NSK Endo-Mate TC2 User manual

OPERATION MANUAL
Please read this Operation Manual carefully
before use, and file for future reference.
OM-E0390E 001
Cordless Handpiece
The EU directive 93/42/EEC was applied in the design and production of this medical device.
2013.02.20 02 B

OPERATION MANUAL
Cordless Handpiece
English

English
1
Classification of Devices
Classification by type of protection against electric shock:
— Class II devices
Classification by degree of protection against electric shock:
— Applied part type B
Classification by sterilization or disinfection method allowed by the manufacturer:
— Refer to Sterilization.
Classification by mode of operation:
— Continuously operating device
Thank you for purchasing the ENDO-MATE TC2.
Read this Operation Manual carefully before use for operation instructions and care and
maintenance guidelines. Keep this Operation Manual for future reference.
Application
This product is a cordless handpiece used primarily for root canal enlargement.
User
Only qualified personal is allowed to use the unit only in dentistry.
Prohibition
Do not use this motor handpiece for formation of an extremely bent root canal. Do not use this
for implants other than endodontic treatment or other dental treatment.
Guidance and manufacturer's declaration - electromagnetic emissions
The ENDO-MATE TC2 is intended for use in the electromagnetic environment specified below. The
customer or the user of the ENDO-MATE TC2 should assure that is used in such an environment.
Emissions test Compliance Electromagnetic environment - guidance
RF emissions
CISPR11
RF emmissions
CISPR11
Harmonic emissions
IEC61000-3-2
Voltage fluctuations/
flicker emissions
IEC61000-3-3
Group 1
class B
class A
Complies
The ENDO-MATE TC2 uses RF energy only for
its internal function. Therefore, its RF emissions
are very low and are not likely to cause any
interference in nearby electronic equipment.
The ENDO-MATE TC2 is suitable for use in
all establishments, including domestic
estabilishments and those directly connected
to the public low-voltage power supply
network that supplynetwork that spplies
buidings used for domestic purposes.

English
2 3
Guidance and manufacturer's declaration - electromagnetic immunity
The ENDO-MATE TC2 is intended for use in the electromagnetic environment specified below. The
customer or the user of the ENDO-MATE TC2 should assure that it is used in such an environment.
NOTE: Ut is the a.c. mains voltage prior to application of the test level.
Immunity test IEC60601 test level Electromagnetic environment - guidance
Electrostatic
discharge (ESD)
IEC61000-4-2
Electrical fast
transient/burst
IEC61000-4-4
Surge
IEC61000-4-5
Voltage dips,
short
interruptions and
voltage variations
on power supply
input lines
IEC61000-4-11
Power frequency
(50/60Hz)
magnetic field
IEC61000-4-8
±6kV contact
±8kV air
±2kV for power
supply lines
±1kV for
input/output
±1kV line(s) to line(s)
±2kV line(s) to earth
<5% Ut
(>95% dip in Ut)
for 0.5 cycle
40% Ut
(60% dip in Ut)
for 5 cycles
70% Ut
(30% dip in Ut)
for 25 cycles
<5% Ut
(>95% dip in Ut)
for 5 secs
3 A/m
Compliance level
±6kV contact
±8kV air
±2kV for power
supply lines
±1kV line to line
±2kV lines to earth
<5% Ut
(>95% dip in Ut)
for 0.5 cycle
40% Ut
(60% dip in Ut)
for 5 cycles
70% Ut
(30% dip in Ut)
for 25 cycles
<5% Ut
(>95% dip in Ut)
for 5 sec
3 A/m
Floors should be wood, concrete
or ceramic tile. If floors are covered
with synthetic material, the relative
humidity should be at least 30%.
Mains power quality should be that
of a typical commercial or hospital
en
vironment.
Mains power quality should be that
of a typical commercial or hospital
environment.
Mains power quality should be that
of a typical commercial or hospital
environment. If the user of the
ENDO-MATE TC2 requires
continued operation during power
mains interruptions, it is
recommended that the ENDO-MATE
TC2 be powered from an
uninterruptible power supply or a
battery.
Power frequency magnetic fields
should be at levels characteristic of a
typical location in a typical
commercial or hospital environment.
Guidance and manufacturer's declaration - electromagnetic immunity
The ENDO-MATE TC2 is intended for use in the electromagnetic environment specified below. The
customer or the user of the ENDO-MATE TC2 should assure that it is used in such an environment.
NOTE 1 At 80MHz and 800MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects and people.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones
and land mobiles radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be
predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in
the location in which the ENDO-MATE TC2 is used exceeds the applicable RF compliance level
above, the ENDO-MATE TC2 should be observed to verity normal operation. If abnormal
performance is observed, additional measures may be necessary, such as reorienting or relocating
the ENDO-MATE TC2.
b Over the frequency range 150kHz to 80MHz, field strengths should be less than 3 V/m.
Immunity test
IEC60601 test level Electromagnetic environment - guidance
Conducted RF
IEC61000-4-6
Radiated RF
IEC61000-4-3
3Vrms
150 kHz to 80MHz
3V/m
80MHz to 2.5 GHz
Compliance level
3Vrms
3V/m
Portable and mobile FRO
communications equipment should be
used no closer to any part of the
ENDO-MATE TC2, including cables,
than the recommended separation
distance calculated from the equation
applicable to the frequency of the
transmitter.
Recommended separation distance
d= 1.2 P
d= 1.2 P80MHz to 800MHz
d= 2.3 P800MHz to 2.5GHz
Where Pis the maximum output power
rating of the transmitter in watts (W)
according to the transmitter
manufacturer and dis the
recommended separation distance in
meters (m).
Field strengths from fixed RF
transmitters as determined by an
electromagnetic site survey, should be
less than the compliance level in each
frequency range.
Interference may occur in the vicinity of
equipment marked with the following
symbol:

English
- - - - - - - - - - - - - - - - - - - - - - 5
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 20
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 21
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 21
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 24
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 25
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 27
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 27
150kHz to 80MHz
d=1.2 P
4 5
CONTENTS
Cautions for handling and operation
1. FEATURES
2. SPECIFICATION
3. Name of each part
4. Parts and its function
5. Operations
6. Convenient Function
7. Cleaning
8. Sterilization
9. Motor Cap
10. Safety System
11. Changing Batteries
12. Error Code
13. Troubleshooting
14. Warranty
15. Disposing Product
Recommended separation distances between portable and mobile RF communications
equipment and the ENDO-MATE TC2
The ENDO-MATE TC2 is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer or the user of the ENDO-MATE TC2 can help prevent
electromagnetic interference by maintaining a minimum distance between portable and mobile RF
communications equipment (transmitters) and the ENDO-MATE TC2 as recommended below,
according to the maximum output power of the communications equipment.
For transmitters rated at a maximum output power not listed above, the recommended separation
distance d in meters (m) can be estimated using the equation applicable to the frequency of the
transmitter, where Pis the maximum output power rating of the transmitter in watts (W) according
to the transmitter manufacturer.
Rated maximum output
power of transmitter
W
0.01
800MHz to 2.5GHz
d=2.3 P
80MHz to 800MHz
d=1.2 P
0.12 0.230.12
0.1 0.38 0.730.38
1 1.2 2.31.2
10 3.8 7.33.8
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations.
Electromagnetic propagation is affected by absorption and reflection from structures, objects and
people.
100 12 2312
Separation distance according to frequency of transmitter
m
Cautions for handling and operation
Read these safety cautions thoroughly before use and operate the product properly.
These indicators are to allow you to use the product safely and prevent danger and harm to
you and others. These are classified by degree of danger, damage and seriousness. All
indicators concern safety, therefore always follow them.
Degree of danger or damage and seriousness
Explains an instruction where death or serious injury may occur.
Explains an instruction where bodily injury or damage to device may
occur.
Explains an instruction where possibility for minor to medium bodily
injury or damage to device may exist.
Explains an instruction that should be observed for safety reasons.
Classification
DANGER
WARNING
CAUTION
NOTICE

English
6 7
• Use the specified batteries for this product. Never use any other batteries than those that
NSK specifies.
• This product is designed specifically for use with rechargeable batteries. Do not use
manganese or alkaline batteries. Using and charging these by error may cause a fluid leak
or explosion.
• Always replace both batteries with the same type at the same time. Using batteries of
different-types or an exhausted battery with a fully charged one may cause a fluid leak or
explosion.
DANGER
• This product is Medical Electrical equipment. EMC (Electromagnetic compatibility) is
described in the accompanying documentation.
• Portable and mobile RF communications equipment can affect Medical Electrical
equipment. Do not use RF equipment outskirts for the product.
• If the handpiece has not been used for long period of time, check it before use to perform
correctly.
• Do not handle the power cord with wet hands. Failure to do so may result in an electric
shock.
• Do not spill water or a chemical solution onto or into the motor handpiece or battery
charger. Failure to do so may result in fire or electric shock due to a short-circuit or
breakage due to rust formation.
• Do not disassemble or alter the motor handpiece.
• Do not drop the motor handpiece or battery charger. Place the battery charger on a flat
and stable surface.
• Should the battery fluid leak and get into your eyes, immediately wash eyes thoroughly with
clean water and see your doctor. Failure to do so may result in loss of sight.
• Should the battery fluid leak and adhere to skin or clothing, immediately wash the exposed
skin thoroughly with clean water and completely wash away the fluid. Failure to do so may
result in skin irritation.
• If you notice a battery fluid leak within the motor handpiece, deformation of the motor
handpiece casing or partial discoloring, immediately stop use and contact your dealer.
• If you will not use the product for a long period of time, remove the batteries to avoid a fluid
leak.
• Do not charge the handpiece without battery.
• Be careful not to drop conductive parts such as wires and safety pins into the charging
terminal area of the battery charger.
• To charge the motor handpiece, only use a dedicated genuine NSK charger. Never charge
this handpiece with a charger other than the genuine NSK charger.
• When inserting the motor handpiece into the charger, check that the alarm sounds and the
LED indicate charging (animation for remaining battery capacity). Unless charging is
indicated, this function is not performed and burns may result by heat generation or liquid
leakage may result, therefore, stop use and contact your dealer.
WARNING
• Exercise sufficient care in using the product by giving patient safety first priority.
• The product is to be used for dental treatment only by qualified personnel.
• Use commercially available batteries as specified by NSK. Read the instruction manual
included by the battery manufacturer thoroughly before use.
• Do not use a bent, damaged, deformed or non-ISO-conforming file. Using such a file may
result in personal injury due to its sudden breakage or flying off during rotation.
• Do not use or leave the product in a high-temperature environment such as under strong
direct sunlight, in a car under a blazing sun, by a fire or near a stove.
• Check the product before use, pay attention to looseness, vibration, noise and temperature
(heat generation). If any abnormal condition is found even slightly at that time, immediately
stop use and contact your dealer.
• Always clean the shank of the file to be installed. Allowing dirt to enter the chuck could
cause loss of concentricity and deterioration of chucking force.
• Before changing the head or file, turn off the power of the motor handpiece. Changing with
the power on may cause unintended rotation by accidental activation of the ON/OFF
switch.
• When inserting the motor handpiece into the battery charger, position the handpiece
correctly. Pushing it into the charger forcibly in the incorrect orientation may cause
damage.
• Do not lubricate the motor handpiece. Only lubricate the head and shank.
• Do not heat sterilize the motor handpiece. Do not autoclave the motor handpiece.
• If you are using corrosive or harsh solutions please clean the motor handpiece etc.,
immediately after use. Failure to quickly clean the motor handpiece etc., can result in
damage to the equipment or color changes of the outer casing.
• Do not reverse positive (+) and negative (-) when fitting the batteries.
• Do not throw the batteries into fire as the batteries will rupture, resulting in an accident.
• This equipment is for indoor use only.
• Observe the allowable rotation speed which the file manufacturer specifies for use.
• The motor handpiece has an electronic circuit (TORQUE LIMITER Function) to prevent files
from breaking; however, files may still break due to metal fatigue if the torque is
conditioned to be higher.
CAUTION

English
Battery charger
Power cord
Contra Angle Handpiece
(Included in the MP-F16R SET) F-type spray nozzle Motor cap
Motor Handpiece
8 9
2. Specification
• Ergonomic design and compact body.
• “6 position type head” allows direction of contra angle head to be changed and the ON/OFF
key to be set to a position where it can be easily activated.
• The larger ON/OFF key enhances operability (compared with conventional products).
• Operates continuously for approx. 1.2 hour at rated load. (Dependent upon use conditions.)
• The liquid crystal panel enhances user friendliness.
• Memory for up to 5 programs .
• The auto reverse function is activated depending on the load. A wide variety of functions such
as “AUTO REVERSE”, “AUTO STOP” and “AUTO REVERSE OFF” are available.
• The motor handpiece can be turned on and off by pressing the ON/OFF key. Alternatively the
unit can be operated by holding down the ON/OFF key during operation and letting go of the
ON/OFF key to stop the handpiece.
• The motor handpiece softly starts. Since the rotation briefly stops before changing direction
there are no vibrations and shocks during the change of directions.
• Energy saving. The power of the motor handpiece automatically turns off when there are no
operations for 10 minutes. (Auto power-off function)
• The feedback circuit, which keeps rotation at a constant speed even when the load on the
motor handpiece changes, is built in.
• Non-contact charger prevents improper charging due to deterioration of metallic terminal.
•
In spite of non-contact charging, this has realized rapid charging, shortening the time for charging.
• The contra angle heads provided for this product are all autoclavable at 135ºC (excluding the
motor handpiece).
1. Features
3. Name of each part
Symbols
This conforms to CE European Directive of “Medical equipment directive 93/42/EEC.”
TUV Rhineland of North America is a Nationally Recognized Testing Laboratory (NRTL) in
the United States and is accredited by the Standards Council of Canada to certify
electro-medical products with Canadian National Standards.
Follow the waste of electric and electronic equipment (WEEE) Directive (2002/96/CE) to
dispose of the product and accessories.
Class II equipment
• The motor handpiece is designed for commercially available AAA nickel metal hydride
batteries (rechargeable).
• The motor handpiece consumes electricity very slightly even when the power is off. In
addition, fully-charged rechargeable batteries, in general, discharge gradually over time
even though it is not used. It is recommended to recharge the batteries just before use.
• When the motor handpiece automatically stops by detecting a low battery voltage, leaving
it for a while and turning on the power again may not detect the low voltage immediately.
This is not a failure, but due to battery characteristics. Since the voltage drop does not
coincide with the remaining battery capacity, consider it only as a yardstick.
•
Recharge rechargeable batteries after they deplete as much as possible. Repeating short
time use and subsequent recharging may shorten their operating time due to a “memory
effect.” Batteries may recover from the memory effect after fully discharging and then fully
charging and repeating this procedure a few times.
• Eventually completely discharged batteries cannot be charged and need to be replace with
new ones.
• User shall be responsible for operation, maintenance and inspection.
• No special training is required for this device.
NOTICE
Refer to the Operation Manual.
Type B conforming component
Manufacturer
Battery Charger
Model
Input Voltage
Input Power
Charging Time
NE233
AC120/240V±10%
50/60Hz
15VA
Approx. 90 min.
Motor Handpiece
Model
Input Voltage
Input Power
EM10M2
DC2.4V±20%
0.3VA
Use environment
Temperature
Humidity
Atmospheric pressure
10 - 40 ˚C
10 - 75 %
(Non condensing)
700-1060 hPa
Store environment
Temperature
Humidity
Atmospheric pressure
-10 - 50 ˚C
10 - 80 %
(Non condensing)
500-1060 hPa

English
*Speed = Rotation speed
of the file
<Operation Panel Details>
• POWER Key
- Holding down the POWER key for more than one second turns on the power and the LCD
panel lights.
- Holding down the POWER key for more than one second while the power is on. The power
and the LCD panel turns off.
• ON/OFF Key
Pressing this switch, when the power is on, rotates the motor handpiece, and de-pressing
the switch again stops the handpiece. (Normal rotation operation) Pressing and holding the
switch for approx. one second or longer rotates the motor handpiece and releasing the
switch stops the handpiece. (Temporary rotation operation)
• SELECT Key
Press the SELECT key to change speed, torque or gear ratio setting. Select the parameter
for which you want to adjust the set value.
The following parameters can be changed in the following order: speed (SP) torque (TQ)
gear ratio (GR). However, gear ratio cannot be set during rotation of handpiece.
Pressing and holding this SELECT Key for 1 second or longer, when the motor handpiece is
stopped can change the Auto reverse mode. (See Auto Reverse)
10 11
• PROGRAM Key
A program can be selected.
The present program number is displayed. There are 5 programs available, numbered from 1
to 5.
Up to five programs can be set, and program settings can be memorized by pressing this
key for one second or longer.
The following parameters can be set: Speed, torque, gear ratio and auto reverse setting.
• UP/DOWN Key
Use this key when adjusting the set value for each parameter.
Alarm sounds if the set value exceeds the upper limit or lower limit.
Unit to be set is min-1 for speed and N·cm for torque. Set torque suitable for contra angle.
For gear ratio, 4:1, 10:1, 16:1 or 20:1 can be set.
<LCD panel>
• AUTO REVERSE
The current auto reverse mode mark is displayed.
AUTO REVERSE: If the load is removed after auto reverse rotation, it returns to the
normal rotation again.
AUTO STOP: If the load is removed after auto reverse rotation, it stops.
AUTO REVERSE OFF: Auto reverse rotation is not activated. (There will be no symbol
displayed)
4. Parts and its function • If the speed or torque set value has reached the upper limit or lower limit when the
gear ratio has been changed, the alarm sounds.
• The indication of “ ” for torque setting is the upper limit value of torque. If you
attempt to set torque which exceeds this value, the alarm sounds.
• The speed can be set at any time if it is normally indicated.
NOTICE
Program No.
Speed*
Torque
Auto Reverse mode
Buttery Symbol
Alarm Symbol Gear ratio
(Gear ratio setting screen)(Torque setting screen)
<LCD Panel>
LCD Panel
ON/OFF Key
PROGRAM Key
SELECT Key
DOWN Key
UP Key
Power Key
<Operation Panel Details>
No
Display

English
Power Cord Jack
Inlet
Power Lamp
Power Switch
12 13
(1) Charging Batteries
1. Insert the power cord jack into the inlet at the back of the battery charger. (Fig. 1)
2. Insert the power cord and plug in. Make sure you have the correct model/voltage.
3. Turn on the power switch. At this time, check that the power lamp lights up. (Fig. 2)
4. Insert the motor handpiece into the battery charge. Charging starts with the charge mark
flashing on LCD.
5. When the alarm sounds and “ ” is displayed on the liquid crystal panel, charging is
completed.
5. Operations
• BATTERY Symbol
The symbol indicating the battery status is displayed. The symbol will be animated when the
batteries are being charged or in the refresh mode.
: Full charge or nearly full charge
: About 30-80% remains
: Less than about 30% remains
: Batteries are drained or in a remarkably low voltage. Charge the batteries.
• ALARM Symbol
The present alarm symbol is displayed.
: Alarm ON
: Alarm OFF(No display) When the alarm does not sound and the charging animation is not displayed despite
batteries being replaced with new ones, immediately stop using and contact your dealer.
(Refer to Changing Batteries)
WARNING
The symbol indicating theremaining amount of the batteries indicates a voltage. When
load is applied to the motor handpiece, the symbol indicating the remaining amount of
the battery charge appears to become lower.
NOTICE
Load alarm when the motor rotates and auto reverse sound can be set to ON/OFF.
(Refer to 6 (4) Alarm Sound Volume Control)
NOTICE
No
Display
Fig. 2Fig. 1

English
Positioning convex
Contra angle head
Positioning groove
Motor handpiece
14 15
(2) Changing Contra Angle Head
The contra angle head can be connected with
the motor handpiece at 6 adjustable head
positions. Align the positioning pins of the contra
angle head with the positioning slots of the
motor handpiece and insert the head until they
click. When removing the contra angle head, pull
it out axially.
(3) Mounting and Removing File
Insert file to contra angle head, lightly turn the file until it engages with the latch mechanism.
Push it inward to click.
File Removal, depress the push-key and pull out the file.
• Turn OFF the power to remove or attach the contra angle head.
• Do not connect other than NSK F-type contra angle handpiece.
(In the EU, use the CE-marked handpiece.)
• Check that the contra angle head is securely connected to the motor handpiece.
CAUTION
• When attaching and detaching the file, turn off the power beforehand.
• After the file is locked in place, lightly pull out the file to make sure the file is locked.
• Always clean the shank of the file to be installed before use. Allowing dirt to enter the
chuck could cause loss of concentricity and deterioration of chucking force.
• Do not exceed the rotation speed recommended by the file manufacturers.
CAUTION
• When the power lamp for the charger does not light up, the internal fuse may be
faulty. In this case please contact your dealer.
• Be careful of handling when placing the motor handpiece in to the charger. Do not
force the handpiece into the charger. Otherwise, failure may be occur.
• If the power cord is inserted into the jack or the power switch is pressed with
unnecessary force, the cord or switch may be broken or a short-circuit may occur.
• Never use the battery charger for anything other than the motor handpiece of this
product.
• The charging normally takes approx. 90 minutes, but it depends on battery use
conditions, battery freshness, ambient temperature, etc. Older batteries are especially
prone to significantly shorter charging and operating times.
• Batteries may slightly warm up during charging, but this is not a failure. If the
handpiece is inserted or removed into/from the charger at short intervals, (approx. 5
minutes) charging cannot be properly completed and the battery compartment may
feel hot. We recommend that you charge batteries for as longer periods as possible.
• The power of the motor handpiece should not be turned on immediately after it has
been removed from the charger, wait at least approx. 2 seconds before you switch on
the power.
• Completely discharged batteries cannot be charged. Replace them with new ones.
• Do not put anything (metal or other devices such as wire, safety pin, or coin) other
than the handpiece on the charger. Otherwise, burn or failure may result due to heat
generation.
• The temperature of the batteries is measured during charging. Proper charging cannot
be performed if the charger is placed in an environment which is subject to sharp
temperature change (next to window, subject to direct sunlight, near air outlet of fan
heater). Place it in a place where temperature change is minimal.
• Charging may not be started in the following case.
· The temperature of the batteries is excessively high or low.
(Lower than approx. 0°C or higher than approx. 40°C)
· Battery voltage is sufficient
· Battery voltage is abnormal
CAUTION
Fig. 3
Fig. 5Fig. 4

Liquid crystal panel
ON/OFF key
PROGRAM key
DOWN key
POWER key
UP key
SELECT key
<Operation Panel>
English
16 17
(4) Preparatory Operations
1. Hold down the POWER key for more than one second
to turn on the power.
2. Keep holding down the PROGRAM key until program
No. suitable for file to be used is displayed.
3. When changing the set value of speed, torque, gear
ratio or auto reverse, press the SELECT key, select the
setting item and press the UP/DOWN key to change.
(5) Operation
If you press the ON/OFF key briefly, the motor handpiece
starts. If you re-press the key, it stops. (Alternate
operation)
If you hold down the ON/OFF key for more than one
second, the motor handpiece starts while the key is
pressed. If you release the key, it stops. (Intermittent
operation)
Auto Reverse Function
Auto reverse setting can be changed by pressing the SELECT key for one second or longer
while the motor handpiece stops. As the auto reverse mark flashes while the SELECT key is
kept pressed, press the UP/DOWN key to adjust it.
: Auto Reverse
: Auto Stop
: Auto Reverse OFF (flashes while the SELECT key is kept pressed, and goes out
when it is released)
The alarm will sound when it becomes a value of half of a torque limit set up during motor
handpiece rotation, and the alarm will change near the torque limit value. (Load alarm) When it
continues applying a load and it exceeds the torque limit value you can select mode from the
following three modes.
• When the battery charge goes down, the actual load may not reach the preset torque
limit value. In this case this auto reverse function will not be activated.
• If a load is continuously applied to the motor handpiece, it may automatically stop to
prevent overheating. In this case, leave the motor handpiece for a while until it cools
down.
• If the ambient temperature is low, the alarm may sound when the motor handpiece
rotates, however, this is not a failure. If the alarm does not stop sounding even when
the ambient temperature increases, clean the contra angle head and perform
calibration. (Refer to 6 (3) Calibration)
CAUTION
The GEAR RATIO key is fast-forwarded, when it is
continuously held down.
NOTICE Reverse rotation
when load continues,
forward rotation
when load is removed
Load lower than
the set torque limit value
Load higher than
the set torque limit value
AUTO REVERSING
The handpiece stop that it reaches for the loaded value, the file rotates in reverse. When a load
is removed, the file returns to normal rotation (forward rotation) automatically
Reverse rotation
when load continues,
stop when load is removed
Load lower than
the set torque limit value
Load higher than
the set torque limit value
Forward rotation Returns to forwardReverse rotation
Forward rotation StopReverse rotation
Fig. 7
AUTO STOP
The motor handpiece starts in reverse. When a load is removed, the motor handpiece stops. If
you want it to rotate (forward-rotate) again, re-press the ON/OFF Key or re-step.
AUTO REVERSE OFF
The motor handpiece stops without reverse rotation. If you want it to rotate (forward-rotate)
again, re-press the ON/OFF Key or re-step.
Fig. 8
Fig. 6

English
18 19
(3) Calibration
This function is to decrease fluctuation in the rotation speed of the motor handpiece and the
difference in torque by the contra angle head.
1. Lubricate the contra angle head with NSK PANA SPRAY/PANA SPRAY Plus (option). (Refer
to the “7 (1) Lubricating Contra Angle Head.”)
2. Turn on the power.
3. Hold down UP/DOWN key simultaneously for more than one second.
4. The LCD panel displays “ ” with the alarm sound.
5. Attach the contra angle head to the motor handpiece and press the ON/OFF key. (Remove
the bur or TEST bur.)
6. If the motor handpiece begins to rotate, leave it as it is until it stops.
7. This process ends, if the rotation stops and the LCD panel display returns to its original
state.
8. If you want to stop this process, turn off the power.
(4) Alarm Sound Volume Control
1. Setting alarm sound
You can turn ON/OFF the alarm (load alarm) which sounds near the torque limit value when the
motor handpiece rotates and the alarm during auto reverse (auto reverse sound).
1. Turn off the power
2. While pressing SELECT key, keep pressing POWER key one second or more.
3. The alarm mark and ON or OFF on the LCD panel, and the sound volume changes.
4. Press the SELECT key to select ON or OFF for alarm sound.
5. Display on the liquid crystal panel (LCD) returns to the original state if no operation is
performed for a while.
(1) Program
You can change any preset values and have them memorized to your desired settings. (rotation
speed, torque limit value, gear ratio and auto reverse mode)
1. Press the PROGRAM key until it turns to the program number which you want to have
memorized.
2. Adjust the rotation speed, torque limit value, gear ratio and auto reverse mode by UP/DOWN
key according to your needs.
3. Hold down the PROGRAM key for more than one second. When the alarm sounds the
settings have been memorized.
(2) Initialization of Program (Factory-set configuration)
The program can be returned to the original state configured at the time of factory shipment, if
setup becomes confusing.
1. Turn off the power, when the power is on.
2. Hold down the PROGRAM key and ON/OFF key for more than one second, while pressing
the POWER key at the same time.
3. Release the keys when the LCD panel indicates “ ”, and re-press the PROGRAM key
while this is displayed.
4. Initialization is completed, when “ ”is displayed.
6. Convenient Function
(6) Completion of Medical Treatment
When the treatment is completed, return the motor handpiece to the handpiece stand and hold
down the POWER key for more than one second to turn off the power.
Auto Power Off
If the key is not operated or approximately 10 minutes passes during rotation with no-load, the
power is automatically turned OFF to save energy and prevent improper operation. However, if
load is applied during rotation of the motor handpiece, the power is not turned OFF even during
no operation.
LAST MEMORY
The last setting used before the power is turned OFF is memorized. The setting when the
power is turned ON next is as that immediately used before the power has been turned OFF.
• The program cannot be memorized while the motor handpiece is in motion.
• The program is not memorized unless the PROGRAM key is held down for more than
one second. If the program number is changed by the PROGRAM key, the initially
memorized preset values remain. (Cancel function)
NOTICE
If this function is used, all programs will disappear and return to the originally set values.
Record the present program details if required before you carry out this operation.
NOTICE
NOTICE
• This function does not work unless remaining battery capacity is sufficient.
• Perform calibration after cleaning the contra angle head. Residual contamination on
the rotating shaft will impair correct measurement.
• Do not touch or apply a load to the rotating shaft of the contra angle head. It will
obstruct accurate measurement.
• This function cannot completely absorb the individual difference of the actual motor
handpiece and contra angle head.
NOTICE
The volume setting is memorized automatically to the last setting and remains
unchanged even if the power is turned off.

English
Contra angle head
F type spray nozzle
PANA-SPRAY/PANA-SPRAY Plus
(option)
Motor Cap
Motor Handpiece
20 21
Sterilize the contra angle head only.
For the sterilization method, we recommend the autoclaving. Sterilization is required first time
you use and after each patient as noted below.
Autoclaving
1. Brush the dirt off the surface of the contra angle head, and wipe it off with a cotton cloth
moistened with surgical spirit. Do not use a metal brush.
2. Lubricate the head with the PANA-SPRAY/PANA-SPRAY Plus. (Refer to the “7 (1) Lubricating
Contra Angle Head.”)
3. Insert the head into an autoclave pouch and seal it.
4. Autoclavable up to a max. 135°C (275°F).
ex.) Autoclave for 20 min. at 121°C (250°F), or 15 min. at 132°C (270°F).
5. Keep the handpiece in the autoclave pouch to keep it clean until you use it.
* Sterilization at 121°C for more than 15 minutes is recommended by EN13060 or
EN ISO17665-1.
8. Sterilization
(1) Lubricating Contra Angle Head
• Lubricate the contra angle head only.
• Apply PANA SPRAY/PANA SPRAY Plus after each use and/or before each calibration and
autoclaving
1. Lubricate it before each autoclaving or once a
day if you do not autoclave, using
PANA-SPRAY/PANA-SPRAY Plus lubricant.
Screw the F type spray nozzle onto the
Pana-Spray nozzle by approx. 10 turns.
2. Insert the F type spray nozzle into the rear
part of the contra angle head and lubricate the
head for 2-3 seconds. If the contra angle head
does not push into nozzle enough, oil may not go around into the handpiece and it may flows
backward.
(2) Cleaning Motor Handpiece
When the motor handpiece becomes dirty, wipe it off with a cotton cloth moistened with
rubbing alcohol.
(3) Cleaning Charger
When the charger becomes dirty, wipe it off with a cotton cloth moistened with surgical
solution.
7. Cleaning
• Do not heat sterilize the motor handpiece.
• Do not wipe with, or clean or immerse in, high acid water or sterilizing solutions.
CAUTION
• Do not lubricate the motor handpiece.
• Before mounting the lubricated contra angle head to the motor handpiece, wipe off
excess oil. Stand it on its end or lean it in the proper position for gravity draining.
Mount it after excess oil has been completely drained.
• Hold the contra angle head securely to prevent it from flying off by the pressure of the
spray.
• Hold the spray can upright.
• When cleaning the motor handpiece, do not use any solvent such as benzene and,
thinner.
CAUTION
Fig. 9
When the contra angle head is removed from the
motor handpiece for battery charging,
lubrication, or sterilization, mount the motor cap
onto the motor handpiece to prevent debris from
entering.
9. Motor Cap
Fig. 10

English
Battery Cover Rubber Cover
Screw
Battery Cover
Battery Cover
22 23
Changing Batteries
Prepare small screwdrivers (Phillips, flatblade).
1. Turn off the power of the motor handpiece.
2. Remove the rubber cover from the battery
cover with a thin flatblade screwdriver.
(Fig. 11)
3. Remove the screw fixing the battery cover
with a Phillips screwdriver. (Fig. 12)
4. Remove the battery cover by sliding it toward
the charging terminal. (Fig. 13)
5. Remove old batteries.
6. Insert new batteries according to the polarity
marking in the battery box. A mix-up between
the positive and negative sides will not allow
operation of the handpiece.
7. Attach the battery cover.
8. Tighten the screw with a Phillips screwdriver.
Do not overtighten it.
9. Insert the rubber cover back into the screw
hole of the battery cover in the originally
inserted direction.
Changing of batteries is now completed. Charge
them fully before use.
The motor handpiece monitors temperature of the batteries. If the batteries can potentially
become abnormally hot, this system functions and the motor handpiece automatically stops. In
such a case, wait until the motor handpiece cools down sufficiently. If this safety system
functions repeatedly, either the batteries or motor handpiece is not in the normal operating
condition and you should contact your dealer.
10. Safety System
The motor handpiece uses rechargeable batteries. They can be recharged 300-500 times,
depending on the use conditions of the motor handpiece. If the operating time becomes
shorter or the rotation speed becomes slower, although the “MEMORY EFFECT” described in
“ NOTICE” is not applicable, the batteries may be at the end of their life expectancy. In such
a case, ask your dealer to replace the batteries or replace them with new ones yourself. (Refer
to the “ Changing Batteries.”) When replacing them by yourself, be sure to observe the
following “ CAUTIONS ON CHANGING BATTERIES.” Please note that NSK shall not be liable
for any malfunction or failure resulting from you changing the batteries yourself and not
following the “ CAUTIONS ON CHANGING BATTERIES.”
11. Changing Batteries
• Do not misplace the rubber cover and screw.
• The used nickel metal hydride batteries are recyclable, but their disposal may
sometimes not be permitted by the respective country. Return them to your dealer.
CAUTION
• Do not open any part other than the battery cover.
• Use only batteries as specified by NSK.
• Designated Batteries : AAA (marking may be different) nickel metal hydride batteries,
nominal 1.2 V
• Do not use non-charging type batteries such as alkaline batteries and manganese
batteries. Charging with these batteries may cause fluid leaks, explosion or chlorine
gas generation.
• Should the battery fluid leak and get into your eyes, immediately wash thoroughly with
clean water and seek medical attention.
• Should the battery fluid leak and adhere to skin or clothing, immediately wash the
exposed skin thoroughly with clean water and completely wash away the fluid. Failure
to do so may result in a skin irritation.
• Always replace two batteries of the same type by the same manufacturer at the same
time. Using batteries of different-types, an exhausted battery with a fully charged one,
or a new battery with an old one may cause a fluid leak or explosion.
• Do not work with wet hands. Failure to do so may result in rust formation on battery
terminals or moisture intrusion inside, and could cause failure of the product.
CAUTIONS on CHANGING BATTERIES
Fig. 11
Fig. 12
Fig. 13

English
24 25
When trouble is found, please check the following again before consulting your dealer. If none
of these is applicable or the trouble is not remedied even after action has been taken, a failure
of this product is suspected. Contact your dealer.
13. Troubleshooting
If the motor handpiece stops due to an abnormality such as a malfunction, overload, break or
wrong use, it automatically checks the state of the control unit and detects the cause of the
abnormality and displays an error code on the LCD panel. If an error code is displayed, turn on
the power again and check whether the same error code is displayed. If the same error code is
displayed, take action by referring to the instructions provided in the “Check/Remedy” column
in the following table.
12. Error Code
Contact your dealer.
Remove load.
Contact your dealer.
Leave it as it is until it
cools down.
Contact your dealer.
Replace with new
batteries.
Contact your dealer.
Use within the range of
working temperature.
Replace the batteries. If
the heat generates from
the new set of batteries,
malfunction of the circuit
may be suspected.
Contact your dealer.
Replace the motor
handpiece or contra angle
head.
Malfunction of circuit
The motor handpiece is
locked. (at the time of
the auto reverse mode)
Malfunction of circuit
High load was
continuously applied to
the motor handpiece
for a relatively long time.
Malfunction of charger
The voltage of batteries
is too low (The life of
batteries.)
The voltage of batteries
is too high.
(Malfunction of circuit)
Outstanding the range of
working temperature or
break in the thermistor in
the battery section
The batteries generate
abnormal heat.
The operating life of the
motor handpiece or
contra angle has expired.
Check/RemedyCause
Self-Check
error
Overcurrent
Overvoltage
Overheating of
motor
Charger failure
Low voltage of
batteries
High voltage of
batteries
Outside the
range of
working
temperature
Abnormal heat
generation from
batteries
Beyond the
upper limit
Below the lower
limit
ErrorError code
During
rotation of
the motor
handpiece
At the time
of
Charging
Other
At the time
of
calibration
Recharge the batteries. If battery does
not fully discharge, charge will start. If
the battery fully discharge, change it for
new.
Insert batteries.
Contact your dealer.
Replace with new batteries.
If the temperature of batteries is less
than 0°C (32°F), the batteries are not
rechargeable. Charge the batteries in a
warm room. (Be careful about moisture
condensation.)
If the temperature of batteries is more
than 40°C, the batteries are not
rechargeable. Charge within the range
of working temperature. It is normal that
the batteries become a little bit warm
right after charging. If the batteries are
hot under normal operating conditions,
not right after charging, there may be
an abnormality. Contact your dealer.
Check that no battery other than
nickel-hydrogen battery is used.
Set correctly.
Remove metal on the charger.
See 12. Error Code.
Insert the power cord plug into the
outlet.
Insert the power cord jack into the inlet
on the charger.
Turn ON the power for the charger.
Contact your dealer.
Batteries have fully discharged.
(Has the handpiece been left
with batteries inserted for a
long time?)
No batteries are inserted.
The internal fuse has burnt.
Batteries have been completely
discharged.
The temperature of batteries is
low.
The temperature of batteries is
high.
The voltage of a battery is too high
The motor handpiece is not
correctly set to the charger.
Metal such as wire or safety pin is
placed on the charger.
An error code is displayed.
The power cord plug is not
inserted into the outlet.
The power cord jack is not
inserted into the inlet on the
charger.
The power for the charger is OFF.
The fuse has burnt.
The power is
not turned on.
The battery
charger does
not work. (The
CHARGE
animation does
not display)
The battery
charger does
not work. (the
power for the
charger is not
turned ON)
SolutionCauseProblem

English
26 27
Manufacturer warrants its products to the original purchaser against defects in material and
workmanship under normal practices of installation, use and servicing. Batteries etc., are
disposable components, and are not covered by this warranty.
14. Warranty
• Please consult with the dealer from whom you purchased regarding waste disposal.
• The used nickel metal hydride batteries are recyclable, but their disposal may
sometimes not be permitted by the respective country. Return them to your dealer.
15. Disposing Product
Contact your dealer.
Clean or replace the contra angle head.
Charge the batteries.
Charge the batteries.
Charge the batteries.
Use in a warm room.
Clean the contra angle head.
If nothing is displayed on the liquid
crystal panel of the handpiece
even when it is set to the charger,
failure in the circuit is predicted.
The contra angle head has
jammed up.
Batteries are weakened (lower
remaining battery capacity)
Batteries are weakened (lower
remaining battery capacity)
Batteries are weakened (lower
remaining battery capacity)
The ambient temperature is low.
There is some residual
contamination on the rotating shaft
of the contra angle head.
The motor
handpiece set
to the charger
abnormally gets
hot.
The motor
handpiece does
not rotate.
Power from the
motor handpiece
is weaker than
usual.
The Auto
Reverse does
not work.
Rotation speed
of the motor
handpiece is
lower.
The alarm
sounds when
the motor
handpiece is
rotated.
