MULTISPAN TC-29P User manual

OPERATING MANUAL
TEMPERATURE CONTROLLER
TC-49P
www.multispanindia.com
Page - 1
TC-29P
2) If Sensor is not Connected, Display will show “ ” message.OPeN
3) To Show set point, press Key.
Note:
4) Auto out time is 15 sec without saving.
5) Every time the instument is turn on,following pattern will be displayed.
Technical Specification
POWER ON
Display for 2 sec
display for 2 sec, according to the input
sensor programmed.
display for 2 sec, according to the control
action programmed.
Process Value
8.8.8.8.
t c _ J
P I D
0 0 5 0
SETSET
Connection Diagram
OPERATING MANUAL
PID TEMPERATURE CONTROLLER
TC-29P
4 Digit 7 seg 0.56”,red LED Display
J type: 0 to 400°C
PID/ ON-OFF
Output
Power Supply
Operating
Temperature
Relative
Humidity
230V AC,50 Hz, Approx 3VA
0°C To 55°C
Up to 95% RH Non Condensing
Model
Display
Size (mm)
Panel Cutout
Input
Temperature
Range
Control Action
72 (H) X 72 (W) X 60 (D) mm
68 X 68 mm
TC-29P
J TYPE
1Relay, 1C/O Contact,5A, 230V AC
S.S.R, 12V DC approx,10mA DC.
Protection
Level
(As per request)
IP-65 (Front side) As per IS/IEC 60529 : 2001
1) If Sensor Connection is reverse, Display will show “ ” message.SRE
SET
H
TC 29P
PID
ºC
01 8 0
230V AC
50Hz,3VA
TC
NC
NO
C
Relay
+
-
L
N
1
2
3
4
5
6
7
-
+
SSR
12V DC
8
9
10
11
12
13
14
!

SET
Press key
to Save & Exit
On releasing key will store
the latest set value
0 0 5 0
0 2 0 0
Process Value
P A S s
0 0 7 3
C T R L
p I D
O F S T
O 0 0 0
Password Message
Control Action
TO ENTER BASIC
CONFIGURATION
SETTING, ENTER “73”
PID/ON-OFF
Offset
www.multispanindia.com
Page - 2
1) Press + Or Key to set the set point.
2) Press Key to go next parameter.
3) Relese the Key, to save the set point.
SET
SET
SET
SET
SET
Press Key to go next parameter.
SETSET
SET
Press key for 4 sec.
SETSET
SET
Press + Or Key to set the set point.
SETSET
Key Operations
TC-29P
Basic Configuration
Set Point Setting
Key Operation

www.multispanindia.comPage - 3
P A s s Password
Message
IF PID SELECTED IF ON-OFF SELECTED
p B
0 2 0 0.
I T
0 1 2 5
C T
0 0 3 0
M R
D T
0 0 1 5
0 0 0 0
Proportional
Band
Integral
time
Derivative
time
Cycle Time
Manual Reset
0 0 3 7
TO ENTER CONTROL
PARAMETER
SETTING, ENTER “37”
SET
SET
Press key
to Save & Exit
Press key
to Save & Exit
Hysteresis
Y S t
0 0 0 3
TC-29P
PID AUTO-TUNNING
Press key for 6 sec to start/stop
PID auto-tunning
PV
1 2 3 4
Off-set correction -10°C to +10°C
IT
CT
0 To 9999
4 Sec To 99 Sec
Hysteresis 1°C to 10°C
DT
MR
0 To 9999
-9°C to 9°C
PB
Sr.
1
2
3
4
5
6
7
0 To 999.9
Parameter Range for J type
Factory Setting
FACTORY SETTING
PARAMETER
IT
CT ( For PID)
OFFSET
PB
DT
HYSTERESIS-1
MR
VALUES
125
15 SEC.
20.0
30
3°C
0
0
SR.
2
4
1
3
5
6
7
Y E S
SET
SET
yes : press key to apply factory set
values as shown in table.
nO : press key to escape
from factory setting.
n O
Press + key
for 3 sec
1 2 3 4
f C S T
Control Parameter

SET
H
TC 29P
PID
ºC
01 8 0
TC-29P
www.multispanindia.comPage - 4
All safety related codifications, symbols and instructions that appear in this operating manual
or on the equipment must be strictly followed to ensure the safety of the operating personnel as
well as the instrument.
If all the equipment is not handled in a manner specified by the manufacturer, it might impair the
protection provided by the equipment .
Product improvement and upgrade is a constant procedure. So for more updated operating information and support,
Please contact our helpline : [phone]/82 or Email at mark[email protected] Ver: 01-2016
=> Read complete instructions prior to installation and operation of the unit.
WARNING : Risk of electric shock.
3) Cable used for connection to power source, must have a cross section of 1mm or greater. These wires
should have insulations capacity made of at least 1.5kV.
2) To reduce electro magnetic interference, use wire with adequate rating and twists of the same of
equal size shall be made with shortest connection.
4) When extending the thermocouple lead wires, always use thermocouple compensation wires for wiring
for the RTD type, use a wiring material with a small lead resistance (5 max per line)and no resistance
Ω
differentials among three wires should be present.
1) To prevent the risk of electric shock power supply to the equipment must be kept OFF while doing the
wiring arrangement. Do not touch the terminals while power is being supplied.
5) A better anti-noise effect can be expected by using standard power supply cable for
the instrument.
1) This equipment, being built-in-type, normally becomes a part of main control panel and in such case the
terminals do not remain accessible to the end user after installation and internal wiring.
2) Do not allow pieces of metal, wire clippings, or fine metallic fillings from installation to enter the product
or else it may lead to a safety hazard that may in turn endanger life or cause electrical shock to the operator.
3) Circuit breaker or mains switch must be installed between power source and supply terminal to
facilitate power ‘ON’ or ‘OFF’ function. However this mains switch or circuit breaker must be
installed at convenient place normally accessible to the operator.
4) Use and store the instrument within the specified ambient temperature and humidity ranges as
mentioned in this manual.
Warning Guidelines
Installation Guidelines
Mechanical Installation
Maintenance
Safety Precautions
1) Prepare the panel cutout with proper dimensions as show above.
2) Fit the unit into the panel with the help of clamp given.
3) The equipment in its installed state must not come in close proximity to any heating source,
caustic vapors, oils steam, or other unwanted process by products.
4) Use the specified size of crimp terminal (M3.5 screws) to wire the terminal block. Tightening the
screws on the terminal block using the tightening torque of the range of 1.2 N.m.
5) Do not connect anything to unused terminals.
1) The equipment should be cleaned regularly to avoid blockage of ventilating parts.
2) Clean the equipment with a clean soft cloth. Do not use isopropyl alcohol or any
other cleaning agent.
3) Fusible resistor must not be replaced by operator.
2
A
B
C
D
EF
MODEL A
72mm 72mm 68mm 68mm 3mm 60mm
BC
DE F
DIMENSIONS
102mm - 4.02 inches
90mm - 3.5 inches
