Mustang Survival MD2014 User manual

I
OWNER'S MANUAL
DO NOT REMOVE PRIOR TO SALE
HT3159 REV 15JULY2020
MD2014 INFLATABLE PFD
MANUAL INFLATION MODEL
USCG APPROVALS:
RECREATIONAL: TYPE III
UNINSPECTED COMMERCIAL VESSELS:
TYPE V
MD2016 INFLATABLE PFD
MANUAL WITH AUTOMATIC BACKUP
INFLATION MODEL
USCG APPROVALS:
RECREATIONAL: TYPE III
UNINSPECTED COMMERCIAL
VESSELS: TYPE V
FOR MODEL NUMBERS MD2014 AND MD2016

II
TABLEOFCONTENTS
APPROVAL CONDITIONS AND CARRIAGE REGULATIONS .....................1
NOTE TO UNINSPECTED COMMERCIAL VESSEL OPERATORS..............1
WHY ARE PFDS REQUIRED SAFETY EQUIPMENT?...................................2
WHAT IS AN INFLATABLE PFD? ........................................................................2
INSTRUCTIONS FOR USE .....................................................................................2
UNINSPECTED COMMERCIAL VESSEL USE .........................................2
COMPONENT INSPECTION INSTRUCTIONS.........................................2
READINESS CHECKLIST................................................................................. 3
SIZING AND FIT................................................................................................... 4
DONNING INSTRUCTIONS .................................................................................. 4
INFLATING YOUR INFLATABLE PFD ...............................................................5
SPECIAL CONSIDERATIONS FOR AUTOMATIC DEVICES (MD2016) .. 6
DEFLATING THE INFLATABLE PFD .................................................................7
USAGE BELOW FREEZING ..................................................................................7
RE-ARMING YOUR PFD (MD2014) .................................................................. 8
RE-ARMING YOUR PFD (MD2016) .................................................................. 9
REPACKING .............................................................................................................12
IS YOUR PFD IN GOOD AND SERVICEABLE CONDITION? ...................13
CARE AND MAINTENANCE INSTRUCTIONS ..............................................13
INSPECTING YOUR INFLATABLE PFD ...................................................13
CLEANING AND STORING OF YOUR INFLATABLE PFD ..............14

III
HOW AND WHY TO TEST YOUR PFD ...........................................................15
HOW DO YOU TEST YOUR PFD USING
THE AUTOMATIC INFLATOR? (MD2016).............................................15
HOW DO YOU TEST YOUR PFD USING
THE MANUAL INFLATOR?...........................................................................16
HOW DO YOU TEST YOUR PFD USING
THE ORAL INFLATOR?..................................................................................17
WEAR YOUR PFD ..................................................................................................18
HYPOTHERMIA........................................................................................................18
HOW HYPOTHERMIA AFFECTS MOST ADULTS...............................18
SOME POINTS TO REMEMBER ABOUT
HYPOTHERMIA PROTECTION....................................................................18
EACH OF THESE DEVICES IS INTENDED TO
HELP YOU SAVE YOUR OWN LIFE..................................................................19
INFLATABLE PFD SAFETY ACCESSORIES..................................................20
ADDITIONAL INFORMATION............................................................................20
DO NOT ATTACH PFD’S TO YOUR BOAT.....................................................20
AIRLINE OPERATOR POLICY ON CARRIAGE OF
INFLATABLE PFDS AND CO2CARTRIDGES ..............................................20

1
APPROVAL CONDITIONS AND CARRIAGE REGULATIONS
Recreational - This Inflatable personal flotation device (PFD) is
approved by the U.S. Coast Guard (USCG) for use as a Type III PFD.
It is not approved for water skiing or other high impact, high-speed
activities.
This Inflatable PFD was designed to be more comfortable and
less restrictive to wear than inherently buoyant PFDs. When worn,
used, and serviced according to this owner’s manual, this Inflatable
PFD can greatly increase your chances of survival in the water.
Not recommended for non-swimmers or weak swimmers. Users of
inflatable PFDs must be at least 16 years old.
Commercial - Models MD2014 and MD2016 are U.S. Coast Guard
approved Type V inflatable PFDs, approved ONLY WHEN WORN for
use on uninspected commercial vessels less than 40 feet in length
not carrying passengers for hire as a substitute for a Type III PFD
when used in accordance with this owner’s manual.
Conditions for Type V Approval in commercial applications:
1. The Inflatable PFD must be worn before getting underway and
whenever above deck and not within an enclosed space to meet
the carriage requirement.
2. The operator of an uninspected commercial vessel is responsible
for servicing and maintaining the Inflatable PFD in good
serviceable condition in accordance with this owner’s manual. See
Care and Maintenance Instructions for servicing information.
3. The operator of an uninspected commercial vessel is responsible
for providing each person onboard with the safety information
required for use of the Inflatable PFD. See below for information.
NOTE TO UNINSPECTED COMMERCIAL VESSEL OPERATORS
The operator of the vessel is required to provide the following user
information to each person on board.
Inflatable PFDs will not provide any buoyancy without being inflated.
Follow these instructions to be sure your PFD is armed and donned
correctly, and that you understand how to inflate the device.
Basic visual inspection for readiness (see “Readiness Checklist” on
page 3).
Inflation system status check (see “Care and Maintenance
Instructions” on page 13).
Donning (see “Donning Instructions” on page 4).

2
Inflation (see “Inflating Your Inflatable PFD” on page 5).
WHY ARE PFDS REQUIRED SAFETY EQUIPMENT?
Drownings are the leading cause of fatalities involving recreational
boating. A PFD provides flotation to help keep your head above
water, help you to stay face up in the water, and increase your
chances for survival and rescue. Most adults only need an extra 7 to
12 lb (3.2 to 5.5 kg) of flotation to keep their heads above water. The
proper size PFD will properly support the weight of the wearer.
Since this Inflatable PFD does not have inherent buoyancy, it
provides flotation only when inflated. Familiarize yourself with the
use of this Inflatable PFD so you know what to do in an emergency.
WHAT IS AN INFLATABLE PFD?
While traditional PFDs are inherently buoyant, inflatable PFDs rely
entirely on inflation for buoyancy. Uninflated, the Inflatable PFD
is a comfortable slim collar that can be inflated at any time with a
CO2gas cylinder. The Inflatable PFD is designed to oer maximum
mobility with minimum bulk. The Inflatable PFD (MD2014) can be
inflated either manually by jerking a pull-tab, or orally by mouth. The
Inflatable PFD (MD2016) can be inflated either automatically during
water immersion, manually by jerking a pull-tab, or orally by mouth.
It is recommended that you familiarize yourself with the procedures
outlined in INSTRUCTIONS FOR USE .
INSTRUCTIONS FOR USE
This manual supplies instructional, maintenance and safety
information for models MD2014 and MD2016. Model numbers are
listed on the underside label.
UNINSPECTED COMMERCIAL VESSEL USE
This Inflatable PFD is not approved for “hot work” and care must be
taken to avoid damage from abrasion and sharp objects.
COMPONENT INSPECTION INSTRUCTIONS
1. Examine the service indicator through the window panel (Fig.
1). Ensure the service indicator is green. If the service indicator
is red, the mechanism has been fired or is incorrectly fitted (see
“Re-arming Your PFD (MD2014)” on page 8 or see “Re-arming
Your PFD (MD2016)” on page 9).

3
READINESS CHECKLIST
Check your Inflatable PFD and ensure all of the checkpoints listed
below are true before use.
 Service indicator is green.
 No rips, tears or holes; all seams are securely sewn; and the fabric,
straps and hardware are still strong.
 All Velcro™ and waist belt are securely fastened.
 Inflatable PFD is not twisted.
 Oral-inflation dust cap is in the stowed position (Fig. 6).
 Ensure the inflation pull-tab is hanging on the outside (Fig. 1)
 For the MD2016 only - Ensure the bobbin is valid. The PFD, or
bobbin, must have been purchased within the last three (3) years.
If the purchase date is unknown, check the date printed on the
bobbin and replace if older than three (3) years (see Re-arming
Your PFD (MD2016) on page 9).
THE SERVICE INDICATOR MUST BE GREEN BEFORE PROCEEDING.
2. Undo the Velcro™ strips along both sides of the PFD.
3. Ensure the oral-inflation dust cap is in the stowed position (Fig. 6).
4. For the MD2016 only - Ensure the bobbin is valid. The PFD, or
bobbin, must have been purchased within the last three (3) years.
If the purchase date is unknown, check the date printed on the
bobbin and replace if older than three (3) years (see Re-arming
Your PFD (MD2016) on page 9).
5. Ensure the service indicator is green and the pull-tab lanyard is
hanging on the outside (Fig. 1); secure the Velcro™ strips on both
sides of the Inflatable PFD.
MD2016 Service Indicator
Automatic Inator
MD2014 Service Indicator
Pull Tab
Manual Inator
Pull Tab
FIGURE 1 SERVICE INDICATORS

4
FIGURE 2
DONNING
Your Inflatable PFD is ready for use if all applicable boxes are
checked.
CONTACT YOUR MUSTANG DEALER IF YOU HAVE ANY CONCERNS ABOUT THE
READINESS OF YOUR INFLATABLE PFD.
SIZING AND FIT
This PFD provides a minimum of 22.5 lbs of buoyancy when inflated
and is designed for wearers over 16 years of age, with a chest range
of 30-52 inches (76-132 cm) weighing over 80 pounds (36 kg).
DONNING INSTRUCTIONS
It is important that the Inflatable PFD is properly adjusted to fit
the person wearing it. An incorrect fit or improper fastening of
attachments could impede its eectiveness.
All belts and straps are already threaded correctly and only need to be
adjusted for fit. The belt should fit below your rib cage adjusted to a
tight personal fit.
Put the Inflatable PFD on just like a jacket (Fig. 2) and fasten the front
buckle. Adjust the waist belt using the side buckle on the belt and
secure the belt’s loose end in the belt loop.
WARNING: DO NOT WEAR INFLATABLE PFDS UNDER CLOTHING AS THE INFLATION
COULD BE RESTRICTED OR YOU COULD BE INJURED.

5
INFLATING YOUR INFLATABLE PFD
It is recommended that the following procedures be followed to
inflate your Inflatable PFD:
1. Manual Inflation
Activate the inflation system by jerking firmly downward on
the pull-tab (Fig. 3). The Inflatable PFD should fully inflate
within 5 seconds.
MD2014 MD2016
Manual Inator Automatic Inator
FIGURE 3 PULL-TAB
2. Automatic Backup Inflation (MD2016 only)
Inflation will occur automatically within 10 seconds after the
inflator is immersed in water. The water-sensing bobbin will
disintegrate, triggering a spring-loaded plunger, which punctures
the CO2cylinder (Figs. 10 and 11) to inflate the Inflatable PFD.
When inflated, the carbon dioxide (CO2) used to inflate the PFD will
slowly escape through the fabric over time. A slight reduction of
pressure will be observed after several hours of inflation. Topping
up by oral inflation may be required in the event of very prolonged
immersion.
SEE SPECIAL CONSIDERATIONS FOR AUTOMATIC DEVICES

6
FIGURE 4 ORAL INFLATION
3. Oral Inflation
Properly armed and inspected
Inflatable PFDs will inflate
when manually or automatically
activated. However, you can fully
inflate the Inflatable PFD by mouth
(Fig. 4) should inflation not occur,
or if you are in a non-emergency
situation.
To orally inflate the Inflatable
PFD, first locate the oral inflation
tube by opening the wearer ’s left
front panel of the Inflatable PFD.
Remove the dust cap from the end
of the oral tube and blow into the
tube until the Inflatable PFD is fully inflated. Place the oral inflator
dust cap back in the stowed position (Fig. 6).
AVOID DOUBLE INFLATION!
DO NOT MANUALLY OR AUTOMATICALLY ACTIVATE THE INFLATOR WHEN YOUR
FLOTATION DEVICE IS FILLED WITH AIR. DOING SO WILL RESULT IN EXCESSIVELY
HIGH PRESSURE WITHIN THE INFLATION CHAMBER, WHICH MAY CAUSE PERMANENT
DAMAGE TO YOUR DEVICE AND/OR EXTREME DISCOMFORT TO YOU.
SPECIAL CONSIDERATIONS FOR AUTOMATIC DEVICES (MD2016)
The Inflatable PFD might not be armed when needed, either
knowingly or unknowingly. Premature automatic inflation causes
several risks that you must address to avoid drowning. Much less
common but also important are:
1. Inflation when stored in a tight space could damage the PFD, and
2. The PFD could inflate when you are in an awkward place or
position. Premature inflation may occur in certain conditions,
including when the device is subjected to: heavy splashing, high
humidity, heavy fog, and heavy rain.
Care and attention should be taken to ensure that when the
device is used in these types of conditions, auto-inflation does not
occur prematurely.
If this PFD should inflate prematurely, a re-arm kit (MA2014) is
required to re-arm the device.
THE INFLATABLE PFD SHOULD BE RE-ARMED ACCORDING TO THE INSTRUCTIONS
(SEE “RE-ARMING YOUR PFD (MD2016)” ON PAGE 9).

7
DEFLATING THE INFLATABLE PFD
1. To deflate the Inflatable PFD, reverse the oral-inflation tube dust
cap and insert it into the valve. The dust cap will not lock in the
deflate position so it is necessary to hold it in place (Fig. 5).
2. Gently squeeze the Inflatable PFD until all air or gas has been
expelled. To avoid damage, do not wring or twist the Inflatable
PFD. Put the inflation tube dust cap back in its stowed position on
the oral inflation tube (Fig. 6).
3. Examine the service indicator (Fig. 1). If the service indicator is
red, the mechanism has been fired or is incorrectly fitted and the
inflator requires service (see Re-arming your PFD (for your model)).
THE SERVICE INDICATOR MUST BE GREEN BEFORE PROCEEDING.
4. Your device is ready to be repacked (see “Repacking” on page 13).
FIGURE 5
Cap in
deflate
position
Cap in
deflate
position
Cap in
stowed
position
FIGURE 6
Cap in
deflate
position
Cap in
deflate
position
Cap in
stowed
position
DEFLATE POSITION CLOSE-UP VIEW
USAGE BELOW FREEZING
As temperatures approach freezing, your flotation device will provide
less buoyancy and will inflate more slowly. At temperatures near
freezing, the device should be worn partially inflated with the CO2
cylinder to ensure that some buoyancy is immediately available to you
if you fall overboard. The oral inflator can then be used to adequately
top up the flotation device after CO2inflation.
CAUTION: DO NOT FULLY INFLATE THE DEVICE ORALLY AND THEN ACTIVATE THE CO2
CYLINDER. THE RESULTING OVERPRESSURE COULD SERIOUSLY DAMAGE THE DEVICE
RESULTING IN LOSS OF FLOTATION.
Inflatable flotation devices are not recommended for use in
temperatures below freezing.

8
MD2014 Manual Inflator
Cylinder
Step 2
Sensor Ring
Step 3
Bayonet
Tab
Step 4
O-Ring
Step 3
Lever
Step 4
Service Indicator
Step 5
If GREEN
unit is operable
If RED
stop and service unit
Service Indicator:
FIGURE 7 MD2014 MANUAL INFLATOR
RE-ARMING YOUR PFD (MD2014)
A RE-ARM KIT (MA2014) IS REQUIRED FOR THIS PROCEDURE.
FOLLOW INSTRUCTIONS IN THE EXACT SEQUENCE BELOW.
1. Open inflator cover flap so that manual inflator is exposed (Fig. 7).
2. Remove the cylinder/bayonet assembly by rotating
counterclockwise and then pull out. Discard the used cylinder/
bayonet assembly.
3. Check the new cylinder/bayonet assembly to ensure the o-ring is
in place and the sensor ring is attached (Fig. 7). Ensure that the
CO2cylinder has not been pierced (Fig. 10).

9
RE-ARMING YOUR PFD (MD2016)
A RE-ARM KIT (MA2014) WITH A VALID BOBBIN INSTALL-BY-DATE (CHECK RE-ARM KIT
PACKAGING) IS REQUIRED FOR THIS PROCEDURE.
FOLLOW INSTRUCTIONS IN THE EXACT SEQUENCE BELOW.
1. Open inflator cover flap so that the manual/automatic inflator is
exposed (Fig. 9).
2. Remove the cylinder/bayonet assembly by rotating counter-
clockwise and then pull out. Discard the used cylinder/bayonet
assembly.
3. Remove cap by turning counter-clockwise. (Fig. 9).
4. Remove bobbin from cap or housing unit. Discard bobbin.
4. Raise, and hold, the lever into the inflator housing. Install a new
cylinder/bayonet assembly by engaging bayonet tabs in housing,
pushing in then turning clockwise 1/8 turn to a full stop (Fig. 8).
PFD WILL ONLY INFLATE IF CYLINDER IS TURNED TO A FULL STOP.
5. Examine the service indicator (Fig. 8) and ensure it is GREEN. If
the service indicator is red, the mechanism has been fired or is
incorrectly fitted and the inflator requires service.
THE SERVICE INDICATOR MUST BE GREEN BEFORE PROCEEDING.
6. Refold the Inflatable PFD in accordance with the Repacking
section (see “Repacking” on page 12).
YOUR INFLATABLE PFD (MD2014) IS NOW READY FOR MANUAL USE
Tab
Piercing Pin
Cylinder
Lever
Service Indicator
MD2014 Manual Inator
1/8 Turn
FIGURE 8 CYLINDER INSTALLATION

10
MD2016 Automatic Inflator
Cap
Step 3
Yellow Bobbin
(white side up)
Step 3
HOUSING***
Step 4
Housing Shoulder
Step 8
Service Indicator
Step 11
Cylinder
Step 2
Cylinder/Bayonet Assembly
Sensor Ring
Step 9
Bayonet
Tab
Step 10
O-Ring
Step 9
Pins
Lever
Step 10
Pull Tab
If GREEN, unit is operable
If RED, stop and service unit
Service Indicator:
FIGURE 9 MD2016 AUTOMATIC INFLATOR
THE YELLOW BOBBIN MAY REMAIN IN THE HOUSING OR IN THE CAP ASSEMBLY WHEN
YOU REMOVE THE CAP. THE BOBBIN MUST BE REMOVED PRIOR TO RE-ARMING.
5. Check the housing to be sure it is clear and dry. If necessary,
rinse the inflator with fresh water to remove dirt and salt. Let dry
before going to step 6.
6. Inspect the bobbin. If the bobbin has been fired or damaged,
replace it! Ensure the new bobbin is valid. It must have been
purchased within the last three (3) years. If the bobbin purchase
date is unknown, check the manufacturing date printed on the
bobbin and replace if older than three (3) years.

11
7. IMPORTANT! Bobbin (yellow) must be installed into the HOUSING
(***Figure 9), white side up, aligning the slots on the bobbin with
the ridges inside the threaded housing. The bobbin will slide in
easily if installed correctly.
8. Install cap by screwing clockwise until it meets the housing
shoulder.
9. Check the new cylinder/bayonet assembly to ensure the o-ring is
in place and the sensor ring is attached (Fig. 9). Ensure that the
CO2cylinder has not been pierced (Fig. 10).
YOU WILL DAMAGE THE SENSOR RING IF BOBBIN AND CAP ARE NOT
INSTALLED FIRST.
10. Push, and hold, the lever into the inflator housing. The pull-cord
should be situated in the groove (Fig. 11). Install a new cylinder/
bayonet assembly by engaging bayonet tabs in housing, pushing
in then turning clockwise 1/8 turn to a full stop (Fig. 11).
PFD WILL ONLY INFLATE IF CYLINDER IS TURNED TO A FULL STOP
11. Examine the service indicator (Fig. 9) and ensure it is GREEN. If
the service indicator is red, the mechanism has been fired or is
incorrectly fitted and the inflator requires service.
THE SERVICE INDICATOR MUST BE GREEN BEFORE PROCEEDING.
12. Refold Inflatable PFD in accordance with the Repacking section
(see “Repacking” on page 12).
YOUR INFLATABLE PFD (MD2016) IS NOW READY FOR MANUAL
USE WITH AUTOMATIC BACKUP
Solid
Cylinder
Top
At
tached
Sensor
Ring
Pierced
Cylinder
Top
Broken
Sensor
Ring
Caution: Do not use the
cylinder/bay
onet assembly
if either the o-ring or
sensor ring is broken,
missing, or damaged.
FIGURE 10 CHECKING C02CYLINDER

12
REPACKING
Repacking should only be done after deflating and re-arming the PFD.
1. Fold sides (A) and (B) outward along dotted lines. Secure with
Velcro™.
2. Make sure inflator status indicator is viewable through window.
3. Make sure the inflator pull-tab is on the outside of the folded PFD.
Fig. 13 depicts a correctly folded PFD.
FIGURE 13 CORRECT
FIGURE 12 FOLD SIDES
Service
Indicator
Groove
Pull-cord
Tab
Piercing
Pin
Cylinder
MD2017 Automatic Inflator
1/8 Turn
Figure 11
A B
View Status Indicator
FIGURE 11 CYLINDER INSTALLATION

13
IS YOUR PFD IN GOOD AND SERVICEABLE CONDITION?
Check your Inflatable PFD between outings to be sure that it is
properly armed; that it is free of rips, tears or holes; that all seams are
securely sewn; and that the fabric, straps and hardware are still strong
(see “Readiness Checklist” on page 3). Inspect the inflatable portion
of the Inflatable PFD in accordance with the “Care and Maintenance
Instructions,” below.
CARE AND MAINTENANCE INSTRUCTIONS
Federal Regulations require Coast Guard approved PFDs that are
legibly marked with the Coast Guard approval number, are in good
and serviceable condition, and are the correct size for each person
on board. It is the responsibility of the operator to be sure this PFD is
in serviceable condition. To be considered serviceable, this PFD shall
not exhibit deterioration that could diminish its performance, such as
broken or deformed hardware, detached webbing, rotted structural
components, air leaks or nonfunctional inflators. Unless worn inflated,
this PFD must also be properly armed with a cylinder installed in
the inflator, a yellow bobbin (water sensing element) installed for
MD2016, and service indicator showing green. See Component
Inspection Instructions. Failure to follow these instructions rigorously
could result in a non-functioning PFD causing injury or death. We
suggest you keep a record of the inspections performed on your
flotation device – using permanent ink on the Care and Storage label
below the oral inflation tube.
You are required to check this flotation device:
• Before each use (component inspection)
• Every six months (leak test and thorough visual examination)
• Annually (suggested at the beginning of each boating season)
INSPECTING YOUR INFLATABLE PFD
Before Each Use:
 Examine the single point status indicator ensuring it is green. If the
indicator is red, your PFD needs to be re-armed (see “Re-arming
Your PFD (MD2014)” on page 8 or see “Re-arming Your PFD
(MD2016)” on page 9).
 Ensure the manual pull-tab is accessible.
 Visually examine your inflatable PFD for damage or excessive
abrasion, wear, tear and/or contamination. If any item shows
signs of damage, perform tasks listed in “Every Six (6) Months”
inspection details.

14
Every Six (6) Months:
In addition to the inspections specified for before each use, perform
the following at least every 6 months, or more often if exposed to
potential damage or used in extreme conditions.
 Leak Test: The PFD should be tested for general leakage by orally
inflating your PFD until firm and letting stand for at least two hours
in a temperature controlled environment. A leaking PFD will not
hold its firmness and should be replaced. If your PFD leaks, contact
Mustang Survival customer service.
Annually:
In addition to the inspections specified for every six months, perform
the following at the beginning of each boating season or whenever
the integrity of your inflatable PFD is in doubt:
 Thoroughly check all components for dirt and/or corrosion. Clean
or replace, as necessary. If any item shows signs of damage,
perform inspections listed in “Every Six (6) Months” inspection
details. If in doubt, contact Mustang Survival customer service.
 For MD2016 only. Ensure the current date is not three (3) years
past the date on the bobbin. If it is, re-arm the inflator (see
Re-arming Your PFD (MD2016) on page 10).
 Record as an “Annual” inspection in permanent ink on the Care and
Storage label, in the Date Maintained column. Repack the PFD as
outlined in the Repacking section, on page 12.
CLEANING AND STORING OF YOUR INFLATABLE PFD
To clean your inflatable PFD, hand wash or sponge down in warm,
soapy water, taking care not to expose the inflator to water. Rinse
your PFD with clean water, and hang to dry on a plastic coat hanger.
Do not dry-clean, use chlorine bleach, or apply direct heat. Always
store your fully dried PFD in a warm, dry, well ventilated place out of
direct sunlight.

15
HOW AND WHY TO TEST YOUR PFD
Inflate your Inflatable PFD and try it out in the water to:
1. Make sure it floats you:
• Comfortably (when worn properly)
• Adequately for expected wave conditions (body shapes/densities
affect performance)
2. Make sure it works:
• A flow of bubbles should not appear (see “Care and Maintenance
Instructions” on page 13 for leak tests). It should inflate quickly
and easily.
3. Learn how it works by:
• Activating the CO2inflation system
• Re-arming the CO2inflation system
• Using the oral inflator tube
The U.S. Coast Guard recommends that you purchase two re-arming
kits. One to be used immediately in testing the inflation system and
the other to carry onboard as a spare.
For MD2016
The U.S. Coast Guard recommends you test the automatic inflation
system in-water at the beginning of each boating season. By doing
this, you demonstrate that the automatic inflation system is still
working properly and reduce the likelihood of premature inflation and
its associated dangers.
For Both MD2014 and MD2016
Check the manual inflation system by first removing the CO2cylinder/
bayonet assembly: rotate counterclockwise and pull out. On the
flotation device, move the lever (attached to the pull-tab) several
times down and up to determine that the lever arm and piercing pin
move freely. There should be no binding of the mechanical parts.
HOW DO YOU TEST YOUR PFD USING THE AUTOMATIC INFLATOR? (MD2016)
A1. To test your Inflatable PFD, you will need:
• your fully armed Inflatable PFD
• the re-arming kit approved for your device (MA2014)
A2. Put on the Inflatable PFD.

16
A3. Get into shallow water, just deep enough that you can stand with
your head above the surface. Once the inflator is underwater
the Inflatable PFD should fully inflate automatically within 10
seconds.
A4. See if the Inflatable PFD will float you on your back or just
slightly back of vertical. In a relaxed floating position, verify that
your mouth is well above the water’s surface. Note the effect of
where you hold your legs on how you float.
A5. Get out of the water and remove the Inflatable PFD.
A6. Deflate the Inflatable PFD by depressing the oral inflator valve
(see “Deflating the Inflatable PFD” on page 7). Remove the used
CO2cylinder/bayonet assembly and the used bobbin from the
Inflatable PFD inflator.
A7. Let the Inflatable PFD dry thoroughly. Re-arm and Repack the
PFD (see “Re-arming Your PFD (MD2016)” on page 9 and see
“Repacking” on page 12).
HOW DO YOU TEST YOUR PFD USING THE MANUAL INFLATOR?
M1. To test your Inflatable PFD, you will need:
• your fully armed Inflatable PFD
• the re-arming kit approved for your device (MA2014)
M2. Put on the Inflatable PFD.
M3. Actuate the inflation system by jerking firmly downward on the
pull-tab. The Inflatable PFD should fully inflate within 5 seconds.
M4. Get into shallow water, just deep enough that you can stand with
your head above the surface.
M5. See if the Inflatable PFD will float you on your back or just
slightly back of vertical. In a relaxed floating position, verify that
your mouth is well above the water’s surface. Note the effect of
where you hold your legs and how you float.
M6. Get out of the water and remove the Inflatable PFD. Completely
deflate the Inflatable PFD using the oral inflator (see Deflating
the Inflatable PFD on page 7). Remove the CO2cylinder/bayonet
assembly from the inflator.
M7. Let the Inflatable PFD dry thoroughly. Re-arm and Repack the
PFD (see “Re-arming Your PFD (MD2014)” on page 8 or see
“Re-arming Your PFD (MD2016)” on page 9 and see “Repacking”
on page 12).

17
HOW DO YOU TEST YOUR PFD USING THE ORAL INFLATOR?
You will not need any spare parts, or re-arming kits, to test your
flotation device with oral inflation, and it gives you the opportunity to
learn about how much inflation is needed to float you.
O1. Remove the CO2cylinder/bayonet assembly to prevent
inadvertent inflation, which could potentially damage the
Inflatable PFD. Inspect the cylinder to confirm it is unused (Fig.
10). Unscrew and remove the cap and the bobbin (MD2016 only).
Otherwise the bobbin will disintegrate during water immersion.
O2. Put on the Inflatable PFD.
O3. Get into shallow water, just deep enough that you can stand with
your head above the surface.
O4. If you are a weak swimmer or non-swimmer, orally inflate the
Inflatable PFD partially so that you are supported well enough to
be able to complete inflation without touching bottom. Note this
level of inflation because it is the minimum needed for you to
safely use this Inflatable PFD.
O5. Fully inflate the Inflatable PFD using the oral inflator.
O6. See if the Inflatable PFD will float you on your back or just
slightly back of vertical. In a relaxed floating position, verify that
your mouth is well above the water’s surface. Note the effect of
where you hold your legs on how you float.
O7. Get out of the water and remove the Inflatable PFD. Completely
deflate the Inflatable PFD using the oral inflator.
O8. Let the Inflatable PFD dry thoroughly. Re-arm (for your model)
and Repack the PFD (see “Re-arming Your PFD (MD2014)” on
page 8 or see “Re-arming Your PFD (MD2016)” on page 9 and
see “Repacking” on page 12).
