NIVELCO NIPRESS D-300 Series User manual

NIPRESS
Manufacturer
H-1043 Budapest, Dugonics u. 11.
Phone: [phone] Fax: [phone]
:
E-mail: [e-mail] www.nivelco.com
NIVELCO Process Control Co.
Thank you for choosing NIVELCO instrument
We are sure that you will be satisfied throughout its use
1. APPLICATION
The NIPRESS D-300 series pressure transmitters measuring pressure and converting it into voltage and
current output can be used in 2- and 3-wire systems. The wide choice of the models makes it suitable for the
most pressure measurement tasks whether relative or absolute pressure, static or dynamic measurement is
required. The series is available with two different accuracy classes.
The design of the transmitter, its overload capability and wide range of temperature and the possibility to
install the unit in any position allows their application in the most different industrial circumstances.
2. TECHNICAL SPECIFICATION
Type D-3-
Measurement range -1 – 600 bar (according to the order code)
Overload capability According to the order code
Accuracy Pn> 0.4 bar :0.25 %, 0.5% or 0.1% according to the order code;
Pn≤0.4 bar: 0.5 % or 0.1%
Medium temperature -40 °C … +125 °C
Ambient temperature -40 °C … +85 °C
Sensor type Piezoresistive
Sensor 1. 4435 stainless steel (internal membrane)
Sensor sealing FKM (Viton), optional NBR, EPDM (Pn≤ 160 bar)
Process conn. 1.4404 stainless steel
Materials
of the
wetted
parts Housing 1.4404 stainless steel
Output 4 – 20 mA or 0 – 10 V
Power supply 4 – 20 mA output: 8 – 32 V DC; 0 – 10 V DC output: 14 – 30 V DC
4 – 20 mA 2-wire current output Ω
A0.02
V8U
Rs
t
–
≤
Load resistance
0 – 10 V DC voltage output R > 10 kΩ
Process connection According to the order code
Electrical connection Pg 9 DIN 43650 connector/with integral cable
Ingress protection IP65/IP68 with integrated cable
Shock-hazard protection SELV Class III
Mass ~ 0.14 kg
2.1 ACCESSORIES
− User’s manual, Warranty Card, Declaration of Conformity
2.2 ORDER CODE
NIPRESS D – 3 –
ORDER
CODE CODE PROCESS CONNECTION CODE
RANGE /(OVERLOAD
CAPABILITY)
BAR
CODE
RANGE /(OVERLOAD
CAPABILITY)
BAR
CODE OUTPUT CODE
Relative R ¼” BSP A -1 – 0 (5) 0 0 – 10 (40) A 4 – 20 mA 2
Absolute (1) E ½” BSP C 0 – 0.1 (0.5) 1 0 – 16 (80) B 0 – 10 V 3
¼” NPT (2) G 0 – 0.16 (1) R 0 – 25 (80) C
½” NPT H 0 – 0.25 (1) 2 0 – 40 (105) D
0 – 0.4 (2) 3 0 – 60 (210) E ACCURACY CODE
0 – 0.6 (5) 4 0 – 100 (600) F 0.25 % (1) 1
0 – 1 (5) 5 0 – 160 (600) G 0.5 % 2
0 – 1.6 (10) 6 0 – 250 (1000) H 0.1 % 4
0 – 2.5 (10) 7 0 – 400 (1000) J
(1) Only above 0.4 bar
(2) Up to max 40 bar
0 – 4 (20) 8 0 – 600 (1000) K
0 – 6 (40) 9

2.3 DIMENSIONS
~33
335017
14
Ø34,5
Ø26,5
SW27
G1/2"
p ≤ 40 bar
~33
335917
14
Ø34,5
Ø26,5
SW27
G1/2"
p > 40 bar
3. MOUNTING
Due to its small size and weight NIPRESS D-300 can be directly installed on
tanks, pipes, machines, etc without mounting device.
To provide chance for replacement of the instrument during operation the use
of closing armature is recommended. A simple ball valve will be suitable for
lower pressure and for higher pressure (above 6 bar g) a three-way blow-off
needle-valve can be suggested. With pressure measurements of medium with
temperature over 75°C, the application of condensing device would protect the
instrument against overheating and extends its lifetime.
Temperature of the condensation in the condensing devices (in the water
lodge) is practically only 10 … 20°C higher than the ambient temperature.
Using longer impulse tube its proper sloping for the necessary de-aerating and
emptying has to be ensured.
Measuring low pressure values in systems with substantial height difference
between the transmitter and place of measurement the hydrostatic pressure of
the medium in the impulse pipe should be taken into consideration. In the case
of outside installation the unit is supposed to be protected against rain or
splash water.
3.1 INSTALLATION
For mounting and dismantling SW27 open-end wrench should be used.
The cylindrical housing of the transmitter should not be gripped
and tightened with pipe wrench!
The plug-in electric connector can be unplugged after releasing and removing
its fastening screw. The connection insert can be pushed out by a screw driver
from the direction of the screw.
Pushing electric cable through the cable gland it can be connected to the
relevant points of the connector. Make sure that the cable gland and sealing
plate of the connector will be tight.
For the sake of noise suppression the transmitter housing is grounded. If the
grounding of the appliance with the pressure transmitter is appropriate no
further action will be needed. If not, the grounding should be performed.
4. WIRING
+
brown
yellow/black
green
–
white
+ Out
12
3
+
–
+ Out
+
1:2:
3: Out
+
4:
CONNECTION
OF INTEGRAL CABLE
CONNECTION
OF DIN PLUG
CONNECTION
OF M12 X 1/4PLUG
4.1 EXAMPLES OF ARRANGEMENTS
WIRING OF 2-WIRE PRESSURE TRANSMITTERS
P
I
Current controlled
switch
PKK-312
~230V
Pressure transmitter
PLK-501
display
P
I
Panel instrument
PMM-300
PMM-500
~230V
Pressure transmitter
Power supply
PPK-331
P
I
Current loop indicator
PDF-401
~230V
Pressure transmitter
WIRING OF 3-WIRE PRESSURE TRANSMITTERS
Power supply
PPK-331
P
U
Panel instrument
PMG-411
+
Out
~230V
~230V
Pressure
transmitter
5. MAINTENANCE AND REPAIR
The instrument does not require regular maintenance. If necessary possible dirt
deposited should be cleaned off.
All repairs will be carried out at the Manufacturer’s premises.
6. STORAGE CONDITIONS
Storage temperature: -40 °C ... +85 °C
Relative humidity: max. 98 %
7. WARRANTY
NIVELCO provides warranty of 3 (three) years in compliance with details
described in the Warranty Card.
drc3612a0600h_04
June 2017
NIVELCO reserves the right to change technical data without notice.
