NETGEAR NIGHTHAWK CM2000 User manual

User Manual
Nighthawk® 2.5Gbps Multi-Gig Speed
Cable Modem
Model CM2000
NETGEAR, Inc.
350 E. Plumeria DriveMay 2020
San Jose, CA 95134, USA202-12065-01

Support
Thank you for purchasing this NETGEAR product.
You can visit https://www.netgear.com/support/ to register your product, get help,
access the latest downloads and user manuals, and join our community. We recommend
that you use only official NETGEAR support resources.
Contact your Internet service provider for technical support.
Trademarks
©NETGEAR, Inc. NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc.
Any non-NETGEAR trademarks are used for reference purposes only.
Compliance and Conformity
For regulatory compliance information, visit https://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
Note to CATV system Installer- This reminder is provided to call the CATV systems
installer's attention to Section 820-93 of the National Electrical Code which provide
guidelines for proper grounding and in particular, specify that Coaxial cable shield shall
connected to the grounding system of the building, as close to the point of cable entry
as practical
2
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

Contents
Chapter 1 Hardware Setup
Front Panel and LEDs...........................................................................5
Rear Panel..............................................................................................6
Label.......................................................................................................8
System Requirements...........................................................................8
Install and Activate Your Cable Modem............................................9
Connect Your Cable Modem to a Computer...............................9
Activate Your Internet Service......................................................10
Perform a Speed Test....................................................................11
Connect Your Cable Modem to a Router After Installation and
Activation........................................................................................11
Chapter 2 Manage Your Network
Log in to the cable modem...............................................................14
Change the admin password............................................................14
View cable modem initialization.......................................................15
View cable modem status..................................................................16
View and clear event logs..................................................................16
Specify the cable connection starting frequency...........................17
Reboot the cable modem..................................................................17
Reset the cable modem to factory default settings........................18
Use the reset button on the back panel..........................................19
Use the factory reset software button..............................................19
Chapter 3 Troubleshooting
Use LEDs to Troubleshoot.................................................................21
Cannot log in to the cable modem..................................................22
Troubleshoot the cable internet connection..................................23
Chapter 4 Supplemental Information
Factory Settings..................................................................................25
Technical Specifications.....................................................................25
3

1
Hardware Setup
This chapter covers the following topics:
• Front Panel and LEDs
• Rear Panel
• Label
• System Requirements
• Install and Activate Your Cable Modem
For more information about the topics covered in this manual, visit the support website
at support.netgear.com.
4

Front Panel and LEDs
The cable modem provides status LEDs on the front.
Figure 1. Front panel
You can use the LEDs to verify status and connections. The following table lists and
describes each LED on the cable modem.
User Manual5Hardware Setup
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

Table 1. LED descriptions
DescriptionIconLED
•Solid white. Power is supplied to the cable modem.
•Off. No power is supplied to the cable modem.
•Solid red. The cable modem is too warm and might overheat. For
more information about this condition, see Use LEDs to Troubleshoot
on page 21.
Power
•Solid amber. One downstream channel is locked.
•Solid white. Two or more downstream channels are locked.
•Blinking white. The cable modem is scanning for a downstream
channel.
•Off. No downstream channel is locked.
Downstream
•Solid amber. One upstream channel is locked.
•Solid white. Two or more upstream channels are locked.
•Blinking white. The cable modem is scanning for an upstream
channel.
•Off. No upstream channel is locked.
Upstream
•Solid white. The cable modem is online.
•Blinking white. The cable modem is synchronizing with the cable
provider’s cable modem termination system (CMTS).
•Off. The cable modem is offline.
Online
•Solid white. A 2.5 Gbps connection is established.
•Blinking blue. The port is sending or receiving traffic at 2.5 Gbps.
•Solid white. A 1 Gbps connection is established.
•Blinking white. The port is sending or receiving traffic at 1 Gbps.
•Solid amber. A 100 Mbps connection is established.
•Blinking amber. The port is sending or receiving traffic at 100 Mbps.
Multi Gig Port
Rear Panel
The connections and button on the rear panel are shown in the following figure.
User Manual6Hardware Setup
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

Figure 2. Rear panel
Viewed from top to bottom, the back panel contains the following components:
•Reset button. Pressing the Reset button resets the cable modem. If the Reset button
is pressed for at least seven seconds, the Power LED blinks white and the cable
modem returns to its factory settings.
•Ethernet port. For installation and activation, connect a computer to the Ethernet
port. After you install your cable modem and activate your Internet service, you can
disconnect your computer and connect a router to the Ethernet port.
User Manual7Hardware Setup
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

•Coaxial cable port. Connect the cable port to a cable wall outlet.
•DC power connector. Connect the power adapter that came in the product package
to the DC power connector.
Label
The cable modem label shows the login information, MAC address, and serial number.
Figure 3. Cable modem label
System Requirements
You need the following to install your cable modem:
•Compatible operating system:
- Windows 10
- Windows 8
- Windows 7
- Windows Vista
- Windows XP
- Windows 2000
- Mac OS
- Other operating systems running a TCP/IP network
•Compatible web browser:
-Microsoft Internet Explorer 5.0 or later
-Firefox 2.0 or later
User Manual8Hardware Setup
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

-Safari 1.4 or later
- Google Chrome 11.0 or later
•Cable broadband Internet service
Install and Activate Your Cable Modem
The cable modem provides a connection between your cable Internet provider’s network
and your computer, router, or WiFi router.
Connect Your Cable Modem to a Computer
After you install the cable modem and activate your Internet service, you can disconnect
the computer and connect a router to the cable modem.
To connect your cable modem directly to a computer:
1. Turn off and disconnect existing modems and routers.
If you are replacing a modem that is currently connected in your home, unplug the
modem and plug the new cable modem into the same outlet.
2. Connect a coaxial cable.
Use a coaxial cable to connect the cable port on the cable modem to a cable wall
outlet. Make sure that the cable is tightly connected.
3. Connect the power adapter to the cable modem and plug the power adapter into
an electrical outlet.
When the startup is complete, the Power LED lights white.
4. Wait for the cable modem to come online.
The cable modem comes online when the Internet LED stops blinking and lights
solid white.
This process might take up to 10 minutes.
5. Connect a computer to the cable modem.
Use the Ethernet cable that is provided in the package to connect a computer to the
Ethernet port on the cable modem.
6. Reboot the computer.
7. Activate your Internet service.
For information about how to activate your Internet service, see Activate Your Internet
Service on page 10.
User Manual9Hardware Setup
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

Note: After you install and activate the cable modem, you can disconnect the
computer and connect a router to the cable modem. For more information, see
Connect Your Cable Modem to a Router After Installation and Activation on page
11.
Activate Your Internet Service
Before you activate your Internet service, gather the following information:
•Your cable Internet provider account information
•Cable modem model number, which is CM2000
•Cable modem serial number, which is on the cable modem label
•Cable modem MAC address, which is on the cable modem label
Figure 4. Example of a cable modem label
The following is contact information for cable Internet providers that support your cable
modem.
Table 2. Cable Internet provider contact information
Contact InformationCable
Internet
Provider
https://cox.com/activate
1-888-556-1193
Cox
https://support.mediacomcable.com/
1-855-Mediacom (1-855-633-4226)
Mediacom
https://install.optimum.com/JointInstall/
1-877-810-6750
Optimum
https://support.sparklight.com/
1-877-692-2253
Sparklight
User Manual10Hardware Setup
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

Table 2. Cable Internet provider contact information (Continued)
Contact InformationCable
Internet
Provider
https://activate.spectrum.net/
1-833-267-6094
Spectrum
https://xfinity.com/activate/
https://www.xfinity.com/support/internet/activate-purchased-modem/
1-800-XFINITY (1-800-934-6489)
Xfinity
Note: Your cable Internet provider’s contact information might change. You can find
the contact information in your monthly Internet service billing statement.
To activate your Internet service:
1. Visit your cable Internet provider’s website and follow the onscreen instructions to
activate your Internet service.
2. If you are unable to activate your Internet service using the instructions on your cable
Internet provider’s website, call your cable Internet provider for support.
3. To determine the accurate Internet speed, visit your cable Internet provider's speed
test website and perform a speed test. .
If your actual speed is lower than your subscribed speed, contact your cable Internet
provider.
Perform a Speed Test
To determine the accurate Internet speed, visit the speed test website of your cable
Internet provider and perform a speed test.
If your actual speed is lower than your subscribed speed, contact your cable Internet
provider.
Connect Your Cable Modem to a Router After Installation
and Activation
After you install the cable modem and activate your Internet service, you can disconnect
the computer and connect a router to the cable modem.
User Manual11Hardware Setup
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

To connect your cable modem to a router after installation and activation:
1. Reboot the cable modem by unplugging the power cable from the cable modem
and plugging it back in.
Wait for the Internet LED to stop blinking and light solid white.
2. Use an Ethernet cable to connect the Ethernet port on the cable modem to the WAN
or Internet port on the router.
3. Power on the router.
4. Wait until the router is ready.
5. Connect a computer to the router.
For more information about how to set up your router, see the documentation that
came with your router.
User Manual12Hardware Setup
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

2
Manage Your Network
After you set up the cable modem, you do not need to log in to the cable modem for
normal operation. However, you can log in to the cable modem to change a very limited
number of settings and monitor the cable modem.
This chapter includes the following sections:
• Log in to the cable modem
• Change the admin password
• View cable modem initialization
• View cable modem status
• View and clear event logs
• Specify the cable connection starting frequency
• Reboot the cable modem
• Reset the cable modem to factory default settings
13

Log in to the cable modem
To log in to the cable modem:
1. Connect a computer to your cable modem.
You can connect a computer to your cable modem using the following methods:
•Connect a computer to your cable modem using an Ethernet connection.
•Connect a WiFi router to your cable modem using an Ethernet connection, and
then connect a computer to your router using a WiFi or Ethernet connection.
2. Launch a web browser.
3. Enter http://192.168.100.1.
A login window opens.
4. Enter the admin user name and password.
The user name is admin. The default password is printed on the product label. The
user name and password are case-sensitive.
The BASIC Home page displays.
Change the admin password
You can change the default password that is used to log in to the cable modem with
the admin user name.
Note: Be sure to change the password for the user name admin to a secure password.
The ideal password contains no dictionary words from any language and contains
uppercase and lowercase letters, numbers, and symbols. It must be at least 6 and up
to 32 characters.
To set the password for the user name admin:
1. Launch a web browser from a computer that is connected to your cable modem.
2. Enter or http://192.168.100.1.
A login window opens.
3. Enter the admin user name and password.
The user name is admin. The default password is printed on the product label. The
user name and password are case-sensitive.
The BASIC Home page displays.
User Manual14Manage Your Network
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

4. Select ADVANCED > Administration > Set Password.
The Set Password page displays.
5. Type the old password, and type the new password twice.
6. Click the Apply button.
Your settings are saved.
View cable modem initialization
You can track the initialization procedure of the cable modem and get details about
the downstream and upstream cable channel. The time is displayed after the cable
modem is initialized.
The cable modem automatically goes through the following steps in the provisioning
process:
1. Scans and locks the downstream frequency and then ranges the upstream channels.
2. Obtains a WAN address for the cable modem.
3. Connects to the Internet.
To view the status of the cable modem initialization:
1. Launch a web browser from a computer that is connected to your cable modem.
2. Enter http://192.168.100.1.
A login window opens.
3. Enter the admin user name and password.
The user name is admin. The default password is printed on the product label. The
user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Cable Connection.
The Cable Connection page displays.
The Startup Procedure section displays the initialization progress. The page also
displays the status of all downstream and upstream channels. (You must scroll down
to view all the channels.) The number of downstream and upstream channels that
are locked depends on the number of channels that your Internet provider uses.
User Manual15Manage Your Network
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

View cable modem status
To view cable modem status and usage information:
1. Launch a web browser from a computer that is connected to your cable modem.
2. Enter http://192.168.100.1.
A login window opens.
3. Enter the admin user name and password.
The user name is admin. The default password is printed on the product label. The
user name and password are case-sensitive.
The BASIC Home page displays.
4. Click the ADVANCED tab.
The ADVANCED Home page displays information about your cable modem.
View and clear event logs
Event logs capture important cable modem events.
To view and clear the event logs:
1. Launch a web browser from a computer that is connected to your cable modem.
2. Enter http://192.168.100.1.
A login window opens.
3. Enter the admin user name and password.
The user name is admin. The default password is printed on the product label. The
user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Administration > Event Log.
The Event Log page displays the following information:
•Time. The time the event was recorded.
•Priority. The severity for this event.
•Description. A description of this event.
5. To refresh the page, click the Refresh button.
6. To clear the log entries, click the Clear Log button.
User Manual16Manage Your Network
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

Specify the cable connection starting
frequency
The starting frequency is automatically generated. For most Internet connections, you
do not need to specify this information. If you must enter a starting frequency, contact
your Internet provider.
To change the starting frequency:
1. Launch a web browser from a computer that is connected to your cable modem.
2. Enter http://192.168.100.1.
A login window opens.
3. Enter the admin user name and password.
The user name is admin. The default password is printed on the product label. The
user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Cable Connection.
The Cable Connection page displays the status of all downstream and upstream
channels.
5. In the Starting Frequency field, type a number as instructed by your cable Internet
provider.
6. Click the Apply button.
Your settings are saved.
Reboot the cable modem
Rebooting the cable modem disconnects all network connections to the cable modem’s
local area network (LAN). After the cable modem is finished booting and reestablishes
a connection with the Internet, the devices on your network reconnect to the cable
modem’s LAN.
To reboot the cable modem:
1. Launch a web browser from a computer that is connected to your cable modem.
2. Enter http://192.168.100.1.
A login window opens.
User Manual17Manage Your Network
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

3. Enter the admin user name and password.
The user name is admin. The default password is printed on the product label. The
user name and password are case-sensitive.
The BASIC Home page displays.
4. Click the ADVANCED tab.
The ADVANCED Home page displays.
5. Click the Reboot button.
A confirmation message displays.
6. Click the OK button.
The cable modem reboots.
Reset the cable modem to factory default
settings
To reset the cable modem to factory default settings, you can use either the Reset
button on the back panel of the cable modem or the Factory reset software button.
However, if you changed the default password that you use to access the cable modem
and lost the password, you must use the Reset button on the back panel.
After you reset the cable modem to factory default settings, the password is printed on
the product label. The LAN IP address is always 192.168.100.1. You cannot change this
LAN IP address.
User Manual18Manage Your Network
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

Use the reset button on the back panel
CAUTION: This process erases all settings that you configured in the cable modem.
To reset the cable modem to factory default settings using the Reset button:
1. On the back of the cable modem, locate the Reset button.
2. Using a straightened paper clip, press and hold the Reset button until the cable
modem reboots itself.
The configuration is reset to factory default settings. This process takes about one
minute.
Use the factory reset software button
CAUTION: This process erases all settings that you configured in the cable modem.
To reset the cable modem to factory default settings using the Factory reset
software button:
1. Launch a web browser from a computer that is connected to your cable modem.
2. Enter http://192.168.100.1.
A login window opens.
3. Enter the admin user name and password.
The user name is admin. The default password is printed on the product label. The
user name and password are case-sensitive.
The BASIC Home page displays.
4. Click the ADVANCED tab.
The ADVANCED Home page displays.
5. Click the Factory reset button.
A confirmation message displays.
6. Click the OK button.
The configuration is reset to factory default settings. When the reset is complete,
the cable modem reboots. This process takes about one minute.
WARNING: To avoid the risk of corrupting the firmware, do not interrupt the reset.
For example, do not close the browser, click a link, or load a new page. Do not turn
off the cable modem.
User Manual19Manage Your Network
Nighthawk CM2000 2.5 Gbps Ultra-High Speed Cable Modem

3
Troubleshooting
This chapter provides information about troubleshooting your cable modem.
The chapter includes the following sections:
• Use LEDs to Troubleshoot
• Cannot log in to the cable modem
• Troubleshoot the cable internet connection
20
