NordicTrack A.C.T. COMMERCIAL NTEVEL13016.0 User manual

USER’S MANUAL
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
Model No. NTEVEL13016.0
Serial No.
Write the serial number in the space
above for reference.
www.iconeurope.com
Serial
Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: [email protected]
Write:
ICON Health & Fitness, Ltd.
Unit 1D, The Gateway
Fryers Way, Silkwood Park
OSSETT
WF5 9TJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: [email protected]
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA

2
TABLE OF CONTENTS
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.
383106
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS..................................................................3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO USE THE ELLIPTICAL ..............................................................12
MAINTENANCE AND TROUBLESHOOTING.....................................................20
EXERCISE GUIDELINES ....................................................................22
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
ORDERING REPLACEMENT PARTS .................................................. Back Cover
RECYCLING INFORMATION ......................................................... Back Cover
IFIT and NORDICTRACK are registered trademarks of ICON Health & Fitness, Inc. App Store is a trademark of
Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google Inc. The
BLUETOOTH®word mark and logos are registered trademarks of Bluetooth SIG, Inc. and are used under license.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.

3
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical before using your elliptical. ICON
assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.
1. It is the responsibility of the owner to ensure
that all users of the elliptical are adequately
informed of all precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or persons
with pre-existing health problems.
3. The elliptical is not intended for use by
persons with reduced physical, sensory, or
mental capabilities or lack of experience and
knowledge, unless they are given supervi-
sion or instruction about use of the elliptical
by someone responsible for their safety.
4. Use the elliptical only as described in this
manual.
5. The elliptical is intended for home use only.
Do not use the elliptical in a commercial,
rental, or institutional setting.
6. Keep the elliptical indoors, away from mois-
ture and dust. Do not put the elliptical in a
garage or covered patio, or near water.
7. Place the elliptical on a level surface, with at
least 3 ft. (0.9 m) of clearance in the front and
rear of the elliptical and 2 ft. (0.6 m) on each
side. To protect the floor or carpet from dam-
age, place a mat under the elliptical.
8. Inspect and properly tighten all parts each
time the elliptical is used. Replace any worn
parts immediately.
9. Keep children under age 13 and pets away
from the elliptical at all times.
10. The elliptical should not be used by persons
weighing more than 297 lbs. (135 kg).
11. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the elliptical. Always wear athletic
shoes for foot protection while exercising.
12. Hold the handlebars or the handrails
when mounting, dismounting, or using the
elliptical.
13. The heart rate monitor is not a medical
device. Various factors may affect the accu-
racy of heart rate readings. The heart rate
monitor is intended only as an exercise aid in
determining heart rate trends in general.
14. The elliptical does not have a freewheel; the
pedals will continue to move until the fly-
wheel stops. Reduce your pedaling speed in
a controlled way.
15. Keep your back straight while using the ellip-
tical; do not arch your back.
16. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.
IMPORTANT PRECAUTIONS

4
Thank you for selecting the revolutionary
NORDICTRACK®ACT COMMERCIAL elliptical. The
ACT COMMERCIAL elliptical provides an impressive
selection of features designed to make your workouts
at home more effective and enjoyable.
For your benefit, read this manual carefully before
you use the elliptical. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Heart Rate Monitor
Handrail
Water Bottle Holder*
*Water bottle is not included
Handlebar/Grip
Stride Adjustment Knob
Pedal Handle
Handle
Pedal
Console
Tablet Holder
BEFORE YOU BEGIN
Wheel
Leveling Foot
Length: 5 ft. 5 in. (165 cm)
Width: 2 ft. 8 in. (81 cm)
Weight: 231 lbs. (105 kg)

5
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M4 x 16mm
Screw (67)–18
M8 x 25mm Flat
Head Screw (68)–6
M10 Locknut
(105)–4
M10 x 50mm Bolt
(100)–4
M8 Locknut
(111)–4
#8 x 12mm
Screw (146)–4
M8 x 45mm Bolt
(130)–4
M8 x 20mm
Screw (61)–12

6
2. Have a second person raise the Upright (2) and
hold it in the position shown.
Slide the Right and Left Upright Covers (60, 96)
upward as shown.
Secure the Upright (2) to the Frame (1) with four
M8 x 20mm Screws (61); do not tighten the
Screws yet.
2
2
1
61
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you nish all assembly steps.
• Left parts are marked “L” or “Left” and right parts
are marked “R” or “Right.”
• To identify small parts, see page 5.
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
one rubber mallet
one adjustable wrench
Assembly may be easier if you have a set of
wrenches. To avoid damaging parts, do not use
power tools.
ASSEMBLY
1
60, 96
73, 75
61
Avoid pinching
the wires
1. Go to www.iconsupport.eu on your computer
and register your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Service
• allows us to notify you of upgrades and offers
Note: If you do not have internet access, call
Customer Service (see the front cover of this
manual) and register your product.

7
3. Have a second person lift the Right Pedal (9)
and the Right Pedal Arm (15).
Using a plastic bag to keep your fingers clean,
apply some of the included grease to the right
Link Arm Bracket (43) in the location shown.
Tip: Avoid pinching your fingers. Slide the right
Link Arm (8) onto the right Link Arm Bracket (43).
Attach the right Link Arm with two M10 x 50mm
Bolts (100) and two M10 Locknuts (105).
Then, slide the right Link Arm Cover (116)
over the M10 x 50mm Bolts (100) and the M10
Locknuts (105).
Repeat this step on the left side of the
elliptical.
4. Remove the two screws (A) and the shipping
bracket (B) from the right side of the Frame (1).
Discard the screws and the shipping bracket.
Tip: Avoid pinching the wires. Slide the upper
end of the Right Handrail (5) onto the right side
of the Upright (2).
Attach the Right Handrail (5) with two M8 x
45mm Bolts (130) and two M8 Locknuts (111);
make sure that the Locknuts are inside the
hexagonal holes (C), but do not tighten the
Bolts yet.
Then, insert the end of the Right Pulse Wire (80)
into the hole in the right side of the Upright (2)
and route it out of the top of the Upright.
Repeat this step on the left side of the
elliptical.
3
4
105
Grease
130
C
80
5
A
4
2
43
15
9
8
116
100
111
B
Avoid pinching
the wires
Avoid pinching
your fingers
1

8
5
5
4
7
1
5. Attach the lower end of the Right Handrail (5) to
the Frame (1) with four M8 x 20mm Screws (61);
do not tighten the Screws yet.
Attach the lower end of the Left Handrail (4)
in the same way.
See step 2. Tighten the four M8 x 20mm Screws
(61). Then, slide the Right and Left Upright
Covers (60, 96) downward and press them onto
the Right and Left Frame Post Covers (73, 75);
avoid pinching the wires.
See step 4. Tighten the four M8 x 45mm
Bolts (130).
Then, tighten the eight M8 x 20mm
Screws (61).
Do not press the Right and Left Handrail
Covers (7, not shown) into place yet.
6
6. Align the tab (D) on the Right Shield Cover (76)
with the indicated hole (E) in the Right Outer and
Inner Shields (17, 19).
Press the Right Shield Cover (76) onto the Right
Outer and Inner Shields (17, 19).
Attach the Left Shield Cover (102) in the
same way.
76
102
17
19
61
61
E
D

9
7
8
7. Align the plastic post (F) inside the Right
Handrail Cover (7) with the indicated hole (G) in
the Right Shield Cover (76).
Press the Right Handrail Cover (7) onto the
Right Shield Cover (76) and the Right Outer and
Inner Shields (17, 19).
Attach the Right Handrail Cover (7) with an
M4 x 16mm Screw (67). Attach the Left
Handrail Cover (6) in the same way.
8. Attach the Rear Upright Cover (21) to the Upright
(2) with five M4 x 16mm Screws (67); do not
tighten the Screws yet. 2
67
67
21
67
17
7
6
19
76
G
F
9
9. While a second person hold the Console (3)
near the Upright (2), plug the Wires (80, 81, 85)
into the matching receptacles on the back of the
Console.
The connectors on the Wires (80, 81, 85)
should slide in easily and snap into place.
If not, turn the connector and try again. If you
do not connect the connectors properly, the
console may become damaged.
Insert the excess wire into the Upright (2).
Tip: Avoid pinching the wires. Attach the
Console (3) with four M4 x 16mm Screws (67);
start all the Screws, and then tighten them.
3
2
67
80
85
Avoid pinching
the wires
81

10
10
10. Hold the Rear Upright Cover (21) against the
Console (3).
See step 8. Tighten the five M4 x 16mm
Screws (67).
Next, press the tabs on the Front Upright Cover
(20) into the Rear Upright Cover (21). Then,
attach the Front Upright Cover to the Upright (2)
with an M4 x 16mm Screw (67).
3
67
20
2
21
11. Identify the Right Handlebar (11).
Attach the Right Handlebar (11) to the Right
Handlebar Arm (13) with three M8 x 25mm Flat
Head Screws (68).
Attach the Left Handlebar (10) in the same
way.
11
10
68
13
12. Attach the right Handlebar Cover (31) to the
Right Handlebar (11) with three M4 x 16mm
Screws (67).
Attach the left Handlebar Cover (31) in the
same way. 11 31
31
67
11
12
