Nordson Mesa Fulfill Reference guide

FulfillRetrofit for MesaMelters
Customer Product Manual
Part 1121938_02
Issued 5/13
NORDSON CORPORATION DULUTH, GEORGIA USA
www.nordson.com
This document contains important safety information
Be sure to read and follow all safety information in this
document and any other related documentation.
ATTENTION: Information on a new control box, PCA and level sensor is included in Appendix A.
Please refer to the Appendix if your unit was manufactured after May 2013. This information is found in the
serial code of your unit; for example, SA13EXXXXX, where “E” represents the date code “May,” or any se
quential letter after “E.”

Part 1121938_02 2013 Nordson Corporation
All rights reserved
For CE Declaration, refer to equipment documentation.
Nordson Corporation welcomes requests for information, comments, and inquiries about its products. General information
about Nordson can be found on the Internet using the following address: http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
11475 Lakefield Drive
Duluth, GA 30097
Notice
This is a Nordson Corporation publication which is protected by copyright. Original copyright date 2010.
Nopartofthisdocument may be photocopied, reproduced, or translated to another language without the prior written
consent of NordsonCorporation. Theinformationcontained in this publication is subject to change without notice.
Trademarks
AccuJet, AeroCharge, Apogee, AquaGuard, Asymtek, Automove, Baitgun, Blue Box, Bowtie, Build‐A‐Part, CanWorks, Century, CF, CleanSleeve,
CleanSpray, ColorMax, Color‐on‐Demand, ControlCoat, Coolwave, Cross‐Cut, cScan+, Dage, Dispensejet, DispenseMate, DuraBlue, DuraDrum, Durafiber,
DuraPail, Dura‐Screen, Durasystem, EasyCoat, Easymove Plus, Ecodry, Econo‐Coat, e.DOT, EFD, Emerald, Encore, ESP, e stylized, ETI‐stylized,
Excel 2000, Fibrijet, Fillmaster, FlexiCoat, Flex‐O‐Coat, Flow Sentry, Fluidmove, FoamMelt, FoamMix, Fulfill, GreenUV, HDLV, Heli‐flow, Horizon, Hot Shot,
iControl, iDry, iFlow, Isocoil, Isocore, Iso‐Flo, iTRAX, Kinetix, LEANCELL, LittleSquirt, LogiComm, Magnastatic, March, Maverick, MEG, Meltex, Microcoat,
Micromark, Micromedics, MicroSet, Millennium, MiniBlue, Mini Squirt, Mountaingate, NexJet, Nordson, Optimum, Package of Values, Pattern View,
PermaFlo, PicoDot, PorousCoat, PowderGrid, Powderware, Precisecoat, PRIMARC, Printplus, Prism, ProBlue, Prodigy, Pro‐Flo, ProLink, Pro‐Meter,
Pro‐Stream, RBX, Rhino, Saturn, Saturn with rings, Scoreguard, Seal Sentry, SelectCharge, SelectCoat, Select Cure, Signature, Slautterback, Smart‐Coat,
Solder Plus, Spectrum, Speed‐Coat, SureBead, Sure Coat, Sure‐Max, Sure Wrap, TrackingPlus, TRAK, Trends, Tribomatic, TrueBlue, TrueCoat,
Tubesetter, Ultra, UpTime, u‐TAH, Value Plastics, Vantage, VersaBlue, Versa‐Coat, VersaDrum, VersaPail, Versa‐Screen, Versa‐Spray, VP Quick Fit,
Watermark, and When you expect more. are registered trademarks of Nordson Corporation.
Accubar, Active Nozzle, Advanced Plasma Systems, AeroDeck, AeroWash, AltaBlue, AltaSlot, Alta Spray, Artiste, ATS, Auto‐Flo, AutoScan, Axiom,
Best Choice, Blue Series, Bravura, CanPro, Champion, Check Mate, ClassicBlue, Classic IX, CleanCoat, Cobalt, Controlled Fiberization, ControlWeave,
ContourCoat, CPX, cSelect, Cyclo‐Kinetic, DispensLink, Dry Cure, DuraBraid, DuraCoat, DuraPUR, Easy Clean, EasyOn, EasyPW, Eclipse, e.dot+,
E‐Nordson, Equalizer, EquiBead, FillEasy, FillSentry, Flow Coat, Fluxplus, Get Green With Blue, G‐Net, G‐Site, IntelliJet, iON, Iso‐Flex, iTrend,
Lacquer Cure, Maxima, Mesa, MicroFin, MicroMax, Mikros, MiniEdge, Minimeter, Multifill, MultiScan, Myritex, Nano, NexJet, OmniScan, OptiMix, OptiStroke,
Partnership+Plus, PatternJet, PatternPro, PCI, PharmaLok, Pinnacle, Plasmod, PowderPilot, Powder Port, Powercure, Process Sentry, Pulse Spray,
PURBlue, PURJet, Ready Coat, RediCoat, RollVIA, Royal Blue, SelectSeries, Sensomatic, Shaftshield, SheetAire, Smart, Smartfil, SolidBlue, Spectral,
SpeedKing, Spray Works, StediFlo, StediTherm, Summit, SureFoam, SureMix, SureSeal, SwirlCoat, TAH, ThruWave, TradePlus, Trilogy, Ultra FoamMix,
UltraMax, Ultrasaver, Ultrasmart, Universal, ValueMate, Versa, Vista, Web Cure, YESTECH, and 2Rings (Design) aretrademarks of NordsonCorporation.
Designations and trademarks stated in this document may be brands that, when used by third parties for their own purposes,
could lead to violation of the owners' rights.

Table of Contents i
Part 1121938_02
2013 Nordson Corporation
Fulfill)Retrofit for MesatMelters 1...........................
Safety 1......................................................
Safety Alert Symbols 1..........................................
Responsibilities of the Equipment Owner 2.........................
Safety Information 2..........................................
Instructions, Requirements, and Standards 2....................
User Qualifications 3.........................................
Applicable Industry Safety Practices 3............................
Intended Use of the Equipment 3...............................
Instructions and Safety Messages 4............................
Installation Practices 4........................................
Operating Practices 4........................................
Maintenance and Repair Practices 5...........................
Equipment Safety Information 5..................................
Equipment Shutdown 6.......................................
Relieving System Hydraulic Pressure 6.......................
De‐energizing the System 6.................................
Disabling the Applicators 6..................................
General Safety Warnings and Cautions 7........................
Other Safety Precautions 10....................................
First Aid 10...................................................
Safety Labels and Tags 11.......................................
Description 12.................................................
Theory of Operation 13.........................................
Overview 13....................................................
(1). Adhesive Storage Bin 14...................................
(2). Air Pressure Regulator/Solenoid Assembly 14................
(3). Suction Lance 15.........................................
(4). Adhesive Transfer Hose 15.................................
(5). Lid Assembly 15..........................................
Membrane Panel 16........................................
Electrical Components 16........................................
(6). Control Box 16...........................................
PCA 17...................................................
(7). Sensor (Not Shown) 18....................................
Installation 19.................................................
Prepare the Melter 19............................................
Install the Control Box 20.........................................
Install the Tank Lid Components 24................................
Assemble the Transfer Hose, Air Line, and Suction Lance 25..........
Level Sensor Adjustment and Calibration 26........................
Baseline Setting 27...........................................
Final Setting 27...............................................
Operation 28..................................................
Time Settings 28................................................
Monitoring Refill Operation 29.....................................

Table of Contents
ii
Part 1121938_02 2013 Nordson Corporation
Maintenance 29................................................
Troubleshooting 30............................................
Refill PCA Troubleshooting Diagnostic Instructions 31................
Parts 32.......................................................
Using the Illustrated Parts Lists 32.................................
Mesa Retrofit Kit Assemblies 33...................................
Ship With Fastener Kit 33........................................
Lid Assembly Parts 34.........................................
Control Assembly with Bracket 36...............................
Control Box Assembly 38......................................
Container/Wand Kit 40........................................
Service Kits 40..................................................
Accessories 40.................................................
Service Parts 40................................................
Specifications 41..............................................
Wiring Diagram 42..............................................
Dimensions 43.................................................
RetroFit Refill System with Nordson Level Sensor A‐1............
Sensor Features A‐1............................................
Wide Sensing Area A‐1.........................................
Simplified Mechanical Mounting A‐1..............................
Push Button Calibration A‐2.....................................
RTD Temperature Compensation A‐2.............................
Sensor Diagnostics A‐2.........................................
Unit Features A‐3.................................................
Delay Timer A‐4................................................
Overfill Fault Timer A‐4..........................................
Status Relay Contact Output A‐5.................................
Configuration Switch A‐6........................................
Sensor Calibration A‐8............................................
Calibration Summary A‐8........................................
Basic (Empty Level) Calibration A‐9...............................
Precision (Full Level) Calibration A‐9..............................
Troubleshooting A‐10.............................................
Fault LED/Red Status LED A‐10.....................................
Fill Enable LED/Yellow Status LED/Yellow Light Tower A‐11.............
Installation A‐12.................................................
Common Chassis Connection A‐12..................................
Service Parts A‐12...............................................
Retrofit Wiring Diagram A‐13........................................

FulfillRetrofit for MesaMelters 1
Part 1121938_02
2013 Nordson Corporation
FulfillRetrofit for MesaMelters
Safety
Read this section before using the equipment. This section contains
recommendations and practices applicable to the safe installation, operation,
and maintenance (hereafter referred to as “use”) of the product described in
this document (hereafter referred to as “equipment”). Additional safety
information, in the form of task‐specific safety alert messages, appears as
appropriate throughout this document.
WARNING! Failure to follow the safety messages, recommendations, and
hazard avoidance procedures provided in this document can result in
personal injury, including death, or damage to equipment or property.
Safety Alert Symbols
The following safety alert symbol and signal words are used throughout this
document to alert the reader to personal safety hazards or to identify
conditions that may result in damage to equipment or property. Comply with
all safety information that follows the signal word.
WARNING! Indicates a potentially hazardous situation that, if not avoided,
can result in serious personal injury, including death.
CAUTION! Indicates a potentially hazardous situation that, if not avoided,
can result in minor or moderate personal injury.
CAUTION! (Used without the safety alert symbol) Indicates a potentially
hazardous situation that, if not avoided, can result in damage to equipment or
property.

FulfillRetrofit for MesaMelters
2
Part 1121938_02 2013 Nordson Corporation
Responsibilities of the Equipment Owner
Equipment owners are responsible for managing safety information, ensuring
that all instructions and regulatory requirements for use of the equipment are
met, and for qualifying all potential users.
Safety Information
Research and evaluate safety information from all applicable sources,
including the owner‐specific safety policy, best industry practices,
governing regulations, material manufacturer's product information, and
this document.
Make safety information available to equipment users in accordance with
governing regulations. Contact the authority having jurisdiction for
information.
Maintain safety information, including the safety labels affixed to the
equipment, in readable condition.
Instructions, Requirements, and Standards
Ensure that the equipment is used in accordance with the information
provided in this document, governing codes and regulations, and best
industry practices.
If applicable, receive approval from your facility's engineering or safety
department, or other similar function within your organization, before
installing or operating the equipment for the first time.
Provide appropriate emergency and first aid equipment.
Conduct safety inspections to ensure required practices are being
followed.
Re‐evaluate safety practices and procedures whenever changes are
made to the process or equipment.

FulfillRetrofit for MesaMelters 3
Part 1121938_02
2013 Nordson Corporation
User Qualifications
Equipment owners are responsible for ensuring that users:
receive safety training appropriate to their job function as directed by
governing regulations and best industry practices
are familiar with the equipment owner's safety and accident
prevention policies and procedures
receive equipment and task‐specific training from another qualified
individual
NOTE: Nordson can provide equipment‐specific installation,
operation, and maintenance training. Contact your Nordson
representative for information
possess industry‐ and trade‐specific skills and a level of experience
appropriate to their job function
are physically capable of performing their job function and are not
under the influence of any substance that degrades their mental
capacity or physical capabilities
Applicable Industry Safety Practices
The following safety practices apply to the use of the equipment in the
manner described in this document. The information provided here is not
meant to include all possible safety practices, but represents the best safety
practices for equipment of similar hazard potential used in similar industries.
Intended Use of the Equipment
Use the equipment only for the purposes described and within the limits
specified in this document.
Do not modify the equipment.
Do not use incompatible materials or unapproved auxiliary devices.
Contact your Nordson representative if you have any questions on
material compatibility or the use of non‐standard auxiliary devices.

FulfillRetrofit for MesaMelters
4
Part 1121938_02 2013 Nordson Corporation
Instructions and Safety Messages
Read and follow the instructions provided in this document and other
referenced documents.
Familiarize yourself with the location and meaning of the safety warning
labels and tags affixed to the equipment. Refer to Safety Labels and Tags
at the end of this section.
If you are unsure of how to use the equipment, contact your Nordson
representative for assistance.
Installation Practices
Install the equipment in accordance with the instructions provided in this
document and in the documentation provided with auxiliary devices.
Ensure that the equipment is rated for the environment in which it will be
used. This equipment has not been certified for compliance with the
ATEX directive nor as nonincendive and should not be installed in
potentially explosive environments.
Ensure that the processing characteristics of the material will not create a
hazardous environment. Refer to the Material Safety Data Sheet (MSDS)
for the material.
If the required installation configuration does not match the installation
instructions, contact your Nordson representative for assistance.
Position the equipment for safe operation. Observe the requirements for
clearance between the equipment and other objects.
Install lockable power disconnects to isolate the equipment and all
independently powered auxiliary devices from their power sources.
Properly ground all equipment. Contact your local building code
enforcement agency for specific requirements.
Ensure that fuses of the correct type and rating are installed in fused
equipment.
Contact the authority having jurisdiction to determine the requirement for
installation permits or inspections.
Operating Practices
Familiarize yourself with the location and operation of all safety devices
and indicators.
Confirm that the equipment, including all safety devices (guards,
interlocks, etc.), is in good working order and that the required
environmental conditions exist.
Use the personal protective equipment (PPE) specified for each task.
Refer to Equipment Safety Information or the material manufacturer's
instructions and MSDS for PPE requirements.
Do not use equipment that is malfunctioning or shows signs of a potential
malfunction.

FulfillRetrofit for MesaMelters 5
Part 1121938_02
2013 Nordson Corporation
Maintenance and Repair Practices
Allow only personnel with appropriate training and experience to operate
or service the equipment.
Perform scheduled maintenance activities at the intervals described in
this document.
Relieve system hydraulic and pneumatic pressure before servicing the
equipment.
De‐energize the equipment and all auxiliary devices before servicing the
equipment.
Use only new Nordson‐authorized refurbished or replacement parts.
Read and comply with the manufacturer's instructions and the MSDS
supplied with equipment cleaning compounds.
NOTE: MSDSs for cleaning compounds that are sold by Nordson are
available at www.nordson.com or by calling your Nordson representative.
Confirm the correct operation of all safety devices before placing the
equipment back into operation.
Dispose of waste cleaning compounds and residual process materials
according to governing regulations. Refer to the applicable MSDS or
contact the authority having jurisdiction for information.
Keep equipment safety warning labels clean. Replace worn or damaged
labels.
Equipment Safety Information
This equipment safety information is applicable to the following types of
Nordson equipment:
hot melt and cold adhesive application equipment and all related
accessories
pattern controllers, timers, detection and verification systems, and all
other optional process control devices

FulfillRetrofit for MesaMelters
6
Part 1121938_02 2013 Nordson Corporation
Equipment Shutdown
To safely complete many of the procedures described in this document, the
equipment must first be shut down. The level of shut down required varies by
the type of equipment in use and the procedure being completed.
If required, shut down instructions are specified at the start of the procedure.
The levels of shut down are:
Relieving System Hydraulic Pressure
Completely relieve system hydraulic pressure before breaking any hydraulic
connection or seal. Refer to the melter‐specific product manual for
instructions on relieving system hydraulic pressure.
De‐energizing the System
Isolate the system (melter, hoses, applicators, and optional devices) from all
power sources before accessing any unprotected high‐voltage wiring or
connection point.
1. Turn off the equipment and all auxiliary devices connected to the
equipment (system).
2. To prevent the equipment from being accidentally energized, lock and
tag the disconnect switch(es) or circuit breaker(s) that provide input
electrical power to the equipment and optional devices.
NOTE: Government regulations and industry standards dictate specific
requirements for the isolation of hazardous energy sources. Refer to the
appropriate regulation or standard.
Disabling the Applicators
NOTE: Adhesive dispensing applicators are referred to as “guns” in some
previous publications.
All electrical or mechanical devices that provide an activation signal to the
applicators, applicator solenoid valve(s), or the melter pump must be
disabled before work can be performed on or around an applicator that is
connected to a pressurized system.
1. Turn off or disconnect the applicator triggering device (pattern controller,
timer, PLC, etc.).
2. Disconnect the input signal wiring to the applicator solenoid valve(s).
3. Reduce the air pressure to the applicator solenoid valve(s) to zero; then
relieve the residual air pressure between the regulator and the applicator.

FulfillRetrofit for MesaMelters 7
Part 1121938_02
2013 Nordson Corporation
General Safety Warnings and Cautions
Table 1 contains the general safety warnings and cautions that apply to
Nordson hot melt and cold adhesive equipment. Review the table and
carefully read all of the warnings or cautions that apply to the type of
equipment described in this manual.
Equipment types are designated in Table 1 as follows:
HM = Hot melt (melters, hoses, applicators, etc.)
PC = Process control
CA = Cold adhesive (dispensing pumps, pressurized container, and
applicators)
Table 1 General Safety Warnings and Cautions
Equipment
Type Warning or Caution
HM
WARNING! Hazardous vapors! Before processing any polyurethane
reactive (PUR) hot melt or solvent‐based material through a compatible
Nordson melter, read and comply with the material's MSDS. Ensure
that the material's processing temperature and flashpoints will not be
exceeded and that all requirements for safe handling, ventilation, first
aid, and personal protective equipment are met. Failure to comply with
MSDS requirements can cause personal injury, including death.
HM
WARNING! Reactive material! Never clean any aluminum component
or flush Nordson equipment with halogenated hydrocarbon fluids.
Nordson melters and applicators contain aluminum components that
may react violently with halogenated hydrocarbons. The use of
halogenated hydrocarbon compounds in Nordson equipment can
cause personal injury, including death.
HM, CA WARNING! System pressurized! Relieve system hydraulic pressure
before breaking any hydraulic connection or seal. Failure to relieve the
system hydraulic pressure can result in the uncontrolled release of hot
melt or cold adhesive, causing personal injury.
Continued...

FulfillRetrofit for MesaMelters
8
Part 1121938_02 2013 Nordson Corporation
General Safety Warnings and Cautions (contd)
Table 1 General Safety Warnings and Cautions (contd)
Equipment
Type Warning or Caution
HM
WARNING! Molten material! Wear eye or face protection, clothing that
protects exposed skin, and heat‐protective gloves when servicing
equipment that contains molten hot melt. Even when solidified, hot melt
can still cause burns. Failure to wear appropriate personal protective
equipment can result in personal injury.
HM, PC
WARNING! Equipment starts automatically! Remote triggering devices
are used to control automatic hot melt applicators. Before working on
or near an operating applicator, disable the applicator's triggering
device and remove the air supply to the applicator's solenoid valve(s).
Failure to disable the applicator's triggering device and remove the
supply of air to the solenoid valve(s) can result in personal injury.
HM, CA, PC
WARNING! Risk of electrocution! Even when switched off and
electrically isolated at the disconnect switch or circuit breaker, the
equipment may still be connected to energized auxiliary devices.
De‐energize and electrically isolate all auxiliary devices before
servicing the equipment. Failure to properly isolate electrical power to
auxiliary equipment before servicing the equipment can result in
personal injury, including death.
HM, CA, PC
WARNING! Risk of fire or explosion! Nordson adhesive equipment is
not rated for use in explosive environments and has not been cerfified
for the ATEX directive or as nonincendive. In addition, this equipment
should not be used with solvent‐based adhesives that can create an
explosive atmosphere when processed. Refer to the MSDS for the
adhesive to determine its processing characteristics and limitations.
The use of incompatible solvent‐based adhesives or the improper
processing of solvent‐based adhesives can result in personal injury,
including death.
HM, CA, PC
WARNING! Allow only personnel with appropriate training and
experience to operate or service the equipment. The use of untrained
or inexperienced personnel to operate or service the equipment can
result in injury, including death, to themselves and others and can
damage to the equipment.

FulfillRetrofit for MesaMelters 9
Part 1121938_02
2013 Nordson Corporation
Warning or Caution
Equipment
Type
HM
CAUTION! Hot surfaces! Avoid contact with the hot metal surfaces of
applicators, hoses, and certain components of the melter. If contact
can not be avoided, wear heat‐protective gloves and clothing when
working around heated equipment. Failure to avoid contact with hot
metal surfaces can result in personal injury.
HM
CAUTION! Some Nordson melters are specifically designed to
process polyurethane reactive (PUR) hot melt. Attempting to process
PUR in equipment not specifically designed for this purpose can
damage the equipment and cause premature reaction of the hot melt. If
you are unsure of the equipment's ability to process PUR, contact your
Nordson representative for assistance.
HM, CA
CAUTION! Before using any cleaning or flushing compound on or in
the equipment, read and comply with the manufacturer's instructions
and the MSDS supplied with the compound. Some cleaning
compounds can react unpredictably with hot melt or cold adhesive,
resulting in damage to the equipment.
HM
CAUTION! Nordson hot melt equipment is factory tested with Nordson
Type R fluid that contains polyester adipate plasticizer. Certain hot melt
materials can react with Type R fluid and form a solid gum that can
clog the equipment. Before using the equipment, confirm that the hot
melt is compatible with Type R fluid.

FulfillRetrofit for MesaMelters
10
Part 1121938_02 2013 Nordson Corporation
Other Safety Precautions
Do not use an open flame to heat hot melt system components.
Check high pressure hoses daily for signs of excessive wear, damage, or
leaks.
Never point a dispensing handgun at yourself or others.
Suspend dispensing handguns by their proper suspension point.
First Aid
If molten hot melt comes in contact with your skin:
1. Do NOT attempt to remove the molten hot melt from your skin.
2. Immediately soak the affected area in clean, cold water until the hot melt
has cooled.
3. Do NOT attempt to remove the solidified hot melt from your skin.
4. In case of severe burns, treat for shock.
5. Seek expert medical attention immediately. Give the MSDS for the hot
melt to the medical personnel providing treatment.

FulfillRetrofit for MesaMelters 11
Part 1121938_02
2013 Nordson Corporation
Safety Labels and Tags
Figure 1 illustrates the location of the product safety labels and tags affixed to
the equipment. Table 2 provides an illustration of the hazard identification
symbols that appear on each safety label and tag, the meaning of the
symbol, or the exact wording of any safety message.
1
Figure 1 Safety labels and tags
Table 2 Safety Labels and Tags
Item Part Description
1. 1021984
WARNING! Hazardous voltage. Disconnect all power supply
connections before servicing.

FulfillRetrofit for MesaMelters
12
Part 1121938_02 2013 Nordson Corporation
Description
The Mesa Fulfill Retrofit Kit converts a Mesa melter into an automatic fill
system that maintains adhesive in the melter, improving productivity and
reducing maintenance. The retrofit kit adds adhesive to the sealed tank,
reducing the possibility of char, contaminants, thermal shock and incorrect
adhesive temperatures that result in poor adhesive bonding.
The Fulfill system is shipped with the components illustrated in Figure 2.
23
1
6
7
5
4
8
Figure 2Fulfill system components
1. Adhesive storage bin
2. Transfer hose
3. Suction lance
4. Control box and mounting bracket
with level sensor, filter-regulator w/
gauge, and solenoid
5. Hose clamp (2)
6. Air line (4m)
7. Wire tie (5)
8. Lid assy
Optional accessories available for the Fulfill Retrofit include:
a vibrator kit for the adhesive storage bin
a remote mount kit
a light tower kit for audio/visual fill/fault indication of the Fulfill processes.
Contact your Nordson representative for more information on these kits.

FulfillRetrofit for MesaMelters 13
Part 1121938_02
2013 Nordson Corporation
Theory of Operation
NOTE: Refer to Appendix A, Retrofit Refill System With Nordson Level Sensor, for updated
information.
Overview
The system adds small quantities of adhesive to the sealed tank at regular
intervals, reducing the possibility of adhesive char, contaminants, thermal
shock and incorrect adhesive temperatures that result in poor bonding.
A capacitance sensor located in the melter detects low adhesive level, and
then sends a signal to the system control. A delay timer prevents the fill
system from frequently cycling on and off.
At the end of the delay the control activates the vacuum via a solenoid valve.
Air pressure flows to a suction lance that is placed in the supplied bulk
adhesive container. Using vacuum, the system conveys adhesive from the
bulk container to the adhesive melter tank.
The controller activates the suction lance for a limited amount of time to
prevent over‐fill conditions. If the maximum fill time is exceeded, the
controller activates a fault that stops the system from filling.

FulfillRetrofit for MesaMelters
14
Part 1121938_02 2013 Nordson Corporation
Pneumatic & Mechanical Components
Refer to Figure 3 as you learn about the components of the Mesa Fulfill
retrofit assembly.
1
2
3
45
6
Figure 3Assembled Mesa Fulfill retrofit assembly.
(1). Adhesive Storage Bin
Place adhesive in the adhesive storage bin. The bin contains a gasket that
prevents debris from entering the bin. For best results, break up the
adhesive as much as possible when emptying into the bin. Do not get the
adhesive wet.
(2). Air Pressure Regulator/Solenoid Assembly
The supplied air pressure regulator is permanently set at 65 psig, the optimal
setting for most adhesives.
The solenoid valve turns on after the sensor indicates level state and the time
delay has been reached. The solenoid directs compressed air to flow to the
suction lance.

FulfillRetrofit for MesaMelters 15
Part 1121938_02
2013 Nordson Corporation
(3). Suction Lance
The suction lance draws adhesive from the adhesive storage bin. The
suction lance includes:
A venturi pump to draw in and transport the adhesive.
A vibrator to keep the adhesive in loose condition. The vibrator is active
as long as compressed air is supplied to the suction lance.
Air line tubing and the adhesive transfer hose are connected to the suction
lance. The lance is placed in the PVC pipe located in the adhesive storage
bin.
(4). Adhesive Transfer Hose
The adhesive transfer hose connects the suction lance to the lid assembly.
The transfer hose conveys adhesive from the adhesive storage bin to the
melter tank.
(5). Lid Assembly
The lid assembly includes the filter stack, lid, fill tube, baffle and deflector:
The filter stack contains a replaceable filter sock to prevent adhesive
fines and talc/powder in the adhesive from being emitted into the ambient
air.
The fill tube attaches to the adhesive transfer hose.
The baffle prevents adhesive from entering the filter sock.
The deflector distributes adhesive evenly in the tank.
The thumb screws mount the lid to the melter. The thumbscrews can be
replaced by Allen head screws supplied in the ship with kit. Do not remove
the lid during operation, unless the system is disabled by turning power off at
the control box.

FulfillRetrofit for MesaMelters
16
Part 1121938_02 2013 Nordson Corporation
Electrical Components
NOTE: Refer to Appendix A, Retrofit Refill System With Nordson Level Sensor, for updated
information.
(6). Control Box
The control box contains the membrane panel and PCA. It connects to the
melter via the supplied bracket. An optional remote mount kit is available to
mount the control box away from the melter.
Membrane Panel
The front panel of the electrical control box shown in Figure 4 contains three
LEDs that have different colored lights to indicate the unit condition:
Enable LED (green light) - Indicates that the system is enabled.
Pressing the Enable button will toggle the indicator.
Enable button - Press the enable button to turn the fill system on or
off.
Adhesive transfer LED (blue light) - Indicates adhesive delivery is
active. When a low level is detected, the indicator notes that
adhesive is being transferred from the adhesive storage bin into the
melter tank through the transfer hose.
Fault LED (red light) - activates if the system exceeds the user
defined fill time limit. The system will not resume operation until the
fault is cleared with the clear fault button.
Clear fault button - Press the clear fault button to reset fault and
resume normal activity.
123
4
Figure 4Fill system controls and indicators
1. Enable On/Off
2. Filling activated symbol and blue LED
3. Fault symbol and red LED
4. Clear fault
