NetApp DS224C User manual

Maintain
ONTAP Systems
NetApp
June 27, 2022
This PDF was generated from https://docs.netapp.com/us-en/ontap-systems/sas3/service-hot-swap-
drive-ds224c-ds212c.html on June 27, 2022. Always check docs.netapp.com for the latest.

Table of Contents
Maintain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê1
Hot-swap a disk drive in a DS224C or DS212C disk shelf - shelves with IOM12 modules . . . . . . . . . . . . . . . Ê1
Hot-swap a disk drive in a DS460C disk shelf - shelves with IOM12 modules . . . . . . . . . . . . . . . . . . . . . . . . Ê5
Replacing a drive drawer in a DS460C disk shelf - shelves with IOM12 modules. . . . . . . . . . . . . . . . . . . . . Ê12
Replace a fan module in a DS460C disk shelf - shelves with IOM12 modules . . . . . . . . . . . . . . . . . . . . . . . Ê31
Hot-remove a shelf - shelves with IOM12 modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê34
Hot-swap or replace an IOM12 module - shelves with IOM12 modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê42
Hot-swap a power supply - shelves with IOM12 modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê45
Monitor disk shelf LEDs - shelves with IOM12 modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê47

Maintain
Hot-swap a disk drive in a DS224C or DS212C disk shelf -
shelves with IOM12 modules
You can hot-swap a failed disk drive in a DS224C or DS212C disk shelf.
Before you begin
•The disk drive that you are installing must be supported by the DS224C or DS212C disk shelf.
NetApp Hardware Universe
•All other components in the system must be functioning properly; if not, contact technical support.
•The disk drive you are removing must be failed.
You can verify the disk drive is failed by running the storage disk show -broken command. The
failed disk drive appears in the list of failed disk drives. If it does not, you should wait, and run the
command again.
Depending on the disk drive type and capacity, it can take up to several hours for the disk
drive to appear in the list of failed disk drives.
•If you are replacing a self-encrypting disk (SED), you must follow the instructions for Replacing an SED in
the ONTAP documentation for your version of ONTAP.
Instructions in the ONTAP documentation describe additional steps you must perform before and after
replacing an SED.
NetApp encryption overview with the CLI
About this task
•You should take steps to avoid electrostatic discharge (ESD):
◦Keep the disk drive in the ESD bag until you are ready to install it.
◦Open the ESD bag by hand or cut the top off with a pair of scissors.
Do not insert a metal tool or knife into the ESD bag.
◦Always wear an ESD wrist strap grounded to an unpainted surface on your storage enclosure chassis.
If a wrist strap is unavailable, touch an unpainted surface on your storage enclosure chassis before
handling the disk drive.
•You should take steps to handle disk drives carefully:
◦Always use two hands when removing, installing, or carrying a disk drive to support its weight.
Do not place hands on the disk drive boards exposed on the underside of the disk drive
carrier.
1

◦You should place disk drives on cushioned surfaces, and never stack disk drives on top of each other.
◦You should be careful not to bump disk drives against other surfaces.
•Disk drives should be kept away from magnetic devices.
Magnetic fields can destroy all data on the disk drive and cause irreparable damage to the
disk drive circuitry.
•The best practice is to have the current version of the Disk Qualification Package (DQP) installed before
hot-swapping a disk drive.
Having the current version of the DQP installed allows your system to recognize and utilize newly qualified
disk drives; therefore, avoiding system event messages about having non-current disk drive information.
You also avoid the possible prevention of disk partitioning because disk drives are not recognized. The
DQP also notifies you of non-current disk drive firmware.
NetApp Downloads: Disk Qualification Package
•The best practice is to have the current versions of disk shelf (IOM) firmware and disk drive firmware on
your system before adding new disk shelves, shelf FRU components, or SAS cables.
Current versions of firmware can be found on the NetApp Support Site.
NetApp Downloads: Disk Shelf Firmware
NetApp Downloads: Disk Drive Firmware
•Disk drive firmware is automatically updated (nondisruptively) on new disk drives with non current firmware
versions.
Disk drive firmware checks occur every two minutes.
•If needed, you can turn on the disk shelf’s location (blue) LEDs to aid in physically locating the affected disk
shelf: storage shelf location-led modify -shelf-name shelf_name -led-status on
A disk shelf has three location LEDs: one on the operator display panel and one on each IOM12 module.
Location LEDs remain illuminated for 30 minutes. You can turn them off by entering the same command,
but using the off option.
•If needed, you can refer to the Monitoring disk shelf LEDs section for information about the meaning and
location of disk shelf LEDs on the operator display panel and FRU components.
Steps
1. If you want to manually assign disk ownership for the replacement disk drive, you need to disable
automatic drive assignment if it is enabled; otherwise, go to the next step.
You need to manually assign disk ownership if disk drives in the stack are owned by both
controllers in an HA pair.
You manually assign disk ownership and then reenable automatic drive assignment later in
this procedure.
a. Verify if automatic drive assignment is enabled:storage disk option show
2

If you have an HA pair, you can enter the command at the console of either controller.
If automatic drive assignment is enabled, the output shows “on” (for each controller) in the “Auto
Assign” column.
b. If automatic drive assignment is enabled, you need to disable it:storage disk option modify
-node node_name -autoassign off
You need to disable automatic drive assignment on both controllers in an HA pair.
2. Properly ground yourself.
3. Unpack the new disk drive, and set it on a level surface near the disk shelf.
Save all packaging materials for use when returning the failed disk drive.
NetApp requires that all returned disk drives be in a ESD-rated bag.
4. Physically identify the failed disk drive from the system console warning message and the illuminated
attention (amber) LED on the disk drive.
The activity (green) LED on a failed disk drive can be illuminated (solid), which indicates the
disk drive has power, but should not be blinking, which indicates I/O activity. A failed disk
drive has no I/O activity.
5. Press the release button on the disk drive face, and then pull the cam handle to its fully open position to
release the disk drive from the mid plane.
When you press the release button, the cam handle on the disk drive springs open partially.
Disk drives in a DS212C disk shelf are arranged horizontally with the release button located
on the left of the disk drive face. Disk drives in a DS224C disk shelf are arranged vertically
with the release button located at the top of the disk drive face.
The following shows disk drives in a DS212C disk shelf:
The following shows disk drives in a DS224C disk shelf:
3

6. Slide out the disk drive slightly to allow the disk to safely spin down, and then remove the disk drive from
the disk shelf.
An HDD can take up to one minute to safely spin down.
When handling a disk drive, always use two hands to support its weight.
7. Using two hands, with the cam handle in the open position, insert the replacement disk drive into the disk
shelf, firmly pushing until the disk drive stops.
Wait a minimum of 10 seconds before inserting a new disk drive. This allows the system to
recognize that a disk drive was removed.
Do not place hands on the disk drive boards that are exposed on the underside of the disk
carrier.
8. Close the cam handle so that the disk drive is fully seated into the mid plane and the handle clicks into
place.
Be sure to close the cam handle slowly so that it aligns correctly with the face of the disk drive.
9. If you are replacing another disk drive, repeat Steps 3 through 8.
10. Verify the disk drive’s activity (green) LED is illuminated.
When the disk drive’s activity LED is solid green, it means the disk drive has power. When the disk drive’s
activity LED is blinking, it means the disk drive has power and I/O is in progress. If the disk drive firmware
is automatically updating, the LED will be blinking.
11. If you disabled automatic drive assignment in Step 1, manually assign disk ownership, and then reenable
automatic drive assignment if needed:
a. Display all unowned disks:storage disk show -container-type unassigned
b. Assign each disk:storage disk assign -disk disk_name -owner owner_name
You can use the wildcard character to assign more than one disk at once.
4

c. Reenable automatic drive assignment if needed:storage disk option modify -node
node_name -autoassign on
You need to reenable automatic drive assignment on both controllers in an HA pair.
12. Return the failed part to NetApp, as described in the RMA instructions shipped with the kit.
Contact technical support at NetApp Support, 888-463-8277 (North America), 00-800-44-638277 (Europe),
or [phone] (Asia/Pacific) if you need the RMA number or additional help with the replacement
procedure.
Hot-swap a disk drive in a DS460C disk shelf - shelves with
IOM12 modules
You can hot-swap a failed disk drive in a DS460C disk shelf.
Before you begin
•The replacement disk drive must be supported by the DS460C disk shelf.
NetApp Hardware Universe
•All other components in the system must be functioning properly; if not, contact technical support.
•The disk drive you are removing must be failed.
You can verify the disk drive is failed by running the storage disk show -broken command. The
failed disk drive appears in the list of failed disk drives. If it does not, you should wait, and run the
command again.
Depending on the disk drive type and capacity, it can take up to several hours for the disk
drive to appear in the list of failed disk drives.
•If you are replacing a self-encrypting disk (SED), you must follow the instructions for Replacing an SED in
the ONTAP documentation for your version of ONTAP.
Instructions in the ONTAP documentation describe additional steps you must perform before and after
replacing an SED.
NetApp encryption overview with the CLI
About this task
•You should take steps to avoid electrostatic discharge (ESD):
◦Keep the disk drive in the ESD bag until you are ready to install it.
◦Open the ESD bag by hand or cut the top off with a pair of scissors.
Do not insert a metal tool or knife into the ESD bag.
◦Always wear an ESD wrist strap grounded to an unpainted surface on your storage enclosure chassis.
If a wrist strap is unavailable, touch an unpainted surface on your storage enclosure chassis before
handling the disk drive.
5

•You should take steps to handle disk drives carefully:
◦Always use two hands when removing, installing, or carrying a disk drive to support its weight.
Do not place hands on the disk drive boards exposed on the underside of the disk drive
carrier.
◦You should place disk drives on cushioned surfaces, and never stack disk drives on top of each other.
◦You should be careful not to bump disk drives against other surfaces.
•Disk drives should be kept away from magnetic devices.
Magnetic fields can destroy all data on the disk drive and cause irreparable damage to the
disk drive circuitry.
•The best practice is to have the current version of the Disk Qualification Package (DQP) installed before
hot-swapping a disk drive.
Having the current version of the DQP installed allows your system to recognize and utilize newly qualified
disk drives; therefore, avoiding system event messages about having non-current disk drive information.
You also avoid the possible prevention of disk partitioning because disk drives are not recognized. The
DQP also notifies you of non-current disk drive firmware.
NetApp Downloads: Disk Qualification Package
•The best practice is to have the current versions of disk shelf (IOM) firmware and disk drive firmware on
your system before adding new disk shelves, shelf FRU components, or SAS cables.
Current versions of firmware can be found on the NetApp Support Site.
NetApp Downloads: Disk Shelf Firmware
NetApp Downloads: Disk Drive Firmware
•Disk drive firmware is automatically updated (nondisruptively) on new disk drives with non current firmware
versions.
Disk drive firmware checks occur every two minutes.
•If needed, you can turn on the disk shelf’s location (blue) LEDs to aid in physically locating the affected disk
shelf: storage shelf location-led modify -shelf-name shelf_name -led-status on
A disk shelf has three location LEDs: one on the operator display panel and one on each IOM12 module.
Location LEDs remain illuminated for 30 minutes. You can turn them off by entering the same command,
but using the off option.
•If needed, you can refer to the Monitoring disk shelf LEDs section for information about the meaning and
location of disk shelf LEDs on the operator display panel and FRU components.
•The DS460C drive shelf consist of five drive drawers (drive drawer 1 at the top through drive drawer 5 at
the bottom) that each contain 12 drive slots.
6

•The following illustration shows how the drives are numbered from 0 to 11 in each drive drawer within the
shelf.
Steps
1. If you want to manually assign disk ownership for the replacement disk drive, you need to disable
automatic drive assignment if it is enabled; otherwise, go to the next step.
You need to manually assign disk ownership if disk drives in the stack are owned by both
controllers in an HA pair.
You manually assign disk ownership and then reenable automatic drive assignment later in
this procedure.
a. Verify if automatic drive assignment is enabled:storage disk option show
If you have an HA pair, you can enter the command at the console of either controller.
7

If automatic drive assignment is enabled, the output shows “on” (for each controller) in the “Auto
Assign” column.
b. If automatic drive assignment is enabled, you need to disable it:storage disk option modify
-node node_name -autoassign off
You need to disable automatic drive assignment on both controllers in an HA pair.
2. Properly ground yourself.
3. Unpack the new disk drive, and set it on a level surface near the disk shelf.
Save all packaging materials for use when returning the failed disk drive.
NetApp requires that all returned disk drives be in a ESD-rated bag.
4. Identify the failed disk drive from the system console warning message and the illuminated amber attention
LED on the drive drawer.
The 2.5-inch and 3.5-inch SAS drive carriers do not contain LEDs. Instead, you must look at the Attention
LEDs on the drive drawers to determine which drive has failed.
The drive drawer’s Attention LED (amber) blinks so you can open the correct drive drawer to identify which
drive to replace.
The drive drawer’s Attention LED is on the front-left side in front of each drive, with a warning symbol on
the drive handle just behind the LED.
5. Open the drawer containing the failed drive:
a. Unlatch the drive drawer by pulling on both levers.
b. Using the extended levers, carefully pull the drive drawer out until it stops.
c. Look at the top of the drive drawer to find the Attention LED that resides on the drawer in front of each
drive.
6. Remove the failed drive from the open drawer:
a. Gently pull back the orange release latch that is in front of the drive you want to remove.
8

Orange release latch
b. Open the cam handle, and lift out the drive slightly.
c. Wait 30 seconds.
d. Use the cam handle to lift the drive from the shelf.
9

e. Place the drive on an antistatic, cushioned surface away from magnetic fields.
7. Insert the replacement drive in the drawer:
a. Raise the cam handle on the new drive to vertical.
b. Align the two raised buttons on each side of the drive carrier with the matching gap in the drive channel
on the drive drawer.
10

Raised button on the right side of the drive carrier
c. Lower the drive straight down, and then rotate the cam handle down until the drive snaps into place
under the orange release latch.
d. Carefully push the drive drawer back into the enclosure.
Possible loss of data access: Never slam the drawer shut. Push the drawer in slowly
to avoid jarring the drawer and causing damage to the storage array.
11

e. Close the drive drawer by pushing both levers towards the center.
The green Activity LED for the replaced drive on the front of the drive drawer comes on when the drive
is inserted correctly.
8. If you are replacing another disk drive, repeat Steps 4 through 7.
9. Check the Activity LED and the Attention LED on the drive you replaced.
LED status Description
The Activity LED is on or blinking,
and the Attention LED is off
The new drive is working correctly.
The Activity LED is off The drive might not be installed correctly. Remove the drive, wait 30
seconds, and then reinstall it.
The Attention LED is on The new drive might be defective. Replace it with another new drive.
When you first insert a drive, its Attention LED might be
on. However, the LED should go off within a minute.
10. If you disabled disk ownership automatic assignment in Step 1, manually assign disk ownership, and then
reenable disk ownership automatic assignment if needed:
a. Display all unowned disks:storage disk show -container-type unassigned
b. Assign each disk:storage disk assign -disk disk_name -owner owner_name
You can use the wildcard character to assign more than one disk at once.
c. Reenable disk ownership automatic assignment if needed:storage disk option modify -node
node_name -autoassign on
You need to reenable disk ownership automatic assignment on both controllers in an HA pair.
11. Return the failed part to NetApp, as described in the RMA instructions shipped with the kit.
Contact technical support at NetApp Support, 888-463-8277 (North America), 00-800-44-638277 (Europe),
or [phone] (Asia/Pacific) if you need the RMA number or additional help with the replacement
procedure.
Replacing a drive drawer in a DS460C disk shelf - shelves
with IOM12 modules
You must stop all host I/O activity and power off the shelf before replacing the drive
drawer.
Each of these 60-drive shelves has five drive drawers.
12

And each of the five drawers can hold up to 12 drives.
Before you begin
You need these items for this procedure:
•Antistatic protection
Possible hardware damage: To prevent electrostatic discharge damage to the drive shelf,
use proper antistatic protection when handling drive shelf components.
•Replacement drive drawer
•Replacement left and right cable chains
•Flashlight
13

Removing the cable chains
Left and right cable chains for each drive drawer in the DS460C drive shelf allow the
drawers to slide in and out. Before you can remove a drive drawer, you must remove both
cable chains.
Before you begin
•You have stopped host I/O activity and powered off the shelf.
•You have obtained the following items:
◦Antistatic protection
Possible hardware damage: To prevent electrostatic discharge damage to the shelf,
use proper antistatic protection when handling shelf components.
◦Flashlight
About this task
Each drive drawer has left and right cable chains. The metal ends on the cable chains slide into corresponding
vertical and horizontal brackets inside the enclosure, as follows:
•The left and right vertical brackets connect the cable chain to the enclosure’s midplane.
•The left and right horizontal brackets connect the cable chain to the individual drawer.
Steps
1. Put on antistatic protection.
2. From the rear of the drive shelf, remove the right fan module, as follows:
a. Press the orange tab to release the fan module handle.
The figure shows the handle for the fan module extended and released from the orange tab on the left.
14

Fan module handle
b. Using the handle, pull the fan module out of the drive shelf, and set it aside.
3. Manually determine which of the five cable chains to disconnect.
The figure shows the right side of the drive shelf with the fan module removed. With the fan module
removed, you can see the five cable chains and the vertical and horizontal connectors for each drawer.
The callouts for drive drawer 1 are provided.
15

16

Cable chain
Vertical connector (connected to the midplane)
Horizontal connector (connected to the drive drawer)
The top cable chain is attached to drive drawer 1. The bottom cable chain is attached to drive drawer 5.
4. Use your finger to move the cable chain on the right side to the left.
5. Follow these steps to disconnect any of the right cable chains from its corresponding vertical bracket.
a. Using a flashlight, locate the orange ring on the end of the cable chain that is connected to the vertical
bracket in the enclosure.
17

Orange ring on the vertical bracket
b. Disconnect the vertical connector (connected to the midplane) by gently pressing on the center of the
18
