MULTISPAN UTC - 413P User manual

www.multispanindia.com
Page - 1
UTC-413P
Note:
1) If Sensor Connection is reversed, Display will show “SRE” message.
2) If Sensor is not connected, Display will show Opn message.
3) Every time the instrument is turned ON, Following pattern will be displayed
J: 0 to 600°C / K: 0 to 999°C /
PT-100: -99 to 400ºC
PID / ON-OFF (selectable)
Output
Power Supply
Operating
Relative
Protection Level
(As per request)
Temperature
Humidity
1 relay, 1 C/O contact, 230V AC, 5A ; 1 SSR,12V DC Approx, 30mA DC
100 to 270V AC, 50 / 60 Hz, Approx 4VA
IP-65(Front side) AS per IS/IEC 60529:2001
0°C To 55°C
Up to 95% RH Non Condensing
Display
Size(HXWXD)
Panel Cutout(HxW)
Input
Temperature
Range
Control Action
45 X 45 mm
48 X 48 X 70 mm
3 Digit 7 seg 0.56”,red LED Display
J, K, PT-100 (selectable)
Technical Specification
Connection Diagram
OPERATING MANUAL
PID TEMPERATURE CONTROLLER
UTC - 413P
1 2 3
UTC 413P
POWER ON
All digit segment will be turned ON for 3 sec
Previous or default sensor input will be display for 2 sec
Process Value
8 88
- J -
1 2 3
www.multispanindia.com
Page - 2
All safety related codifications, symbols and instructions that appear in this operating manual
or on the equipment must be strictly followed to ensure the safety of the operating personnel as
well as the instrument.
If all the equipment is not handled in a manner specified by the manufacturer, it might impair the
protection provided by the equipment .
Product improvement and upgrade is a constant procedure. So for more updated operating information and support,
Please contact our helpline : [phone]/9978991474/9978991482 or Email at [email protected] Ver: 2102
=> Read complete instructions prior to installation and operation of the unit.
WARNING : Risk of electric shock.
3) Cable used for connection to power source, must have a cross section of 1mm or greater. These wires
should have insulations capacity made of at least 1.5kV.
2) To reduce electro magnetic interference, use wire with adequate rating and twists of the same of equal size shall
be made with shortest connection.
4) When extending the thermocouple lead wires, always use thermocouple compensation wires for wiring for the RTD
type, use a wiring material with a small lead resistance (5Ω max per line)and no resistance differentials among
three wires should be present.
1) To prevent the risk of electric shock power supply to the equipment must be kept OFF while doing the wiring
arrangement. Do not touch the terminals while power is being supplied.
5) A better anti-noise effect can be expected by using standard power supply cable for the instrument.
1) This equipment, being built-in-type, normally becomes a part of main control panel and such in case the
terminals do not remain accessible to the end user after installation and internal wiring.
2) Do not allow pieces of metal, wire clippings, or fine metallic fillings from installation to enter the product
or else it may lead to a safety hazard that may in turn endanger life or cause electrical shock to the operator.
3) Circuit breaker or mains switch must be installed between power source and supply terminal to
facilitate power ‘ON’ or ‘OFF’ function. However this mains switch or circuit breaker must be
installed at convenient place normally accessible to the operator.
4) Use and store the instrument within the specified ambient temperature and humidity ranges as
mentioned in this manual.
Warning Guidelines
Safety Precautions
Installation Guidelines
Mechanical Installation
Maintenance
1) Prepare the panel cutout with proper dimensions as show above.
2) Fit the unit into the panel with the help of clamp given.
3) The equipment in its installed state must not come in close proximity to any heating source,
caustic vapors, oils steam, or other unwanted process by products.
4) Use the specified size of crimp terminal (M3.5 screws) to wire the terminal block. Tightening the
screws on the terminal block using the tightening torque of the range of 1.2 N.m.
5) Do not connect anything to unused terminals.
1) The equipment should be cleaned regularly to avoid blockage of ventilating parts.
2) Clean the equipment with a clean soft cloth. Do not use isopropyl alcohol or any other cleaning agent.
3) Fusible resistor must not be replaced by operator.
2
UTC-413P
1 2 3
UTC 413P
48
70
45
45
3
48
Outline Dimension (mm) Panel Cutout
Dimension (mm)
TC
+
-
+
SSR
O/P
RTD
6
7
8
9
10
-
1
2
3
4
5
NC
C
R1
NO
L
!
100
250V AC
50/60 HZ
4VA
~
!
100
270V AC
50/60 Hz
4VA
~
N
Made in India
www.multispanindia.com

www.multispanindia.com
Page - 4
P A s Password Message
O N F ON-OFF
IF PID SELECTED IF ON-OFF SELECTED
p I d
p B
2 0 0
I T
3 0 0
C T
0 7 5
M R
D T
0 1 5
0 0 0
Proportional
Band
PID
Integral
time
Derivative
time
Cycle Time
Manual Reset
3 7
SET
TO ENTER CONTROL
PARAMETER
SETTING, ENTER “37”
SET
Press + key
to Save & Exit
SET
Press + key
to Save & Exit
Off-set correction -20°C to +20°C
1 sec to 999 sec
DELAY TIME
IT
CT
0 To 999
4 Sec To 99 Sec
Hysteresis 1°C to 50°C
DT
MR
0 To 999
-9 to +9°C
PB
Sr.
1
2
3
4
5
7
6
8
0 To 999
Parameter Range for J, K, PT100
SET
Set Point
P A S
S E T
Password Message
0 5 0
1 0 0
Press key for 3 sec to
enter password parameter
SET
0 0 0 Process Value
Relay Mode
ON-OFF
PID
P A S
0 7 3
O F S
S L L
S H L
I N P
J P T
0 0 0
0 0 0
6 0 0
C T R
Password Message
OFFSET
Input
KJ/K/PT-100
Press + key to Save & Exit
SET
Press key
P I D
O N F
R L Y
H T C O L
TO ENTER BASIC
CONFIGURATION
SETTING, ENTER “73”
Set Point Low Limit
Set Point High Limit
Control Action
www.multispanindia.com
Page - 3
Press + key
SET
Press Key to go next parameter.
SET
SET
Hysteresis
H Y S
Delay time D t m
If Cool is
If Heat is
Selected
Selected
0 0 6
0 0 3
Press key
SET
Press key
SET
Press key
SET
Press key
SET
Basic Configuration Control Parameter
Set Point Setting
1) Press Key to go parameter setting.
3) Press + Key to save changes in setting.
4) To start or stop Auto-Tuning press key for 6 sec.
5) Press + key for 3 sec to go to factory setting mode.
2) Use Or key to change value of parameter.
SET
SET
Key Operation
PID AUTO-TUNING
Press key for 6 sec to start/stop
PID auto-tuning
PV
1 2 3
Factory Setting
FACTORY SETTING
PARAMETER
IT
CT
OFFSET
PB
DT
MR
HYSTERESIS
DELAY TIME
VALUES
300
15 sec
200
075
0°C
0°C
3°C
6 sec
SR.
2
4
6
1
3
5
7
8
yes : press key to apply factory
set value as shown in table.
nO : press key to escape from
factory setting.
Press + key
for 3 sec
F S T
1 2 3
Y E S n O
+
+
SET
UTC-413P UTC-413P
