Sauder Harbor View 420471 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-32
Français pg 33-36
Español pg 37-40
Lot # 392344 07/18/16
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Corner Entertainment Credenza
Harbor View Collection | Model 420471
Entertaining what
entertains you.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
3
4-5
6-32
33-36
37-40
41-42
43
WARNING
!
Use of a TV that is too heavy or large is hazardous. A TV that is too heavy will create a risk of a tip-over that can cause severe injury or
death. A TV that is too large for the available space might be accidentally pushed or bumped o the furniture, or subject to tip-over.
• Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly!
• This Sauder unit is designed for use with televisions weighing less than 135 pounds. Never use with a TV that weighs more.
• The size of the television, front-to-back and side-to-side, must fit within the space defined in the diagram.
• Never place the front edge of the TV past the front edge of the TV support shelf (or stop molding – if equipped)
• Never allow the sides of the TV to extend past the side edges of the TV support surface.
• If the TV has a CRT picture tube, the picture tube cone may extend past the rear of the support shelf.
• Be sure to apply the warning label as instructed in the last assembly step. The label provides important safety related information.
135 lbs.
135 lbs.
19"
19"
61-3/8"
61-3/8"
420471 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A2 RIGHT END (1)
B2 LEFT END (1)
C2 UPRIGHT (1)
D2 TOP (1)
D69 DRAWER BACK (2)
D107 RIGHT DRAWER SIDE (2)
D108 LEFT DRAWER SIDE (2)
D969 DRAWER BOTTOM (2)
E2 SHELF (2)
G2 BOTTOM (1)
H BACK (1)
I RIGHT BACK (1)
J LEFT BACK (1)
K ADJUSTABLE SHELF (2)
L BRACE (2)
M2 SIDE ADJUSTABLE SHELF (2)
N2 FRONT VALANCE (1)
O2 RIGHT VALANCE (1)
P2 LEFT VALANCE (1)
Q RIGHT DRAWER FRONT (1)
R LEFT DRAWER FRONT (1)
W2 HORIZONTAL MOLDING (1)
X FRONT BASE MOLDING (1)
Y RIGHT BASE MOLDING (1)
Z LEFT BASE MOLDING (1)
AA LONG END MOLDING (2)
BB2 VERTICAL MOLDING (2)
CC END MOLDING (4)
EE LONG BRACE (1)
420471www.sauder.com/services Page 3
A2
B2
C2
D2
E2
E2
G2
H
I
J
K
L
M2
N2
O2
P2 Q
R
W2
X
Y
Z
AA
BB2
EE
K
M2
AA
BB2
L
CC
CC
D107
D108
D969
D69
D107
D108
D969
D69

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
420471 www.sauder.com/servicesPage 4
4L WARNING LABEL - 1
WARNING
Never use this furniture with a TV that is too
large or too heavy. Severe injury or death
can occur.The TV and furniture will be
unstable and may tip.
-The TV must less than 135 lbs.
-The base of the TV must be able to sit
completely on this shelf.
-Refer to instruction book for complete safety
information.
Note: This is a permanent label. Do not try
to remove. Surface will be damaged.
02/ 02 2 6 9 2 3 2 269232
(Refer to step 25 for proper
location and application)
FOOT BASE - 1
24E
35DA CABINET RIGHT - 2 35DD DRAWER LEFT - 2 35DC DRAWER RIGHT - 2 35DB CABINET LEFT - 2
KNOB - 2
CONNECTOR
PLATE - 4
35G
METAL BRACKET - 31
4G
GROMMET CAP - 1
1P
10A SLIDE CAM - 4 ADJUSTABLE FOOT - 1 25E
NAIL - 21
1N
HIDDEN CAM - 26
1F
CAM DOWEL - 26
2F 134K

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
420471www.sauder.com/services Page 5
RUBBER SLEEVE - 16
2R
BLACK 1-1/8" PAN HEAD SCREW - 2
9S3S GOLD 5/16" FLAT HEAD SCREW - 16
METAL PIN - 16
1R
GROMMET - 1
10P
SILVER 5/8" FLAT HEAD SCREW - 4
23S 30S BLACK 1-9/16" FLAT HEAD SCREW - 8
BLACK 9/16" LARGE HEAD SCREW - 89
1S BLACK 1-7/8" FLAT HEAD SCREW - 10 2S

420471 www.sauder.com/servicesPage 6
Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
Step 1
å Push twenty-six HIDDEN CAMS (1F) into the ENDS (A2
and B2), UPRIGHT (C2), SHELVES (E2), BACKS (I
and J), and BRACES (L). Then, insert the metal end of a
CAM DOWEL (2F) into each HIDDEN CAM.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
E2
E2
A2
C2
B2
Arrow
1F
2F
(26 used)
Arrow
1F
2F
J
I
L
L
Some assembly
(and snacks) required.

Step 2
420471www.sauder.com/services Page 7
å Fasten four METAL BRACKETS (4G) to the ENDS (A2 and B2).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the BRACKETS are even with the edges of
the ENDS (A2 and B2).
å Fasten the VERTICAL MOLDINGS (BB2) to the ENDS (A2
and B2). Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: There are no pre-drilled holes in the MOLDINGS. The
SCREWS will tighten into the grooves.
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
A2
B2
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
These edges should be even.
4G
4G
BB2
BB2
Groove

å Fasten the CABINET RIGHT (35DA) and the CABINET
LEFT (35DB) to the ENDS (A2 and B2). Use four GOLD
5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3.
Step 3
420471 www.sauder.com/servicesPage 8
35DA
35DA
35DB
35DB
Roller end
1
3
2
1
3
2
Roller end
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
A2
B2
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
BB2
BB2

Step 4
420471www.sauder.com/services Page 9
å Fasten the CABINET RIGHT (35DA) and the CABINET
LEFT (35DB) to the UPRIGHT (C2). Use four GOLD 5/16"
FLAT HEAD SCREWS (3S) through holes #1 and #3.
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
35DA
35DA
35DB
35DB
1
3
2
C2
Surface with
HIDDEN CAMS
Finished edge
Roller end
1
3
2

Step 5
420471 www.sauder.com/servicesPage 10
4G
4G
L
L
EE
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
P2
O2
N2
å Fasten sixteen METAL BRACKETS (4G) to the
BRACES (L and EE) and VALANCES (N2, O2, and P2).
Use sixteen BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the METAL BRACKETS are even with the
edges of the BRACES and VALANCES.
BLACK 9/16" LARGE HEAD SCREW
(16 used in this step)
1S
4G
(16 used)
4G

Step 6
420471www.sauder.com/services Page 11
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
å Fasten the UPRIGHT (C2) to the TOP (D2). Tighten two
HIDDEN CAMS.
D2
C2
Finished edge
Unfinished surface
Surface without
HIDDEN CAMS
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution

Step 7
420471 www.sauder.com/servicesPage 12
E2
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
å Fasten the SHELVES (E2) to the UPRIGHT (C2). Tighten
four HIDDEN CAMS.
Arrow
Minimum
190 degrees
Maximum
210 degrees
E2
C2
Edge with
CAM DOWELS
Edge with
CAM DOWELS

å Fasten the ENDS (A2 and B2) to the TOP (D2) and
SHELVES (E2). Tighten eight HIDDEN CAMS.
å Fasten the HORIZONTAL MOLDING (W2) to the
SHELVES (E2). Tighten four HIDDEN CAMS.
Step 8
420471www.sauder.com/services Page 13
A2
B2 D2
W2
Surface without
HIDDEN CAMS
Finished edge
Surface with
HIDDEN CAMS
Finished edge
Arrow
Minimum
190 degrees
Maximum
210 degrees
E2
E2

å Fasten the FRONT VALANCE (N2) to the TOP (D2). Use
three BLACK 9/16" LARGE HEAD SCREWS (1S) through
the BRACKETS on the VALANCE and into the TOP.
Step 9
420471 www.sauder.com/servicesPage 14
D2
BLACK 9/16" LARGE HEAD SCREW
(3 used in this step)
1S
N2
Don't worry. It isn't
Rome. This can be built
in a day.

å Fasten the BOTTOM (G2) to the ENDS (A2 and B2)
and UPRIGHT (C2). Use six BLACK 1-7/8" FLAT
HEAD SCREWS (2S).
Step 10
420471www.sauder.com/services Page 15
A2
B2
C2
G2
BLACK 1-7/8" FLAT HEAD SCREW
(6 used in this step)
2S
Unfinished surface
These holes must be here.

å Carefully turn your unit over on its TOP (D2).
å Fasten the BACKS (I and J) to the TOP (D2). Tighten four
HIDDEN CAMS.
å Fasten the BACKS (I and J) to the BOTTOM (G2). Use
four BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 11
420471 www.sauder.com/servicesPage 16
Arrow
Minimum
190 degrees
Maximum
210 degrees
G2
D2 I
J
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Notched
edge
Notched
edge

å Slide the LONG END MOLDINGS* (AA) onto the notched
edges of the BACKS (I and J).
å * U.S. Patent No. 5,499,886
Step 12
420471www.sauder.com/services Page 17
IJ
AA AA
Notched
edge
Notched
edge
Slide the LONG END MOLDINGS (AA)
onto the notched edges.

å Fasten the VALANCES (O2 and P2) to the TOP (D2). Use
four BLACK 9/16" LARGE HEAD SCREWS (1S) through
the BRACKETS on the VALANCES and into the TOP.
Step 13
420471 www.sauder.com/servicesPage 18
D2
P2
O2
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S

å Fasten eleven METAL BRACKETS (4G) to the BOTTOM (G2)
and BACKS (I and J). Use eleven BLACK 9/16" LARGE
HEAD SCREWS (1S).
å NOTE: Be sure the BRACKETS are even with the edges of the
BOTTOM and BACKS.
å Fasten the FRONT BASE MOLDING (X) to the BOTTOM (G2).
Use three BLACK 9/16" LARGE HEAD SCREWS (1S).
Step 14
420471www.sauder.com/services Page 19
I
J
X
G2
BLACK 9/16" LARGE HEAD SCREW
(14 used in this step)
1S
4G
4G
4G
4G
4G

å Fasten the BASE MOLDINGS (Y and Z) to the BOTTOM (G2).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å Fasten the END MOLDINGS (CC) to the BACKS (I and J). Use
four BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: There are no pre-drilled holes in the END
MOLDINGS (CC). The SCREWS will tighten into the grooves.
Step 15
420471 www.sauder.com/servicesPage 20
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
I
J
G2
Y
CC
Z
CC
