Smooth Operator Configuration Note
For Smooth Operator Family of Products
Disclaimer: Configuration Notes are designed to be a general guide reflecting Octel's experience
configuring its systems. These notes cannot anticipate every configuration possibility given the inherent
variations in all hardware and software products. Please understand that you may experience a problem not
detailed in a Configuration Note. If so, please notify Sales Engineering at [phone], and if
appropriate we will include it in our next revision. Octel accepts no responsibility for errors or omissions
contained herein.
Octel
Voice
Processing
Module
Configuration Note 77175
NEC Neax 2400 * with
Direct Serial Link
Revised 10/24/97
Analog Ports
RS 232 Connection
via Cable to the
serial port on the PC
Personal Computer
Voice Board(s)
NEC Neax 2400
MCI Link on NEC
1.0 METHOD OF INTEGRATION
RS-232 / Direct Serial Integration. Smooth Operator communicates with
the NEAX 2400 using Feature 2 of the Message Center Interface (MCI).
Call forward to personal greeting is achieved by call information being sent
over the MCI link to the RS232 port on Smooth Operator when calls are
forwarded to the Voice Mail UCD group. Message Waiting Lights are set
and canceled using the NEC message center feature. A hookflash followed
by the extension transfers the caller to the operator.
2.0 SMOOTH OPERATOR ORDERING INFORMATION
There are many options available for both kit and turnkey versions of this
product, depending on the application. Please consult with your sales
representative. TheRS-232 Serial Software for NEC NEAX 2400 diskette,
part number S-COM-1031, and Modem cable (BEL-ATHAY10), part
number H-COM-2215 must be used.
Communications between the
Neax 2400 and the Smooth
Operator are through a RS-232
Connection to the serial port on
the PC.
Smooth Operator Ordering
Information

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 2
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
3.0 SWITCH HARDWARE REQUIREMENTS
NEAX Message Center Interface (MCI) link I/O card I002-A
One single line port port for each integrated voice port to be
programmed into a UCD group. (PA-16LCQ is recommended since
it can be programmed to provide loop current detection).
NEAX MCI RS 232, requires TTY-CA cable and TTY-CA-1 cable
One RJ-14 jack with 4-conductor line cord for every two Sm Oper
ports
80 volt power supply for for messaage waiting lights on single line
phones
One analog line for remote service access
One RJ-11 Jack for above and 2-conductor modular telephone cord.
If FaxMail is installed.
- One analog line per FAX port.
- One RJ-11 Jack for every Brooktrout TR-112 fax port OR one
RJ-14 Jack for every two Brooktrout TR-114 fax ports, along
with
4-conductor modular telephone cords.
3.1 SWITCH SOFTWARE REQUIREMENTS
NEAX 2400 SIM or IMG 5200
NEAX 2400 MMG or UMG 4200 or 5200
Note: Versions prior to 4200 may not provide overflow to UCD, also
there may be problems passing caller information from the MCI
to the Smooth Operator on internal transfers.
4.0 SUPPORTED FEATURES
[9] Items are supported
System Forward to Personal Greeting Message Waiting
All Calls [ ] LCD Display [9]
Ring/no answer [ ] LED [ ]
Busy [ ] Lamp [9]
Busy/No Answer [ ] Audible / Stutter Dial Tone [ ]
Do Not Disturb [ ] Multiple Return to Operator [9]
Station Forward to Personal Greeting Direct Call [9]
All Calls [9] Auto Attendant [9]
Ring/no answer [9] Outcalling [9]
Busy [9] Personal Greeting of Original-Called Party
Busy/No Answer [ ] Multiple Call Forward [9]
Do Not Disturb [ ] Double Call Forward [ ]
Flexible Forwarding Call Coverage [
]
Forward to No Answer Greeting [9] Intercom Paging [9]
Forward to Busy Greeting [9] Supervised Transfers
Intercom/CO Forwarding [ ] Call Screening [9]
Call Queuing [9]
Switch hardware requirements
Switch software requirements
Supported integration features

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 3
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
Intercom Paging [9]
Record Telephone Conversation [ ]
4.1 DISCONNECT TYPE
Disconnect is achieved by either Drop in Loop or Fast busy. For proper
external disconnect supervision, Ground start or Supervised Loop start CO
lines are recommended. (see Note 7.1)
5.0 CONFIGURING THE NEC NEAX 2400
Before you begin programming, it is recommended that a hard copy of the
customer database be obtained to verify existing programming.
When configuring the MCI link, the switch system administrator should be
contacted to avoid possible programming conflicts. Remember to instruct
the SWITCH that the MCI is not a MAT terminal.
Note: In the following examples, 100 will represent the UCD pilot number
for Voice Mail. Single Line extensions to the Smooth Operator will be 100,
101, 102 and 103.
5.1 NEAX 2400 SYSTEM PROGRAMMING
Refer to the Programming section in the NEC manual for information on
entering, saving, and exiting database programming.
To allow multiple call forward to personal greeting, enter system
programming. Data will specify the number of hops allowed on calls
forwarded under Busy/No answer conditions.
Assignment of System Data
SYS : 1 SYS: System Data Items
INDEX : 5DATA: XX 1-System Data 1
2-System Data 2
3-System Data 3
INDEX: System Data Index
System Index
1 0-255
2 0-15
3 0-31
DATA: System Data
(Hexadecimal)
SYS: Number of hops allowed on calls forwarded is a system-wide
parameter, type 1 in this field, then press ENTER.
INDEX: Enter 5for number of hops allowed on calls forwarded.
DATA: Max value allowed is 05 for 5 hops. Consult the System
Administrator for proper value.
Programming switch system
parameters

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 4
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
To allow blind transfer to the attendant(s) console, enter system programming.
Assignment of System Data
SYS : 1 SYS: System Data Items
INDEX : 5 DATA: XX 1-System Data 1
2-System Data 2
3-System Data 3
INDEX: System Data Index
System Index
1 0-255
2 0-15
3 0-31
DATA: System Data (Hexadecimal)
SYS: Allow blind transfer to the attendant(s) console is a system-wide
parameter, type 1 in this field, then press ENTER.
INDEX: Enter 17 for allow blind transfer to the attendant(s) console.
DATA: Minimum value is 08 to enable bit 4. Consult the System
Administrator for proper value. For 4200 or 5200 Rel I series
software an application disk must be loaded.
5.2 CONFIGURING THE SINGLE LINE PORTS
The following screens are taken from a NEAX MAT terminal.
* * * 2400 MAINTENANCE COMMAND MENU * * *
1 SYSTEM CONTROL
2 SYSTEM BACKUP
3 MAKE BUSY CONTROL
4 TRAFFIC DATA
5 TEST
6 STATION DATA
7 TRUNK DATA
8 NUMBERING PLAN
9 SERVICE FEATURE DATA (1)
10 SERVICE FEATURE DATA (2)
11 SIGNAL TRANSLATION DATA
12 RESTRICTION DATA
13 INSTALLATION
14 LIST UP
ENTER MENU ITEM NO [ 6 ]

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 5
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
Select Menu Item 6.Then press the ENTER key
For this example we are using a consecutive block (100-103) of extension
numbers. You must add each extension to the system and program it
properly.
* * * STATION DATA COMMANDS * * *
1 ASDT: Assignment of Station Data [CM01]
2 ASCL: Assignment of Station Class Data [CM01]
3 ASTN: Assignment of Station Number [CM01]
4 DSTN: Display of Station Data [CM01]
5 AKYD: Assignment of Key Data for Dterm [CM01]
6 ASHP: Assignment of Station Hunting-Pilot [CM01]
7 RSHP: Remove Station Hunting-Pilot [CM01]
8 ASHC: Assignment of Station Hunting-Circular [CM01]
9 RSHC:Remove Station Hunting-Circular [CM01]
10 ACPG:Assignment of Call Pickup Group [CM01]
11 AISA: Assignment of Individual Speed Calling Entry Area [CM02]
12 APHN:Assignment of Phantom Station Number [CM02]
13 ASHU:Assignment of Station Hunting-UCD [CM01]
14 RSHU:Remove Station Hunting-UCD [CM01]
15 AUOG: Assignment of UCD Overflow Group [CM01]
ENTER MENU ITEM NO [ 1]
Select ASSIGNMENT OF STATION DATA option by typing 1then press the
ENTER key.
Enter The station administration data for extension 100 (the first single line port).
In order to correctly set up the single line ports, follow the steps below:
TN: Tenant Number (default = 1). Consult the System Administrator to see if
this value should be modified. If this value does not need modification,
press ENTER to go to the next field.
STN: Station Number. Enter the extension number of the first single line port,
(as per our example, this would be 100). Press ENTER to go to the next
field. The extension of the first single line voice mail port will be the
forwarding target for the subscribers.
LENS: Line Equipment Number (default=00000). Consult the System
Administrator for the proper line equipment assignment. After entering
the correct data, press ENTER.
TEC: Telephone Class (default-1). This should be changed to 3to allow dial
pulse and push button functions. Press ENTER to go to the next field.
RSC: Route Restriction Class (default=0). Consult the System Administrator
for proper value.
SFC: Service Feature Class (default=0). Consult the System Administrator
for proper value.

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 6
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
When programming a port, you may need to change the Tenant Number.
You will need to select and enter a proper Station Number and Line
Equipment Assignment. Telephone Class must be set to 3. A Route
Restriction Class and Service Feature Class must be selected. There are no
known conflicts with the options in either Route Restriction Class or
Service Feature Class at this time.
Assignment of Station Data
TN: Tenant Number
TN: 1 STN: 100 STN: Station Number
LENS: 000000 LENS: Line Equipment Number (6 Digits)
TEC: 3RSC: 0 SFC: 0 TEC: Telephone Class (1-31)
1-DP (10PPS) 22-EMM
2-PB
3-DP/PB
11-VMM/VMZ
12-Dterm V
13-Data Terminal Via Dterm V
14-Hot Line
15-Cas Line
RSC: Route Restriction Class (0-15) 16-Data Terminal via Data Module
For assignment of RSC, ARSC command 18-Virtual Line Appearance
SFC: Service Feature Class (0-15) 19-TMM
For assignment of SFC, ASFC command 20-PSM
When you are done editing the final field on this screen, press the ENTER key
to confirm the single line station programming. When assigning the first
station data command for a Line Package, the message "PKG CHECK" will
be displayed on the screen. At this point, check that the right circuit card is in
the slot on the switch and then press the ENTER key. All assignments to the
same Line Package, after the initial one, will prompt you with a "WRT?"
message after entering the station data. Type "Y" then press the ENTER key
to confirm your information. The cursor will then move to the first field,
allowing you to configure the next single line port. Repeat this step for each
single line port.
When you have configured all your single line ports, press the \
(BACKSLASH) key to return to the Station Menu.

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 7
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
5.3 ASSIGNING SINGLE LINE PORTS TO A UCD GROUP
* * * STATION DATA COMMANDS * * *
1 ASDT: Assignment of Station Data [CM01]
2 ASCL: Assignment of Station Class Data [CM01]
3 ASTN: Assignment of Station Number [CM01]
4 DSTN: Display of Station Data [CM01]
5 AKYD: Assignment of Key Data for Dterm [CM01]
6 ASHP: Assignment of Station Hunting-Pilot [CM01]
7 RSHP: Remove Station Hunting-Pilot [CM01]
8 ASHC: Assignment of Station Hunting-Circular [CM01]
9 RSHC: Remove Station Hunting-Circular [CM01]
10 ACPG: Assignment of Call Pickup Group [CM01]
11 AISA: Assignment of Individual Speed Calling Entry Area [CM02]
12 APHN: Assignment of Phantom Station Number [CM02]
13 ASHU: Assignment of Station Hunting-UCD [CM01]
14 RSHU: Remove Station Hunting-UCD [CM01]
15 AUOG: Assignment of UCD Overflow Group [CM01]
ENTER MENU ITEM NO [ 13 ]
From the Station Data Menu, type 13, for Assignment of Station Hunting-
UCD. Press the ENTER key.
The Tenant Number that was used when configuring the single line ports
must be the same one used in the Assignment of Station Hunting-UCD.
The first single line port, is entered as the Station Number (STN: 100).
Note: Not all versions use the first station number as the pilot number
of the hunt group. Contact the System Administrator and
determine if a pilot number is assigned or the number of the first
station is used.
By setting the Count (CNT) to 4, you have created a UCD group for four
single line ports accessed through the UCD target number 100. Enter the
second single line port number for the second Station Number (STN: 101).
Assignment of Station Hunting-UCD
TN: 1 TN: Tenant Number
STN: 100 STN: Station Number
CNT: 4 2 STN: 101 CNT: Number of Stations to be entered
(number of Voice Mail ports)
ADD: Number of Stations to be added
*STN: Station Number of the Stations
included in the UCD group.
(*indicates the order of a
station in the group)
After adding the second single line port number, press ENTER. The
screen will update as shown below.

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 8
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
Assignment of Station Hunting-UCD
TN: 1 TN: Tenant Number
STN: 100 STN: Station Number
CNT: 4 3 STN: 102 CNT: Number of Stations to be entered
(number of Voice Mail ports)
ADD: Number of Stations to be added
*STN: Station Number of the Stations
included in the UCD group.
(*indicates the order of a
station in the group)
You are now prompted to enter the extension of the third single line port,
(102). After entering the extension press ENTER.The screen will update
in the same manner, prompting you for the fourth member of the UCD
group. After entering the data for the final UCD member, you will be
prompted with a "WRT?" message. Type "Y" and press ENTER.
Press the "\" (BACKSLASH) key to return to the Station Data Menu, then
press the "\" (BACKSLASH) key again to return to the 2400 Maintenance
Command Menu.
5.4 CONFIGURING THE MESSAGE CENTER INTERFACE LINK
* * * 2400 MAINTENANCE COMMAND MENU * * *
1 SYSTEM CONTROL
2 SYSTEM BACKUP
3 MAKE BUSY CONTROL
4 TRAFFIC DATA
5 TEST
6 STATION DATA
7 TRUNK DATA
8 NUMBERING PLAN
9 SERVICE FEATURE DATA (1)
10 SERVICE FEATURE DATA (2)
11 SIGNAL TRANSLATION DATA
12 RESTRICTION DATA
13 INSTALLATION
14 LIST UP
ENTER MENU ITEM NO [ 13 ]
Select option 13 (INSTALLATION) from the Main Menu. Press ENTER

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 9
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
* * * INSTALLATION COMMANDS * * *
1 ASYD: Assignment of System Data [CM03]
2 AUNT: Assignment of Unit Data [CM03]
3 ASTD: Assignment of State Translation Data [CM03]
4 ATCC: Assignment Terminal Configuration Command [CM03]
5 ASMD: Assignment of Service Module Data [CM03]
6 MMNF: Make Menu File [CM02]
ENTER MENU ITEM NO [ 1]
Type 1to select System Data. Press ENTER
The next five steps represent the minimum requirements necessary for the
MCI integration to work correctly. The data field entered may be different
for each installation and should never be changed without first consulting
the Switch Administrator.
ONE: MESSAGE WAITING LIGHT PROGRAMMING
Assignment of System Data
SYS : 1 SYS: System Data Items
INDEX : 28 DATA: 20 1-System Data 1
2-System Data 2
3-System Data 3
INDEX: System Data Index
System Index
1 0-255
2 0-15
3 0-31
DATA: System Data (Hexadecimal)
SYS: Message waiting control is a system-wide parameter, type 1
in this field, then press ENTER.
INDEX: Enter 28 for message waiting control.
DATA: Enter a value of 20 to set bit 5 of index 20 to 1, this allows the
MCI link to control Message Waiting Lights. This value should
not be changed without consulting the System Administrator.

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 10
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
TWO: MCI LINK PORT ASSIGNMENT
There are different ports available to the switch and one is reserved for the
MAT terminal. Consult your Switch Administrator before programming
this parameter. In our example we have assumed that Terminal 1 is
assigned as the MCI link.
Assignment of System Data
SYS : 1 SYS: System Data Items
INDEX : 29 DATA: 02 1-System Data 1
2-System Data 2
3-System Data 3
INDEX: System Data Index
System Index
1 0-255
2 0-15
3 0-31
DATA: System Data (Hexadecimal)
SYS: MCI data link programming is a system-wide parameter, type 1
in this field, then press ENTER.
INDEX: Set index to 29 to assign a communications port for the data link.
DATA: There are different ports available to the switch, one is reserved
for the MAT terminal. Consult your Switch Administrator
before programming this parameter. Use the following table to
determine the proper data input for index 29.
Link number DATA PORT
Mat Terminal 00 0
1 02 1
2 04 2
3 08 3
4 10 4
5 20 5
THREE: DATA BITS AND PARITY ASSIGNMENT
Assignment of System Data
SYS : 1 SYS: System Data Items
INDEX : 34 DATA: 09 1-System Data 1
2-System Data 2
3-System Data 3
INDEX: System Data Index
System Index
1 0-255
2 0-15
3 0-31
DATA: System Data (Hexadecimal)

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 11
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
SYS: Data bits and Parity Assignment is a system-wide parameter,
type 1 in this field, then press ENTER.
INDEX: Set index to 34 to assign Data bits and Parity.
DATA: Data bits and Parity effect the SMDS and MCI data link. This
value should not be changed without consulting the System
Administrator. Use the following table to determine the proper
data input for
index 34.
Bit System Data Contents
0 0/1 Out/ In services for SMDS and MCI link
1
2
0 = No parity 2 = No parity
4 = Odd parity 6 = Even parity
3
4
0 = Unused 8 = 1 Stop bit
10 = 1.5 stop bits 18 = 2 Stop bits
FOUR: DEFINE THE MCI PORT AS TERMINAL
Assignment of System Data
SYS : 1 SYS: System Data Items
INDEX : 117 DATA: 01 1-System Data 1
2-System Data 2
3-System Data 3
INDEX: System Data Index
System Index
1 0-255
2 0-15
3 0-31
DATA: System Data (Hexadecimal)
SYS: MCI data link programming is a system-wide parameter, type 1
in this field, then press ENTER.
INDEX: 117 is used as an example. Index is specific to the port you
selected in the previous screen. Use the chart below to select the
index value. Enter this value in the INDEX field.
PORT INDEX DATA
Mat Terminal 116 02
1 117 01
2 118 01
3 119 01
4 120 01
5 121 01

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 12
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
DATA: Selecting 01 in the DATA field insures that the port is seen as a
MCI port and not a MAT terminal interface, then press ENTER.
FIVE: ASSIGN THE MCI LINK TO THE UCD GROUP
Assignment of System Data
SYS : 2 TN: 1SYS: System Data Items
INDEX : 6 DATA: 01 1-System Data 1
2-System Data 2
3-System Data 3
INDEX: System Data Index
System Index
1 0-255
2 0-15
3 0-31
DATA: System Data (Hexadecimal)
SYS: MCI data link association with a UCD Group is on a tenant by
tenant basis. Type 2 in this field, then press ENTER.
TN: You need to use the same tenant value you used when creating
the Single Line ports and UCD group.
INDEX: Index 6includes field that allow you to associate the MCI link
with the UCD group.
DATA: Setting DATA to 01 sets bit 0 to tell the Switch that the MCI link
is associated with the UCD group.
MCI SERVICE FOR CALLS VIA ATTENDANT CONSOLE
Assignment of System Data
SYS : 2 TN: 1SYS: System Data Items
INDEX : 7 DATA: 00 1-System Data 1
2-System Data 2
3-System Data 3
TN: Tenant Number
INDEX: System Data Index
System Index
1 0-255
2 0-15
3 0-31
DATA: System Data (Hexadecimal)
SYS: MCI Service for calls Via Attendant Console is on a tenant by
tenant basis. Type 2 in this field, then press ENTER.
TN: You need to use the same tenant value you used when creating
the Single Line ports and UCD group.
INDEX: Index 7includes the field that allow MCI Service for calls via
Attendant Console.

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 13
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
DATA: Setting DATA to 02 sets bit 1 to tell the Switch that the MCI
Service is for calls via Attendant Console. This value should not
be changed without consulting the System Administrator.
5.5 DATA LINK CONFIGURATION FOR THE MCI
Set up the MCI I/) port (P/N PAI002) to the same baud, parity, data bit and
stop bit settings as the NEC.CFG file in the Smooth Operator system. If
the MCI data link is configured for 2 stop bits it should be reconfigured for
1 stop bit. 2 stop bits will cause inconsistent operation of the MCI link.
Note: After making any changes to the Data Link on the NEAX you
must Reboot the switch for the changes to take effect. If you make
changes to the Integration Configuration program of the Smooth
Operator system, you must exit the Smooth Operator system and
relaunch it by rebooting the PC..
The normal settings for the MCI data link are 1200 baud, 8 data bits, 1 stop
bit, and no parity bit. Below are the jumper settings that are needed to
achieve this.
Switch Settings Function
SW01/ 1 2 3
SW11 on off on 1200 BPS
4 off Parity bit invalid
5 off Even parity
6 off 8 bits
7 on 1 stop bit
8 on Send side FIFO is 1 byte.
8 off For version 5200 J4.38 and above set switch
8 off.
Switch Settings Function
SW02/ 1 on When PB lead is - terminal is busy
SW12 2 on DTR signal is always on
3 on DSR signal is not provided
4 on CD is not provided
5 on CS is not provided
6 on CI is not provided
7 on PB signal is not provided
8 off Not used
Switches 01 and 02 are configured when you are using port 0 on the I/O
card, 11 and 12 are configured when you are using port 1.
5.6 PROGRAMMING THE STATION SETS
Forward RNA:

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 14
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
1. Lift handset of phone to be forwarded, wait for dial tone.
2. Dial the access code or press the function key for forward RNA, at
this point you will get a second dial tone.
3. Dial the forwarding target number. (This is the first member extension
of the UCD group.)
Cancel Forward RNA:
1. Lift handset of phone that you want to cancel forwarding on, wait for
dial tone.
2. Dial the access code or use the function key for canceling forward
RNA, at this point you will receive a confirmation tone.
Note: Call Forward RNA SFI=8 must be allowed in the stations service
feature class. Dterm sets may have a function key for RNA forward -
FKY=22.
Forward Busy:
1. Lift handset of phone to be forwarded, wait for dial tone.
2. Dial the access code or press the function key for busy forward, at this
point you will get a second dial tone.
3. Dial the forwarding target number. (This is the first member extension
of the UCD group.)
Cancel Forward Busy:
1. Lift handset of phone that you want to cancel forwarding on, wait for
dial tone.
2. Dial the access code or use the function key for canceling forward
busy, at this point you will receive a confirmation tone.
Note: SFI=9 Call forward busy, must be in the stations service feature
class. Dterm sets may have a function key for forward busy - FKY=1.
Forward All Calls:
1. Lift handset of phone to be forwarded, wait for dial tone.
2. Dial the access code or press the function key for forward all calls, at
this point you will get a second dial tone.
3. Dial the forwarding target number. (This is the first member extension
of the UCD group.)
Cancel Forward All Calls:
1. Lift handset of phone that you want to cancel forward all calls on,
wait for dial tone.
2. Dial the access code or use the function key for canceling forward all
calls, at this point you will receive a confirmation tone.
Note: RNA SFI=7 Call forward all calls, must be in the stations service feature
class. Dterm sets may have a function key for forward all calls - FKY=2.

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 15
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
6.0 CONFIGURING THE SMOOTH OPERATOR
During the install process, run the Integrator program and choose the
NEC NEAX 2400. The Integrator will place appropriate feature codes into
the Smooth Operator Setup.
The following codes should be inserted by the integrator. Four digit
extensions are assumed.
Outside Line Access Code 9,
Off Hook Delay (OFFHDLY) 50
Hook Flash Interval (FLINTVL) 50
DTMF Tone Length (TONELEN) 8
Message Waiting Parameters
Permit Message Waiting Lights 9
Use MW Data from Serial Port [COMMMWL] 9
Inband Parameters
Total Number of DID Digits 10
Seconds to Wait for First Digit 1
Location of Inband Signaling Code 1
Millisecs to Wait for Next Digit 100
Code for Go to Voice Mail F
Start at End of String for Go to Voice Mail Enabled
Location of Mailbox Number for Go to Voice Mail 4
Code for Immediate Subscriber Login to Mailbox C
Start at End of String for Immediate Login Enabled
Location of Mailbox Number for Immediate Login 4
Code for Busy Extension B
Start at End of String for Busy Extension Enabled
Location of Mailbox Number for Busy Extension 4
Code for No Answer Extension N
Start at End of String for No Answer Extension Enabled
Location of Mailbox for No Answer Extension 4
Start at End of String for Default Code Enabled
Location of Mailbox Number for Default Code 4
Note: Verify these dialing sequences for your installation.
In addition to running the Integrator, ensure the following parameters are
set to their corresponding values in System Setup:
SMDI Parameters
Use SMDI 9
Note: Verify all these dialing sequences for your switch
Smooth Operator
programming

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 16
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
6.1 INTEGRATION CONFIGURATION PROGRAM
When the Integration Configuration Program is run, ensure that the Serial
Communication Protocol matches the NEC 2400, which was set in section
5.4 step 3 of this document to 1200 baud, no parity, eight data bits, and one
stop bit (1200, 8,N,1). Set Time-out to 10.
Next, select PORT ID, enter the extension numbers connected to the
corresponding Smooth Operator ports.
Note: The NEC Serial interface is less sensitive to protocol matches then
the NEC 2400. The Smooth Operator may be excepting digits but
message waiting lights may not work. Try setting the protocol of
the Serial link to odd parity, seven data bits, and two stop bit
(1200, 7,O,2).
7.0 CONSIDERATIONS / ALTERNATIVES
The following items should be considered, below:
Supervised Transfers
Disconnect Type
7.1 SUPERVISED TRANSFERS
If the NEC 2400 is programmed to execute a supervised transfer,
Handsfree Announce must be disabled. If call forwarding is on at the
station, ensure that it is for Ring/No Answer only, and that the ring timer is
greater than the Maximum Rings for the mailbox.
7.2 DISCONNECT TYPE
The NEC line card 16LC-Q provides a 128-194 millisecond Drop in Loop
current. If you are not using the 16LC-Q card the NEC PBX will send a
Fast Busy which must be “learned” by running CCA.
© Copyright 1994, 1995, 1996, 1997 Octel Communications Corporation. All rights reserved.
Printed in the United States
*Trademark of NEC
®
COMMUNICATIONS CORPORATION
Sarasota City Center
1819 Main Street, Suite 900
Important notes concerning this
integration

Smooth Operator Configuration Note (77175)
NEC Neax 2400 w/ Direct Serial LinkConfidentialPage 17
The above information is provided by Octel Communications Corporation as a guide.
See disclaimer on page 1
Octel Communications
Sarasota, FL 34236
[phone]
(CFN 77175)
