USER INSTRUCTIONS
OVER-BED / CHAIR TABLE
M01278 Over Bed / Chair Table (No Castors) M15691 Over Bed / Chair Table (Castors)
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
1. INTENDED USE
Designed for use when sitting in either a chair or bed
these tables provide an adjustable height flat surface
for reading, writing, eating etc. The table top can be
tilted for increased comfort during use.
2. SAFETY
Warning: Do not overload the table top, 5kg
Max Load.
CHECK hand-wheels are secure at regular intervals.
DO NOT attempt to use the table as a walking aid.
DO NOT attempt to sit or stand on the table.
3. UNPACKING
Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
3.1 Contents:
1. Table Leg with Castors (M15691) x 2
2. Table Leg without Castors (M01278) x 2
3. Cross Bar (with Castors) x 1
4. Telescopic Tube x 1
5. Hand-wheel - Long-screw x 2
6. Hand-wheel - Short-screw x 2
4. ASSEMBLY/INSTALLATION
4.1 Frame Assembly:
1. Refer to Figure 1. Position the cross brace over
the two side frames as shown.
Figure 1: Assemble the Cross Brace
2. Use the 2 x long-screw hand-wheels to secure
the cross brace to the side frames.
4.2 Table-top Assembly:
1. Turn the table top upside down and lay flat.
Note: The table-top brackets are set at different
distances from the table-top edges.
2. Slide the two silver telescopic tubes through the
first set of brackets closest to the edge of the
table-top.
A
Figure 2: Assembling the Table-top
3. Press in the button clips (A), then slide the
telescopic tubes all the way through the first set
of brackets.

2
4. Slide the telescopic tube through the second set
of table-top brackets.
Figure 3: Assembling the Table-top
5. Refer to Figure 3. Push in the first telescopic
tube button clip, then slide the tube through
the bracket until the button clip clicks back into
place.
6. Repeat step 5 for the second telescopic tube.
4.3 Connect the Table Top to the Base:
1. Refer to Figure 1. Slide the telescopic tubes
into the open ends of the two side frames and
secure with the two short-screw hand-wheels.
5. IN USE
5.1 Adjust the Height
Loosen both of the hand-wheels at the top of the two
black side frames by turning anti-clockwise.
Lift the table top up or push down gently to move it to
the required height.
Tighten the two hand-wheels by turning clockwise to
secure in position.
5.2 Adjust the Angle
Note: The table top can be tilted towards the user to
a maximum of 45°.
Loosen the hand-wheel at the top of the black side
frame furthest away from the user.
Lift the far edge of the table top or push down gently
to increase/decrease the angle of tilt.
Tighten the two hand-wheels by turning clockwise to
secure in position.
5.3 Operating the Brakes
The ‘rear’ 2 castors are fitted with brakes.
To apply: firmly push the brake lever down until it
clicks into position.
To release: lift the brake lever up until the castor is
free to rotate.
6. MAINTENANCE
Check castors are securely fitted and are free to
rotate. Remove any build-up of dirt/debris.
Check the height and tilt adjustment operates
correctly and the hand wheels are tight.
Inspect product regularly for signs of wear. Any
suspected faults or damage should immediately be
reported to the supplier and the product taken out of
use.
7. CLEANING INSTRUCTIONS.
Clean regularly using a general purpose, neutral
detergent and warm water.
Please check the suitability of the cleaning products
before use. Do not use abrasive cleaners or cloths
as these could permanently damage the surface and
invalidate any warranty.
Allow product to fully dry prior to use/storage.
Always check local authority guidelines for additional
advice regards cleaning healthcare products.
8. PRODUCT DISPOSAL
This product must be thoroughly cleaned/sterilised
prior to disposal.
This product is manufactured from metal, plastic and
wood and can be disposed of through Local Authority
Household Waste and Recycling Centres or through
Local Trade Waste Collectors.
9. PRODUCT GUARANTEE
NRS Healthcare guarantee this product for a period
of 12 months, from the date of purchase, against
faulty materials and workmanship.
This guarantee does not cover; abuse, misuse,
interference or tampering with any part of the
product.
Any guarantee issued by NRS Healthcare does not
affect your statutory rights.
