Nidec Answer Drives 1000 Series Operating instructions

AD1000
User and Maintenance Manual

NIDEC ASI S.p.A. – USER AND MAINTENANCE MANUAL
IMAD10002EN – Rev. 01 – 1st June 2016

NIDEC ASI S.p.A. – USER AND MAINTENANCE MANUAL
IMAD10002EN – Rev. 01 – 1st June 2016
AD1000
Answer Drives 1000
Voltage Source Drive
User and Maintenance Manual
Code: IMAD10002EN
Revision: Rev. 01
Date: 1st June 2016
Language: English
Translation of the Original
Instructions

NIDEC ASI S.p.A. – USER AND MAINTENANCE MANUAL
IMAD10002EN – Rev. 01 – 1st June 2016
DOCUMENT REVISIONS
Revision
Date
Notes
00 30th July 2015 First issue
01 1st June 2016 General update
For further information, go to: nidec-answerdrives.com

AD1000 SUMMARY
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IMAD10002EN I
SUMMARY
Manufacturer ............................................................................................................................................................................................................ 1
Manufacturer’s address ............................................................................................................................................................................................ 1
Warranty and limitation of liability ............................................................................................................................................................................. 1
Introductions and warnings for the purchaser .......................................................................................................................................................... 1
User and Maintenance Manual ................................................................................................................................................................................ 2
Safety rules in the manual ........................................................................................................................................................................................ 3
Symbols used ........................................................................................................................................................................................................... 3
Safety symbols .........................................................................................................................................................................................................
Terms and acronyms used ....................................................................................................................................................................................... 5
Warranty ................................................................................................................................................................................................................... 5
AD1000 management ............................................................................................................................................................................................... 6
1 INSTALLATION OVERVIEW AND DIAGRAM ................................................................................................................................................ 7
1.1 Overview................................................................................................................................................................................................... 7
1.2 Installation diagram .................................................................................................................................................................................. 8
2 TECHNICAL DATA .......................................................................................................................................................................................... 9
2.1 Notes on control methods ........................................................................................................................................................................ 9
2.2 Identification abbreviation....................................................................................................................................................................... 10
2.3 Plate ....................................................................................................................................................................................................... 11
2. Admissible environmental conditions ..................................................................................................................................................... 12
2.5 Electrical data ......................................................................................................................................................................................... 13
2.6 Switching frequencies ............................................................................................................................................................................ 1
2.7 General data ........................................................................................................................................................................................... 15
2.8 Losses and ventilation data .................................................................................................................................................................... 17
2.9 Overall dimensions and weights............................................................................................................................................................. 19
2.9.1 FRAME I - AD1A0P3-0P -0P6F.................................................................................................................................................. 20
2.9.2 FRAMES II-III-IIIX-IIIL - AD1A008-011-015-018-022-028F......................................................................................................... 21
2.9.3 FRAME IIIN - AD1A030-036F ..................................................................................................................................................... 22
2.9. FRAMES IVN-VN-VIN - AD1A0 5-053-066-086-108-125-150-166F .......................................................................................... 23
2.9.5 FRAME VII - AD1A210-260-290F ............................................................................................................................................... 2
2.9.6 FRAME VIII - AD1A350-370- 0- 80-520F ................................................................................................................................ 25
2.10 Terminal block and power diagrams ................................................................................................................................................. 27
2.10.1 FRAME I - AD1A0P3-0P -0P6F.................................................................................................................................................. 29
2.10.2 FRAME II - AD1A008F ................................................................................................................................................................ 30
2.10.3 FRAME III - AD1A011-015F ........................................................................................................................................................ 31
2.10. FRAME IIIX - AD1A018-022F ...................................................................................................................................................... 32
2.10.5 FRAME IIIL - AD1A028F ............................................................................................................................................................. 33
2.10.6 FRAME IIIN - AD1A030-036F ..................................................................................................................................................... 3
2.10.7 FRAME IVN - AD1A0 5-053F ..................................................................................................................................................... 35
2.10.8 FRAME IVN - AD1A066F ............................................................................................................................................................ 36
2.10.9 FRAME VN - AD1A086-108F ...................................................................................................................................................... 37
2.10.10 FRAME VIN - AD1A125-150-166F .............................................................................................................................................. 38
2.10.11 FRAME VII - AD1A210-260-290F ............................................................................................................................................... 39
2.10.12 FRAME VIII - AD1A350-370- 0- 80-520F ................................................................................................................................ 1
3 APPLICATION NOTES.................................................................................................................................................................................. 3
3.1 Principle of operation .............................................................................................................................................................................. 3
3.2 General formulas that describe drive operation .....................................................................................................................................
3.3 Drive selection ........................................................................................................................................................................................ 6
3. Application notes .................................................................................................................................................................................... 6
3.5 Applications with special motors ............................................................................................................................................................ 6
3.6 Motor selection ....................................................................................................................................................................................... 7
GENERAL INFORMATION ........................................................................................................................................................................... 9
.1 Technical standards applied................................................................................................................................................................... 9
.2 Standard of reference ............................................................................................................................................................................. 50
.2.1 CE marking .................................................................................................................................................................................. 50
.2.2 UL certification ............................................................................................................................................................................. 50
.3 General information ................................................................................................................................................................................ 51
.3.1 General safety requirements ....................................................................................................................................................... 51
.3.2 Requirements in the event of electrical installation ..................................................................................................................... 53
.3.3 Regulations in the event of maintenance .................................................................................................................................... 5
.3. General information - standards .................................................................................................................................................. 55
.3.5 Applied directives and declaration of incorporation ..................................................................................................................... 55
.3.6 Intended use and limits of use ..................................................................................................................................................... 56
.3.7 Danger zones .............................................................................................................................................................................. 56
. Environmental working conditions .......................................................................................................................................................... 58
. .1 Vibrations ..................................................................................................................................................................................... 58
.5 Environmental storage conditions .......................................................................................................................................................... 59

SUMMARY AD1000
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
II IMAD10002EN
.5.1 Storage site.................................................................................................................................................................................. 59
.6 Fixed protections .................................................................................................................................................................................... 60
.7 Personal protective equipment (PPE) .................................................................................................................................................... 61
.7.1 Residual risks .............................................................................................................................................................................. 62
.7.2 Impact and crushing .................................................................................................................................................................... 62
.7.3 Shearing ...................................................................................................................................................................................... 62
.7. Electrocution ................................................................................................................................................................................ 62
.7.5 Fire ............................................................................................................................................................................................... 63
.7.6 Explosive atmosphere ................................................................................................................................................................. 63
.7.7 Blinding ........................................................................................................................................................................................ 63
.7.8 Falling and/or expulsion of objects .............................................................................................................................................. 63
.7.9 Tripping ........................................................................................................................................................................................ 63
.7.10 Circuit faults ................................................................................................................................................................................. 6
.7.11 Lighting ........................................................................................................................................................................................ 6
.7.12 Noise ............................................................................................................................................................................................ 6
.7.13 Vibrations ..................................................................................................................................................................................... 6
.8 Additional hazard instructions ................................................................................................................................................................ 65
.9 Additional warning instructions ............................................................................................................................................................... 67
.10 Warning plates .................................................................................................................................................................................. 68
5 RECEPTION, STORAGE AND INSTALLATION ........................................................................................................................................... 69
5.1 Receiving, unloading, unpacking and inspecting the AD1000 ............................................................................................................... 69
5.2 Storage ................................................................................................................................................................................................... 70
5.3 Mechanical installation ........................................................................................................................................................................... 71
5.3.1 General precautions .......................................................................................................................................................................... 71
5.3.2 Frames VII and VIII installation ......................................................................................................................................................... 72
5.3.3 Free space near the drive ................................................................................................................................................................. 73
5.3. IPXX degree ...................................................................................................................................................................................... 76
5.3.5 Access to the terminal blocks ........................................................................................................................................................... 77
5. Electrical installation ............................................................................................................................................................................... 78
5. .1 Power cables, motor cables and power fuses .................................................................................................................................. 81
5. .2 Auxiliary power supplies ................................................................................................................................................................... 8
5.5 Reactors ................................................................................................................................................................................................. 85
5.5.1 Input reactors .................................................................................................................................................................................... 85
5.5.2 Output reactors ................................................................................................................................................................................. 86
5.5.3 RFI filters ........................................................................................................................................................................................... 87
5.6 Voltage protection .................................................................................................................................................................................. 89
5.7 Control section ....................................................................................................................................................................................... 90
5.7.1 Basis control board ........................................................................................................................................................................... 90
5.8 Expansion board .................................................................................................................................................................................... 97
5.8.1 Analogue input and digital input and RTC expansion board (GIABA) .............................................................................................. 97
5.8.2 Analogue input and digital output and RTC expansion board (GIABB) ............................................................................................ 99
5.8.3 Modbus TCP and Profibus expansion board (ETH-PROFI) ........................................................................................................... 102
5.9 Installation check list ............................................................................................................................................................................ 103
5.10 Installation instructions in compliance with the EMC directive ....................................................................................................... 10
5.10.1 EN61800-3 EMC product standard for variable speed electrical drives ......................................................................................... 10
5.10.2 RFI filters for radio frequency interferences .................................................................................................................................... 106
5.10.3 AD1000 compliance with IEC 61800-3 ........................................................................................................................................... 108
5.10. Motor cables ................................................................................................................................................................................... 109
6 OPTIONS AND ACCESSORIES ................................................................................................................................................................. 113
6.1 Introduction ........................................................................................................................................................................................... 113
6.2 Dynamic braking ................................................................................................................................................................................... 11
6.2.1 Braking unit ................................................................................................................................................................................ 11
6.2.2 Resistor installation and connection .......................................................................................................................................... 116
6.2.3 Choosing the resistor ................................................................................................................................................................. 117
6.3 Keypad ................................................................................................................................................................................................. 119
6.3.1 Installation on panel door .......................................................................................................................................................... 120
6. STO safety function (Safe Torque Off) ................................................................................................................................................. 121
6. .1 Safety function identification ...................................................................................................................................................... 121
6. .2 Field of application ..................................................................................................................................................................... 121
6. .3 Safety functions and corresponding level .................................................................................................................................. 122
6.5 Sinusoidal filter ..................................................................................................................................................................................... 12
6.6 Carriage ................................................................................................................................................................................................ 126
6.7 External power supply to the control .................................................................................................................................................... 127
7 PREVENTIVE MAINTENANCE ................................................................................................................................................................... 129
7.1 AD1000 – PM001 Drive ........................................................................................................................................................................ 130
7.2 AD1000 – PM002 Drive ........................................................................................................................................................................ 131
7.3 AD1000 – PM003 Drive ........................................................................................................................................................................ 132
7. AD1000 – PM00 Drive ........................................................................................................................................................................ 133

AD1000 SUMMARY
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IMAD10002EN III
7.5 AD1000 – PM005 Drive ........................................................................................................................................................................ 13
7.6 AD1000 – PM006 Drive ........................................................................................................................................................................ 135

SUMMARY AD1000
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IV IMAD10002EN
This page is intentionally left blank.

AD1000 INTRODUCTION
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IMAD10002EN 1
MANUFACTURER
ANSWER DRIVES 1000 was built at the Nidec ASI S.p.A. plant in Montebello (VI) Italy
MANUFACTURER’S ADDRESS
For any type of information regarding use, maintenance, installation, customer assistance at the customer’s premises, ordering spare parts,
etc. contact the closest Nidec customer assistance centre.
The manufacturer is always available to satisfy the purchaser/customer’s requests for any type of information or clarification on use,
maintenance, installation, etc.
It is important for the purchaser/customer to ask questions referencing this manual, always indicating the data found on the AD1000
identification plate.
Further information on the product can be found at nidec-answerdri es.com
WARRANTY AND LIMITATION OF LIABILITY
Refer to the order acceptance for the warranty period and conditions.
The manufacturer is not liable for damage caused during transport, reception, installation or commissioning.
The manufacturer is not liable for damages or consequences due to inappropriate, negligent or improper drive installation, incorrect drive
operating parameter setting, installation in a dusty location, with corrosive substances, with excessive vibrations or operating temperatures
exceeding the nominal data.
The customer must always purchase original spare parts, under penalty of oiding the warranty.
The manufacturer declines all liability due to incorrectly or improperly using the system, using non recommended spare parts and tampering
with the circuits and system components.
The manufacturer declines all liability for any damage caused by the AD1000 to people, animals or property in the following cases:
• Incorrect use or for different purposes to those for which it was built
• Incorrect incorporation/installation in machine, system or equipment for which it was intended.
• Failure to comply with the installation/incorporation rules stated in this Manual
• Use by unqualified or unauthorised personnel
• Defects in the electrical, hydraulic, pneumatic and water supplies (if any)
• Failure to comply with the technical specifications concerning the power supplies listed in chapter 2 of this Manual
• Missing or insufficient periodic maintenance
• Modifications or interventions on the equipment not agreed upon with or authorised by the Manufacturer
• Using non original spare parts or, in any case, different spare parts to those specified
• Total or partial non compliance with the instructions contained in this Manual.
Following the safety rules listed hereinafter is the responsibility of whoever plans and manages the tasks expected for the AD1000, who must
make sure that authorised personnel:
• are qualified to perform the requested activities
• know and carefully follow the rules in this Manual
• know and apply all general and specific safety rules applicable to the AD1000.
Failure to follow the safety rules may cause injuries to personnel and damage the AD1000.
INTRODUCTIONS AND WARNINGS FOR THE PURCHASER
This manual contains all the information regarding the Low Voltage variable frequency Drives of the AD1000 product family, with 0.75 450kW
power and 380/480V voltages.
The User and Maintenance Manual, along with the Declaration of Incorporation, is an integral part of the AD1000 and must always accompany
it; it is the integrator and user’s duty to keep these documents in order and in good condition throughout the entire lifespan of the AD1000.
The manual must be consulted before any of the operations listed below:
• Lifting, transport, positioning, moving, storage;
• Installation, first start up, commissioning, use
• Maintenance, cleaning, adjustments and calibrations;
• Repairs, replacements, consumables, technical support;
• Demolition.

INTRODUCTION AD1000
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
2 IMAD10002EN
HAZARD
Read this Manual very carefully before commissioning, using and performing any type of maintenance on the AD1000, in order to be able to
strictly follow the instructions herein. All users must read and understand the instructions in this Manual.
HAZARD
Answer Drives 1000 is designed to be incorporated into a complete equipment/system. Refer to the equipment/system manual to obtain all the
information relating to it and the safety rules on using the complete equipment/system. Using the AD1000 before having read and understood
the instructions in this manual and the manual of the equipment/system incorporating the AD1000 is strictly prohibited.
Customers can request training courses for their personnel from Nidec ASI, with the purpose of guaranteeing appropriate knowledge of the
AD1000 and of the rules for proper incorporation, integration, use and maintenance.
NOTE
This manual must stay with the system for its entire life cycle. Keep this manual and all the attached documents in place that can be accessed
by all personnel in charge of running and servicing the system. This manual is an essential part of the system and contains information to
ensure that all personnel that use it can work safely and ensure it functions efficiently for its entire life cycle.
You can ask the manufacturer for a copy of the User and Maintenance Manual in case of loss or destruction, specifying the exact model, serial
number and year of manufacture.
This manual reflects the state of the art at time of supply. The manufacturer reserves the right to modify the product without having to upgrade
the previous Equipment and Production manual.
This manual provides all information necessary to incorporate/install, commission, use and service the AD1000.
The manual is intended for personnel in charge of incorporating/installing, commissioning, using and servicing the AD1000.
USER AND MAINTENANCE MANUAL
Read this manual carefully in full before incorporating/installing, commissioning, using and servicing the AD1000.
The user and/or integrator of the AD1000 and of its User and Maintenance Manual must know and be able to use the basic principles of
electrical engineering and physics, the practice of electrical wiring, the symbols used in wiring diagrams, the safety rules and must be
experienced in using Low and Medium Voltage electrical equipment.
Even thoroughly reading this manual cannot, in any way, replace the fact that authorised personnel in charge of incorporating/installing, using
and servicing the AD1000 must have adequate experience and have been properly trained.
The user and/or integrator can contact the manufacturer at any time to request further information to what is contained in this manual or to
propose improvements.
This manual, along with the programming manual and the job order documents, makes up all the documents that the user or integrator must
know and apply.
In order to guarantee maximum operating reliability, the manufacturer has carefully chosen the materials and components used to manufacture
the AD1000, performing a series of rigorous checks and tests before shipment.
Proper AD1000 operation over time depends on correct use and on adequate maintenance, following the instructions listed in this manual and
in the documents provided.
The instructions contained in this manual are intended for expert and specialised technical personnel with adequate knowledge in the electrical,
electronic and mechanical fields.
For further details on the definition of experienced person and designated person, refer to the EN 50110 1 standard.
To properly integrate and use the AD1000 inside the final equipment/machine/system (not supplied by the manufacturer and not described in
this manual), it is assumed that the work environment is suitable and complies with the laws in force with regard to health and safety.
The information contained in this manual must only be used as a guide and does not constitute any sort of contract.

AD1000 INTRODUCTION
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IMAD10002EN 3
Manual updates are available at nidec answerdrives.com
All rights reserved.
Duplicating or transmitting this manual in any form or by any means, including photocopies, recordings or using storage or data retrieval
systems is prohibited without written consent from the editor.
SAFETY RULES IN THE MANUAL
The purpose of the rules, instructions and notes concerning safety that are described in the different chapters of this Manual is to define a
series of behaviours and obligations to respect in executing different activities, in order to work in safe conditions for personnel, the equipment
and the surrounding environment.
The written safety rules are intended for all authorised and trained personnel who will perform the various tasks and operations relating to the
AD1000 in the different phases of its use:
• transport;
• incorporation/installation;
• operation;
• use;
• maintenance;
• cleaning;
• disassembly and dismantling.
HAZARD
Even thoroughly reading this manual cannot, in any way, replace adequate experience and appropriate training of personnel in charge of tasks
on the AD1000.
ADDITIONAL INFORMATION
Only expressly qualified personnel, according to the EN 50110 1 standard, can perform tasks on the AD1000.
ADDITIONAL INFORMATION
Chapter 4 of this manual includes the instructions for personnel operating on the AD1000.
SYMBOLS USED
This Manual uses some symbols to attract the reader’s attention and to highlight some particularly important aspects of the instructions.
The following Table describes the meaning of the different symbols used.
HAZARD
Indicates a hazard with a risk of injury, even death, for the user. Pay the utmost attention to the parts of text highlighted by this
symbol.
WARNING
Indicates a warning of possible damage or deterioration of the AD1000, the equipment and other objects belonging to the user. Pay
attention to the parts of text highlighted by this symbol.
WARNING, NOTE
Indicates a warning or a note regarding key functions or useful information. Pay attention to the parts of text highlighted by this
symbol.

INTRODUCTION AD1000
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
4 IMAD10002EN
ADDITIONAL INFORMATION
Indicates the parts of text containing additional information. This information is not directly related to functions or procedures. It can
be references to additional documents, such as annexes or Manuals or technical documents, or to other sections in this Manual.
AVOID DAMAGING THE MATERIALS
Indicates a high risk of damaging a part, for example, by using an incorrect tool or carrying out an operation with the wrong
procedure.
SPECIAL TOOL
Indicates that a special tool or equipment is required.
VISUAL OBSERVATION
Indicates that the user must perform a visual observation: the user is requested to read a measured value, verify a warning, etc.
HEARING OBSERVATION
Indicates that the user must perform an auditory observation: the user is requested to listen to the operating noise.
SAFETY SYMBOLS
DANGER OF CRUSHING LIMBS
Indicates a hazard with the risk of injury for the integrator/user or personnel in charge. Pay the utmost attention to the signs and
areas where this symbol appears.
DANGER OF MOVING PARTS
Indicates a hazard in area(s) where there are moving parts.
The integrator/user or personnel in charge must pay the utmost attention to signs and areas where this symbol is present and
respect the safety distances.
DANGER OF DANGEROUS VOLTAGE
Indicates a hazard with the risk of even fatal injury for the integrator/user or personnel in charge. Pay the utmost attention to signs
and areas where said signs are present and do not access the areas so marked unless such area, or the components object of said
sign, have been previously de energised.
DO NOT REMOVE THE PROTECTIVE GUARDS
Indicates that the integrator/user or personnel in charge is prohibited from removing the protections installed on the partly completed
machine.
Running the partly completed machine without the supplied protective guards is strictly prohibited. Pay the utmost attention to the
signs and areas where this symbol appears.
DO NOT SMOKE OR USE OPEN FLAMES NEAR THE PARTLY COMPLETED MACHINE OR MOTORS, ELECTRICAL CONTROL
UNITS.
Indicates the integrator/user or personnel in charge is prohibited from smoking or using open flames near the partly completed
machine, motors or electrical control units and, in any case, in any area where this sign is present. All prohibitions in force in the
country where the partly completed machine is used and in house plant or establishment regulations set out by the employer remain
valid.
NO UNAUTHORISED ACCESS
Indicates the integrator/user or personnel in charge is prohibited from approaching and going past the area where this sign is
present. Pay the utmost attention to the signs and areas where this symbol appears.
NO MANOEUVRES FOR WORK IN PROGRESS
Indicates the integrator/user or personnel in charge is prohibited from activating/powering the partly completed machine for work in
progress on said machine or on its components.
Pay the utmost attention to the signs and areas where this symbol appears
DO NOT DIRECT JETS OF WATER TOWARDS ELECTRICAL EQUIPMENT.
Indicates that using or directing jets of water towards electrical equipment and, in any case, in all areas where this sign is present is
prohibited.
ENTANGLEMENT HAZARD
Indicates a hazard with the risk of injury for the integrator/user or personnel in charge. Using suitable clothing such as shoes,
overalls, gloves, etc. is mandatory.
Pay the utmost attention to the signs and areas where this symbol appears.

AD1000 INTRODUCTION
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IMAD10002EN 5
SHEARING, CUTTING HAZARD
Indicates a hazard with the risk of injury for the integrator/user or personnel in charge. Using suitable clothing such as shoes,
overalls, gloves, etc. is mandatory.
Pay the utmost attention to the signs and areas where this symbol appears.
DANGEROUS TEMPERATURE
Indicates a hazard with the risk of injury for the integrator/user or personnel in charge. Using suitable clothing such as shoes,
overalls, gloves, etc. is mandatory.
Pay the utmost attention to the signs and areas where this symbol appears
HIGH TEMPERATURE HAZARD
Indicates a hazard with the risk of injury for the integrator/user or personnel in charge. Using suitable clothing such as shoes,
overalls, gloves, etc. is mandatory.
Pay the utmost attention to the signs and areas where this symbol appears
DEVICES SENSITIVE TO ELECTROSTATIC DISCHARGES
Indicates a hazard with risk of damaging the equipment and/or people as a result of the presence of electrostatic discharges.
Using PPE (such as cuffs for grounding) when handling electrical/electronic boards or equipment where this symbol is present is
mandatory. However, always avoid touching the boards unless strictly necessary.
TERMS AND ACRONYMS USED
EXPOSED PERSON: (Annex I, 1.1.1 c Directive 2006/42/EC).
Anyone who is entirely or partially in a dangerous area.
INTENDED USE: (Annex I, 1.1.1 h Directive 2006/42/EC).
Using the partly completed machine in compliance with the information supplied in the instructions for use.
DANGEROUS AREA: (Annex I, 1.1.1 b Directive 2006/42/EC).
Any area inside and/or near the partly completed machine where the presence of an exposed person constitutes a health and safety risk for
that person.
RISK: (Annex I, 1.1.1 e Directive 2006/42/EC).
Combination of probability and seriousness of an injury or harm to health that could occur in a dangerous situation.
RESIDUAL HAZARDS: (Ref. EN 12100)
Hazard that has not been possible to eliminate or reduce through the design, against which the protections are not (totally or partially) efficient.
The Manual (Chap. 4) describes the residual risks and information, instructions and warnings/prescriptions to manage the Residual Risks that
must be borne by the user.
PROTECTION DEVICE: (Annex I, 1.1.1 g Directive 2006/42/EC). Device (different from a guard) that reduces the risk, on its own or associated
to a guard.
GUARD: (Annex I, 1.1.1 f Directive 2006/42/EC).
Element of the partly completed machine used specifically to guarantee protection through a physical barrier.
PARTLY COMPLETED MACHINE (Article 2 g Directive 2006/42/EC).
Assemblies that almost constitute a machine but that, on their own, are unable to guarantee a well determined application. A drive system is a
partly completed machine.
Partly completed machines are solely intended to be incorporated or assembled with other machines or other partly completed machines or
appliances to form a machine in accordance with Directive 2006/42/EC.
WARRANTY
The general conditions are stated in detail in the Contract of Sale.
However, in more general and valid terms, it is highlighted that:
• Nidec ASI S.p.A. is not liable for damages or malfunctions in case of lack of maintenance, unauthorised replacement of equipment parts with
non original spare parts and different use of the AD1000 to that set out in this User and Maintenance Manual.
• The warranty does not cover any and all liability for direct or indirect damages to people and property deriving from incorrect use,
installation/integration not complying with the instructions in this manual and in the Standards to which this manual refers and in the event of
incorrect AD1000 maintenance.

INTRODUCTION AD1000
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
6 IMAD10002EN
AD1000 MANAGEMENT
Only experienced and qualified personnel with adequate knowledge in the electrical, electronic and mechanical fields, who are authorised and
duly trained and are aware of all the risks regarding low and medium voltage equipment can manage the AD1000, which includes
incorporation/installation, operation, use, maintenance, cleaning, disassembly and dismantling.
Personnel in charge of incorporation/installation, operation and maintenance of the AD1000 must be aware that knowing and applying the
safety rules is an integral part of their tasks.
The definition of an experienced person and of a designated person for managing the electrical systems is as per the EN 50110 1 standard, to
which reference must be made for further details.
In accordance with the EN 50110 1 standard, unauthorised and unqualified personnel cannot access the area where the AD1000 is installed
Perform the following operations before starting to use the AD1000:
• Read this User and Maintenance Manual and the related documentation carefully
• Make sure the AD1000 is fully incorporated/installed in the equipment or system for which it is intended
• Make sure all of the necessary safety devices are present to ensure the equipment/system conforms with the instructions of the applicable
Directives
• Know which safety devices and protections have been provided and are available in the AD1000, with their position and function inside the
equipment.
Do not start the AD1000 unless the equipment/system/machinery into which it must be incorporated or installed has been declared in
compliance with the rules of Machinery Directive 2006/42/EC and of the Directives applicable to the equipment/system/machinery in its entirety.
WARNING
The various safety devices and systems are listed in chapter 4.
HAZARD
Disconnecting or partially removing the safety protections positioned to protect against dangerous parts is prohibited.
Removing any danger, caution, prohibition, notice signs is prohibited.
Opening the electrical panels while they are operating or immediately after power has been disconnected is strictly prohibited. Wait at least 10
minutes before opening the electrical panels after having disconnected power.
All of the safety and protection devices must be maintained fully efficient in order to ensure they work properly. They must be immediately
repaired or replaced by the after sales assistance centre in case of damage or malfunction.

AD1000 1 - INSTALLATION OVERVIEW AND DIAGRAM
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IMAD10002EN 7
1INSTALLATION OVERVIEW AND DIAGRAM
1.1 Overview
The AD1000 is a high performance drive that can reduce energy demand significantly by automatically adjusting pumps’ operating conditions to
meet system demands in a wide range of water, wastewater and irrigation pump applications. Developed by pump automation e perts at
Nidec, the versatile and reliable AD1000 is designed for optimum performance and reliability with minimal maintenance.
While virtually ‘plug and play’ for standard applications, the AD1000’s fle ible, modular design can also be easily configured to meet the most
challenging applications.
The AD1000 drive is designed with today’s pump system requirements in mind. The AD1000 drive’s highly responsive, built-in intelligence
enables it to continuously monitor operating conditions and adjust automatically to changes to ensure safe operation and optimal water flow
control.

1 - INSTALLATION OVERVIEW AND DIAGRAM AD1000
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
8 IMAD10002EN
1.2 Installation diagra
REMOVE THE PACKAGING AND CHECK THE SUPPLIED COMPONENTS. MAKE SURE
THE SUPPLY CORRESPONDS TO THE ORDER. Paragraph 5.1
PLAN THE INSTALLATION,
CHECK THE ENVIRONMENTAL CONDITIONS,
THE DATA ON THE PLATE,
THE COOLING DETAILS,
THE INPUT AND OUTPUT CABLES,
MOTOR COMPATIBILITY AND THE OTHER TECHNICAL DATA.
SELECT THE CABLES, FUSES AND OTHER POWER ELEMENTS
Paragraph 2.4
Paragraph 2.3
Paragraph 2.7, 2.8
Paragraph 5.4.1
Paragraph 2.5
Paragraph 3.4 and 3.5
IF THE DRIVE NEEDS TO BE CONNECTED TO AN IT NETWORK, CHECK THE RULES IN
PARAGRAPH 5.10 Paragraph 5.10
INSTALL THE AD1000 DRIVE IN A CABINET
Paragraph
5.3
-
Mechanical installation
CHECK CABLE INSTALLATION (POWER AND CONTROL)
Paragraph
5.4.1
-
Motor cables
CHECK GROUND
CONNECTIONS
Paragraph
5.10.4.4
-
Ground connection
CHECK MOTOR AND CORRESPONDING CABLE INSULATION
CHECK THE INSTALLATION
COMMISSION THE DRIVE

AD1000 2 - TECHNICAL DATA
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IMAD10002EN 9
2TECHNICAL DATA
2.1 Notes on control methods
V/f Scalar control
Scalar control with Sensorless Vector V/f performance
Voltage
-
Frequency regulation with constant or variable ratio
Voltage
-
Frequency regulation with constant or variable ratio, with
torque current control
Voltage boost
Good static and dynamic performance
Open loop regulation
Open loop regulation
Frequency regulation field 1 15
Speed regulation field 1 15
Frequency resolution 0.05 Hz (typical)
Speed resolution 0.05 Hz (typical)
Slip comp
ensation
Static accuracy of typical speed 0.4 x fslip %
Output current control
Output current control
Response on torque control 5 ms
The AD1000 drive can control the motor in two different ways
a. Scalar V/f for simple applications without speed feedback.
b. Sensorless Vector V/f for applications that require more dynamic performance and accuracy and without speed feedback.

2 - TECHNICAL DATA AD1000
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
10 IMAD10002EN
2.2 Identification abbreviation
AD1 A XXX F N F H N N N 00 NN
1, 2 ,3 4 5, 6, 7 8 9 10 11 12 13 14 15 16, 17 18, 19
Product series
Cooling
A = Air-cooled
Rated power (kVA)
(see electrical data table)
Input voltage F = 380-480Vac ±10%
Control board B = Basis board
Dynamic braking N = Not installed
B = Installed
Internal RFI filter N = Not installed
F = Installed
Keypad H = Installed
Communication expansion N = Not installed
P = Profibus and Modbus TCP (ETH-PROFI)
Expansion board N = Not installed
A = Analogue input, digital input and Real Time Clock (GIABA) expansion
B = Analogue input, digital output and Real Time Clock (GIABB) expansion
Safe Torque function Off N = Not installed
D = STO Single Channel board installed (up to frame 028F)
T = STO board installed (from 030F)
External power supply 00 = Not installed
10 = Control board external power supply (24Vdc)
Carriage (only for VIII frame) NN = Not installed
CN = Carriage installed
CR = Carriage with output reactor installed
NOTES
•Each different Identification Code configuration corresponds to a different SAP code.
•STO Function
-For frames up to 028F, the STO function requires an external contactor on the main AC line (letter D in field 15).
-For frames starting from 030F, the function is entirely carried out inside the drive (letter T in field 15).
-The STO option must be defined before ordering the inverter (factory installed and tested).
-When the STO function is installed, the DO3 relay programmable digital output is no longer available.
•Dynamic Braking
-The braking switch is always integrated from frame 0P3F to frame 036F;
-From frame 045F to frame 290F the internal braking switch is optional;
-From frame 350F to frame 520F the internal braking switch is not available.
•Internal RFI filter
-The RFI filter is optional for drives up to frame 028F;
-The RFI filter is standard for drives from frame 030F to 520F;

AD1000 2 - TECHNICAL DATA
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
IMAD10002EN 11
2.3 Plate
The following figure shows an example of a plate that is on all AD1000 family drives, which shows the nominal drive data.
AD1000 AC POWER SUPPLY
1
2-3
4-5-6
7-8
9
-
10
-
11
12-13
14
15-16-17
18
-
19
20
21-22
23
24
25
Figure 2.1 Plate
1.
Drive type
2. Serial number
3. Production/testing date
4. Input voltage
5. Input frequency
6. Number of input phases
7. Input current
8. Maximum symmetrical short circuit current
9. Auxiliary voltage
10. Auxiliary voltage frequency
11. Number of auxiliary voltage phases
12. Auxiliary voltage rated current
13. Notes
14.
Output power [kVA]
15. Output voltage
16. Output frequency
17. Number of output phases
18. kW motor power (Cl.1)
19. HP motor power (CI.1)
20. Output current (Cl.1)
21. kW motor power (Cl.2)
22. HP motor power (CI.2)
23. Output current (Cl.2)
24. Operating temperature
25. SAP code

2 - TECHNICAL DATA AD1000
NIDEC ASI S.P.A. – AD1000 USER AND MAINTENANCE MANUAL
12 IMAD10002EN
2.4 Admissible environmental conditions
Table 2.4.1 Admissible environmental conditions
Operation Operate in a stable environment that is protected from the elements according to IEC
721-3-3.
Environmental
temperature
From 0 to 40 °C (from 32 to 104 °F) – If the ambient temperature exceeds + 40°C (104 °F), reduce tje rated
output current by 1% for every °C (1.8°F). (max. 55°C – max. 131°F )
Relative humidity From 5 to 95% without condensate
Contamination levels Painted boards – Chemical gases IEC 721-3-3, Class 3C2
Solid parts IEC 721-3-3, Class 3S2
Altitude Up to 1000 m (3280 ft) above sea level. Over i 1000 m (3280 ft) above sea level, the rated output current must
be reduced by 1% for every additional 100 m (328 ft). Maximum height 3000 m (9840 ft)
Vibrations Max. 0.3 mm (0.012 in) (from 2 to 9 Hz), max. 1 m/s
2
(3.28 ft/s
2
) (from 9 to 200 Hz) sinusoidal (Class 3M1)
Environmental notes •Avoid exposure to corrosive gases - including hydrogen sulphide
•Avoid exposure to strong magnetic fields, nuclear radiation and high levels of RFI
from communication
transmitters.
Storage Store in protective packaging in a protected location according to IEC 721-3-1.
Environmental
temperature
From -25°C to +70°C (From -13°F to +158°F)
Relative humidity Max. 95% at 40°C (Max. 95% at 104°F)
Altitude Up to 1000 m (3300 ft)
Atmospheric pressure From 70 to 106 kPa
Vibrations Max 1.5 mm (0.06 in) (from 2 to 9 Hz), max. 5 m/s
2
(16.4 ft/s
2
) (from 9 to 200 Hz) sinusoidal (Class 1M3)
Shock Max 100 m/s
2
(330 ft/s
2
), 11 ms (36 fts) (Class 1M3)
Contamination levels Painted boards - Chemical gases IEC 721-3-3, class 1C2
Solid parts IEC 721-3-3, class 1S3
Environmental notes •Avoid exposure to corrosive gases - including hydrogen sulphide.
•Avoid exposure to strong magnetic fields, nuclear radiation and
high levels of RFI from communication
transmitters
Transport Remove the drive in its protective packaging according to IEC 721-3-2.
Environmental
temperature
From -25 to +70°C (From -13°F to +158°F)
Relative humidity Max. 95% at 40 °C (Max. 95% at 104 °F)
Atmospheric pressure From 60 to 106 kPa
Vibrations Max 3.5 mm (0.14 in) (from 2 to 9 Hz), max. 10m/s
2
(32.85 ft/s
2
) (from 9 to 200 Hz) sinusoidal (Class 2M1)
Shock Max 100 m/s
2
(max 330 ft/s
2
), 11 ms (36 fts )
Free fall 250 mm (0.82 ft) (weight less than 100 kg / 220 lb)
100 mm (0.33 ft) (weight more than 100 kg / 220 lb)
