NEC Dterm IP User manual

Dterm IP 4D Dterm IP 8D Dterm IP 16D
Network Parameters
Interface 10/100 base T
(IEEE 802.3), RJ45 10/100 base T (IEEE 802.3), RJ45 multi-
port Switch
10/100 base T
(IEEE 802.3), RJ45 multi-
port Switch
Internet Layer All Models: IPv4
IP Protocol All Models: NEC Peer-to-Peer (only)
Jitter Buffer All Models: Max 300msec (10msec steps)
Payload Interval All Models: 10ms ~ 40ms (10ms steps)
IP Addressing All Models: DHCP or Static Assignable
QoS 801.p, ToS and Diff-Service
Equipment Specification Size (W x D x H)
Tilt up 7.57”x 8.69”x 5.57” 9.09”x 8.54”x 5.28” 9.09”x 9.57”x 5.28”
Tilt down 7.57”x 8.69”x 3.80”
(without stand unit) 9.09”x 8.54”x 4.17” 9.09”x 9.57”x 4.17”
Weight 1.98Ibs 2.51Ibs 2.51Ibs
Power Specification
External All Models: AC: 24V, Current 750mA
Inline and Spare Pair
Voltage:
Current:
Power Consumption:
Protocol Support:
Protocol Support (with
ILPA Integration):
48V
90mA
4.32W
IEEE802.3af
With ILPA can support
CDP and NDP
48V
92mA
4.42W
IEEE802.3af
and CDP (DIP Switch)
With ILPA can support
NDP
48V
92mA
4.42W
IEEE802.3af
and CDP (DIP Switch)
With ILPA can support
NDP
Operating
Temperature All Models: 0 – 40 deg C
IP Telephony Equipment Requirements
UNIVERGE All Models
Hardware: SV7000T
Software: FP30-100 R16 or greater
NEAX 2400 IPX All Models
Software: FP20-100 R15 or greater
NEAX 2000 IPS Model: 4
Software: 3200 Series R 6.1 or greater Models: 8, 16, 32 Software: 3300 Series R8 or greater
Dterm IP Terminal Specifications
