Njoy Balder Series User manual

Balder Series User Manual
Manual de utilizare
PWUP-OL06KBA-AZ01B
PWUP-OL10KBA-AZ01B
150.1
Before using this product, carefully read all product documentation and retain it for future reference.

02 03
BYPASS LINE BATT FAULT
OUTPUT
02
Hz
UPS Unit
User Manual
Warranty card
Software CD
USB Cable
Rack mounting holders
Tower mounting stand
Screws
Connection cable between UPS and battery
cabinet
Package Contents
Product Overview
1
2
Front View
LCD panel
The following models belong to the Balder Series:
Balder 6000
Balder 10000
6000VA
10000VA
Thank you for purchasing our products!
Please read this manual before using the product.
Focusing on quality at competitive prices, nJoy
designs consumer products for a better and
enjoyable way into the digital world.
NOTE: If any of the above package content is missing or is
damaged please contact the shop where you have bought the
UPS from.
English
Română
This UPS will protect your electronic equipment from
physical damage and will provide emergency battery
backup power to prevent data loss in the event of power
problems.

04 05
LCD Panel
1. Input/output/battery
voltage info
2. Backup time info
3. Warning and fault info
4. Battery info
5. Mode Operation Info
6. Load Info
7. Mute Operation
6
BYPASS LINE BATT FAULT
OUTPU T
02
Hz
LCD panel
There are 4 LEDs on front panel to show the UPS working
status:
Note: ● means LED is lighting, and means LED is faded.
Mode LED Bypass Line Battery Fault
UPS Startup ○○○○
No Output mode 
Bypass mode ○
AC mode ○
Battery mode ○
CVCF mode ○
Battery Test ○○○
ECO mode ○○
Fault ○
1
7
3
2
1
5
4
English
Română

06 07
1. Share current port (only
available for parallel
model)
2. Parallel port (only available
for parallel model)
3. External battery connector
4. Intelligent slot
5. RS-232 communication port
6. USB communication port
7. Emergency power o
function connector (EPO
connector)
8. Input circuit breaker
9. Output terminals
10.Ground
11.Input terminals
12.Cooling Fan
13.External maintenance
bypass switch port
14.Battery pack output circuit
breaker
15.External battery connector
Back View
Balder 6000 / 10000
2
3
6
10
13
1112
7
9
4
8
Please comply with all warnings and operating
instructions in this manual strictly. Save this manual
properly and carefully read the following instructions
before installing the unit. Do not operate this unit before
reading through all safety information and operating
instructions carefully:
Important Safety Warnings3
Transportation
Please transport the UPS system only in the original
package to protect against shock and impact.
Preparation
Condensation may occur if the UPS system is moved
directly from cold to warm environment. The
UPS system must be absolutely dry before being
installed. Please allow at least two hours for the
UPS system to acclimate to the environment
Do not install the UPS system near water or in moist
environments.
Do not install the UPS system where it would be
exposed to direct sunlight or near heat sources.
Do not block ventilation holes in the UPS housing.
1
5
15
14
14
15
Diagram 1: UPS Rear Panel
Diagram 2: 2U battery pack Diagram 3: 3U battery pack
English
Română

08 09
Installation
Do not connect appliances or devices which would
overload the UPS system (e.g. big motor-type
equipment) to the UPS output sockets.
Place cables in such a way that no one can step on
or trip over them.
Do not connect domestic appliances such as hair
dryers to UPS output sockets.
The UPS can be operated by any individuals with no
previous experience.
Do not block air vents in the housing of UPS. The
UPS must be installed in a location with good
ventilation. Ensure enough space on each side for
ventilation.
The UPS can be installed only by qualified
maintenance personnel.
An appropriate disconnect device as short-circuit
backup protection should be provided in the
building wiring installation.
An integral single emergency switching device
which prevents further supply to the load by the
UPS in any mode of operation should be provided in
the building wiring installation.
Connect the ground before connecting to the
building wiring terminal.
Installation and Wiring must be performed in
accordance with the local electrical laws and
regulations.
Connection Warnings
There is no standard backfeed protection inside
of the UPS. Please isolate the UPS before working
according to Diagram 1. The isolation device must
be able to carry the UPS input current.
Diagram 1: External backfeed protection wiring
This UPS should be connected with TN earthing
system.
The power supply for this unit must be single-
phase rated in accordance with the equipment
nameplate. It also must be suitably grounded.
Use of this equipment in life support applications
where failure of this equipment can reasonably be
expected to cause the failure of the life support
equipment or to significantly affect its safety or
effectiveness is not recommended. Do not use
this equipment in the presence of a flammable
anesthetic mixture with air, oxygen or nitrous
oxide.
Connect your UPS power module’s grounding
terminal to a grounding electrode conductor.
The UPS is connected to a DC energy source
(battery). The output terminals may be live when
the UPS is not connected to an AC supply.
Legend
B Coil Remote Switch
Q Magneto-Thermal Input Main Swich
T AC Contactor as backfeed protection device
N/L2 Neutral I/L2
L/L1 L1 Line Input
External Distribuiton Panel UPS
Q
L/L1 L/L1
B
N/L2 N/L2
T
English
Română

10 11
Operation
Do not disconnect the earth conductor cable
on the UPS system or the building wiring outlet
(shockproof socket outlet) during operations since
this would cancel the protective earthing of the
UPS system and of all connected loads.
Due to the UPS is connected to batteries, its
output sockets or output terminals block may
be electrically live even if the UPS system is not
connected to the building wiring outlet.
In order to fully disconnect the UPS system, first
press the OFF/ESCbutton to disconnect the mains.
Prevent fluids or other foreign objects from
entering the inside of the UPS system.
Maintenance, service and faults
The UPS system operates with hazardous voltages.
Repairs may be carried out only by qualified
maintenance personnel.
Caution - risk of electric shock. Even after the unit
is disconnected from the mains (building wiring
outlet), components inside the UPS system are still
connected to the battery and electrically live and
dangerous.
Before carrying out any kind of service and/or
maintenance, disconnect the batteries and verify
that no current is present and no hazardous voltage
exists in the terminals of high capacitors such as
BUS-capacitors.
Only persons who are adequately familiar with
batteries and with the required precautionary
measures may replace batteries and supervise
operations. Unauthorized persons must be kept
well away from the batteries.
Caution - risk of electric shock. The battery circuit
is not isolated from the input voltage. Hazardous
voltages may occur between the battery terminals
and the ground. Before touching, please verify that
no voltage is present!
Batteries may cause electric shock and have a high
short-circuit current. Please take the precautionary
measures specified in this manual and any other
measures necessary when working with batteries:
remove wristwatches, rings and other metal
objects, use only tools with insulated grips and
handles.
When changing batteries, install the same number
and same type of batteries.
Do not attempt to dispose of batteries by burning
them. This could cause battery explosion. Do not
open or destroy batteries. Escaping electrolyte can
cause injury to the skin and eyes. It may be toxic.
Please replace the fuse only with the same type
and amperage in order to avoid fire hazards.
Do not dismantle the UPS system.
English
Română

12 13
First x the holders of the rack on the UPS.
Then x the UPS on the rack through the holders
A. Rack - mount instalation
First x the holders
to t the UPS.
Then put the UPS in
place.
B. Tower instalation
Installation4
The UPS can protect your equipment from all power
problems such as surges, spikes, blackouts, brownouts
and line noise. When AC power is present, the Input
circuit breaker is switched ON and the unit is turned on
from the ON/ENTER button, the UPS will provide pure
and stable AC power to the output. The UPS will also
charge the battery in the on-line mode.
The UPS is simple to install and operate. Please read
the following steps before connecting any equipments
to this UPS:
NOTE: Before installation, please inspect the unit. Be sure
that nothing inside the package is damaged. Please keep the
original package in a safe place for future use
English
Română

14 15
Single UPS Installation4.1
Installation and wiring must be performed in accordance
with the local electric laws/regulations and execute the
following instructions by professional personnel.
Step 1. Make sure the mains wire and breakers in the
building are enough for the rated capacity of
UPS to avoid the hazards of electric shock or
re.
NOTE: Do not use the wall receptacle as the input power
source for the UPS, as its rated current is less than the UPS’s
maximum input current. Otherwise the receptacle may be
burned and destroyed.
NOTE: The cable for Balder 6000 should be able to withstand
over 40A current. It is recommended to use 10AWG or thicker
wire for safety and eciency.
The cable for Balder 10000 should be able to withstand over
63A current. It is recommended to use 8AWG or thicker wire
for safety and eciency.
The selections for color of wires should be followed by the
local electrical laws and regulations.
NOTE 1: Make sure that the wires are connected tightly to
the terminals.
NOTE 2: Please install the output breaker between the
output terminal and the load, and the breaker should be
qualied with leakage current protective function if necessary.
Step 2. Switch o the mains switch in the building
before installation.
Step 3. Turn o all the connected devices before
connecting to the UPS.
Step 4. Prepare wires based on the following table:
Model Wiring specs: AWG / cross section(mm)
Input Output Battery Ground
Balder
6000
10 AWG
2.59 mm
10 AWG
2.59 mm
10 AWG
2.59 mm
10 AWG
2.59 mm
Balder
10000
8 AWG
3.26 mm
8 AWG
3.26 mm
8 AWG
3.26 mm
8 AWG
3.26 mm
Step 5. Remove the terminal block cover on the rear
panel of UPS. Then connect the wires according
to the following terminal block diagrams.
Connect the ground wire rst when making
wire connection. Disconnect the earth wire last
when making wire disconnection!
Terminal Block wiring diagram
Step 6. Put the terminal block cover back to the rear
panel of the UPS.
Output Line
Output Neutral
Input Neutral
Input Line
Ground
English
Română

16 17
UPS Installation for Parallel System4.2
If the UPS is only available for single operation, you may
skip this section to the next.
Parallel system functional explanation
The parallel system consists in a link of up to max. 3
units of Balder 6000/Balder 10000 UPS’s and its main
goal is to insure greater reliability for critical
applications. Therefore, for such special applications,
the reliability is increased by running 2 or 3 units in
parallel. In case of failure of one unit, the applications
is still properly powered by the other one or two units.
However, the total power rating of the parallel system
will not multiply by the number of the units linked
together. The software management of the units will
still be done separately for each.
Parallel system installation
Step 1. Install and wire all the UPSs according to the
section 4.1.
Step 2. Connect the output wires of each UPS to an
output breaker.
Step 3. Connect all output breakers to a major output
breaker. Then this major output breaker will
directly connect to the loads.
Make sure the UPS is not turned on before
installation. The UPS should not be turned on
during wiring connection.
Make sure a DC breaker or other protection
device between UPS and external battery pack is
installed. If not, please install it carefully. Switch
o the battery breaker before installation.
Pay highly attention to the rated battery voltage
marked on the rear panel. If you want to change
the numbers of the battery pack, please make
sure you modify the setting simultaneously. The
connection with wrong battery voltage may cause
permanent damage of the UPS. Make sure the
voltage of the battery pack is correct.
Pay highly attention to the polarity marking on
external battery terminal block, and make sure
the correct battery polarity is connected. Wrong
connection may cause permanent damage of the
UPS.
Make sure the protective earth ground wiring is
correct. The wire current spec, color, position,
connection and conductance reliability should be
checked carefully.
Make sure the utility input & output wiring is
correct. The wire current spec, color, position,
connection and conductance reliability should
be checked carefully. Make sure the L/N site is
correct, not reverse and short-circuited.
WARNINGS
WARNINGS
NOTE: Set the battery pack breaker in “OFF” position and
then install the battery pack.
English
Română

18 19
Software Installation4.3
For optimal computer system protection, install UPS
monitoring software to fully congure UPS shutdown:
https://www.power-softwaredownload.com/viewpower.html
Step 4. Each UPS is connected to an independent
battery pack.
Step 5. Remove the cover of parallel share current
cable port on the UPS, connect each UPS one
by one with the parallel cable and share current
cable, and then screw the cover back again.
Diagram 1: Power cable connection
Diagram 1: Wiring diagram of parallel system
NOTE: The parallel system can not use only one battery
pack. Otherwise, it will cause system permanent failure.
To allow for unattended UPS shutdown/start-up and
status monitoring, connect the communication cable
one end to the USB/RS-232 port and the other to the
communication port of your PC. With the monitoring
software installed, you can schedule UPS shutdown/
start-up and monitor UPS status through PC. The UPS is
equipped with slot perfect for either SNMP or AS400
card. When installing either an SNMP or AS400 card in
the UPS, it will provide advanced communication and
monitoring options.
Communication port:
USB Port RS-232 Port Intelligent slot
Communication Port Connection4.4
Parallel communication port connection
Output Line
Ground Ground
Output Neutral
Input Line
Input Neutral
Share current cable connection
English
Română

20 21
Button operations
Operations
5.1
5
ON/Enter Button
Turn on the UPS: Press and hold the button more
than 0.5s to turn on the UPS.
Enter Key: Press this button to conrm the selection
in setting menu.
OFF/ESC Button
Turn o the UPS: Press and hold the button more
than 0.5s to turn o the UPS.
Esc key: Press this button to return to last menu in
setting menu.
NOTE: By pressing and holding the OFF/ESC button more
than 0.5s the UPS enters bypass mode; to turn o UPS
completely you need to open main Input circuit breaker
(see section 2, Diagram 1: UPS Rear Panel).
BYPASS LINE BATT FAULT
OUTPU T
02
Hz
ON/EnterOFF/ESC Test/Up Mute/Down
Test/Up Button
Battery test: Press and hold the button more than
0.5s to test the battery while in AC mode, or CVCF
mode.
UP key: Press this button to display next selection
in setting menu.
Mute/Down Button
Mute the alarm: Press and hold the button more
than 0.5s to mute the buzzer. Please refer to
section 5.3 for details.
Down key: Press this button to display previous
selection in setting menu.
Test/Up + Mute/Down Button
Press and hold the two buttons simultaneous more
than 1s to enter/escape the setting menu.
English
Română

22 23
LCD Panel Indicators5.2
Display Function
Remaining backup time information
88 Indicates battery discharge time in
numbers.
H: hours, M: minutes, S: seconds
Warning & Fault information
Indicates that the specied warning and
fault occurs.
88 Indicates the fault codes, and the codes
are listed in details in section 3-9.
Mute operation
Indicates that the UPS alarm is disabled.
Input/Output & Battery information
OUTPUT
Vac
Hdc
Hz
Indicates the output voltage, frequency
or battery voltage.
Vac: output voltage, Vdc: battery voltage, Hz:
frequency
Load information
Indicates the load level by 0-25%, 26-
50%, 51-75%, and 76-100%.
OVER LOAD Indicates overload.
SHORT Indicates the load or the output is short.
Mode operation information
Indicates the UPS connects to the mains.
Indicates the battery is working.
Indicates the bypass circuit is working.
ECO Indicates the ECO mode is enabled.
Indicates the Inverter circuit is working.
Indicates the output is working.
Battery information
Indicates the Battery capacity by 0-25%,
26-50%, 51-75%, and 76-100%.
BATT. FAULT Indicates the battery is not connected.
LOW BATT. Indicates low battery level and low bat-
tery voltage.
Input & Battery voltage information
INPUT 12
Vac
Hdc
Hz
Indicates the input voltage or frequency
or battery voltage.
Vac: Input voltage, Vdc: battery voltage,
Hz: input frequency
English
Română

24 25
Audible Alarm Indicators
LCD display wordings index
5.3
5.4
UPS status Alarm
Bypass mode Beeping once every 2 minutes
Battery Mode Beeping once every 4 seconds
Fault mode Beeping continuously
Abbreviation Display content Meaning
ENA ENA Enable
DIS d1 5 Disable
ATO A O Auto
Abbreviation Display content Meaning
BAT bA Battery
NCF NCF Normal mode (not
CVCF mode)
CF CF CVCF mode
SUB SUb Subtract
ADD Add Add
ON ON On
OFF OFF O
FBD Fbd Not allowed
OPN OPN Allow
RES ES Reserved
OP.V O P. U Output voltage
PAR PA Parallel
Warning Alarm
Overload Beeping twice every second
Others Beeping once every second
Fault Alarm
All Beeping continuously
English
Română

26 27
888 888
Vac Vac
88
UPS Settings5.5
There are three parameters to set up the UPS. Refer to fol-
lowing diagram.
•Parameter 1: For program alternatives. There are 16 pro-
grams to set up. Refer to the table below.
•Parameter 2 and 3: The settings options or values for each
program.
Programs available list for parameter 1:
Description Code
Bypass/
No
output
AC ECO CVCF Battery Battery
Test
Output
voltage 01 Y
Output
frequency 02 Y
Voltage range
for bypass 03 Y
Frequency
range for
bypass
04 Y
Description Code
Bypass/
No
output
AC ECO CVCF Battery Battery
Test
ECO mode
enable/
disable
05 Y
Voltage range
for ECO mode 06 Y
ECO mode
frequency
range setting
07 Y
Bypass mode
setting 08 Y Y
Battery backup
time setting 09 YY Y Y Y Y
Reserved 10 Reserved for future use
Reserved 11 Reserved for future use
Hot standby
function
enable/disable
12 Y Y Y Y Y Y
Battery
voltage
adjustment
13 Y Y Y Y Y Y
Charger
voltage
adjustment
14 Y Y Y Y Y Y
Inverter
voltage
adjustment
15 Y Y Y
Output
voltage
calibration
16 Y Y Y
*Y means that this program can be set in this mode.
NOTE: All parameter settings will be saved only when UPS
shuts down normally. Normal UPS shutdown means turning o
input breaker in bypass mode.
NOTE: Most of Balder UPS parameters can be set-up only
on Bypass mode (see below table); please be sure you are in
Bypass mode and then press and hold Test/Up + Mute/Down
Buttons simultaneous more than 1s to enter the setting menu
(see section 5.1 for details).
Parameter 1
Parameter 2 Parameter 3
English
Română

28 29
Interface Settings
01: Output voltage settings
0 1
220
OUTPUT
Vac
Parameter 3: Output voltage
You may choose the following output
voltage in parameter 3:
208: presets output voltage is 208Vac
220: presets output voltage is 220Vac
230: presets output voltage is 230Vac
240: presets output voltage is 240Vac
NOTE: When the output voltage is set to 208V, the power
of the UPS is de-rated to 90%.
02: Output frequency
60 Hz, CVCF mode
02
600 Cf
OUTPUT
Hz
50 Hz, Normal mode
02
500 NCf
OUTPUT
Hz
ATO
02
500
A 0
F
OUTPUT
Hz
Parameter 2: Output Frequency
Setting the output frequency as follows:
50.0Hz: The output frequency is setting
for 50.0Hz.
60.0Hz: The output frequency is setting
for 60.0Hz.
ATO: If selected, output frequency
will be decided according to the latest
normal utility frequency. If it is from
46Hz to 54Hz, the output frequency
will be 50.0Hz. If it is from 56Hz to
64Hz, the output frequency will be
60.0Hz. ATO is default setting.
Parameter 3: Frequency mode
Setting output frequency at CVCF mode
or not CVCF mode. You may choose
following two options in parameter 3:
CF: Setting UPS to CVCF mode. If
selected, the output frequency will
be xed at 50Hz or 60Hz according
to setting in parameter 2. The input
frequency could be from 46Hz to 64Hz.
NCF: Setting UPS to normal mode (not
CVCF mode). If selected, the output
frequency will synchronize with the
input frequency within 46~54 Hz
at 50Hz or within 56~64 Hz at 60Hz
according to setting in parameter 2. If
50 Hz selected in parameter 2, UPS will
transfer to battery mode when input
frequency is not within 46~54 Hz. If
60Hz selected in parameter 2, UPS will
transfer to battery mode when input
frequency is not within 56~64 Hz.
*If Parameter 2 is ATO, the Parameter 3
will show the current frequency.
NOTE: If the UPS is set to CVCF mode, the bypass function
will be disabled automatically. When used in CVCF mode, the
power of the UPS is de-rated to 60%.
But when a single UPS without parallel function is powered
on with mains and before the UPS nished the startup, there
will be a few seconds of voltage pulse (same as the input
voltage) on the bypass output. For the UPS with parallel
function, this pulse situation won’t happen.
03: Voltage range for bypass
Parameter 2: Set the acceptable low
voltage for bypass. Setting range is from
110V to 209V and the default value is
110V.
Parameter 3: Set the acceptable high
voltage for bypass. Setting range is from
231V to 276V and the default value is
264V.
English
Română

30 31
04: Frequency range for bypass
Parameter 2: Set the acceptable low
frequency for bypass.
50 Hz system: Setting range is from
46.0Hz to 49.0Hz.
60 Hz system: Setting range is from
56.0Hz to 59.0Hz.
The default value is 46.0Hz/56.0Hz.
Parameter 3: Set the acceptable high
frequency for bypass.
50 Hz: Setting range is from 51.0Hz to
54.0 Hz.
60 Hz: Setting range is from 61.0Hz to
64.0Hz.
The default value is 54.0Hz/64.0Hz.
05: ECO mode enable/disable
Parameter 3: Enable or disable ECO
function. Available options:
DIS: disable ECO function
ENA: enable ECO function
If ECO function is disabled, voltage
range and frequency range for
ECO mode still can be set, but it is
meaningless unless the ECO function is
enabled.
06: Voltage range for ECO mode
Parameter 2: Low voltage point in ECO
mode. The setting range is from 5% to
10% of the nominal voltage.
Parameter 3: High voltage point in ECO
mode. The setting range is from 5% to
10% of the nominal voltage.
07: Frequency range for ECO mode
Parameter 2: Set low frequency point
for ECO mode.
50 Hz system: Setting range is from
46.0Hz to 48.0Hz.
60 Hz system: Setting range is from
56.0Hz to 58.0Hz.
The default value is 48.0Hz/58.0Hz.
Parameter 3: Set high frequency point
for ECO mode.
50 Hz: Setting range is from 52.0Hz to
54.0 Hz.
60 Hz: Setting range is from 62.0Hz to
64.0Hz.
The default value is 52.0Hz/62.0Hz.
08: Bypass mode setting
Parameter 2:
OPN: Bypass allowed. When selected,
UPS will run at Bypass mode depending
on bypass enabled/disabled setting.
FBD: Bypass not allowed. When
selected, it’s not allowed for running in
Bypass mode under any situations.
Parameter 3:
ENA: Bypass enabled. When selected,
Bypass mode is activated.
DIS: Bypass disabled. When selected,
automatic bypass is acceptable, but
manual bypass is not allowed. Manual
bypass means users manually operate
UPS for Bypass mode. For example,
press OFF button in AC mode to turn
into Bypass mode.
English
Română

32 33
09: Battery backup time setting
Parameter 3:
000~999: Set the maximum backup
time from 0 min to 999 min. UPS will
shut down to protect battery after
backup time arrives.
DIS: Disable battery discharge
protection and backup time will depend
on battery capacity.
The default value is DIS.
10: Reserved
Reserved
11: Reserved
Reserved
12: Hot standby function enable/disable
Parameter 2: HS.H
Enable or disable Hot standby function.
You may choose following two options
in Parameter 3:
YES: Hot standby function is enabled.
It means that the current UPS is set to
host of the hot standby function, and
it will restart after AC recovery even
without battery connected.
NO: Hot standby function is disabled.
The UPS is running at normal mode and
can’t restart without battery
13: Battery voltage adjustment
Parameter 2: Select “Add” or “Sub”
function to adjust battery voltage to
the real value.
Parameter 3: the voltage range is from
0V to 5.7V, the default value is 0V.
14: Charger voltage adjustment
Parameter 2: you may choose Add or
Sub to adjust charger voltage
Parameter 3: the voltage range is from
0V to 9.9V, the default value is 0V.
NOTE:
*Before making voltage adjustment, be sure to disconnect all
batteries rst to get the accurate charger voltage.
*We strongly suggest to use the default value (0). Any
modication should be suitable to battery specications.
15: Inverter voltage adjustment
Parameter 2: you may choose Add or
Sub to adjust inverter voltage
Parameter 3: the voltage range is from
0V to 6.4V, the default value is 0V.
16: Output voltage calibration
When the output voltage can not
be detected (less than 50VAC), this
menu will be reserved, “ ” will
be displayed in parameter 2 and
parameter 3.
English
Română

34 35
Operating Mode and Status Description
5.6
• AC mode
When the input voltage is within acceptable range, UPS will
provide pure and stable AC power to output. The UPS will
also charge the battery at AC mode.
LCD display
• ECO mode (Eciency Corrective Optimizer)
When the input voltage is within voltage regulation range
and ECO mode is enabled, UPS will bypass voltage to output
for energy saving.
LCD display
• CVCF mode
When input frequency is within 46 to 64Hz, the UPS can be
set at a constant output frequency, 50 Hz or 60 Hz. The UPS
will still charge battery under this mode. When used in CVCF
mode, the power of the UPS is de-rated to 60%.
LCD display
• Battery mode
When the input voltage is beyond the acceptable range
or power failure, UPS will backup power from battery and
alarm will beep every 4 seconds.
Parameter 2: it always shows OP.V as
output voltage.
Parameter 3: it shows the internal
measurement value of the output
voltage, and you can calibrate it by
pressing Up or Down according to
the measurement from an external
voltage meter. The calibration result
will be eective by pressing Enter. The
calibration range is limited within +/-
9V. This function is normally used for
parallel operation.
If parallel UPS systems are successfully set up, it will show
one more screen with “PAR” in parameter 2 and be assigned
number in parameter 3 as below parallel screen diagram.
The master UPS will be default assigned as “001” and slave
UPSs will be assigned as either “002” or “003”. The assigned
numbers may be changed dynamically in the operation;
English
Română

36 37
LCD display
• Bypass mode
When the input voltage is beyond the acceptable range or
power failure, UPS will activate backup power from battery
and alarm will beep every 4 seconds.
LCD display
• Battery Test
When UPS is in AC mode or CVCF mode, press “Test” key
for more than 0.5s. Then the UPS will beep once and start
“Battery Test”. The line between I/P and inverter icons will
blink to remind users. This operation is used to check the
battery status.
LCD display
• Fault status
When UPS has fault happened, it will display fault messages
in LCD panel.
LCD display
English
Română

38 39
Faults Reference Code5.7
Fault event Fault code Icon
Bus start failure 01 X
Bus over 02 X
Bus under 03 X
Bus unbalance 04 X
Inverter soft start fail 11 X
High inverter voltage 12 X
Low inverter voltage 13 X
Inverter output short
circuited 14 SHORT
Negative power fault 1A X
Inverter over current 1d X
Inverter waveform
abnormal 1e X
Fault event Fault code Icon
Battery SCR short
circuited 21 X
Inverter relay short cir-
cuited 45 X
Charger short circuited 2a X
Parallel communication
failure 35 X
Parallel output current
unbalance 36 X
Over temperature 41 X
CPU communication failure 42 X
Overload 43 OVER LOAD
English
Română
