Multistore MAXI-C06 User manual

Assembly InstructIons
PACKS
2
Jumbo
DrAWerS
2
3 StAnDArD
DrAWerS
3
WHITE #0027258 LIgHT Oak #2683495 Dark COCO #2683533
1065H x 608W x 450D
ComPACt rAnge
mAXI-C06

ASSEMBLY INSTRUCTION FOR MSM AND MAXI C06
PARTS IDENTIFICATION LIST
TOP of UNIT
NO MODEL DESCRIPTION QTY
1CONFIRMAT SCREWS 50mm x 5mm 14
2CAPS 14
3BACKING NAILS 50
NO MODEL DESCRIPTION QTY
516mm PAN HEAD SCREWS 1
625mm PAN HEAD SCREWS 1
7“L” SAFETY BRACKET 1
When aaching unit to wall put safety bracket in
middle of unit with 16mm pan head screw then
25mm pan head screw into wall.
For plasterboard without a stud it is recommended
to use a plug with screw (not provided).
F

INFILL STEP
YOU WILL NEED TO RETRIEVE THE INFILL AND
3 X 60mm SCREW FROM PART 2, USING YOU
SCREWS PROVIDED, ATTACH THE INFILL TO
THE UNDER-SIDE OF THE TOP FIXED SHELF.
FIRST STEP:- UNPACKED YOUR CARTON PART 1 OF 2, LAY A,B,C,D,E ON FLOOR & RETRIEVE THE INFILL &
SCREWS FROM PART 2. ATTACH THE INFILL TO THE UNDERNEATH OF THE FRONT EDGED TOP FIXED SHELF AS
DEMONSTRATED DOWN BELOW IN INFILL STEP.
STAND LEFT-HAND GABLE FACING DOWN ON THE EDGED FRONT, USING THE 30mm 8 GAUGE CONFIRMAT
SCREWS PROVIDED YOU CAN NOW SCREW YOUR KICK FIRST, BOTTOM SHELF NEXT AND THEN TOP SHELF WITH
INFILL ALLREADY ATTACHED FACING DOWN INTO THE LEFT-HAND GABLE.
WHEN FINISHED DO THE SAME TO THE RIGHT-HAND GABLE.
LEAVE YOUR CARCASS FACING DOWN AND GO TO ..STEP 3.
YOU ARE NOW READY TO MOVE TO
PART 2 TO ASSEMBLE YOUR DRAWERS
TO GO INTO YOUR FINISHED CARCASS.
STEP 1 STEP 2
STEP 3 FINISHED

HOW TO ASSEMBLE YOUR 5—DRAWER
STEP1.
LAYOUT YOUR DRAWER PIECES FLAT AS PER DESIGN WITH PRE-DRILLED HOLES FACING UP.
START WITH THE BACK OF THE FRONT DRAWER AND PLACE YOUR DOWELS & CAM PIN IN THE
PRE-DRILLED HOLES ON EITHER SIDE AS INSTRUCTED BELOW.
NO MODEL DESCRIPTION QTY
1CONFIRMAT SCREWS 20
2DOWELS 20
3BACKING NAILS 100
45/8 X 6 WOOD SCREWS 30
5 HANDLES 5
NO MODEL DESCRIPTION QTY
6CAMS 10
7CAM PINS 10
830mm 8 GAUGE INFILL SCREW 3
9EURO SCREWS 20
10 INFILL 1
11 RUNNERS PER SET 5
STEP 2.
GRAB YOUR FIRST SIDE AND INSERT YOUR CAMS
INTO THE HOLE PROVIDED ON THE OUTSIDE OF THE
DRAWER GENTLY AS PER INSTRUCTIONS BELOW.
PUSH THE SIDE INTO THE FRONT DOWELS & PIN THEN CAREFULLY USING A SCREW DRIVER
TURN UNTIL IT LOCKS IN. REPEAT THIS PROCESS WITH THE OTHER SIDE.
NOW PLACE YOUR LAST PIECE BETWEEN THE TWO SIDES USING THE
SCREWS NO.1 SUPPLIED SCREW INTO THE SIDES OF THE BACK DRAWER
PIECE.
IMPORTANT NOTICE:
PLACE THE FITTING OVER THE HOLE
KEEPING THE SQUARE EDGE OF THE
FITTING PARALLEL TO THE FACE OF
THE BOARD, KNOCK IN CAREFULLY.

PICTURE OF YOUR FINISHED
STEP 5.
USING THE HANDLE SCREW (NO:6) ATTACH THE HANDLE TO THE
BACK OF THE DRAWER. FRONT INTO THE PREDRILLED HOLES ALL
READY PROVIDED.
DRAWER ASSEMBLY
STEP 6.
PLACE YOUR DRAWER RUNNER ON THE BOTTOM OF THE
DRAWER USING THE WOOD SCREWS PROVIDED (No:4)
SCREW TWO INTO EACH RUNNER. REPEAT FOR THE OTH-
ER SIDE.
STEP 3.
YOUR DRAWER SHOULD BE FACING
DOWN WITH THE FRONT DRAWER
EXSPOSING THE CUTOUT FOR THE
BASE TO BE PUSHED INTO FACE DOWN
WITH THE BROWN SIDE SHOWING. MAK-
ING SURE YOU HAVE THE DRAWER
SQUARE, PROCEED TO NAIL DOWN THE
BASE SPACING THEM OUT AROUND THE
EDGE OF THE THREE SIDES.
PLACE YOUR RUNNERS INTO THE
DESIGNATED HOLES MAKING SURE THE
WHEEL IS FACING TO THE FRONT OF THE
GABLE. HOLE POSITION NO 1,8 AND 15.
YOUR DRAWER RUNNER WILL HAVE THE
WHEEL TO THE BACK OF THE DRAWER.
STEP 4

DIAGRAM 1
30. ● ●
29. ● ●
28. ● ●
27. ● ●
26. ● ●
25. ● ●
24. ● ●
23. ● ●
22. ● ●
21. ● ●
20. ● ●
19. ● 5mm HOLES ●
18. ● ●
17. ● ●
15. ● ●
15. ● ●
14. ● ●
13. ● ●
12. ● ●
11. ● ●
10. ● ●
9. ● ●
8. ● ●
7. ● ●
6. ● ●
5. ● ●
4. ● ●
3. ● ●
2. ● ●
1. ● ●
* * *
MAXI ULTRA ‘H’ SERIES
Models Hole Positions CAM PIN-Hole Positions
H1 1 8
HS2 1 8 – 15
H2 1 – 8 13
HS 8
MAXI ULTRA & ULTRA SERIES
Models Hole Positions Models Hole Positions
450 1-6-11-16 LSD550 1-8
315C 1-8-15-20 LSD330 1
515 1-6-11-16-21
Executive 750 ‘H’ SERIES
Models Hole Positions CAM PIN-Hole Positions
HS 8
H1 1 8
H2 1 – 6 11
H3 1 – 8 – 13 20
MAXI & MSM SERIES
Models Hole Positions Fixed Shelf Position
16J3 1 – 8 – 15 22
C16 1 – 8 – 15 – 20 – 25 30
C06 1 – 8 – 15 – 20 – 25 30
600J3 8 – 15 - 22
400J3 1 – 8 – 15
Executive Series
Models Hole Positions Fixed Shelf Position
EXC – 4J 1 – 8 – 15 - 22 N/A
EXC – 5C 1 – 8 – 15 – 20 – 25 N/A
EXC – 4B 8 – 16 – 24 - 32 N/A
EXC – 2B 8 – 14 N/A
EXB - 5C 1 – 8 – 15 – 20 – 25 N/A
EXB – 4J 1 – 8 – 15 – 20 N/A
EXB – 4B 8 – 16 – 22 – 28 N/A
INSTRUCTIONS FOR RUNNER PLACEMENT
* = FIXED SHELF HOLES & KICK
Place metal runners in their correct hole posions
(see above DIAGRAM 1) making sure CL = LEFT HAND
GABLE & CR = RIGHT HAND GABLE, then aach using
the special 7.5 euro screws provided.
(see diagram to the right).

multistore.com.au
Multistore Industries (Aust) Pty Ltd
9 Nevilles Street, Underwood QLD 4119 P:[phone] [email protected]
For easy assembly instructions, please refer to video on our website: www.multistore.com.au
Versatile Storage Units
for any room
