Nederman FlexPAK Manual

PLC Settings Manual
Compact dust collectors
FlexPAK
Software #2168209-X
Originalplc settings manual
EN PLC SETTINGS MANUAL
2021-05-12 2130258 (02)

FlexPAK
Trace back information:
Workspace Main version a43
Checked in 2021-05-12
Skribenta version 5.4.015

FlexPAK
Table of contents
Figures ............................................................................................................................................................................. 6
1 Preface ............................................................................................................................................................................ 9
2 Safety .............................................................................................................................................................................. 9
2.1 Classification of important information ......................................................................................................... 9
2.2 General safety requirements ........................................................................................................................... 9
3 PLC messages ................................................................................................................................................................. 10
3.1 Status messages ................................................................................................................................................ 10
3.1.1 Nederman FlexPAK Off (Off mode) .................................................................................................. 10
3.1.2 FlexPAK Standby (Standby mode) ................................................................................................... 10
3.1.3 Running (Running mode) ................................................................................................................... 10
3.1.4 FlexPAK Idling (Idling mode) .............................................................................................................. 10
3.1.5 Filter Cleaning ...................................................................................................................................... 11
3.1.6 Emptying pre-separator ..................................................................................................................... 11
3.1.7 Open Upper Slide Valve V12 .............................................................................................................. 11
3.1.8 Close Upper Slide Valve V12 .............................................................................................................. 11
3.1.9 Emptying bin TVFD Advanced ........................................................................................................... 11
3.1.10 Close Lower Slide Valve V11 .............................................................................................................. 12
3.1.11 Flushing duct ........................................................................................................................................ 12
3.1.12 Isolation Damper Closing Duct .......................................................................................................... 12
3.1.13 Emptying bin AEB flap valve .............................................................................................................. 12
3.1.14 Emptying bin TVFD simple ................................................................................................................. 12
3.1.15 Pressure Sensor Display ..................................................................................................................... 13
3.1.16 Emptying bin by rotary valve ............................................................................................................. 14
3.1.17 Temperature Sensor Display ............................................................................................................. 15
3.1.18 Vibration Sensor Display .................................................................................................................... 15
3.2 Warning messages ............................................................................................................................................. 16
3.2.1 Time For service ................................................................................................................................... 16
3.2.2 Warning! Main Filter Clogged ............................................................................................................. 16
3.2.3 Dustbin Full ........................................................................................................................................... 16
3.2.4 Bag Replacement Switch Activated ................................................................................................. 17
3.2.5 Warning Low Vacuum ......................................................................................................................... 17
3.2.6 AUX Temp Limit Exceeded 1 .............................................................................................................. 17
3.2.7 AUX Temp Limit Exceeded 2 .............................................................................................................. 18
3.2.8 Rotary valve fault ................................................................................................................................ 18
3.2.9 Rotary rotation detection .................................................................................................................. 18
3.3 Alarms .................................................................................................................................................................. 19
3.3.1 External Fire Alarm Explosion Detected .......................................................................................... 19
3.3.2 Frequency Conv Alarm ........................................................................................................................ 19
3.3.3 Emergency Stop Activated ................................................................................................................ 19
3.3.4 Low Pressure or Duct Isolation Released ........................................................................................ 20
3.3.5 Alarm! Hi Vacuum ................................................................................................................................ 20
3.3.6 Exhaust Air Temp High ....................................................................................................................... 20
3.3.7 Bag Replacement Switch Time Out .................................................................................................. 20
3.3.8 Alarm! Control Filter Clogged ............................................................................................................. 21
3.3.9 TVFD Alarm! Upper Slide Not Closed ................................................................................................ 21
3.3.10 TVFD Alarm! Upper Slide Not Open .................................................................................................. 21
3.3.11 TVFD Alarm! Lower Slide Not Closed ................................................................................................ 22
3.3.12 TVFD Alarm! Lower Slide Not Open .................................................................................................. 22
3.3.13 TVFD Alarm! Slides In Open Position ................................................................................................ 22
3.3.14 Alarm! Dustbin Full .............................................................................................................................. 23
3.3.15 Alarm! Main Filter Clogged ................................................................................................................. 23
3.3.16 AUX Hi Temp Limit Exceeded ............................................................................................................ 23
3.3.17 AUX Lo Temp Limit Exceeded ........................................................................................................... 24
3.3.18 Vibration Limit Exceeded ................................................................................................................... 24
3.3.19 Rotary valve fault ................................................................................................................................ 25
3

FlexPAK
4 PLC settings .................................................................................................................................................................... 26
4.1 Find a parameter and set its value .................................................................................................................. 26
4.2 Parameter settings ............................................................................................................................................ 27
4.2.1 Adjust the time and date .................................................................................................................... 27
4.2.2 Set the weekly timer ........................................................................................................................... 27
4.2.3 H-Meter 1 .............................................................................................................................................. 29
4.2.4 SSR_Time .............................................................................................................................................. 29
4.2.5 CoolTmr ................................................................................................................................................. 30
4.2.6 FltClean ................................................................................................................................................. 30
4.2.7 DIR_Time ............................................................................................................................................... 30
4.2.8 Weekly Timer ........................................................................................................................................ 30
4.2.9 Presep .................................................................................................................................................... 31
4.2.10 MFDPS-Wr ............................................................................................................................................. 31
4.2.11 MFDPS-FC ............................................................................................................................................. 31
4.2.12 BLI-Empt ............................................................................................................................................... 31
4.2.13 BLI-Wr .................................................................................................................................................... 32
4.2.14 AEBTme ................................................................................................................................................. 32
4.2.15 BinOpnTm ............................................................................................................................................. 32
4.2.16 CFDPS-Al ............................................................................................................................................... 32
4.2.17 TVFDAdv ............................................................................................................................................... 33
4.2.18 PSCFlush ................................................................................................................................................ 33
4.2.19 Auto Empt ............................................................................................................................................. 33
4.2.20 LiAuto .................................................................................................................................................... 33
4.2.21 LSOTmr .................................................................................................................................................. 33
4.2.22 FlushCy2 ................................................................................................................................................ 34
4.2.23 OTTmr .................................................................................................................................................... 34
4.2.24 FlushTmp .............................................................................................................................................. 35
4.2.25 CoolTmp ................................................................................................................................................ 35
4.2.26 TVFD-Al-Tmr ........................................................................................................................................ 35
4.2.27 BRSTmr .................................................................................................................................................. 36
4.2.28 Vac_Low ................................................................................................................................................ 36
4.2.29 AEB-TVFD ............................................................................................................................................. 36
4.2.30 FlushCy1 ................................................................................................................................................ 37
4.2.31 VacLoTm ............................................................................................................................................... 37
4.2.32 PSIFC ...................................................................................................................................................... 37
4.2.33 PresepTm .............................................................................................................................................. 37
4.2.34 FlushTmr ............................................................................................................................................... 38
4.2.35 FCDelay .................................................................................................................................................. 38
4.2.36 IsoVDly ................................................................................................................................................... 38
4.2.37 DuctIsoDamp ........................................................................................................................................ 39
4.2.38 BLI-Alarm .............................................................................................................................................. 39
4.2.39 MFDPS-Al .............................................................................................................................................. 39
4.2.40 DPFClean ............................................................................................................................................... 39
4.2.41 EmtyIdli .................................................................................................................................................. 40
4.2.42 Clean cycle ............................................................................................................................................ 40
4.2.43 Rot valve ............................................................................................................................................... 40
4.2.44 Rot valve LI ........................................................................................................................................... 40
4.2.45 Rot fault Al ............................................................................................................................................ 40
4.2.46 Vibr Setting ........................................................................................................................................... 41
4.2.47 AUX Setting .......................................................................................................................................... 42
4.2.48 Layout Pressure Measurement FlexPAK system .......................................................................... 43
4.2.49 CFdP Setting ......................................................................................................................................... 44
4.2.50 MFdP Setting ........................................................................................................................................ 44
4.2.51 Fire Alarm input Setting ..................................................................................................................... 46
5 Automatic bin emptying function .............................................................................................................................. 46
5.1 AEB-Flap Valve settings ................................................................................................................................... 46
5.1.1 Hardware .............................................................................................................................................. 46
5.1.2 PLC Settings ......................................................................................................................................... 46
5.1.3 Timer Settings ...................................................................................................................................... 46
4

FlexPAK
5.2 Simple TVFD Valve Settings ............................................................................................................................. 47
5.2.1 Hardware .............................................................................................................................................. 47
5.2.2 PLC Settings ......................................................................................................................................... 47
5.2.3 Timer Settings ...................................................................................................................................... 47
5.3 Pre-Separator Settings ..................................................................................................................................... 47
5.3.1 Hardware .............................................................................................................................................. 47
5.3.2 PLC Settings ......................................................................................................................................... 47
5.3.3 Timer settings: Pre-Separator 1 ....................................................................................................... 47
5.3.4 Timer settings: Pre-Separator 2 ....................................................................................................... 47
5.4 Advanced TVFD Valve Settings ....................................................................................................................... 48
5.4.1 Hardware .............................................................................................................................................. 48
5.4.2 PLC Settings ......................................................................................................................................... 48
5.4.3 Timer settings ...................................................................................................................................... 48
5.5 Rotary valve settings ........................................................................................................................................ 48
5.5.1 Hardware .............................................................................................................................................. 48
5.5.2 PLC settings .......................................................................................................................................... 48
6 Machining chips and swarf extraction ....................................................................................................................... 49
6.1 Electrical connection of indicator lamp .......................................................................................................... 49
7 Pneumatic filter cleaning valve .................................................................................................................................. 49
7.1 Filter cleaning button ........................................................................................................................................ 49
7.2 Filter cleaning in Standby mode ...................................................................................................................... 49
7.3 Filter cleaning in Running mode ...................................................................................................................... 49
7.4 Filter cleaning valve function .......................................................................................................................... 49
8 ATEX Duct Isolation Valve settings ............................................................................................................................ 49
8.1 Flush Cycle settings ........................................................................................................................................... 50
8.1.1 FlushCy1(T) (Timer) ............................................................................................................................ 50
8.1.2 FlushCy2(T) (Timer) (Dual Function) ................................................................................................ 50
8.2 Tuning Duct Isolation Damper sequence ....................................................................................................... 50
8.2.1 FCDely(T) Parameter .......................................................................................................................... 50
8.2.2 FCDely(T) Parameter Calculation See, Timing diagram ................................................................ 50
8.2.3 Default FCDely(T) Parameter Settings ............................................................................................ 50
8.3 IsoVDly(T) Parameter Settings ........................................................................................................................ 50
8.3.1 Default IsoVDly(T) Parameter Settings ........................................................................................... 50
8.4 Default ClenCyl(T) Parameter Settings .......................................................................................................... 51
8.4.1 Procedure to set ClenCyl(T) Parameter ........................................................................................... 51
8.4.2 Settings TH = Cleaning Pulse Time (FC Valve opening Time) ...................................................... 51
8.5 Total Filter Cleaning sequence time ............................................................................................................... 51
8.5.1 Settings TL = Vacuum Load Time ..................................................................................................... 51
8.6 FC Start Impulse .................................................................................................................................................. 51
9 FlexPAK IOT System ...................................................................................................................................................... 51
9.1 Preset IP Addresses for FlexPAK IOT Units ................................................................................................... 52
10 Appendix A: PLC settings protocol ............................................................................................................................. 53
5

FlexPAK
Figures
ESC OK
FlexPak
Hi Vacum Unit
OFF
TimeTo Service
2000 Hours
ESC OK
NEDERMAN
FLEXPAK
Standby
Wai ng For
Pilot Signal
Mo 15:33
ESC OK
FlexPak
Hi Vacuum Unit
IDLING
Time To StandBy
11:59m
ESC OK
Running
kPA -20
DIRTm 00:00 s
OTTmr 00:00 h
Exhaust
Air Temp 60°C
ESC OK
FlexPak
Hi Vacuum Unit
IDLING
Time To StandBy
05:33m
PS
PS
ESC OK
Running
kPA -20
DIRTm 09:00 s
OTTmr 00:00 h
Exhaust
Air Temp 60°C
ESC OK
FlexPak
Hi Vacuum Unit
IDLING
Time To StandBy
00:00m
PS
Running
P = -5 à-20/-35 kPa
IDLING
P = 0 kPa
PS
PS
Pilot signal OFF
Pilot signal On
DIRTm < 10:00 s DIRTm > 10:00 s
ESC OK
Running
kPA -20
DIRTm 00:00 s
OTTmr 00:00 h
Exhaust
Air Temp 60°C
T > 12:00m T < 12:00m
FlexPAK Off
Standby
Running
Idling
E
M
E
R
G
E
N
C
Y
S
T
O
P
E
M
E
R
G
E
N
C
Y
S
T
O
P
1
6

FlexPAK
*$
*$
*$#
*
*
$
$
#
#
#
2
7

FlexPAK
Run mode
Run Closed valve Closed valve Open valve Open valve Off
FCDelay
Clencyl
FC Start
Impulse
Output Q3
(FC Valve)
Output
Q12 Duct Isola"on
Damper SFV2)
Duct Isola"on Damper
Mechanical status
Closing Time
Extra delay "mer to FC
TL=2s
TL=3s TH=2s
TH=
1s
TL=3s
15s
TH=2s TL=3s TH=2s
T=Approximately 22 seconds
Filter Cleaning
IsoVDly(T=4s)
Vacuum
Equaliza"on
"me
Opening Time
Timing Diagram FlexPAK 800-1000 ATEX Duct Isola"on Damper: So#ware 2168079-1, 2168209-X
3
8

FlexPAK
1Preface
Thank you for using a Nederman product!
The Nederman Group is a world-leading supplier and
developer of products and solutions for the environ-
mental technology sector. Our innovative products
will filter, clean and recycle in the most demanding of
environments. Nederman's products and solutions will
help you improve your productivity, reduce costs and
also reduce the impact on the environment from in-
dustrial processes.
Read all product documentation and the product iden-
tification plate carefully before installation, use, and
service of this product. Replace documentation im-
mediately if lost or damaged. Nederman reserves the
right, without previous notice, to modify and improve
its products including documentation.
This product is designed to meet the requirements
of relevant EC directives. To maintain this status, all
installation, maintenance, and repair is to be done
by qualified personnel using only Nederman original
spare parts and accessories. Contact the nearest au-
thorized distributor or Nederman for advice on tech-
nical service and obtaining spare parts. If there are
any damaged or missing parts when the product is de-
livered, notify the carrier and the local Nederman rep-
resentative immediately.
2Safety
2.1Classification of important informa-
tion
This document contains important information that
is presented either as a warning, caution or note, ac-
cording to the following examples:
WARNING!Risk of personal injury
Warnings indicate a potential hazard to the
health and safety of personnel, and how that
hazard may be avoided.
CAUTION!Risk of equipment damage
Cautions indicate a potential hazard to the
product but not to personnel, and how that
hazard may be avoided.
Notes contain other information that is import-
ant for personnel.
2.2General safety requirements
WARNING!High vacuum
A high vacuum system creates a powerful suc-
tion that may cause serious eye injury or hear-
ing impairment. Persons who will be using Flex-
PAK, or may come in contact with FlexPAK, is to
be informed about this risk.
WARNING!Risk of personal injuries
Never look into the exhaust air duct. Debris and
particles coming out of the outlet may cause
eye injuries.
WARNING!Risk of electric shock
Personnel operating FlexPAK need to pay spe-
cial attention to avoiding discharge of static
electricity.
Only authorized personnel are allowed to have
access to this unit.
9

FlexPAK
3PLC messages
The following sections show the different status, warning, and alarm messages that can be seen in the PLC dis-
play.
3.1Status messages
The following status messages give information about what mode the unit is in or what routine service is being
performed. See Figure1 for a chart that shows how FlexPAK moves between different unit modes.
3.1.1 Nederman FlexPAK Off (Off mode)
The unit is in Off mode, which is also the unit’s start menu. The unit can also go into Off mode if something is
wrong, such as if an alarm is activated. The pump motor is off, there is no vacuum, the Filter Cleaning Valve
(FCV) is closed, and the unit cannot be activated by a pilot signal.
ESC OK
FlexPak
Hi Vacuum Unit
OFF
Time To Service
2000 hours
TimeToService: The amount of time until the next scheduled service. The
default setting is 2000 hours. See Section4.2.3H-Meter 1.
3.1.2 FlexPAK Standby (Standby mode)
The unit is in Standby mode. The pump motor is off, there is no vacuum, the FCV is closed, and the unit is waiting
for a pilot signal to go into Running mode.
ESC OK
NEDERMAN
FLEXPAK
Standby
Wai ng For
Pilot Signal
Mo 15:33
3.1.3Running (Running mode)
The unit in Running mode. The pump motor is on and the unit generates a vacuum. The FCV is closed. The cur-
rent vacuum of the unit is shown on the display, for example, -20 kPa.
ESC OK
Running
kPA -20
DIRTm 00:00 s
OTTmr 00:00 h
Exhaust
Air Temp 60°C
DIRTm: The amount of time before the unit goes into Idling mode. The de-
fault is 10 seconds. See also Section4.2.7DIR_Time.
OTTmr: If the Overtime timer has been activated, OTTmr shows the elapsed
time since the overtime timer started.
The temperature of the exhaust air is displayed at the bottom of the dis-
play.
3.1.4 FlexPAK Idling (Idling mode)
The unit in Idling mode. The pump motor is on, there is no vacuum, and the FCV is open. The unit goes into Idling
mode when there has been no pilot signal for the time set in DIR_Time, see Section4.2.7DIR_Time.
ESC OK
FlexPak
Hi Vacuum Unit
IDLING
Time To StandBy
05:33m
TimeToStandby: The amount of time until the unit goes into Standby mode.
The default setting is 12 minutes. See Section4.2.4SSR_Time.
10

FlexPAK
3.1.5Filter Cleaning
The unit is cleaning its filter.
ESC OK
Filter
Cleanining
Cycles 1
Elapsed 0
Clean 00:00 s
Charge 00:00 s
Cycles: How many cleaning pulses will be carried out.
Elapsed: How many cleaning pulses are made.
Clean: Remaining time for cleaning pulse.
Charge: Remaining vacuum build time; the time until cleaning pulse is activ-
ated.
3.1.6Emptying pre-separator
The time remaining until the pre-separator bin is to be emptied.
ESC OK
EMPTYING
Preseparator
Bin 1 08:00s
Bin 2 06:00s
Bin 1: The time remaining to empty the pre-separator as set in BinOpnTm.
Bin 2: The time remaining for pre-separator 2 to be emptied as set in Pre-
sepTm.
3.1.7Open Upper Slide Valve V12
The message appears when the TVFD Upper Solenoid Valve is expected to open. The timer is set with TVF-
DO-Al, see Section4.2.39MFDPS-Al. If the timer elapses, the ‘TVFD Alarm! Upper Slide Not Open is activated.
This message is only shown when TVFD advanced is activated.
ESC OK
Open Upper
Slide Valve
Remaing time
06:00s
Remaining Time: The remaining time for the valve to open before the alarm
is activated.
3.1.8Close Upper Slide Valve V12
The message appears when the TVFD Upper Solenoid Valve is expected to close. The timer is set with TVFDC-Al,
see Section4.2.26TVFD-Al-Tmr. If the timer elapses, the ‘TVFD Alarm! Upper Slide Not Closed is activated. This
message is only shown when TVFD advanced is activated.
ESC OK
Close Upper
Slide Valve
Remaing !me
08:00s
Remaining Time: The remaining time for the valve to close before the alarm
is activated.
3.1.9Emptying bin TVFD Advanced
The message appears when the TVFD Lower Solenoid Valve is expected to open. The timer is set with TVF-
DC-Al, see Section4.2.26TVFD-Al-Tmr. If the timer elapses, the ‘TVFD Alarm! Lower Slide Not Open is activated.
This message is shown when TVFD advanced is activated. TVFD-Al is only activated when using TVFD advanced.
ESC OK
EMPTYING BIN
Open Lower
Slide Valve
Remaing Time
02:00s
Remaining Time: The remaining time for the valve to open before the alarm
is activated.
11

FlexPAK
3.1.10Close Lower Slide Valve V11
The message appears when the TVFD Lower Solenoid Valve is expected to close. The timer is set with TVF-
DC-Al, see Section4.2.26TVFD-Al-Tmr. If the timer elapses, the ‘TVFD Alarm! Lower Slide Not Closed is activ-
ated. This message is only shown when TVFD advanced is activated.
ESC OK
Close Upper
Slide Valve
Remaing !me
08:00s
Remaining Time: The remaining time for the valve to close before the alarm
is activated.
3.1.11Flushing duct
The unit is flushing the duct system. This message is shown when FlushCy1 and FlushCy2 activate the
flush valve. This message is also shown when FlushTemp is activated, see Section4.2.30FlushCy1, Sec-
tion4.2.22FlushCy2 and Section4.2.24FlushTmp.
ESC OK
Flushing
Ducts
Cycl 1 03:00 s
Cycl 2 05:00 s
Cycl1: The time remaining for the flush cycle with the flush valve 1 (SFV1).
Cycl2: The time remaining for the flush cycle with the flush valve 2 (SFV2).
3.1.12Isolation Damper Closing Duct
When the parameter (Softkey, DuctIsoDamp = On), FlexPAK is configured to control a damper that separates
the filter from the factory’s channel system. The message appears before filter cleaning starts. The display
shows the time delay set for opening the damper after filter cleaning.
ESC OK
Isolation Damper
Closing Duct
Delay Open Time
04:00s
RemaningTm 02:00s
3.1.13Emptying bin AEB flap valve
When the system is configured for an AEB Flap Valve, the following message appears when BIN emptying is per-
formed. The message is displayed about Parameter → AEB-TVFD = On.
ESC OK
EMPTYING BIN
Open
AEB Flap Valve
Remaing Time
04:00s
3.1.14Emptying bin TVFD simple
When the system is configured for a simple TVFD without the limit mode sensor, the message below will be dis-
played when BIN emptying is performed. The message is displayed about Parameter → AEB-TVFD = Off.
ESC OK
EMPTYING BIN
Open Lower
Slide Valve
Remaing Time
02:00s
When the system is configured for an AEB Flap Valve, the following mes-
sage appears when BIN emptying is performed.
The message is displayed about Parameter → AEB-TVFD = On.
12

FlexPAK
3.1.15Pressure Sensor Display
The Pressure Sensor Reading display is manually activated.
ESC OK
Thu 10:45
2018-02-01
ESC OK
ESC + C 9/9
Date Window Arrow Window
The display is activated by the following sequence:
• Toggle with arrow key “UP” or “Down” until Date Window is visible.
• Toggle with arrow key “Left” or “Right” until Arrow Window is visible.
Press the “ESC” button simultaneously while pressing the arrow key “Up” to view pressure sensor data. Pressure
sensor data is only available if a pressure sensor is physically installed and sensor setup is done in the parameter
setting.
• CFdP Setting “Stat = ON” (Control Filter Sensor)
• MFdP Setting “Stat = ON” (Main Filter Sensor)
• Stat = On → Activated sensor input for Analog sensor 0-10V
• Stat = Off → Activated sensor input for Dp Switch input configuration
Displayed when only Main Filter is installed
ESC OK
Ppump -20 kPa
Total System
Pressure Dropp
SystdP 3.1 kPa
Duct P 16.9 kPa
MaxdP 5.0 kPa ESC
MFdP Setting, Set = ON
CFdP Setting, Set = OFF
Press “OK” button to close display.
Ppump -20 kPa →Pressure readings from the pump pressure sensor
SystdP 3.1 kPA →dp pressure System “dp Pump to the dirty side of filter”
Duct P -16.9 kPa →Pressure sensor readings from a sensor placed on filter dirty side or
duct
MaxdP 5.0 kPa →Main Filter Max dp pressure Limit setting
See “CFdP Setting” for more information
Displayed when only Control Filter is installed
ESC OK
Ppump -21 kPa
CF dP 2.8 kPa
Max dP 5.0 kPa ESC
MFdP Setting, Set = OFF
CFdP Setting, Set = ON
Press the “OK” button to close the display.
13

FlexPAK
Ppump -21 kPa →Pressure readings from the pump pressure sensor
CFdP 2.8 kPA →Control Filter dp pressure
MaxdP 5.0 kPa →Control Filter Max dp pressure Limit setting
See “CFdP Setting” for more information
Displayed when Main Filter and Control Filter are installed
ESC OK
Ppump -22 kPa
MF dP 1.8 kPa
CF dP 0.8 kPa
MF Lim 5.0 kPa
CF Lim 5.0 kPa ESC
MFdP Setting, Set = ON
CFdP Setting, Set = ON
Press the “OK” button to close the display.
Ppump -20 kPa →Pressure readings from the pump pressure sensor
MFdP 1.8 kPA →Main Filter dp pressure
CFdP 0.8 kPA →Control Filter dp pressure
MF Lim 5.0 kPA →Main Filter Max dp pressure Limit setting
CF Lim 5.0 kPA →Control Filter Max dp pressure Limit setting
See “MFdP Setting” and “CFdP Setting” for more information
3.1.16Emptying bin by rotary valve
When the system is configured for a simple TVFD without the limit mode sensor, the message below will be dis-
played when BIN emptying is performed. The message is displayed about Parameter → AEB-TVFD = Off.
ESC OK
EMPTYING BIN
Open Lower
Slide Valve
Remaing Time
02:00s
When the system is configured for emptying with a rotary valve the follow-
ing message is displayed during rotary valve operation.
14

FlexPAK
3.1.17Temperature Sensor Display
The temperature Sensor Reading display is manually activated.
• Toggle with arrow key “UP” or “Down” until Date Window is visible.
• Toggle with arrow key “Left” or “Right” until Arrow Window is visible.
Press the “ESC” button simultaneously while pressing the arrow key “Left” to view Temperature sensor data.
ESC OK
Temp Sens Input
Exhaust 40 C
Max 135 C
Aux Temp 28 C
Max 50 c
Min 0 c ESC
If Sensor is not installed and sensor input is open, sensor reading is -50°C
Press the “OK” button to close the display.
Exhaust 40C →Fan Exhaust Air Temperature
Max 135C →Fan Exhaust Max Air Temperature Limit setting (Default 135 C)
Aux Temp 28 C →AUX Sensor Temperature
Maxd 50C →AUX Temperature Max Temperature Limit setting (Default 50 C)
Min 0 C →AUX Temperature Min Temperature Limit setting (Default 0 C)
See “AUX Setting” for more information
3.1.18Vibration Sensor Display
The Vibration Sensor Reading display is manually activated.
• Toggle with arrow key “UP” or “Down” until Date Window is visible.
• Toggle with arrow key “Left” or “Right” until Arrow Window is visible.
Press the “ESC” button simultaneously while pressing the arrow key “Down” to view Vibration Sensor data (ac-
tually it is an Alarm display that is opened and viewed without Alarm is activated).
ESC OK
V i b r a t i o n Limit
Exceeded
Level 3,8 mm/s
Delay Tmr 09:00 s
MaxS 10,0 mm/s
MaxR 10,0 mm/s
If Sensor is not installed and sensor input is open, sensor reading is approx-
imate -6.24mm/s
Press the “OK” button to close the display.
Level 3.8 mm/s →Actual Vibration value
Delay Tmr 09:00 s →Reaming time to unit stop, Stop delay timer
MaxS 10.0 mm/s →Max SET Vibration limit setting
MaxR 10.0 mm/s →Max RESET Vibration limit setting
15

FlexPAK
3.2Warning messages
If a warning is activated, a problem needs to be corrected, but the unit continues to work. If a warning message
is displayed in the PLC display, the light in the Standby/Running button flashes one second on, one second off.
This 1/1 on/off sequence continues until the problem is corrected. The backlight colour in the display changes
from white to amber while there is an active warning.
There are two exceptions to this rule, Section3.2.1Time For service and Section3.2.4Bag Replacement Switch
Activated.
3.2.1Time For service
The time interval set in the ‘Service Interval Setting’ menu has expired. If this warning is activated, the light in
the Standby/Running button is lit one second and then again in 7 seconds. This 1/7 on/off sequence continues
until the warning is reset.
Reset the alarm by first putting the unit into Off mode. Restart the unit. In Standby mode, press the manual fil-
ter cleaning button for 10 seconds.
ESC OK
FlexPak
Hi Vacuum Unit
Time for
Service
Th 15:01
Reset OK à
E
M
E
R
G
E
N
C
Y
S
T
O
P
3.2.2Warning! Main Filter Clogged
This Warning is only shown when the Main Filter Delta Pressure Switch (MFDPS) is installed. This message is dis-
played if the Differential Pressure switch “DP switch” is installed and the Dp switch detects a high differential
pressure across the filter.
When the Dp switch detects a high Dp pressure, it activates a timer, which is shown in the display. If the Dp pres-
sure is still high when the timer elapses, the vacuum unit will stop and the alarm message “Alarm! Main Filter
Clogged” is activated.
ESC OK
Warning!
Main Filter Clogged
Th 11:23
Time to Unit
Stop 08:00 m
Reset OK à
Time to Unit Stop: Displays the time until the unit is stopped.
3.2.3Dustbin Full
The Bin Level Indicator has detected that the dust bin has been full for 12 minutes. Empty the dust bin and press
the OK button to reset the warning.
ESC OK
Warning!
D u s t b i n F u l l
Th 15:01
Time To Unit
Stop 05:00 m
Reset OK à
Time to Unit Stop: Displays the time until the unit is stopped.
16

FlexPAK
3.2.4Bag Replacement Switch Activated
The bag replacement switch (SC2) is activated. It shows the maximum allowed time to replace the dust bag, and
how much time is left to replace the dust bag and turn off the bag replacement switch before the unit is put into
Off mode.
If this warning is activated, the light in the Standby/Running button is lit for two seconds and then again in 2
seconds. This 2/2 on/off sequence continues until the warning is reset.
ESC OK
Bag Replacement
Switch Activated
Time to Unit
Stop 02:00m
Max Time 30:00m
Stop: The remaining time to replace the dust bag before the unit is put into
Off mode.
MaxTime: The maximum amount of time allowed to replace the dust bag.
3.2.5Warning Low Vacuum
Function to warn when the vacuum is too low in the system.
When the vacuum is too low, Vac_Low activates the delay timer (VacLoTm) function when the message expires.
When the vacuum rises above the set limit value, the message disappears automatically.
The Vac_Low parameter default setting is -15kPa.
The VacLoTm parameter default setting is 1 minute.
ESC OK
Warning Low
Vacuum
Limit 15kPa
Actual kPa 10kPa
3.2.6AUX Temp Limit Exceeded 1
This message is displayed when one of the AUX temperatures exceeds limits settings, and the stop functional-
ity is not activated.
ESC OK
A UX T e m p L i m i t
E x c e e d e d
Temp 51 C
M a x T e m p 50 C
M i n T e m p 0 C
Temp 51 C →Shows the actual temperature value
MaxTemp 50 C →Shows Max Temperature limit setting
MinTemp 0 C →Shows Min Temperature limit setting
17

FlexPAK
3.2.7AUX Temp Limit Exceeded 2
This message is displayed when one of the AUX temperatures exceeds limits settings, and the stop functional-
ity is activated. This message also shows the remaining time until the unit stops.
ESC OK
A UX T e m p L i m i t E x c e e d e d
Temp -1 C
M a x Temp 50 C
M i n Temp 0 C
Time To Unit
Stop 25:00s
Temp 51 C →Shows the actual temperature value
MaxTemp 50 C →Shows Max Temperature limit setting
MinTemp 0 C →Shows Min Temperature limit setting
Time To Unit
Stop
25:00 s →Shows the remaining time until the unit stops
3.2.8Rotary valve fault
This message is displayed if parameter Rot valve:ERR = ON, and the rotary valve control unit indicates a fault.
The time until the unit stops is also displayed.
3.2.9Rotary rotation detection
This message is displayed if parameter Rot valve:Dete = ON, and no rotation indicating voltage pulses were re-
ceived during rotary valve operation.
18

FlexPAK
3.3Alarms
If an alarm is activated, the unit goes into Off mode until the problem is corrected.
If an alarm message is displayed in the PLC display, the light in the Standby/Running button flashes one second
on, one second off. This 1/1 on/off sequence continues until the problem is corrected and the alarm reset. The
backlight colour in the display changes to red while there is an active alarm.
3.3.1External Fire Alarm Explosion Detected
An external fire alarm is activated or a Relief Panel Sensor (RPS) is connected and has detected an explosion.
Press the green OK button to reset the alarm.
ESC OK
E x t e r n a l
F i r e A l a r m o r
E x p l o s i o n
D e t e c t e d
Th 11:23
Reset OK==>
3.3.2Frequency Conv Alarm
The frequency converter has detected a problem and that the PTC sensors in the motor have reached the max-
imum temperature for the unit (140°C) so the unit has been put into Off mode.
The following list shows the most common problems:
• Connection problem to the main power supply.
• Motor cable problem.
• Power supply fault.
• There is a problem with the frequency converter.
• PTC temp monitor detects an overheated motor.
ESC OK
PTC Detect Hi
Motor Temp or
Inverter Fault
Th 12:23
Unit is stopped
Reset OK à
3.3.3Emergency Stop Activated
If this message appears in the display, one or more emergency stops have been activated and the machine has
been switched off. External systems can be connected to the FlexPAK E-stop circuit, eg On the FlexPAK DX unit.
RPS panel sensor is connected.
Find out why the emergency stop has been activated and correct the problem. When all hazards have been elim-
inated that activated the emergency stop, the emergency stop can be reset. Reset the Emergency Stop Button
by turning it and then pulling it outward.
When all emergency stops have been reset, the security circuit can be reset by pressing the green OK button in
the display.
If the Green OK button can not be reset even though all emergency stops are reset, it may be due to a short cir-
cuit to ground in the emergency stop circuit or pilot signal circuit.
ESC OK
Emergency Stop
Activated
Th 11:23
Reset
E-Stop And Press
OK==>
19

FlexPAK
3.3.4Low Pressure or Duct Isolation Released
The Compressed Air Switch (CAS) indicates that the compressed air pressure is too low.
Or, there is a duct isolation valve connected to the system that has released and isolated FlexPAK from the duct
system. Check the isolation valve release sensor, released isolation valve = open electrical circuit to input on
PLC.
Press the green OK button to reset the alarm.
ESC OK
Low Pressure
CAS<3Bar Or
Duct Isolation
Valve Released
Th 11:23
Reset OK ==>
3.3.5Alarm! Hi Vacuum
The maximum vacuum level has been activated, and the delay time for the vacuum alarm has elapsed. Press OK
to reset the alarm.
ESC OK
Alarm!
Hi Vacuum
Level > -36 kPA
Th 12:23
Unit is Stopped
Reset OK==>
3.3.6Exhaust Air Temp High
The temperature of the air exiting the pump has exceeded the maximum allowable limit of 135ºC (275ºF). When
the ‘Current Value’ has become lower than 90°C (194ºF), press OK to reset the alarm. Check for the cooling air
valve or PT100 sensor values.
ESC OK
Max Temp Exhaust
Air Exceeded
Unit is Stopped
Limit 135 °C
Current 130 °C
Reset OK à
3.3.7Bag Replacement Switch Time Out
The maximum amount of time for the bag replacement being ‘On’ has been exceeded. To restart the unit, the
alarm needs to be reset by turning the bag replacement switch (SC2) to ‘Off‘ and pressing the OK button to reset
the alarm. See also Section4.2.27BRSTmr.
ESC OK
Bag Replacment
Switch Time Out
Th11:23
Unit is Stopped
Reset OK ==>
