NordicTrack Asr 1000 Cwl Elliptical User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manu-
al for future reference.
Serial Number
Decal
Model No. NTEL00907.2
Serial No.
Write the serial number in the
space above for reference.
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
USER’S MANUAL
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if parts are damaged or missing,
PLEASE DO NOT CONTACT THE
STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and serial
number (see the drawing above)
before contacting us:
CALL TOLL-FREE:
1-888-825-2588
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.nordictrackservice.com

TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO USE THE ELLIPTICAL EXERCISER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
2
NordicTrack is a registered trademark of ICON IP, Inc.
iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
WARNING DECAL PLACEMENT
The warning decals shown here have
been applied in the locations shown. If
a decal is missing or illegible, call
the telephone number on the front
cover of this manual and request a
free replacement decal. Apply the
decal in the location shown. Note:
The decal may not be shown at actual
size.

3
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over the age of 35 or
persons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
3. Your elliptical exerciser is intended for home
use only. Do not use your elliptical exerciser
in a commercial, rental, or institutional set-
ting.
4. Keep your elliptical exerciser indoors, away
from moisture and dust. Place your elliptical
exerciser on a level surface, with a mat
beneath it to protect the floor or carpet.
Make sure that there is enough clearance
around your elliptical exerciser to mount,
dismount, and use it.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. Keep children under age 12 and pets away
from your elliptical exerciser at all times.
7. Your elliptical exerciser should not be used
by persons weighing more than 300 lbs.
(136 kg).
8. Wear appropriate exercise clothes when
exercising; do not wear loose clothes that
could become caught on your elliptical exer-
ciser. Always wear athletic shoes for foot
protection.
9. Hold the handgrip pulse sensor or the han-
dlebars when mounting, dismounting, or
using your elliptical exerciser.
10. Keep your back straight while using your
elliptical exerciser; do not arch your back.
11. The pulse sensor is not a medical device.
Various factors, including the user’s move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. When you stop exercising, allow the pedals
to slowly come to a stop.
13. If you feel pain or dizziness while exercising,
stop immediately and cool down.
14. Use your elliptical exerciser only as
described in this manual.
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical exerciser before using your elliptical
exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
IMPORTANT PRECAUTIONS

4
BEFORE YOU BEGIN
Thank you for selecting the revolutionary NordicTrack®
ASR 1000 elliptical exerciser with Universal Dock for
iPod®. The ASR 1000 elliptical exerciser provides a
wide array of features designed to make your work-
outs at home more effective and enjoyable.
For your benefit, read this manual carefully before
you use the elliptical exerciser. If you have ques-
tions after reading this manual, please see the front
cover of this manual. To help us assist you, note the
product model number and serial number before con-
tacting us. The model number and the location of the
serial number decal are shown on the front cover of
this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Handgrip Pulse Sensor
Game Controller
Handlebar
Wheel
Power Cord
Pedal
Ramp
Console
Integrated Universal
Dock for iPod
Water Bottle Holder*
Leveling Foot
Leveling Foot
*No water bottle is included

5
M4 x 16mm
Screw (90)–4
M10 x 120mm Patch Screw (78)–2
M8 x 19mm Patch
Screw (85)–4
M6 x 18mm Patch
Screw (108)–6
M6 x 14mm
Flat Head
Screw (75)–1
M10 x 15mm Patch
Screw (77)–2
M10 x 22mm x
1.5mm Washer
(100)–2
#8 x .50"
Screw (92)–6
#8 x 2"
Screw (74)–4
Barrel Nut (76)–1
M10 x 58mm Bolt (84)–4
M10 Hex Nylon
Locknut (103)–4
M8 Hex Nylon
Locknut (80)–4
M8 x 55mm Patch Screw (115)–4
#8 x 1.75"
Screw (95)–1
ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires the included hex keys and your own Phillips screwdriver , adjustable
wrench , and rubber mallet .
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parentheses
below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number
following the parentheses is the quantity needed for assembly. Note: Some small parts may have been pre-
assembled. If a part is not in the hardware kit, check to see if it has been preassembled.

1.
Remove the two M10 x 120mm Patch Screws
(78) and the shipping bracket (not shown)
attached to the front of the Frame (1). Discard
the shipping bracket; do not discard the two
Patch Screws.
Orient the Front Stabilizer (49) with the Wheels
(8) in the position shown. While a second per-
son tips the Frame (1) backward, attach the
Front Stabilizer to the Frame with the two M10 x
120mm Patch Screws (78).
6
2. Identify the Right Handlebar (36), which is
marked with an “R” sticker. While a second per-
son holds the Right Handlebar near the Right
Upper Body Arm (37), connect the Right
Handlebar Wire (88) to the Right Extension Wire
(111). Insert the excess wire into the Right
Handlebar.
Attach the Right Handlebar (36) to the Right
Upper Body Arm (37) with two M6 x 18mm
Patch Screws (108) using holes (A) and (B) (see
the inset drawing). Next, attach the Upper Body
Endcap (34) to the Right Handlebar and the
Right Upper Body Arm with an M6 x 18mm
Patch Screw (108) using hole (C).
Repeat this step for the other side of the
elliptical exerciser.
78
49
1
2
1
37
8
8
108
36
34
88
111
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.
Wire
Slot 37
B
A
C

7
3. Identify the Upright (3) and orient it as shown.
Then, pull the Pulse Wire (64) out of the top of
the Upright.
While a second person holds the Upright (3)
near the top of the Frame (1), slide the Upright
Cover (6) upward onto the Upright. Have the
second person hold the Upright Cover
around the Upright until step 5.
4. Note: For clarity, the Upright Cover (6) is not
shown in the drawing. Have the second per-
son hold the Upright (3) and the Upright Cover
near the top of the Frame (1). Locate the wire
tie (see the inset drawing) in the Upright. Tie the
lower end of the wire tie to the Wire Harness
(46) and the Left and Right Extension Wires
(110, 111). Next, pull the upper end of the wire
tie upward out of the top of the Upright. Then,
untie and discard the wire tie. Tip: Do not allow
the ends of the wires to fall into the Upright.
Use a piece of tape or an elastic band to
hold the wires in place until step 6.
Slide the Upright (3) onto the Frame (1). Attach
the Upright with four M8 x 19mm Patch Screws
(85). Tip: Avoid pinching the Wire Harness
(46) and the Extension Wires (110, 111) dur-
ing this step.
3
46
110 111
64
64
6
3
1
3
1
85
85
Avoid pinching
the wires during
this step
4Wire Tie
46
110, 111

8
6. While a second person holds the Console (4)
near the Upright (3), connect the console wire to
the Wire Harness (46). Next, connect the con-
sole pulse wire to the Pulse Wire (64). Then,
connect the game wire marked with an “R” tag
to the Right Extension Wire (111), which is also
marked with an “R” tag. Connect the other game
wire to the Left Extension Wire (110). Insert the
excess wire downward into the Upright.
Tip: Avoid pinching the wires during this
step. Attach the Console (4) to the Upright (3)
with four M4 x 16mm Screws (90).
6
90
64
4
Game Wires
Pulse
Wire
5. Slide the Upright Cover (6) downward to the
bottom of the Upright (3). Reattach the Upright
Cover with a #8 x 1.75" Screw (95).
5
95
6
3
111
110
46
Console
Wire 3
Avoid pinching the
wires during this step

9
7. Identify and orient the Rear Stabilizer (2) as
shown. Remove the Ramp Cover (not shown)
and set it aside until step 11.
Lift the Ramp (55) and slide the Rear Stabilizer
(2) onto the Frame (1). Make sure to place the
Ramp on the indicated Rollers (27).
While a second person tips the Frame (1) side-
ways, attach the Rear Stabilizer (2) with four
M10 x 58mm Bolts (84) and four M10 Hex Nylon
Locknuts (103). Make sure that the Hex Nylon
Locknuts are in the hexagonal holes.
Tip: To prevent squeaking, do not overtight-
en the Bolts.
7
84
103
103
84
27
55
Hexagonal
Holes
Hexagonal
Holes
2
8. Cut and remove the wire tie that holds the Link
Tube (30) inside the left Link Arm (25). Leave
the Link Tube inside the left Link Arm and then
position the Left Pedal Leg (24) and the left Link
Arm as shown.
Apply a small amount of the included grease to
a Barrel Nut (76). Insert the Barrel Nut through
the indicated holes in the Left Pedal Leg (24)
and the left Link Arm (25). Then, insert the
Barrel Nut through the Link Tube (30) inside the
left Link Arm.
Tighten an M6 x 14mm Flat Head Screw (75)
into the Barrel Nut (76).
75
30
76
25
24
Grease
Holes
8
1

10
10. Orient a Pedal (26) as shown. Attach the Pedal
to the bracket on the Left Pedal Leg (24) with
two M8 x 55mm Patch Screws (115) and two
M8 Hex Nylon Locknuts (80).
Repeat this step to attach the other Pedal
(26).
10
25
25
77
100
27
9
9. Insert the axle of the Roller (27) through the
right Link Arm (25); make sure that the Roller
is on the inner side of the Link Arm. Attach
the Roller with an M10 x 15mm Patch Screw
(77) and an M10 x 22mm x 1.5mm Washer
(100). Tip: Use a wrench to hold the axle of
the Roller firmly in place while you tighten
the Patch Screw into the axle.
Repeat this step to attach the other Roller
(not shown) to the left Link Arm (25).
24
115
26
26
80
