Muller SCALA wall mounted User manual

SCALA wall mounted
Assembly instruction
Included in delivery:
• 1 Allen key • Wall plug and Screw ( 1 piece each per sidebar/intermediate bar
• Hexagon screws ( number of screws in accordance with height of STACK and with number of installation parts
• 2 fixing brackets for each shelf/box, lacquered in the colour of shelf/box
1. Position sidebar
müller möbelfabrikation GmbH & Co. KG - Werner-von-Siemens-Str. 6 - D-86159 Augsburg
Telefon: [phone] - E-Mail: [email protected] - Web: www.mueller-moebel.com
2. Wall mounting of sidebar
Fix wall connection part
(1 to the wall using plug
and screw.
Screw together
sidebar and wall fixing
parts (1-2 .
(1
Plug sidebar and wall fixing parts
(1-2 together to define position
of wall connection (1 .
(1
(2
3. Wall mounting of second sidebar (or intermediate bar)
Define position of second wall connection as described
in step 1-2. According to width of installation parts
consider the differnt distance of drill holes:
Width of shelf/box - distance of drill holes
60 cm – 62,4 cm
90 cm – 92,4 cm
120 cm – 122,4 cm
Distance of drill holes
4. ounting fixing brackets
All fixing brackets are lacquered according to the colour
of the shelf/box. Screw the apropriate fixing brackets at
the required positions onto both sidebars and tighten
them firmly .

müller möbelfabrikation GmbH & Co. KG - Werner-von-Siemens-Str. 6 - D-86159 Augsburg
Telefon: [phone] - E-Mail: [email protected] - Web: www.mueller-moebel.com
5a. Either: Inserting first shelf
Put the shelf onto the fixing
brackets and screw it with loose
fitting from the bottom.
5b. Or: Inserting first box
Screw it with loose fitting from the bottom.
(1 (2a
(2b
(1 Screw 2 bolts with loose fitting
onto the sidebar.
(2 Attach the box from above.
6. ounting more installation parts
Insert more shelves/boxes step by step from bottom to the top.
Please note:
Connection of fixing bracket and sidebar should immediately be tighten firmly. Connection of fixing
bracket and shelf/box remain with loose fitting untill all components have been mounted.
8. Adjusting sidebars or intermediate bars
Finally tighten all screws with loose fitting underneath the shelves/boxes.
7. Final fixing
If necessary adjust the height of the sidebars/intermediate bar using
the screws at the bottom.
For SCALA shelves with one or more intermediate bars repeat step 1-
8 untill the last section has been completely fixed.
