NSK EX Series User manual

-1-
SM-C0028_E
SERVICE MANUAL
For
EX series Handpieces
EC-30 / E4R / E10R / E16R / E20RI / E64R etc

-2-
Notice
The photograph in the manual is a different product. But the design is only different.
Please advance it according to the following procedure.
1. TOOLS REQUIRED
T-2（Pliers）
Emery Cloth Stick etc

-3-
2. DISASSEMBLY PROCEDURE
Caution
Disassemble on a tray to prevent losing parts.
In case of EC-30
2-1 Removal of Sheath
Protect the Sheath and the ElbowAss’y with Emery Cloth, turn counterclockwise with T-2 to remove the Sheath.
Elbow Ass’y
Drive Shaft Ass’y
Sheath

-4-
In case of E4R / E10R / E16R / E20RI / E64R etc
2-2 Removal of the Rear Joint
Protect the Sheath and the Rear Joint with Emery Cloth, turn counterclockwise with T-2 to remove the Sheath.
2-3 Removal of the Dog Clutch Shaft Ass’y
2-3 Removal of the Reduction Gear Ass’y
Push the the Reduction GearAss’y with Stick etc.
Please refer to the part list for the more detailed disassembly.

-5-
3. REASSEMBLY PROCEDURE
Reverse the procedure for disassembly.
