NIVELCO EchoTREK SG-300 series Assembly instructions

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/1
Manufacturer
H-1043 Budapest, Dugonics u. 11.
Phone: [phone] Fax: [phone]
NIVELCO Process Control Co.
E-mail: [email protected] www.nivelco.com
EchoTREK
SE/SG-300 series two-wire
compact ultrasonic level transmitters

60/2 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
BASIC CONCEPTS AND ELEMENTS OF THE ULTRASONIC MEASUREMENT
Programmed
measurement
range of the
application
P06
Far end blocking
DIST= distance (measured)
Close end blocking (programmed value
LEV= level calculated; H - DIST)
VOL= volume (calculated from DIST LEV)
→
Max measuring distance of the application (H)
Max measuring distance of the device DEFAULT value of P04
XM
Max measurement range of the device
Min measuring distance (dead band) DEFAULT value of P05
programmed value of P04
Xm

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/3
CONTENTS
1. INTRODUCTION.....................................................................................5
2. ORDER CODES......................................................................................6
3. TECHNICAL DATA.................................................................................7
3.1 ACCESSORIES ...................................................................................11
3.2 SAFETY REGULATIONS FOR THE EX APPROVED UNITS............................11
3.3 MAINTENANCE AND REPAIR.................................................................11
4. INSTALLATION ....................................................................................12
4.1 LIQUID LEVEL MEASUREMENT.............................................................12
4.2 OPEN CHANNEL FLOW MEASUREMENT................................................14
4.3 INSTALLATION AND ELECTRICAL CONNECTION ......................................14
4.4 LOOP CURRENT CHECKING ................................................................14
5. PROGRAMMING ..................................................................................15
5.1 PROGRAMMING WITHOUT DISPLAY MODULE.........................................16
5.2 PROGRAMMING WITH THE SAP-200 DISPLAY MODULE .........................19
5.2.1 SAP-200 Display Module ......................................................20
5.2.2 Steps of the SAP-200 Display Module..................................20
5.2.3 Indications of the SAP-200 and LED Status .........................21
5.2.4 QUICKSET............................................................................22
5.2.5 Full Parameter Access..........................................................24
6. PARAMETERS – DESCRIPTIONS AND PROGRAMMING................ 26
6.1 MEASUREMENT CONFIGURATION ........................................................ 26
6.2 CURRENT OUTPUT ............................................................................ 32
6.3 RELAY OUTPUT................................................................................. 33
6.4 DIGITAL OUTPUT................................................................................ 33
6.5 MEASUREMENT OPTIMISATION............................................................ 34
6.6 DATA LOGGER................................................................................... 38
6.6.1 Reading data out from the logger .........................................41
6.7 VOLUME MEASUREMENT .................................................................... 42
6.8 VOLUME FLOW MEASURING ............................................................... 43
6.9 32-POINT LINEARISATION................................................................... 49
6.10 INFORMATIONAL PARAMETERS (READ OUT PARAMETERS).................. 50
6.11 ADDITIONAL PARAMETERS OF THE FLOW METERING........................... 52
6.12 SUPPLEMENTARY PARAMETER OF THE LOGGER .................................. 52
6.13 TEST PARAMETERS ......................................................................... 53
6.14 SIMULATION .................................................................................... 54
6.15 ACCESS LOCK................................................................................. 54
7. ERROR CODES ................................................................................... 55
8. PARAMETER TABLE .......................................................................... 56
9. SOUND VELOCITIES IN DIFFERENT GASES ................................... 58

60/4 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/5
Thank you for choosing a NIVELCO instrument.
We are sure that you will be satisfied throughout its use.
1. INTRODUCTION
A Total beam angle of 5°-7°at –3 dB as is featured by most of Nivelco’s
SenSonic transducers ensuring a reliable measurement in narrow silos with
uneven side walls as well as in process tanks with various protruding objects.
Furthermore, as a result of the narrow beam angle - the emitted ultrasonic
signals have an outstanding focusing - deep penetration through gases,
vapour and foam is ensured.
rr
D
XD
1 m 0,21 m
2 m 0,3 m
5 m 0,56 m
10 m 1 m
15m 1,45 m
X
Diameters
corresponding to
5° beam angle.
Application
The EchoTREK compact ultrasonic level transmitters from NIVELCO are an
excellent tool for the level measurement of liquids.
Level measurement technology based on the non-contacting ultrasonic
principle is especially suited for applications where, for any reason, no
physical contact can be established to the surface of the material to be
measured.
Such reasons may include corrosive attack by the process medium against
the measuring device material (acids), possible contamination (sewage) or
particles of the process medium adhering to the measuring device
(adhesive materials).
Principle of Operation
The ultrasonic level metering technology is based on the principle of
measuring the time required for the ultrasound pulses to make a round trip
from the sensor to the level to be measured and back. The sensor emits an
ultrasonic pulse train and receives the echoes reflected. The intelligent
electronic device processes the received signal by selecting the echo
reflected by the surface and calculates from the time of flight the distance
between the sensor and the surface which constitutes the basis of all output
signals of the EchoTREK
Dead Band is a feature common to all ultrasonic level meters.
It is specified as “Minimum measuring distance” in the Technical Data Table.
Measurement within this range can not be interpreted.
Minimum measuring distance (Xm) is determined by the design of the unit within which the measurement is not possible (Dead Zone). This distance can be
extended by programming in order to avoid disturbing effects of possible disturbing echoes coming from fixed objects. (Close-end Blocking).
Maximum measuring distance (XM) is the greatest distance (determined by the design of the unit) which can be measured by the unit under ideal conditions.
The maximum measuring distance of the actual application (H) must not be greater than XM.

60/6 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
2. ORDER CODES
Note: not all combinations are possible
EchoTREK S - 3 -
TYPE CODE TRANSDUCER /
HOUSING CODE MEASURING RANGE * CODE MOUNTING CODE OUTPUT CODE
Transmitter E PP/Aluminium A 12; 15 m 4 BSP thread 0 4 … 20 mA / LOGGER 1
PP + foam / Aluminum D 7; 10 m 6 NPT thread N 4 … 20 mA 2
Transmitter with
local indicator G PVDF/Aluminium B 6; 8 m 7 DN 80 PN 16 / PP 2 4 … 20 mA / HART / LOGGER 3
PTFE/Aluminium T 5; 6 m 8 DN 100 PN 16 / PP 3 4 … 20 mA / HART 4
SS316Ti/Aluminium S 3; 4 m 9 DN 125 PN 16 / PP 4 4 … 20 mA / LOGGER / Ex 5
PP/Plastic P DN 150 PN 16 / PP 5 4 … 20 mA Ex 6
PP + foam / Plastic G DN 200 PN 16 / PP 6 4 … 20 mA / HART / LOGGER / Ex 7
PVDF/ Plastic V 200 mm bracket K 4 … 20 mA / HART / Ex 8
PTFE/ Plastic F 500 mm bracket L 4 … 20 mA / LOGGER / Relay L
SS316Ti/ Plastic M 700 mm bracket M 4 … 20 mA / Relay R
4 … 20 mA / HART / LOGGER / Relay A
4 … 20 mA / HART / Relay H
The order code of an Ex version should end in “Ex”
* Measuring range depends on the material of the transducer

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/7
3. TECHNICAL DATA
GENERAL DATA
Transducer materials Polypropylene (PP) Kynar (PVDF) Teflon (PTFE) Stainless Steel (DIN 1.4571, AISI SS316Ti)
Housing material Plastic: Glass fibre plastic PBT (DuPont®) Aluminium: Powder paint coated
Process temperature PP,PVDF and PTFE transducers: –30 °C ... +90 °C
Stainless Steel transducer : -30°… +100°C (120°C for max. 2 hours)
Ambient temperature Plastic housing: –25°C ... +70°C Aluminium housing –30 °C ... +70 °C with display –25°C ... +70°C
Pressure (1) (Absolute) 0.5 ... 3 bar (0.05 ... 0.3 MPa) Stainless steel versions 0.9 ... 1.1 bar (0.09 ... 0.11 MPa)
Seals PP transducer: EPDM
All other transducer versions: FPM (Viton)
Ingress protection Sensor: IP68
Housing: IP67 (NEMA 6)
Power supply 12(3)…36 V DC, / 48 mW … 720 mW, galvanic isolation; protection against surge transients
Accuracy (2) ±(0.2% of the measured distance plus 0.05% of the range)
Resolution Depending on the measured distance < 2 m: 1 mm, 2...5 m: 2 mm, 5...10 m: 5 mm, > 10 m: 10 mm
Analogue: 4 … 20 mA (3.9 … 20.5 mA) , Rmax = (Ut- 12V) / 0.02 isolated protection against surge transients
SPDT relay 30 V / 1 A DC; 48 V / 0.5 A AC
Loop power test connectors: 2 pins for mV meter range 200 mV, 0.5%
Display: 6 digits, icons and bargraph, (on SAP-200 display module only)
Outputs
Serial communication: HART interface (terminal resistor 250 Ohm)
Electrical connection 2 x M20x1.5 Metal, Cable ∅7 … 13 mm or M20x1.5 Plastic, Cable ∅6 … 12 mm and
2 x ½” NPT for cable gland; Wire cross section: 0.5 ... 1.5 mm2
Electrical protection Protection Class III
ADDITIONAL DATA FOR EX APPROVED MODELS
Ex marking II 1 G EEx ia IIB T6 IP67
Intrinsical safety Ci≤ 15 nF, Li≤200 µH, Ui≤30 V, Ii≤140 mA, Pi≤1 W Use with EEx ia certified power supply only
Ex approved power supply U0< 30 V, I0< 140 mA, P0< 1 W, Range of power supply 12 V … 30 V, Rsmax = (Us– 12V) / 0,02A
Medium temperature For PP transducer –20 °C ... +70 °C, for PVDF transducer –20 °C ... +80 °C, for St.St transducer –30 ° … +100 °C
Ambient temperature Aluminium housing –30 °C ... +70 °C with display –25 °C… + 60 °C Plastic housing –20 °C ... +70 °C with display –20 °C… + 60 °C
(1) For pressures below 1 bar representative of Nivelco should be consulted.
(2) Under optimal circumstances of reflection and stabilised transducer temperature.
(3) Only partial operation is provided. Reliable operation without any restrictions is guaranteed at >13.4V terminal voltage.

60/8 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
SPECIAL DATA OF THE TWO-WIRE EchoTREK WITH PP AND PVDF TRANSDUCERS (ALSO APPLY FOR EX MODELS)
TYPE SE-39-
SG-39-
SE-38-
SG-38-
SE-37-
SG-37-
SE-36-
SG-36-
SE-34-
SG-34-
Transducer material PP or PVDF PP or PVDF PP or PVDF PP or PVDF PP or PVDF
Maximum measuring
distance * [m / ft] 4 / 13 6 / 20 8 / 26 10 / 33 15 / 49
Min. measuring distance*
(Dead band) [m / ft] 0.2 / 0.65 0.25 / 0.82 0.35 / 1.2 0.35 / 1.2 0.45 / 1.5
Total beam angle (-3 dB) 6° 5° 7° 5° 5°
Measurement frequency 80 kHz 80 kHz 50 kHz 60 kHz 40 kHz
Process connection 1 ½” thread 2” thread 2” thread Flange Flange
* (from the transducer face)
SPECIAL DATA OF THE TWO-WIRE EchoTREK PTFE AND STAINLESS STEEL TRANSDUCERS (ALSO APPLY FOR EX MODELS)
TYPE SE-39-
SG-39-
SE-38-
SG-38-
SE-37-
SB-37-
SE-36-
SG-36-
SE-34-
SG-34-
Transducer material PTFE PTFE PTFE St. St. St. St.
Maximum measuring
distance * [m/ft] 3 / 10 5 / 16 6 / 20 7 / 23 12 / 39
Min. measuring distance*
(Dead band) [m/ft] 0.25 / 0.65 0.25 / 0.82 0.35 / 1.2 0.4 / 1.3 0.55 / 1.8
Total beam angle (-3 dB) 6° 5° 7° 5° 5°
Measurement frequency 80 kHz 80 kHz 50 kHz 60 kHz 40 kHz
Process connection 1 ½” thread 2” thread 2” thread Flange Flange
* (from transducer face)
SAP-200 DISPLAY MODULE
Field indication 6 digits Custom LCD, icons and bargraph
Ambient temperature -25°C … +70°C
Housing material PBT fibre-glass reinforced plastic, (DuPont®)

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/9
Dimensions of the two-wire EchoTREK
EchoTREK S-39-/ PP, PVDF, PTFE EchoTREK S-38-/ PP, PVDF, PTFE EchoTREK S-37-/ PP, PVDF, PTFE
~89
1 1/2" BSP
or NPT
BSP length 15
NPT length 22
2 x M20x1.5
2 x 1/2" NPT
~60
97.5
2 x M20x1.5
2 x 1/2" NPT
~60
~89
97.5
2" BSP
or NPT
BSP length 15
NPT length 22
2 x M20x1.5
2 x 1/2" NPT
~89
97.5
2" BSP
or NPT
BSP length 15
NPT length 22
~80
EchoTREK S-36-/ PP, PVDF EchoTREK S-34-/ PP, PVDF
74
JIS 10K 80A
DIN DN80 PN16
ANSI 3" 150 psi
~89
2 x 1/2" NPT
2 x M20x1,5
97,5
19~46
∅ 122
JIS 10K 125A
ANSI 5" 150 psi
DIN DN125 PN16
*
~89
2 x M20x1.5
2 x 1/2" NPT
97.5
19
~43
* Min required flange size

60/10 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
EchoTREK SS-36-/ SS316 Ti
ANSI 3" 150 psi
DIN DN80 PN16
20
.
5
~89
2 x M20x1.5
2x NPT1/2"
97
.
5
~147
EchoTREK SS-34-/ SS316 Ti
~89
2 x M20x1.5
2x NPT1/2"
97
.
5
~157
ANSI 5" 150 psi
DIN DN125 PN16
25
Cover
Display
unit
Electronics
Housing
Transducer

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/11
3.1 ACCESSORIES
−Certificate of Warranty — 2 x M20x1.5 cable gland
−Installation and Programming Manual — SAP-200 Display Module (option)
−Declaration of Conformity — CD-ROM (EViewLight, DataScope softwares) (option)
3.2 SAFETY REGULATIONS FOR THE EX APPROVED UNITS
The level transmitter must be operated in intrinsically safe circuit only. (see values in Additional data for Ex approved models under Point 3)
For temperatures see values in Additional data for Ex approved models under Point 3
Transducer head of the models SE/SGA, SE/SGB and SE/SGT are made of plastic tending to charge up electrostatically, thus:
•The velocity of the filling and discharging process must be chosen according to the medium.
•During filling the material causing the hazard must be hindered from forming a mist
•It is not permitted to clean the plastic cover in explosion hazardous area
The apparatus is not suitable for flame-proof enclosure towards the external area.
The metal enclosure of the unit must be connected to the EP circuit
3.3 MAINTENANCE AND REPAIR
The EchoTREK SE/SG series do not require maintenance on a regular basis. In some very rare instances, however, the transducer may need a cleaning from
deposited material. This must be carried out gently, without scratching or pressing the surface of the transducer.
Repairs during or after the warranty period are carried out exclusively at the Manufacturers. The equipment sent back for repairs should be cleaned or
neutralised (disinfected) by the User.
3.3.1 SOFTWARE UPGRADE
Based on the observations & needs of our customers NIVELCO constantly improves and revises the operating software of the device. The software can be
upgraded with the help of the IrDA communication port of the SAP-200 or an ELink (USB) communication adapter plugged into the SAP-200 slot. For more
information about software updates please contact Nivelco.

60/12 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
4. INSTALLATION
4.1 LIQUID LEVEL MEASUREMENT
POSITION
The optimal position of the EchoTREK is on the radius
r = (0.3 … 0.5) R of the (cylindrical) tank / silo.
(Take also sonic cone on page 1 into consideration.)
SENSOR ALIGNMENT
The sensor face has to be parallel to
the surface of the liquid within ±2-3°.
TEMPERATURE
Make sure that the transmitter will
be protected against overheating by
direct sunshine.
Sunshade

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/13
STAND-OFF PIPE
The structure of the stand off pipe should be rigid; the inner rim where the ultrasonic beam
leaves the pipe should be rounded.
Dmin
LS - 39 S - 38 S - 37 
150 50 60 60
200 50 60 75
250 65 65 90
300 80 75 105
350 95 85 120
OBSTACLES
Make sure that no in-flow path or objects
(e.g. cooling pipes, ladders, bracing
members, thermometers, etc.) or no tank
wall of the ragged surface protrude into
the sensing cone of the ultrasonic beam.
One fix object in the tank / silo that
disturb the measurement can be blocked
out by the appropriate programming of
the EchoTREK
L
Ø D
r
Dmin
LS - 36 S - 34 
90 80 *
200 80 *
350 85 *
500 90 *
FOAM
Foaming of the liquid surface may render ultrasonic level
metering impossible. If possible, a location should be found,
where foaming is the least (device should be located as far as
possible from liquid inflow) or a stilling pipe or well should be
used.
r
Ø D
L
* For values contact your distributor
Dmin
L
S S – 36 S S – 34 
320 80 -
440 - 125
WIND
Intensive air (gas) movements in the vicinity of the ultrasonic
cone is to be avoided. A strong draft of wind may "blow away"
the ultrasound.
Devices with lower measuring frequency (40, 20 kHz) are
recommended.
L
Ø D
r
FUMES / VAPOURS
For closed tanks containing chemicals or other liquids, which creats fume/gases above the liquid surface especially for outdoor tanks exposed to the sun, a
strong reduction of the nominal measuring range of the ultrasonic device is to be considered during device selection.
Devices with lower measuring frequency (40, 20 kHz) are recommended in these cases units.

60/14 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
4.2 OPEN CHANNEL FLOW MEASUREMENT
•For ultimate accuracy, install the sensor as close as possible above the expected maximum water level (see minimum measuring range).
•Install the device in a place defined by the characteristics of the metering channel along the longitudinal axis of the flume or weir. In case of Parshall
flumes supplied by NIVELCO the location of the sensor is marked.
•In some cases foam may develop on the surface. Make sure that the surface, opposite to the sensor remain free of foam for proper sound reflection.
•From the point of view of measurement accuracy the length of the channel sections preceding and following the measuring flume and their method of
joining to the measuring channel section are of critical importance.
•Despite of the most careful installation, the accuracy of flow metering will be lower than that of specified for the distance measurement. It will be
determined by the features of the flume or weir applied.
4.3 INSTALLATION AND ELECTRICAL CONNECTION
Installation of the (BSP or NPT) threaded models
•Screw the unit in to its place. Use open wrench for
tightening; max torque is 20Nm
•After tightening the enclosure can be rotated to the proper
position. (Safety bolt prevents rotation more than 350°)
•The unit may be damaged by electrostatic discharge (EDS)
via its terminal, thus apply the precautions commonly used
to avoid electrostatic discharge e.g. by touching a properly
grounded point before removing the cover of the enclosure.
2
1
•Ensure that the power supply is turned off at the source.
•With removal of the cover of the housing and taking out the display module (if any), the
screw terminals can be accessed. Suggested cable core cross section:
0.5 ... 1.5 mm2. Arrange grounding by the inner or outer grounding screw first.
•Switch on the unit and make necessary programming.
•After programming ensure proper sealing and closing of the cover.
Display unit
connector
Connect or for
meas. of loop current
VA L ID
4...20 mA loop current
and suppl.voltage (HART)
GND
1/2” NPT 1/2” NPT
M20x1,5
M20x1,5
234 56
C2
54 6
C1
(Only normal
version)
1
RELAY
I
2 31 2
U
4.4 LOOP CURRENT CHECKING
After removing the cover (and the Display Module if there is any) the actual loop current can be measured with an accuracy of 0.5% by connecting an voltmeter
(in the range of 200 mV) to the points indicated on the drawing above

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/15
5. PROGRAMMING
The EchoTrek can be programmed by the following two ways:
•Programming without Display Module see 5.1.
Assignment of the levels to the 4 and 20 mA current output, error indication by the analogue signal and damping can be set.
•With the SAP-200 Display Module, see 5.2.
All features of the unit can be set, such as measurement configuration and optimisation, 32-point linearisation, dimensions
for 11 tanks with different shape and for 21 different open channels (flume, weir, etc).
Devices with the type number EchoTREK SG... are already equipped with the SAP-200.
The EchoTREK is fully operational without the SAP-200. The SAP-200 is only needed for programming and/or displaying measurement values.
The unit will measure during programming in accordance with the previous parameters. The new, modified parameters will only be effective after
returning to the Measurement Mode
If the transmitter is left in Programming Mode by mistake, it will automatically return to Measurement Mode after 30 minutes and will operate with the parameters
entered during the last completed programming.
The EchoTREK will be delivered with the following Factory Default:
⇒Current output, display and bargraph: LEVEL
⇒Current output and bargraph proportional to the level
⇒4 mA: assigned to the minimum level 0%
⇒20 mA: assigned to the maximum level 100%
⇒Error indication by the current output: hold last value
⇒Damping: 60 sec

60/16 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
5.1 PROGRAMMING WITHOUT DISPLAY MODULE
Programming is only possible if the EchoTREK is in Level Measuring
Mode and receives valid echo i.e. “VALID” LED is lit!
The following can be programmed without display module
•Assignment of the 4 mA to a required e.g. min. level / max. distance
•Assignment of the 20 mA to a required e.g. max. level / min. distance
•Error indication by the current output (Hold, 3.6 mA or 22 mA)
•Damping (10, 30 or 60 sec)
•Reset to the factory default
Note: Current output can also be assigned in inverted mode:
4 mA = 100% (Full), 20 mA = 0% (Empty)
RELAY
Procedure of programming: press button in the relevant sequence and check the state of the LED-s. Symbols for the states of the LED-s:
= LED is off, = LED is blinking, = LED is on, = LEDs are blinking alternatively = Dont care
Minimum level, (0%, empty tank) assignment to 4 mA
Action Led state following the action
1) Check for a valid ECHO = Valid ECHO, transmitter programmable
2) Press NEXT button steadily = EchoTREK in programming mode
3) Press UP button steadily = 4 mA assigned to the distance (see picture)
4) Release buttons = Programming completed
B
B
Use level in tank or a fix target e.g. the wall

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/17
Maximum level (100%, full tank) assignment to 20 mA
Action Led state following the action
1) Check for a valid ECHO = Valid ECHO, transmitter programmable
2) Press NEXT button steadily = EchoTREK in programming mode
3) Press DOWN button steadily = 20 mA as signed to the distance
(see picture)
4) Release buttons = Programming completed
B
B
Use level in tank or a fix target e.g. the wall
“Error state” indication by the analogue signal (Check for a valid echo as above)
As a result of this setting the value of the analogue output will be 3.8 mA; 22 mA or according last value (hold) until the error is ceased.
Action Led state following the action
1) Press button steadily = EchoTREK in programming mode
2) Press any of the DOWN ,
ENTER
E
,
NEXT
buttons steadily
– hold last value
= – 3.6 mA
– 22 mA
3) Release buttons = Programming completed

60/18 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
Damping time setting (Check for a valid echo as above)
Action Led state following the action
1) Press ENTER
E
button steadily = EchoTREK in programming mode
2) Press any of the NEXT ,
UP ,
DOWN
buttons steadily
– 10 sec
= – 30 sec
– 60 sec
3) Release buttons = Programming completed
RESET: Returning to the default (Check for a valid echo as above)
Action Led state following the action
1) Press NEXT button steadily = EchoTREK in programming mode
2) Press ENTER
E
button steadily = Default loaded
Indication of mistakes (by LEDs) made during programming
Action Led state following the action Possible correction
Attempted programming = blinking twice = no Echo Find a valid Echo
Attempted programming = blinking three times = no access possible With SAP-200 only See 5.2 (P99)
Attempted programming = blinking four times = EchoTREK not in
Level Measurement Mode With SAP-200 only See 5.2 (P01)

BKI 03 ATEX 027X ♦sea3802a0600p_03 ♦60/19
5.2 PROGRAMMING WITH THE SAP-200 DISPLAY MODULE
The EchoTREK should be adjusted to the process by programming the parameters. The SAP-200 Display Module can be used to display the parameters during
programming and measurement values during measurement.
The SAP-200 supports two separately accessible programming modes representing 2-layers of programming complexity, depending on user choice.
PLUG-IN DISPLAY MODULE
QUICKSET
FULL
PARAMETER
ACCESS
QUICKSET (5.2.4)
Recommended as a simple and fast way to set up the EchoTREK by 6 basic parameters
for the following basic settings, marked by abbreviations easy to remember
•Engineering unit for the display (Metric or US)
•Maximum measuring distance (H)
•Assignment of min level to 4 mA
•Assignment of max level to 20 mA
•Error indication by the current output
•Damping time
Full Parameter Access (5.2.5)
All features of the EchoTREK such as:
•Measurement configuration
•Outputs
•Measurement optimisation
•11 pre-programmed tank shapes for volume calculation
•21 pre-programmed formula for flow metering
•32-point linearisation

60/20 ♦BKI 03 ATEX 027X ♦sea3802a0600p_03
5.2.1 SAP-200 Display Module
Symbols used on the LCD:
•DIST – Distance (measuring) mode
•LEV – Level (measuring) mode
•VOL – Volume (measuring) mode
•FLOW – Open channel (flow metering) mode
•PROG - Programming mode
(device under programming)
•RELAY – ‘C2’ circuit of the relay is closed
•T1 - TOT1 volume flow totaliser
(resetable aggregate)
•T2 - TOT2 volume flow totaliser (aggregate)
•FAIL - Measurement / device error
•- Level changing direction
•Bargraph assigned to the current output or
echo strength
Symbols used on the frame:
•M– Metric system
•US – US calculation system
LEDS lit
•COM – digital (Hart) communication
•VALID – presence of valid echo
IrDA –Infrared communication port for logger
readout, diagnostics and software upgrade.
5.2.2 Steps of the SAP-200 Display Module
Programming will be performed by the pressing and releasing the relevant one or two keys (simultaneously).
Single key pressing
ENTER
E
to select parameter address and go to parameter value
to save parameter value and return to parameter address
NEXT to move the blinking (sign of change) of the digit to the left
UP to increase value of the blinking digit
DOWN to decrease value of the blinking digit
Double key pressing
Press the two keys simultaneously for desired programming step.
yy parameter address (P01, P02…P99)
xxxx parameter value (dcba)
bargraph
yy : xxxx
