XR6/XR3 Transmitter
Pre-installation Manual
Document:XR6/XR3-PREINST
Issue: 3.0 2009-07-15
Status: Preliminary

blank

Nautel Limited
10089 Peggy’s Cove Road
Hackett’s Cove, NS Canada B3Z 3J4
Phone: [phone] or
Toll Free: +1.877.6NAUTEL (6628835) (Canada & USA only)
Fax: [phone]
Nautel Inc.
201 Target Industrial Circle
Bangor, Maine USA 04401
Phone: [phone]
Fax: [phone]
Customer Service (24 hour support)
+1.877.628.8353 (Canada & USA only)
+1.902.823.5100 (International)
Email: [email protected]
Web: www.nautel.com
The comparisons and other information provided in this document
have been prepared in good faith based on publicly available
information. The reader is encouraged to consult the respective
manufacturer's most recent published data for verification.
© Copyright 2009 NAUTEL. All rights reserved.

blank

XR6/XR3 Pre-installation Manual Table of contents
Page v
Contents
About this manual ix
About safety xiii
Safety precautions xv
Description 1-1
Capabilities 1-1
Options 1-2
Pre-installation tasks 2-1
Preparing for installation 2-1
Selecting a location for the transmitter 2-2
Installing an antenna feedline 2-3
Physical requirements 3-1
Clearances 3-1
Dimensions 3-2
Weights 3-5
Cooling requirements 4-1
Air flow in the transmitter 4-1
Cooling 4-2
Heating 4-3
Electrical requirements 5-1
Electrical power 5-1
Station reference ground 5-4

XR6/XR3 Pre-installation Manual
Page vi Issue 3.0 2009-07-15
Control and monitoring 6-1
Controls 6-1
Alarm definitions 6-1
Remote control circuits and alarms 6-7
Remote performance monitoring 6-12
LAN interface (NxLink) 6-13
Other considerations 7-1
External RF drive source 7-1
External 10 MHz frequency reference 7-2
RF output requirements 8-1
Antenna feed cable 8-1
Antenna system 8-3
Parts and tools 9-1
Contacting Nautel 9-1
Parts supplied by Nautel 9-1
Parts not supplied by Nautel 9-2
Parts ordering 9-2
Module replacement program 9-2
Tools for installation 9-3
Accessories 10-1
Contacting Nautel 10-1
Ac line surge protection 10-2
Automatic antenna transfer control unit 10-2
RF contactor 10-3
Automatic switching system 10-4
Dynamic carrier control unit 10-4
Spares 10-4

XR6/XR3 Pre-installation Manual
Issue 3.0 2009-07-15 Page vii
Pre-installation assistance 11-1
Pre-installation consulting 11-1
Installation and commissioning service 11-1
Online documentation 11-3
On-site support 11-3
Training 11-3
Standard warranty 11-4
Extended warranties 11-7
List of terms 12-1
Index IX-1

XR6/XR3 Pre-installation Manual
Page viii Issue 3.0 2009-07-15

XR6/XR3 Pre-installation Manual
Issue 3.0 2009-07-15 Page ix
About this manual
This manual provides information about preparing for the delivery and installation of an XR6/XR3
transmitter. This manual is intended for use by field technicians, site managers, and installation
planners.
Using this manual
Read the task list provided in Section 2, “Pre-installation tasks” on page 2-1. The task list describes
the preparations you must make prior to receiving and installing the XR6/XR3 transmitter.
Later sections of the manual provide reference information regarding physical, cooling, electrical, and
antenna requirements.
Technical support
Nautel offers technical support to customers over the Internet and by telephone. Nautel’s customer
support team will answer your questions and work with you to identify and resolve problems.
For technical support, call the Customer Support Team at 902-823-3900 or - in U.S.A. and Canada
only - call toll free at 1-877-6NAUTEL (662-8835). Or find us on the Internet at http://
www.nautel.com.
For parts and tools information, see “Parts and tools” on page 9-1 of the XR6/XR3 Pre-Installation
Manual.
For accessories or spares, see “Accessories” on page 10-1 of the XR6/XR3 Pre-Installation Manual.
For standard warranty information, see “Pre-installation assistance” on page 11-1 of the
XR6/XR3 Pre-Installation Manual.
For extended warranty information, see “Pre-installation assistance” on page 11-1 of the
XR6/XR3 Pre-Installation Manual.
XR6/XR3 transmitter manuals
The XR6/XR3 documentation suite includes the following documents:

XR6/XR3 Pre-installation Manual
Page x Issue 3.0 2009-07-15
XR6/XR3 Pre-installation Manual, XR6/XR3-PREINST. The Pre-installation Manual provides
instructions and reference information needed when planning and preparing for the installation of an
XR6/XR3 transmitter.
Nautel Site Protection Manual. The Site Protection Manual provides detailed information
about protecting your site from lightning-related hazards.
XR6/XR3 Installation Manual, XR6/XR3-INST. The Installation Manual provides instructions
and reference information needed when installing an XR6/XR3 transmitter.
XR6/XR3 Operating and Maintenance Manual, XR6/XR3-OPS-MAINT. The Operating and
Maintenance Manual provides instructions for operating, maintaining and troubleshooting
an XR6/XR3 transmitter. It also provides reference information needed when performing diagnostic
procedures.
XR6/XR3 Troubleshooting Manual, XR6/XR3-TROUBLE. The Troubleshooting Manual
provides detailed technical information about the XR6/XR3 transmitter, including electrical
schematics and mechanical drawings.
Nautel website / Online resources
The Nautel website provides useful resources to keep you up to date on your XR6/XR3.
Nautel User Group (NUG)
The website includes a special section that customers can log into in order to access the Nautel
customer newsletter, product manuals, frequently asked questions (FAQ), information sheets, and
information about field upgrades. Registration is available online and is required.
Documentation: online and printed
The website’s NUG section provides online access to all the documentation for your XR6/XR3.
Documentation is provided in Acrobat (PDF) format. You can use the documentation online or print
the sections that you need.
When using online documents:
• Click on blue text (hyperlinks) to jump to a related section, or to get additional information
(e.g., view a term’s definition).
• To search a document to find keywords, use Find in Acrobat Reader’s Edit menu.
• To quickly find a specific section, click the section in the PDF file’s Bookmarks list.

XR6/XR3 Pre-installation Manual
Issue 3.0 2009-07-15 Page xi
When using printed documents:
• To find keywords, go to the Index section at the end of the manual.
• To find a specific term, go to the List of Terms section near the end of the manual.

XR6/XR3 Pre-installation Manual
Page xii Issue 3.0 2009-07-15

XR6/XR3 Pre-installation Manual
Issue 3.0 2009-07-15 Page xiii
About safety
All Nautel transmitters are designed to meet the requirements of EN60215, Safety Requirements for
Radio Transmitters.
The philosophy of EN60215 is that the removal of any cover or panel that can only be opened using
a tool is a maintenance activity, and that any person performing a maintenance activity is expected to
be trained for that activity. Under EN60215, it is assumed that trained personnel will be
knowledgeable and will take precautions such as removing all power to the transmitter before
accessing its components.
Electrical hazards
To remove power from the transmitter, switch off and lock out the ac power. There are three amber
LEDs at the bottom rear of the cabinet that glow to remind anyone who has not turned off the
power that the system is live and serious danger is present.
Mount the transmitter ac power disconnect switch/breaker close to the transmitter so that it can be
reached quickly in an emergency. Clearly label the disconnect switch/breaker (e.g., EMERGENCY
SWITCH).
After turning off the power, always perform a measurement to confirm that the power is off before
touching anything within the transmitter. If the wrong breaker was opened, the equipment will be
live.
Use only a non-contact voltage probe or a safety voltmeter (available from vendors such as Fluke,
Ideal, and Teagam).
Use a proper lockout procedure to ensure that another worker cannot accidentally reapply power
while you are performing maintenance on any part of the transmitter or site.
WARNING: It is not enough to remove RF power. The power line is still
connected.
WARNING: Do not use an ordinary multimeter to check for voltage,
since it may have been left inadvertently on the AMP (A) range,
triggering a short and an arc blast that could result in severe burns
and even death.

XR6/XR3 Pre-installation Manual
Page xiv Issue 3.0 2009-07-15
Lightning hazards
Before opening the transmitter and touching internal parts, remove and solidly ground the antenna
connection.
RF hazards
A serious RF hazard and very high voltages exist in the vicinity of the antenna and its networks
during normal operations.
Toxic hazards
There are devices used in this equipment containing beryllium oxide ceramic, which is non-hazardous
during normal device operation and under normal device failure conditions. These devices are
specifically identified with “(BeO)” in the Description column of the Troubleshooting Manual’s parts
list(s).
Do not cut, crush or grind devices because the resulting dust may be hazardous if inhaled.
Unserviceable devices should be disposed of as harmful waste.
Other hazards
Ensure that appropriate fire alarms and fire extinguishers are available. Extinguishers must be suitable
for use on electrical fires.
Many other site safety risks exist. It is beyond the scope of this manual to identify all the risks and
procedures.
WARNING: It is not enough to ground the antenna terminal with the
antenna still connected. Even a small impedance in the ground strap
will result in lethal voltages during a lightning strike.

XR6/XR3 Pre-installation Manual
Issue 3.0 2009-07-15 Page xv
Safety precautions
This section provides very important information about protecting the safety of personnel and
equipment:
• Personal safety - see page xv
• Site safety - see page xvi
• Equipment safety - see page xviii
Personal safety
Training
The training of any personnel who will have physical access to the site or the transmitter is very
important. Personnel must be familiar with the transmitter, so that they can avoid physical danger,
and be aware of hazards to themselves and the equipment.
Nautel offers a number of training courses covering the basic fundamentals of RF systems and
transmitters, and the operation and maintenance of the transmitter. For more information about
available courses and schedules, go to the Nautel website at http://www.nautel.com/Training.aspx,
or ask your Nautel sales representative.
Site orientation
When you give personnel access to the transmitter site (e.g., hiring new personnel, or giving access
keys to personnel), perform a site orientation to ensure that they are familiar with the site, on-site
procedures, and on-site hazards. Cover the following topics:
• Securing the site (locking doors and fences) to prevent unauthorized access
• How and when to call for technical support or emergency assistance
• Areas of the site and pieces of equipment that are off limits

XR6/XR3 Pre-installation Manual
Page xvi Issue 3.0 2009-07-15
Voltage awareness
Ensure that all personnel that are able to access areas with high voltage circuits or high field strengths
are aware of the hazards associated with high voltage. Cover the following topics:
• High voltage or high field strength areas where caution is required
• Physical risks of electric shock
• Risks for personnel with pacemakers or other medical implants
• Induced voltages in high field strength areas
• On-site risks during thunderstorms and lightning strikes
• Operation of safety interlocks (if installed)
First aid
Nautel does not offer first aid training, since the hazards associated with high voltage and RF energy
are not specific to the transmitter. However, the customer should provide first aid training to all per-
sonnel who have access to the transmitter site. First aid training should include CPR, care of burns,
artificial respiration, and defibrillation if specific equipment is available on-site.
Site safety
Controlling access
Transmitters and antennas generate and carry dangerous voltages that can be harmful or fatal. It is
very important that you control access to the site and its equipment. To secure your transmitter site,
use:
• Locking steel or security doors to prevent casual access
• A perimeter fence to keep trespassers away from the antenna system and feedline
• “No Trespassing” signs
• An alarm system

XR6/XR3 Pre-installation Manual
Issue 3.0 2009-07-15 Page xvii
Marking hazards
Place warning signs close to any hazardous areas or systems (e.g., the feedline or the antenna system).
Make the signs large enough that they cannot be missed. Provide signage in all languages used in the
region. These signs are intended not only for authorized personnel, but also for emergency
responders or accidental trespassers.
Qualifying site personnel
Make sure that personnel who have access to the site are qualified to work around electronics and
high voltage systems.
Ac power protection
You should take steps to protect equipment from surges (over-voltage spikes) on the ac power lines.
Surges may occur during thunderstorms, or because of malfunctions in the electrical distribution grid.
Surge suppressors and ac power conditioners can prevent serious damage to your on-site equipment,
including the transmitter.
RF protection
Transmitters and their antenna systems create intense radio frequency fields at the transmitter site,
particularly near the feedline, antenna and tower. At some sites, these fields may cause biological
effects, including the heating of body tissues. Intense fields can also create dangerous high voltages
on ungrounded, conductive surfaces and objects. At certain points where high voltage conductors
come close to grounded conductors (e.g., at feedline junctions or on the tower), dangerous electrical
arcing or flashovers can occur. It is very important that you take the following steps to prevent
damage to equipment or personnel due to RF fields:
• Use safety interlocks to de-energize transmitters if personnel open doors or panels accessing
high field areas
• Place warning signs in any locations where high fields can occur
• Train personnel about the short-term and long-term hazards of RF radiation
• Physically block access to the area around the antenna system, feedline and tower
• Ground all exposed conductive surfaces or objects in high field areas
The RF connection to the transmitter output can be a serious safety hazard. Connect a 50 Ωtest load
during installation and commissioning. It is recommended that a switch be used to automatically
connect the transmitter to the antenna system without human contact with the transmitting
conductors.

XR6/XR3 Pre-installation Manual
Page xviii Issue 3.0 2009-07-15
Safety interlocks
The transmitter contains an electrical interlock, which is an external circuit that turns off the RF
output if any of its switches are opened.
Ac disconnect switch
Safe operation of the transmitter requires an ac disconnect switch. Lock the ac disconnect switch in
the disconnected (open) position during the installation process.
Equipment safety
Electrostatic protection
The transmitter’s systems are very rugged and resistant to damage. However, it is possible for damage
to occur because of high voltage electrostatic discharges during servicing. Train all service personnel
to ground themselves to bleed off any static charge before opening the transmitter or touching any
exposed components. Provide a grounding wand or known ground (e.g., a grounded metal table) that
personnel can use to discharge themselves.
Surge protection
Surge protection is recommended for your entire site. However, even if you do not use a surge
protector on the service entrance to the site, you should install a surge protector in the transmitter’s
ac power feed to prevent over-voltage from entering the transmitter.
Lightning protection
The transmitter is designed to resist lightning strike damage. However, intense or repeated strikes
could damage the transmitter. We recommend that you install lightning suppression on the antenna,
tower and feedline to reduce the effect of lightning strikes on the transmitter itself (and to protect the
rest of your site equipment and your personnel). For detailed information about lightning protection,
see the Nautel Site Preparation Manual, available from your Nautel sales agent, or online from the
Nautel website.
Physical protection
Consider physical hazards to equipment at your site, including the transmitter. Ensure that equipment
is protected from weather (e.g., rain or flooding), even during extreme weather events. Place
equipment so that it is not in the path of swinging doors or high-traffic areas. Do not allow wheeled
items like office chairs or tables with wheels in the transmitter room, as these may damage equipment
if accidentally pushed or knocked over. Do not place the transmitter under water pipes, drains, or
sprinklers. Keep any equipment that generates heat, like the transmitter, away from flammable
materials like ceiling panels, cubicle dividers, and curtains.

XR6/XR3 Pre-installation Manual
Issue 3.0 2009-07-15 Page xix
Earthquake protection
If the transmitter site is in a region that experiences any noticeable earthquake activity, take steps to
prevent the transmitter from shifting or rocking during an earthquake. Even during minor
earthquakes, rocking or movement of the transmitter is likely to damage the feedline connection, and
could even cause a catastrophic failure of the ac power feed into the transmitter. During larger
earthquakes, the weight of the transmitter chassis could be hazardous to nearby equipment or
personnel.

XR6/XR3 Pre-installation Manual
Page xx Issue 3.0 2009-07-15
