below.
Symbol Meaning
This symbol is used to point to situations
that may lead to material damage, but not
to personal injury.
1/ The term “qualified technical personnel” characterizes
persons who
• are familiar with the safety concepts of automation
technology applicable
to the particular project and
• are competent in the field of electromagnetic compatibility
(EMC) or
• have received adequate training for commissioning and
service operations or
• and are familiar with the operation of the device and know the
information required for correct operation provided in the
product documentation
NOTICE

TempoLink Smart Assistant
Operation Manual
I4 I
2.1 Intended use
This product may be used only for the applications defined
under item 1 and item 2 and only in conjunction with the
third-party devices and components recommended or
approved by MTS Sensors. As a prerequisite of proper
and safe operation, the product requires correct transport,
storage, mounting and commissioning and must be operated
with utmost care.
1. The sensor systems of all Temposonics®series are
intended exclusively for measurement tasks encountered
in industrial, commercial and laboratory applications. The
sensors are considered as system accessories and must
be connected to suitable evaluation electronics, e.g. a
PLC, IPC, indicator or other electronic control unit.
2. TempoLink smart assistant is an accessory for
Temposonics R-Series Vsensors for reading out and
adjusting of sensor parameters as well as monitoring
status values.
2.2 Foreseeable misuse
2. Safety instructions
Do not alter the sensor assistant.
The sensor assistant might be damaged.
Do not step on the sensor assistant.
The sensor assistant might be damaged.
Foreseeable misuse Consequence
Wrong sensor connection
The sensor and TempoLink smart
assistant will not work
properly or can be damaged
Power supply is out of the defined
range
The TempoLink smart assistant
can be damaged
Cables are damaged
Short circuit – the sensor and
TempoLink smart assistant can
be destroyed / sensor does not
respond
Wrong connection
of ground / shield
Signal output is disturbed
The electronics can be damaged

TempoLink Smart Assistant
Operation Manual
I5 I
2.3 Installation, commissioning and operation
The position sensors and TempoLink smart assistant must
be used only in technically safe conditions. To maintain
this condition and to ensure safe operation, installation,
connection and service, work may be performed only by
qualified technical personnel.
If danger of injury to persons or of damage to operating
equipment is caused by sensor failure or malfunction,
additional safety measures such as plausibility checks, limit
switches, EMERGENCY STOP systems, protective devices
etc. are required. In the event of trouble, shut down the
sensor and protect it against accidental operation.
Safety instructions for commissioning
To maintain the sensor and TempoLink smart assistant
operability, it is mandatory to follow the instructions given
below.
1. Protect the sensor and TempoLink smart assistant
against mechanical damage during installation and
operation.
2. Do not open or dismantle the sensor and TempoLink
smart assistant.
3. Connect the sensor and TempoLink smart assistant very
carefully and pay attention to the polarity of connections
and power supply.
4. Use only approved power supplies.
5. Ensure the sensor and TempoLink smart assistant are
operating within the defined limits for supply voltage,
environmental conditions, etc.
6. Check the function of the sensor and TempoLink smart
assistant regularly and provide documentation of the
checks.
7. Before system switch-on, ensure that nobody’s safety
is jeopardized by starting machines.
2.4 Safety instructions for use in explosion-hazardous
areas
The sensors are not suitable for operation in explosion-
hazardous areas.
2.5 Warranty
MTS Sensors grants a warranty 2period for the Temposonics®
position sensors and supplied accessories relating to
material defects and faults that occur despite correct use in
accordance with the intended application. The MTS Sensors
obligation is limited to repair or replacement of any defective
part of the unit. No warranty can be taken for defects that are
due to improper use or above average stress of the product,
as well as for wear parts. Under no circumstances will MTS
Sensors accept liability in the event of offense against the
warranty rules, no matter if these have been assured or
expected, even in case of fault or negligence of the company.
MTS Sensors explicitly excludes any further warranties.
Neither the company’s representatives, agents, dealers nor
employees are authorized to increase or change the scope of
warranty.
2.6 Return
For diagnostic purposes, the sensor can be returned to
MTS Sensors or a repair facility explicitly authorized by MTS
Sensors. Any shipment cost will be borne by the sender 2.
2.7 Removal
The product contains electronic components and must be
disposed of in accordance with the local regulations.
2/ See also applicable MTS Sensors sales and supply
conditions, e.g. under www.mtssensors.com

TempoLink Smart Assistant
Operation Manual
I6 I
3. Package content 4. Connection of TempoLink smart assistant to
R-Series Vsensor
The TempoLink smart assistant can be connected to all
sensors of the R-Series Vfamily. Use the adpater cable for
connection of the TempoLink smart assistant to the R-SeriesV
sensor. Connect the barrel connector of the adapter cable
to the connection point labeled “OUTPUT SENSOR” on the
TempoLink smart assistant. Next, connect the opposite end of
the adapter cable to the power supply at the R-Series Vsensor.
The TempoLink smart assistant also provides the supply power
for the sensor.
If the sensor is connected to another power supply
disconnect the power supply before connecting TempoLink
smart assistant to the sensor.
TempoLink smart assistant
Plug-in power supply with plug adapters or cable for
insertion in an existing sensor power supply
with sensor mating connector and barrel connector
Power supply with plug adapters
M8 male (D56)*
M12 male (D58)*
Adapter cable for connection of TempoLink smart
assistant to R-Series Vsensor
EM08 (Sensor – Barrel)*
EM12 (Sensor – Barrel)*
USB cable for optional connection of TempoLink smart
assistant to a computer
* One of the above supplied depending on the congurated
TempoLink kit
NOTICE
When disconnecting the power supply of the sensor
possibly error messages occur at the connected controller.
Fig. 1: Package content of the TempoLink kit
Fig. 2: Connection of TempoLink smart assistant to R-SeriesV
sensor
OUTPUT
INPUT
SENSOR
24V DC

TempoLink Smart Assistant
Operation Manual
I7 I
NOTICE
If you are using a mobile device, ensure cellular data is off.
Depending on your operation system, message can appear,
that there is no internet access. TempoLink smart assistant
does not need internet access.
Connecting to the user interface may take longer if Wi-Fi
and LAN connections are active.
5. Connection of TempoLink smart assistant to
power supply
There are two ways:
5.1 Using the plug-in power supply with plug adapters
Connect the barrel connector to the “INPUT 24 VDC” port
on the TempoLink smart assistant. Next, insert the plug into
the outlet. Additional outlet adapters are supplied to support
regional requirements.
6. Connection of TempoLink smart assistant to
smartphone, tablet or computer
Connect to a smartphone, tablet or computer to display the
graphical user interface of the TempoLink smart assistant.
6.1 Connecting a Wi-Fi enabled device to the
integrated Wi-Fi access point 3
The default password is the serial number printed on the
label on the bottom of the TempoLink smart assistant.
Activate Wi-Fi on the device and choose the network
“TempoLink_xxxx” (xxxx indicates the last four digits of the
serial number).
OUTPUT
INPUT
SENSOR
24V DC
OUTPUT
INPUT
SENSOR
24V DC
5.2 Using the cable for insertion in an existing sensor
power supply with sensor mating connector and
barrel connector
Connect the supplied sensor mating connector to your
existing power supply connector that was removed from the
sensor. Connect the barrel connector to the “INPUT 24 VDC”
port on the TempoLink smart assistant.
Fig. 3: Connection of TempoLink smart assistant with the plug-in
power supply
Fig. 4: Connection of TempoLink smart assistant with the cable for
insertion in an existing sensor power supply cable
Fig. 5: Choose the network “TempoLink_xxxx” in the Wi-Fi
settings of the Wi-Fi-enabled device
6.2 Connecting a computer via USB connection
The TempoLink smart assistant can also be connected via
USB. If the computer is Wi-Fi enabled deactivate Wi-Fi on the
computer before setting up the USB connection.
Connect the USB cable with the micro USB connector to
the port labeled “USB” on the TempoLink smart assistant.
Next, connect the USB type-A connector to a free USB port of
the computer. The USB connection simulates a network card.
In the folder “network connections” on the computer the
connection is shown as “IP-over-USB” or “Remote NDIS”.
3/ The integrated Wi-Fi access point does not provide
internet access

TempoLink Smart Assistant
Operation Manual
I8 I
After the connection via Wi-Fi or USB is established, open the
browser and go to the website-URL: http://tempolink/
The green or red circle in the top right shows the status of
the connection between the TempoLink smart assistant and
the sensor.
Fig. 7: Start page of the graphical user interface
Fig. 8: Connection status
Connection status
Green Information
ON Connection to sensor is established
Red Information
ON Connection to sensor is not established
Click the menu symbol in the top left to get to the main
menu:
TempoLink: includes information about the TempoLink smart
assistant like its serial number, firmware version and product
number. In addition the password for the Wi-Fi access point
can be changed.
Status: includes current information about the sensor status
like
• Position of the magnet(s)
• Temperature inside sensor electronic housing
• Input voltage
• Operational time: total operational hours of the sensor
• Odometer: total distance travelled by the position magnet
• Magnet cycles: total number of directional changes of the
magnet
Sensor Info: includes information about the connected
sensor like stroke length, serial number and order code.
The displayed information depends on the sensor protocol.
Parameters: includes information about the operational
settings of the connected sensor. The displayed parameters
depend on the sensor protocol and some operational settings
may not be adjustable.
Network: includes information about the network settings of
the connected sensor. The displayed information depends on
the sensor protocol.
NOTICE
Only one device can be connected to the TempoLink smart
assistant at a time in order to display the graphical user
interface.
NOTICE
Disable all Wi-Fi and LAN connections before connecting
TempoLink smart assistant via USB.
Connecting to the user interface may take longer if Wi-Fi
and LAN connections are active.
USB connector
Fig. 6: USB port on the TempoLink smart assistant
7. Establishing a connection via browser
8. Graphical user interface
Fig. 9: Main menu of the graphical user interface

TempoLink Smart Assistant
Operation Manual
I9 I
Fig. 10: LED connection status
9. LEDs of TempoLink smart assistant
Three LEDs in the lid of the TempoLink smart assistant
display the current status of the tool:
TempoLink smart assistant LEDs
Status LEDs
LED A
Communication between TempoLink sensor assistant and sensor
LED color Information
Green ON Sensor connected
Red ON Data transfer from TempoLink sensor assistant
to sensor
Orange ON Sensor connected and data transfer from
TempoLink sensor assistant to sensor
LED B
Communication between sensor and TempoLink sensor assistant
LED color Information
Red ON TempoLink sensor assistant receives data from
connected sensor
– OFF No sensor connected
LED C
USB & Wi-Fi connection
LED color (up) Information
Green ON USB connection exists
Red ON USB connection error
– OFF No USB connection
LED color (down) Information
Green ON Wi-Fi activated on TempoLink sensor assistant
Red ON Wi-Fi error on TempoLink sensor assistant

TempoLink Smart Assistant
Operation Manual
I10 I
Notes

TempoLink Smart Assistant
Operation Manual
I11 I
Notes

UNITED STATES
MTS Systems Corporation
Sensors Division
3001 Sheldon Drive
Cary, N.C. 27513
Phone: [phone]
E-mail: [email protected]
GERMANY
MTS Sensor Technologie
GmbH & Co. KG
Auf dem Schüffel 9
58513 Lüdenscheid
Phone: [phone]
E-mail: [email protected]
ITALY
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
FRANCE
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
GREAT BRITAIN
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
CHINA
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
JAPAN
Branch Offi ce
Phone: [phone]
E-mail: [email protected]
www.mtssensors.com
MTS, Temposonics and Level Plus are registered trademarks of MTS Systems Corporation in the United States; MTS SENSORS and the MTS SENSORS logo are trademarks of MTS Systems Corporation within the
United States. These trademarks may be protected in other countries. All other trademarks are the property of their respective owners. Copyright © 2018 MTS Systems Corporation. No license of any intellectual
property rights is granted. MTS reserves the right to change the information within this document, change product designs, or withdraw products from availability for purchase without notice. Typographic and
graphics errors or omissions are unintentional and subject to correction. Visit www.mtssensors.com for the latest product information.
Document Part Number:
551986 Revision B (EN) 10/2018
