IMAQ™
IMAQ PCI/PXI™-1407
User Manual
High-Quality Monochrome Image Acquisition Boards
for PCI, PXI, and CompactPCI Bus
IMAQ PCI/PXI-1407 User Manual
August 2001 Edition
Part Number 322156C-01

Support
Worldwide Technical Support and Product Information
ni.com
National Instruments Corporate Headquarters
11500 North Mopac Expressway Austin, Texas 78759-3504 USA Tel: [phone]
Worldwide Offices
Australia 03 9879 5166, Austria 0662 45 79 90 0, Belgium 02 757 00 20, Brazil 011 284 5011,
Canada (Calgary) 403 274 9391, Canada (Montreal) 514 288 5722, Canada (Ottawa) 613 233 5949,
Canada (Québec) 514 694 8521, Canada (Toronto) 905 785 0085, China (Shanghai) 021 6555 7838,
China (ShenZhen) 0755 3904939, Denmark 45 76 26 00, Finland 09 725 725 11, France 01 48 14 24 24,
Germany 089 741 31 30, Greece 30 1 42 96 427, Hong Kong 2645 3186, India 91805275406,
Israel 03 6120092, Italy 02 413091, Japan 03 5472 2970, Korea 02 596 7456, Malaysia 603 9596711,
Mexico 5 280 7625, Netherlands 0348 433466, New Zealand 09 914 0488, Norway 32 27 73 00,
Poland 0 22 528 94 06, Portugal 351 1 726 9011, Singapore 2265886, Spain 91 640 0085,
Sweden 08 587 895 00, Switzerland 056 200 51 51, Taiwan 02 2528 7227, United Kingdom 01635 523545
For further support information, see the Technical Support Resources appendix. To comment on the
documentation, send e-mail to [email protected].
Copyright ©1998, 2001 National Instruments Corporation. All rights reserved.

Important Information
Warranty
The IMAQ PCI-1407 and PXI-1407 are warranted against defects in materials and workmanship for a period of 90 days from the date of
shipment, as evidenced by receipts or other documentation. National Instruments will, at its option, repair or replace equipment that proves to
be defective during the warranty period. This warranty includes parts and labor.
The media on which you receive National Instruments software are warranted not to fail to execute programming instructions, due to defects
in materials and workmanship, for a period of 90 days from date of shipment, as evidenced by receipts or other documentation. National
Instruments will, at its option, repair or replace software media that do not execute programming instructions if National Instruments receives
notice of such defects during the warranty period. National Instruments does not warrant that the operation of the software shall be
uninterrupted or error free.
A Return Material Authorization (RMA) number must be obtained from the factory and clearly marked on the outside of the package before
any equipment will be accepted for warranty work. National Instruments will pay the shipping costs of returning to the owner parts which are
covered by warranty.
National Instruments believes that the information in this document is accurate. The document has been carefully reviewed for technical
accuracy. In the event that technical or typographical errors exist, National Instruments reserves the right to make changes to subsequent
editions of this document without prior notice to holders of this edition. The reader should consult National Instruments if errors are suspected.
In no event shall National Instruments be liable for any damages arising out of or related to this document or the information contained in it.
EXCEPT AS SPECIFIED HEREIN,NATIONAL INSTRUMENTS MAKES NO WARRANTIES,EXPRESS OR IMPLIED,AND SPECIFICALLY DISCLAIMS ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.CUSTOMER’S RIGHT TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE ON THE PART OF
NATIONAL INSTRUMENTS SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID BY THE CUSTOMER.NATIONAL INSTRUMENTS WILL NOT BE LIABLE FOR
DAMAGES RESULTING FROM LOSS OF DATA,PROFITS,USE OF PRODUCTS,OR INCIDENTAL OR CONSEQUENTIAL DAMAGES,EVEN IF ADVISED OF THE POSSIBILITY
THEREOF. This limitation of the liability of National Instruments will apply regardless of the form of action, whether in contract or tort, including
negligence. Any action against National Instruments must be brought within one year after the cause of action accrues. National Instruments
shall not be liable for any delay in performance due to causes beyond its reasonable control. The warranty provided herein does not cover
damages, defects, malfunctions, or service failures caused by owner’s failure to follow the National Instruments installation, operation, or
maintenance instructions; owner’s modification of the product; owner’s abuse, misuse, or negligent acts; and power failure or surges, fire,
flood, accident, actions of third parties, or other events outside reasonable control.
Copyright
Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or mechanical, including photocopying,
recording, storing in an information retrieval system, or translating, in whole or in part, without the prior written consent of National
Instruments Corporation.
Trademarks
CVI™,IMAQ
™,LabVIEW ™, Measurement Studio™,MITE ™, National Instruments™,ni.com ™,NI ™, NI-IMAQ™,PXI ™,andRTSI ™are
trademarks of National Instruments Corporation.
Product and company names mentioned herein are trademarks or trade names of their respective companies.
WARNING REGARDING USE OF NATIONAL INSTRUMENTS PRODUCTS
(1) NATIONAL INSTRUMENTS PRODUCTS ARE NOT DESIGNED WITH COMPONENTS AND TESTING FOR A LEVEL OF
RELIABILITY SUITABLE FOR USE IN OR IN CONNECTION WITH SURGICAL IMPLANTS OR AS CRITICAL COMPONENTS IN
ANY LIFE SUPPORT SYSTEMS WHOSE FAILURE TO PERFORM CAN REASONABLY BE EXPECTED TO CAUSE SIGNIFICANT
INJURY TO A HUMAN.
(2) IN ANY APPLICATION, INCLUDING THE ABOVE, RELIABILITY OF OPERATION OF THE SOFTWARE PRODUCTS CAN BE
IMPAIRED BY ADVERSE FACTORS, INCLUDING BUT NOT LIMITED TO FLUCTUATIONS IN ELECTRICAL POWER SUPPLY,
COMPUTER HARDWARE MALFUNCTIONS, COMPUTER OPERATING SYSTEM SOFTWARE FITNESS, FITNESS OF COMPILERS
AND DEVELOPMENT SOFTWARE USED TO DEVELOP AN APPLICATION, INSTALLATION ERRORS, SOFTWARE AND
HARDWARE COMPATIBILITY PROBLEMS, MALFUNCTIONS OR FAILURES OF ELECTRONIC MONITORING OR CONTROL
DEVICES, TRANSIENT FAILURES OF ELECTRONIC SYSTEMS (HARDWARE AND/OR SOFTWARE), UNANTICIPATED USES OR
MISUSES, OR ERRORS ON THE PART OF THE USER OR APPLICATIONS DESIGNER (ADVERSE FACTORS SUCH AS THESE ARE
HEREAFTER COLLECTIVELY TERMED “SYSTEM FAILURES”). ANY APPLICATION WHERE A SYSTEM FAILURE WOULD
CREATE A RISK OF HARM TO PROPERTY OR PERSONS (INCLUDING THE RISK OF BODILY INJURY AND DEATH) SHOULD
NOT BE RELIANT SOLELY UPON ONE FORM OF ELECTRONIC SYSTEM DUE TO THE RISK OF SYSTEM FAILURE. TO AVOID
DAMAGE, INJURY, OR DEATH, THE USER OR APPLICATION DESIGNER MUST TAKE REASONABLY PRUDENT STEPS TO
PROTECT AGAINST SYSTEM FAILURES, INCLUDING BUT NOT LIMITED TO BACK-UP OR SHUT DOWN MECHANISMS.
BECAUSE EACH END-USER SYSTEM IS CUSTOMIZED AND DIFFERS FROM NATIONAL INSTRUMENTS' TESTING
PLATFORMS AND BECAUSE A USER OR APPLICATION DESIGNER MAY USE NATIONAL INSTRUMENTS PRODUCTS IN
COMBINATION WITH OTHER PRODUCTS IN A MANNER NOT EVALUATED OR CONTEMPLATED BY NATIONAL
INSTRUMENTS, THE USER OR APPLICATION DESIGNER IS ULTIMATELY RESPONSIBLE FOR VERIFYING AND VALIDATING
THE SUITABILITY OF NATIONAL INSTRUMENTS PRODUCTS WHENEVER NATIONAL INSTRUMENTS PRODUCTS ARE
INCORPORATED IN A SYSTEM OR APPLICATION, INCLUDING, WITHOUT LIMITATION, THE APPROPRIATE DESIGN,
PROCESS AND SAFETY LEVEL OF SUCH SYSTEM OR APPLICATION.

Compliance
FCC/Canada Radio Frequency Interference Compliance*
Determining FCC Class
The Federal Communications Commission (FCC) has rules to protect wireless communications from interference. The FCC
places digital electronics into two classes. These classes are known as Class A (for use in industrial-commercial locations only)
or Class B (for use in residential or commercial locations). Depending on where it is operated, this product could be subject to
restrictions in the FCC rules. (In Canada, the Department of Communications (DOC), of Industry Canada, regulates wireless
interference in much the same way.)
Digital electronics emit weak signals during normal operation that can affect radio, television, or other wireless products. By
examining the product you purchased, you can determine the FCC Class and therefore which of the two FCC/DOC Warnings
apply in the following sections. (Some products may not be labeled at all for FCC; if so, the reader should then assume these are
Class A devices.)
FCC Class A products only display a simple warning statement of one paragraph in length regarding interference and undesired
operation. Most of our products are FCC Class A. The FCC rules have restrictions regarding the locations where FCC Class A
products can be operated.
FCC Class B products display either a FCC ID code, starting with the letters EXN,
or the FCC Class B compliance mark that appears as shown here on the right.
Consult the FCC web site http://www.fcc.gov for more information.
FCC/DOC Warnings
This equipment generates and uses radio frequency energy and, if not installed and used in strict accordance with the instructions
in this manual and the CE Mark Declaration of Conformity**, may cause interference to radio and television reception.
Classification requirements are the same for the Federal Communications Commission (FCC) and the Canadian Department
of Communications (DOC).
Changes or modifications not expressly approved by National Instruments could void the user’s authority to operate the
equipment under the FCC Rules.
Class A
Federal Communications Commission
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Canadian Department of Communications
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Class B
Federal Communications Commission
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Compliance to EU Directives
Readers in the European Union (EU) must refer to the Manufacturer’s Declaration of Conformity (DoC) for information**
pertaining to the CE Mark compliance scheme. The Manufacturer includes a DoC for most every hardware product except for
those bought for OEMs, if also available from an original manufacturer that also markets in the EU, or where compliance is not
required as for electrically benign apparatus or cables.
To obtain the DoC for this product, click Declaration of Conformity at ni.com/hardref.nsf/. This web site lists the DoCs
by product family. Select the appropriate product family, followed by your product, and a link to the DoC appears in Adobe
Acrobat format. Click the Acrobat icon to download or read the DoC.
* Certain exemptions may apply in the USA, see FCC Rules §15.103 Exempted devices,and§15.105(c). Also available in
sections of CFR 47.
** The CE Mark Declaration of Conformity will contain important supplementary information and instructions for the user or
installer.

Conventions
The following conventions are used in this manual:
♦The ♦symbol indicates that the following text applies only to a specific
product, a specific operating system, or a specific software version.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash. When you see this symbol on the
device, refer to the Safety Information section in the user manual.
italic Italic text denotes variables, emphasis, a cross reference, or an introduction
to a key concept. This font also denotes text that is a placeholder for a word
or value that you must supply.
monospace Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames and extensions, and code excerpts.

©National Instruments Corporation vii IMAQ PCI/PXI-1407 User Manual
Contents
Chapter 1
Introduction
About Your 1407 Device ...............................................................................................1-1
Using PXI with CompactPCI.........................................................................................1-2
Software Programming Choices ....................................................................................1-2
NI-IMAQ Driver Software ..............................................................................1-4
IMAQ Vision...................................................................................................1-5
IMAQ Vision Builder......................................................................................1-5
Integration with DAQ......................................................................................1-6
Vision and Motion...........................................................................................1-6
Chapter 2
Installation
What You Need to Get Started ......................................................................................2-1
Optional Equipment.......................................................................................................2-2
How to Set up Your IMAQ System...............................................................................2-2
Safety Information .........................................................................................................2-4
Unpacking......................................................................................................................2-6
Installation .....................................................................................................................2-6
Chapter 3
Hardware Overview
Functional Overview......................................................................................................3-1
Video Buffer....................................................................................................3-2
Gain and Offset Circuitry ................................................................................3-2
8-Bit ADC and LUT........................................................................................3-2
CSYNC Mux ...................................................................................................3-3
Genlock SYNC Generator...............................................................................3-3
Pixel Aspect Ratio Circuitry............................................................................3-3
Acquisition and Region-of-Interest Control....................................................3-3
FIFO Buffer .....................................................................................................3-3
Scatter-Gather DMA Controllers ....................................................................3-3
PCI Interface....................................................................................................3-4
Trigger Control................................................................................................3-4

Contents
IMAQ PCI/PXI-1407 User Manual viii ni.com
Video Acquisition.......................................................................................................... 3-4
Start Conditions............................................................................................... 3-4
Acquisition Window Control .......................................................................... 3-5
Programming Video Parameters ..................................................................... 3-6
Acquisition Modes......................................................................................................... 3-7
Chapter 4
Signal Connections
BNC Connectors............................................................................................................ 4-1
I/O Connector Signal Connection Descriptions.............................................. 4-2
Appendix A
Specifications
Appendix B
Technical Support Resources
Glossary
Index
Figures
Figure 1-1. The Relationship between the Programming Environment,
NI-IMAQ, and Your Hardware............................................................. 1-3
Figure 1-2. NI-IMAQ Functions.............................................................................. 1-4
Figure 1-3. IMAQ Vision Builder and Application Development Tools ................ 1-6
Figure 2-1. How to Set up Your IMAQ System...................................................... 2-3
Figure 2-2. PCI-1407 Parts Locator Diagram.......................................................... 2-7
Figure 3-1. PCI/PXI-1407 Block Diagram.............................................................. 3-2
Figure 3-2. Positive Video Line............................................................................... 3-5
Figure 3-3. Video Field............................................................................................ 3-6
Figure 4-1. PCI/PXI-1407 BNC I/O Connectors..................................................... 4-1
Table
Table 4-1. I/O Connector Signals........................................................................... 4-2

©National Instruments Corporation 1-1 IMAQ PCI/PXI-1407 User Manual
1
Introduction
This chapter describes the IMAQ PCI/PXI-1407 devices and your software
programming choices.
About Your 1407 Device
The PCI-1407 and PXI-1407 are high-accuracy, monochrome IMAQ
devices for PCI, PXI, or CompactPCI chassis that support RS-170 and
CCIR video standards. The PCI/PXI-1407 acquires frames in real time and
transfers them directly to system memory. Revisions E and later of the
PCI-1407 and revisions C and later of the PXI-1407 support progressive
scan formats 25, 30, 50, and 60 frames per second and feature gain
calibration, high-impedance mode, and an 8-bit flash analog-to-digital
converter (ADC) that converts video signals into digital form.
Because the 1407 device is simple to configure, you can easily install the
device and begin your image acquisition. The PCI/PXI-1407 ships with
NI-IMAQ, the National Instruments complete image acquisition driver
software you use to directly control your device. Using NI-IMAQ, you can
quickly and easily start an application without having to program the device
at the register level.
Featuring low cost and high accuracy, the PCI/PXI-1407 is ideal for
both industrial and scientific environments. As a stand-alone device, the
PCI/PXI-1407 supports one video source and an external I/O line that
you can use as a trigger or digital I/O line. If you require more advanced
triggering or additional I/O lines (either digital or analog), you can use
the PCI/PXI-1407 and NI-IMAQ with the National Instruments data
acquisition (DAQ) product line.
See Appendix A, Specifications,for detailed PCI/PXI-1407 specifications.

Chapter 1 Introduction
IMAQ PCI/PXI-1407 User Manual 1-2 ni.com
Using PXI with CompactPCI
Using PXI-compatible products with standard CompactPCI products is an
important feature provided by the PXI Specification, Revision 1.0. If you
use a PXI-compatible plug-in device in a standard CompactPCI chassis,
you will be unable to use PXI-specific functions, but you can still use the
basic plug-in device functions.
The CompactPCI specification permits vendors to develop sub-buses that
coexist with the basic PCI interface on the CompactPCI bus. Compatible
operation is not guaranteed between CompactPCI devices with different
sub-buses or between CompactPCI devices with sub-buses and PXI.
The standard implementation for CompactPCI does not include these
sub-buses. Your PXI-1407 device will work in any standard CompactPCI
chassis adhering to the PICMG 2.0 R2.1 CompactPCI core specification.
Software Programming Choices
Using NI-IMAQ, the National Instruments image acquisition driver
software, you can program your IMAQ device to acquire and save images.
You can use NI-IMAQ with other National Instruments software for a
complete image acquisition and analysis solution, as shown in Figure 1-1.
NI-IMAQ works with LabVIEW and LabWindows/CVI, as well as with
conventional programming languages. National Instruments’
IMAQ Vision adds powerful image processing and analysis to these
programming environments. You can also use IMAQ Vision Builder to
quickly and easily prototype your IMAQ image analysis applications.

Chapter 1 Introduction
©National Instruments Corporation 1-3 IMAQ PCI/PXI-1407 User Manual
Figure 1-1. The Relationship between the Programming Environment,
NI-IMAQ, and Your Hardware
Vision Software
IMAQ Vision
Gauging and
Measurement
Pattern
Matching
Blob
Analysis
Analysis
Morphology
Display
and ROI
Color Matching
and Analysis
Filters
Application Software
Measurement Studio
(LabWindows/CVI, Visual C++, Visual Basic)
LabVIEW
Driver Software
NI-MotionNI-DAQNI-IMAQ
Hardware
ValueMotion/
FlexMotion
DAQIMAQ

Chapter 1 Introduction
IMAQ PCI/PXI-1407 User Manual 1-4 ni.com
NI-IMAQ Driver Software
The NI-IMAQ driver software is included with your IMAQ device.
NI-IMAQ has an extensive library of functions that you can call from your
application programming environment. These functions include routines
for video configuration, image acquisition (continuous and single-shot),
memory buffer allocation, trigger control, and board configuration, as
shown in Figure 1-2.
Figure 1-2. NI-IMAQ Functions
The NI-IMAQ driver software performs all of the functions required for
acquiring and saving images. However, the NI-IMAQ software does not
perform image analysis. For image analysis functionality, refer to the
IMAQ Vision section in this chapter.
For maximum flexibility and performance, NI-IMAQ has both high-level
and low-level functions. The functions to acquire images in single-shot or
continuous mode are examples of high-level functions. Configuring an
imaging sequence is an example of a low-level function, since it requires
advanced understanding of your IMAQ device and image acquisition.
NI-IMAQ internally resolves many of the complex issues between the
computer and your IMAQ device, such as programming interrupts and
DMA controllers.
NI-IMAQ is also the interface path between LabVIEW, LabWindows/CVI,
or a conventional programming environment and the IMAQ device. The
NI-IMAQ software kit includes a series of libraries for image acquisition
for LabVIEW and Measurement Studio, which contains libraries for
LabWindows/CVI, Visual C++, and Visual Basic. These libraries are
functionally equivalent to the NI-IMAQ software.
NI-IMAQ
Buffer ControlImage
Acquisition
Camera Control Lookup Table
Control
DAQ
Synchronization
Triggering
and Timing

Chapter 1 Introduction
©National Instruments Corporation 1-5 IMAQ PCI/PXI-1407 User Manual
IMAQ Vision
National Instruments’IMAQ Vision is an image acquisition, processing,
and analysis library of more than 200 functions for grayscale, color, and
binary image display; image processing; pattern matching; shape
matching; blob analysis; gauging; and measurement.
You can use IMAQ Vision functions directly or in combination for
unique image processing. With IMAQ Vision, you can acquire, display,
manipulate, and store images, as well as perform image analysis,
processing, and interpretation. Using IMAQ Vision, an imaging novice
or expert can perform graphical programming of the most basic or
complicated image applications without knowledge of any algorithm
implementations.
IMAQ Vision is available for LabVIEW and Measurement Studio, which
includes support for LabWindows/CVI, Visual C++, and Visual Basic.
IMAQ Vision Builder
National Instruments’IMAQ Vision Builder is an interactive prototyping
tool for machine vision and scientific imaging developers. With IMAQ
Vision Builder, you can prototype vision software quickly or test how
various vision image processing functions work.
As shown in Figure 1-3, IMAQ Vision Builder generates a Builder file,
which is a text description that contains a recipe of the machine vision and
image processing functions. This Builder file provides a guide you can use
for developing applications into any development environment, such as
LabWindows/CVI or Visual Basic, using the IMAQ Vision machine vision
and image processing libraries. Using the LabVIEW VI creation wizard,
you can create a LabVIEW VI that performs the prototype that you created
in IMAQ Vision Builder.

Chapter 1 Introduction
IMAQ PCI/PXI-1407 User Manual 1-6 ni.com
Figure 1-3. IMAQ Vision Builder and Application Development Tools
Integration with DAQ
Any platform that supports NI-IMAQ also supports NI-DAQ and a variety
of National Instruments’DAQ devices, allowing your IMAQ device and
NI-IMAQ development to integrate with National Instruments’DAQ
products.
Vision and Motion
With National Instruments’IMAQ hardware and IMAQ Vision pattern
matching software, you can quickly and accurately locate objects in
instances when objects vary in size, orientation, focus, and even when the
part is poorly illuminated. Use National Instruments’high-performance
stepper and servo motion control products with pattern matching software
in inspection and guidance applications, such as locating alignment
markers on semiconductor wafers, guiding robotic arms, inspecting the
quality of manufactured parts, and locating cells.
IMAQ
Vision Builder
Builder File
and Application
Software
IMAQ
Vision
Prototype
Vision Application
Development

©National Instruments Corporation 2-1 IMAQ PCI/PXI-1407 User Manual
2
Installation
This chapter lists items you need to get started acquiring images with
your IMAQ device. This chapter also describes optional equipment and
custom cables and explains how to unpack, configure, and install your
IMAQ device.
What You Need to Get Started
To set up your 1407 device, you will need the following items:
❑One of the following 1407 devices:
–PCI-1407
–PXI-1407
❑Getting Started with Your IMAQ System
❑NI-IMAQ Release Notes
❑IMAQ PCI/PXI-1407 User Manual
❑NI-IMAQ for Windows 2000/NT/Me/9xand online documentation
❑Optional software packages and documentation:
–IMAQ Vision for LabVIEW or Measurement Studio
(LabWindows/CVI, Visual C++, Visual Basic)
–IMAQ Vision Builder
–LabVIEW
–Measurement Studio (LabWindows/CVI, Tools for Visual Basic)
❑IMAQ BNC-1 shielded, 75 ΩBNC cable for VIDEO (included
with your PCI-1407)
❑Your Pentium-based PCI, PXI, or CompactPCI computer running
Windows 2000/NT/Me/9x
❑An analog video camera or other video source. See Appendix A,
Specifications,for supported formats.

Chapter 2 Installation
IMAQ PCI/PXI-1407 User Manual 2-2 ni.com
Note The IMAQ PCI/PXI-1407 relies on your computer’s PCI interface chipset for the
highest throughput to system memory. For the best results, your computer should have a
Pentium or faster processor and an Intel 430 or 440 series or compatible PCI interface
chipset.
Optional Equipment
National Instruments offers a variety of products for use with your
PCI/PXI-1407, including other National Instruments DAQ devices
for enhanced triggering, timing, or input/output.
For more specific information about these products, refer to the
National Instruments catalog or Web site, or call the office nearest you.
How to Set up Your IMAQ System
Use Figure 2-1 as a guide when installing the software and hardware,
configuring the hardware, and using NI-IMAQ in your application
programs.
To install your NI-IMAQ software and IMAQ hardware, follow the
instructions in the Getting Started with Your IMAQ System document.
If you plan to access the NI-IMAQ device drivers through LabVIEW,
read the NI-IMAQ Release Notes and the NI-IMAQ User Manual for
information on getting started.

Chapter 2 Installation
©National Instruments Corporation 2-3 IMAQ PCI/PXI-1407 User Manual
Figure 2-1. How to Set up Your IMAQ System
Measurement Studio
(LabWindows/CVI, Visual C++,
Borland C++)
LabVIEW What
application software
are you using?
Configure your hardware using
Measurement & Automation Explorer and
online help.
Read the
Getting Started with Your IMAQ System
document and the NI-IMAQ release notes to install
your NI-IMAQ software, IMAQ hardware,
and documentation.
Measurement
Studio
(Visual Basic) Read Chapter 1,
Introduction
to NI-IMAQ
, in the
NI-IMAQ User Manual .
Read the sections in
chapters 2 and 3 in the
NI-IMAQ
User Manual
that apply to the
function groups you
will use in your application.
Look at the self-documented
example source code on your
distribution CD for your
application language
and environment.
Use the
NI-IMAQ Function
Reference Manual
when you
need specific information about
individual NI-IMAQ functions.
If you are using IMAQ Vision for
LabWindows/CVI, read the
documentation for IMAQ Vision
for LabWindows/CVI.
Read:
• The section in chapter 4 in the
NI-IMAQ User Manual for
information on using LabVIEW
with your IMAQ hardware.
• NI-IMAQ VI online help
• Your IMAQ Vision for
LabVIEW documentation
if you are using IMAQ
Vision for LabVIEW
Read the NI-IMAQ User Manual
for information on using
NI-IMAQ in your
application environment.

Chapter 2 Installation
IMAQ PCI/PXI-1407 User Manual 2-4 ni.com
Safety Information
Caution The following paragraphs contain important safety information you must follow
when installing and operating the device.
Do not operate the device in a manner not specified in the documentation.
Misuse of the device may result in a hazard and may compromise the safety
protection built into the device. If the device is damaged, turn it off and do
not use it until service-trained personnel can check its safety. If necessary,
return the device to National Instruments for repair.
Keep away from live circuits. Do not remove equipment covers or shields
unless you are trained to do so. If signal wires are connected to the device,
hazardous voltages can exist even when the equipment is turned off. To
avoid a shock hazard, do not perform procedures involving cover or shield
removal unless you are qualified to do so. Disconnect all field power prior
to removing covers or shields.
If the device is rated for use with hazardous voltages (>30 Vrms,42.4V
pk,
or 60 Vdc), it may require a safety earth-ground connection wire. See the
device specifications for maximum voltage ratings.
Because of the danger of introducing additional hazards, do not install
unauthorized parts or modify the device. Use the device only with the
chassis, modules, accessories, and cables specified in the installation
instructions. All covers and filler panels must be installed while operating
the device.
Do not operate the device in an explosive atmosphere or where flammable
gases or fumes may be present. Operate the device only at or below the
pollution degree stated in the specifications. Pollution consists of any
foreign matter—solid, liquid, or gas—that may reduce dielectric strength
or surface resistivity. Pollution degrees are listed below.
•Pollution Degree 1—No pollution or only dry, nonconductive
pollution occurs. The pollution has no effect.
•Pollution Degree 2—Normally only nonconductive pollution occurs.
Occasionally, nonconductive pollution becomes conductive because of
condensation.
•Pollution Degree 3—Conductive pollution or dry, nonconductive
pollution occurs. Nonconductive pollution becomes conductive
because of condensation.

Chapter 2 Installation
©National Instruments Corporation 2-5 IMAQ PCI/PXI-1407 User Manual
Clean the device and accessories by brushing off light dust with a soft,
nonmetallic brush. Remove other contaminants with a stiff, nonmetallic
brush. The unit must be completely dry and free from contaminants before
returning it to service.
Yo u must insulate signal connections for the maximum voltage for which
the device is rated. Do not exceed the maximum ratings for the device.
Remove power from signal lines before connection to or disconnection
from the device.
Operate this device only at or below the installation category stated in the
specifications. Installation categories are listed below.
•Installation Category IV—for measurements performed at the source
of the low-voltage (<1000 V) installation. Examples include electricity
meters, measurements on primary overcurrent protection devices, and
ripple-control units.
•Installation Category III—for measurements performed in the building
installation. Examples include measurements on distribution boards,
circuit-breakers, wiring (including cables), bus bars, junction boxes,
switches, socket outlets in the fixed installation, equipment for
industrial use, and some other types of equipment, such as stationary
motors permanently connected to the fixed installation.
•Installation Category II—for measurements performed on circuits
directly connected to the low-voltage installation. Examples include
measurements on household appliances, portable tools, and other
similar equipment.
•Installation Category I—for measurements performed on circuits not
directly connected to mains1. Examples include measurements on
circuits not derived from mains, and specially-protected (internal)
mains-derived circuits
1Mains is defined as the electricity suppy system to which the equipment concerned is designed to be connected for either
powering the equipment or for measurement purposes.

Chapter 2 Installation
IMAQ PCI/PXI-1407 User Manual 2-6 ni.com
The following diagram shows a sample installation.
Unpacking
Your PCI/PXI-1407 is shipped in an antistatic package to prevent
electrostatic damage to the device. Electrostatic discharge can damage
several components on the device. To avoid such damage in handling the
device, take the following precautions:
•Ground yourself via a grounding strap or by holding a grounded object.
•Touch the antistatic package to a metal part of your computer chassis
before removing the device from the package.
•Remove the device from the package and inspect it for loose
components or any other signs of damage. Notify National Instruments
if the device appears damaged in any way. Do not install a damaged
device in your computer.
•Never touch the exposed pins of connectors.
Installation
Note You must install the NI-IMAQ driver software before installing the 1407 device. For
information on how to install NI-IMAQ, see the Getting Started with Your IMAQ System
document and the NI-IMAQ Release Notes.
For proper operation of the PCI-1407 revisions E and later and the
PXI-1407 revisions C and later, make sure one of the video devices is
terminated at 75 Ω, while any other video devices are set to high
impedance. Populate the W1 jumper to terminate the 1407 at 75 Ω.
