CODING
- 133083
KOTKA ASSEMBLY GUIDE
/ 3
’
Read the instructions carefully. Remove all the
wrappings , staples and straps from the carton. Refer
to the hardware and furniture part list for guidance.
Make sure that you have all the parts before you start
assembling. Place all the wooden furniture parts on a
clean, flat and soft surface, such as a carpet or
rubbermat to prevent scratches.
1
2
PART LIST
4
QTY
3
HARDWARE
A
B
C
D
E
1
2
3
4
56
7
8
9
10
11
12
H
I
I
TOP PANEL
SIDE PANEL (L)
SIDE PANEL (R)
BOTTOM PANEL
CENTER PANEL
MIDDLE PANEL
DRAWER FRONT
DRAWER BACK
DRAWER SIDE (L)
DRAWER SIDE (R)
DRAWER BOTTOM
DRAWER BONE
6
7
8
5
9
10
11
12
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
MINI FIX
F
G
ALLEN KEY M4
H
I
J
M6 X 5OMM
CSK CAP WOOD SCREW
M8 X 30MM WOOD DOWEL
M3.5 X 16MM C.B SCREW
M4 X 32MM C.B SCREW
M4 X 38MM C.B SCREW
WOOD HANDLE ( 80MM )
METAL LEG 50 x 50 x H145MM
(CENTER ROUND Ø25 )
12" DRAWER SLIDE
14 SETS
1 PC
A1 A2 A3
18 PCS
8 PCS
4 PCS
4 PCS
2 PCS
28 PCS
1 PC
J1 ( L/R )
J2 ( L/R ) 1 SET
SCREWDRIVER HAMMER
SELF-PREPARED TOOLS: Tools below are NOT included in package.

CODING
- 133083
KOTKA ASSEMBLY GUIDE
/ 32
STEP 6
STEP 4
STEP 2
STEP 5
STEP 3
STEP 1
- Fix hardware J1 (L) into panel (3) with hardware E.
(Repeat 3 times for each hardware.)
- Fix hardware J1 (R) into panel (5) with hardware E.
(Repeat 3 times for each hardware.)
SCREWDRIVER
REQUIRED
x2
ROTATE
x2 x2
ROTATE ROTATE
EEE
Third hole from the edge.First hole from the edge. Small hole at the center.
35
J1 (L)
J1 (R)
- Attach panel (6) to panel (3) and (4).
- Insert all hardware A2 into A1.
- Rotate all A1 until tight.
- Apply A3 onto all A1.
(Repeat 2 times.)
OR
HARDWARE
D
SCREWDRIVER
REQUIRED
* In this step hardware A1, A2 and B are pre-inserted.
ROTATE
Section View
x2
A2 A1
x2
PRESS
A3
6
4
3
- Attach panel (3), (4), (5), and (6) to panel (1).
- Insert all hardware A2 into A1.
- Rotate all A1 until tight.
- Apply A3 onto all A1.
(Repeat 8 times.)
OR
HARDWARE
D
SCREWDRIVER
REQUIRED
* In this step hardware A1, A2 and B are pre-inserted.
6
4
3
1
5
ROTATE
Section View
x8
A1
A2
x8 PRESS
A3
Connect panel (2) to panel (3), (4), (5) and (6).
by using hardware C and D.
(Repeat 8 times.)
HARDWARE
D
ROTATE
x8
C
D
13
5
42
6
Assemble hardware I onto panel (2) by using hardware E.
(Repeat 4 times for each hardware.)
x16
EI
ROTATE
I
I
2
- Insert hardware A1 onto
panel (3), (4), (5), (6), (9), (10), and (12).
(Repeat 14 times.)
- Insert hardware A2 onto panel (1), (3), (4), (7), and (8).
(Repeat 14 times.)
- Insert hardware B onto panel (3), (4), (5), (6), (9), and (10).
(Repeat 18 times.)
SCREWDRIVER
REQUIRED
* Ensure the arrows on hardware A1 point towards mounting positions.
A2
x14
ROTATE
x18
PRESS
B
PRESS
A1
x14
1
6
712
10
9
5
4
3
8
SCREWDRIVER
REQUIRED

CODING
- 133083
KOTKA ASSEMBLY GUIDE
/ 3
3
STEP 12
STEP 10
STEP 8
STEP 11
STEP 9
STEP 7
Fix hardware H onto panel (7) with hardware F.
(Repeat 2 times for each hardware.)
SCREWDRIVER
REQUIRED
ROTATE
Fx2
7
H
Assemble panel (9) and (10) to panel (8) by using hardware G.
(Repeat 4 times.)
SCREWDRIVER
REQUIRED
x4
G
ROTATE
9
10
8
Insert the panel (11) along the slot.
(Repeat 1 times.)
11
- Attach panel (12) to panel (8).
- Attach panel (7) to panel (9), (10) and (12).
- Insert all hardware A2 into A1.
- Rotate all A1 until tight.
- Apply A3 onto all A1.
(Repeat 4 times.)
OR
HARDWARE
D
SCREWDRIVER
REQUIRED
* In this step hardware A1, A2 and B are pre-inserted.
10
8
9
12
7ROTATE x4
A2
A1
PRESS x4
A3
Assemble hardware J2 (L/R) to panel (9) and (10)
by using hardware E.
(Repeat 3 times for each hardware.)
SCREWDRIVER
REQUIRED
x2
E
x2
E
x2
E
ROTATE ROTATE ROTATE
Hole at the center.
Third hole from the edge. Third hole from the edge.
*Hardware J2 (L/R) shall be leaning against panel (7) when assembling.
J2(L) J2(R)
8
10
7
9
Put all the drawer in place along the drawer slides.
10
8
9
