Nuna PEPP next User manual

Designed
around your life

1
1
2
9
10
11
7
8
12
1 1
22
1
2
3
5
4
click
11
2
2
6

1
2
16
17
13
14
15 18
1
2
23
22 19
20
21
24

1
2
29
3630
25
32
31
26
33
27
34
28
35

4037
1
1
2
39
38
click
click

IMPORTANT!
KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE:
READ CAREFULLY
Contents
Product Information
Warranty 3
Contact 3
Child Usage Requirements 4
Warnings 5
Parts List 9
Product Set Up 11
Product Use 12
Accessory
PEPP next Car Seat Adaptors 16
PEPP next Rain Cover 17
Cleaning and Maintenance 18
2PEPP next instructions

Child Usage Requirements
This stroller is suitable for use with children who meet the
following requirements:
Child: from birth
Weight: up to 15 kg maximum
Height: 114.3 cm or less
When using the stroller frame with the KLIK plus infant
carrier, refer to the child usage requirements listed in its
instruction manual.
Product Information
Model Number: ________________________________________________
Manufactured in (date):________________________________________
The model number and the manufactured in date are located
on a label on the stroller frame.
Warranty
We have purposely designed our high-quality products so
that they can grow with both your child and your family.
Because we stand by our product, our gear is covered by a
custom warranty per product, starting from the day it was
purchased. Please have the proof of purchase, model number
and manufactured in date available when you contact us.
For warranty information please visit:
www.nunababy.com/warranty
Contact
For replacement parts, service, or additional warranty
questions, please contact
APB Pty. Ltd.
82 Bellingara Road
Miranda NSW 2228
Ph: 02 8543 5570
Distributed in Australia by
Baby Bunting Pty. Ltd.
955 Taylors Road
Dandenong South Vic 3175
3PEPP next instructions 4PEPP next instructions

It is unsafe to use accessories other than those
approved by the vehicle manufacturer.
Adult assembly required.Use the stroller with a
child weighing no more than 15kg. It will cause
damage to the stroller with an unfitted child.
To prevent a hazardous, unstable condition, do
not place more than 4.5kg in the storage basket.
Overloading, folding incorrectly, or using
component parts from other manufacturers
may cause the stroller to be damaged, broken
or unsafe. Please read the instruction manual
carefully.
Please read all the instructions in the manual
before using the product. Please save instruction
manual for future use. Failure to follow these
warnings and instructions may result in serious
injury or death.
Safety belts and restraint system must be used
correctly.
Child may slip into leg openings and be strangled
if the harness is not used.
Never use stroller on stairs or escalators.
The stroller not be used near an open fire or
exposed flame.
Never allow your child to stand on the stroller or
sit in the stroller with head toward front of stroller.
WARN I N G
TO AVOID INJURY OR DEATH: ALWAYS APPLY
THE BRAKES WHENEVER THE STROLLER IS
STATIONARY.
DO NOT LEAVE CHILDREN UNATTENDED.
ALWAYS KEEP CHILD IN VIEW WHILE IN
STROLLER.
ALWAYS USE THE CROTCH COMBINATION WITH
THE WAIST BELT. IT IS SUGGESTED THAT THE
SHOULDER HARNESSES BE USED AS WELL.
DO NOT CARRY EXTRA CHILDREN OR BAGS ON
THIS STROLLER.
SECURE THE CHILD IN THE HARNESS AT ALL
TIMES.
USE THIS HARNESS AT ALL TIMES.
MAKE SURE CHILDREN ARE CLEAR OF ANY
MOVING PARTS IF YOU ADJUST THE STROLLER.
TO AVOID SERIOUS INJURY FROM FALLING OR
SLIDING OUT, ALWAYS USE SEAT BELT.
USE THIS TETHER STRAP TO STOP THE
STROLLER ROLLING AWAY.
Ensure that all the locking devices are engaged
before use.
Do not let your child play with this product.
Never leave the harness buckled when not fitted
to a child in the stroller because the harness
can form loops which may pose a strangulation
hazard.
5PEPP next instructions 6PEPP next instructions

To avoid strangulation, do make sure your child is
clear from the canopy.
Discontinue using your stroller if it is damaged or
broken.
Stroller to be used only at walking speed. This
product is not intended for use while jogging.
To avoid suffocation, remove plastic bag and
packaging materials before using this product.
The plastic bag and packaging materials should
then be kept away from babies and children.
This product is not suitable for running or skating.
Stroller designed to be used from birth shall
recommend the use of the most reclined position
for new born babies.
The parking device must be engaged when
placing and removing children.
Please ensure that the storage latch has been
properly locked, before lifting or moving the
stroller.
Never place the stroller on roads or dangerous
area.The stroller is designed for use on flat or
gently sloping surfaces and may be unstable on
higher sloping and uneven surfaces, and users
should be made aware of the possibility of the
stroller tipping over.
Do make sure all parts are assembled and
fastened properly before using the stroller.
To avoid strangulation, do not place items with a
string around your child’s neck, suspend strings
from this product, or attach strings to toys.
To prevent tipping, do not put anything on the
handle. Always lift the child in and out of the
stroller.
Do not lift stroller while child is in stroller.
Do not use storage basket as a child carrier.
To prevent tipping, never let child climb the
stroller.
To avoid finger entrapment or injury to the body,
use care when folding and unfolding the stroller.
Be sure the stroller is fully open or folded before
allowing child near the stroller.
To ensure your child’s safety, please make sure all
parts are assembled and fastened properly before
using the stroller.
Check that the infant child restraint attachment
device is correctly engaged before use.
7PEPP next instructions 8PEPP next instructions

1 8
9
11
10
2
3
4
6
5
7
26
25
12
13
16
15
17
18
19
24
20
22
23
21
14
Parts List
Make sure all parts are available before assembly.
If any part is missing, please contact Nuna (see page 3
for information). No tools are required for assembly.
CHOKING HAZARD: Remove and immediately discard
protective end caps from each wheel and wheel hub axle.
1 Canopy Visor
2 Seat Pad
3 Shoulder Harness
4 Shoulder Harness Pads
5 Armbar
6 Buckle and Crotch
Cover
7 Calf Support
8 Canopy
9 Stroller Frame
10 Waist Harness
11 Calf Support
Adjustment Button
12 Handle
13 Handle Adjustment
Button
14 Tether Strap
15 Canopy Mount
16 Recline Zippers
17 Storage Basket
18 Brake Lever
19 Dream drape™
20 Folding Button
21 Upper Storage Mount
22 Storage Latch
23 Lower Storage Mount
24 Front Swivel Locks
25 Rain Cover
26 Car Seat Adaptors
(sold separately)
9PEPP next instructions 10PEPP next instructions

Product Use
The brake MUST be engaged when the stroller is
stopped and when placing and removing child.
Securing Your Child
1 - Push the center button on the buckle to release the
buckle latch, remove the clips and place your child
in the stroller. (6)
2 - Connect the shoulder buckle and hip buckle. (7)
3 - Secure the shoulder buckle and hip buckle to the buckle
latch and repeat on the opposite side. (8)
4 - Fit the harness snugly to your child by pulling the
adjustment straps to tighten (9)-1. Then pull the waist
adjustment straps out (9)-2.
Shoulder Harness Position
1 - The upper shoulder harness buckles can be moved up
and down for added adjustment. (10)
Avoid serious injury from falling or sliding out. Always
use the seat belt.
Make sure the harness is adjusted properly and your
child is snugly secured. The space between the child
and the shoulder harness should be about the thickness
of one finger. DO NOT cross the shoulder belts. This will
cause pressure on your child’s neck.
Handle
The handle has 5 positions.
1 -To adjust the height of the handle, slide the handle
adjustment buttons up to disengage (11)-1. Then pull the
handle up or down (11)-2.
A “click” sound means the handle is locked in position.
Product Set Up
Open Stroller
1 -Separate the storage latch from the upper storage
mount. (1)
2 -Then, rotate the stroller handle up. A“click” sound
means the stroller frame is open completely. (2)
3 - Secure the storage latch to the lower storage mount.
Check the stroller frame is completely latched open
before continuing. (3)
Assemble Armbar
1 -Align the armbar ends with the armbar mounts, and then
insert to lock. (4) Please ensure that the seat fabric is
not caught in the armbar attachment mount.
2 -To disassemble armbar, press armbar release button
(5) -1 , and then pull out the armbar. (5) -2
11 PEPP next instructions 12PEPP next instructions

Seat Pad
The seat pad can be removed to provide a mesh seating
area for better ventilation during hot weather.
Remove the canopy before removing the seat pad.
1 -To remove the seat pad, unsnap the seat pad from the
back of the seat. (22)
2 -Then, unbuckle the harness, thread the harness through
the harness slots and remove the seat pad. (23)
DO NOT remove the backrest tube.
Front Swivel Locks
It is recommended to use the front swivel locks on uneven
surfaces.
1 -To lock the front wheels, press down on the swivel lock.
The lock will engage when the wheel is straight. (24)
2 -To unlock the front wheels, pull up on both swivel locks.
(25)
Brake
1 - To lock the rear wheels, step down on the brake lever.
(26)
2 - To unlock the rear wheels, lift up on the brake lever. (27)
Always apply the brake when the stroller is stopped.
Push the stroller slightly to ensure the brake is engaged.
Canopy
Fully extend the handle for canopy use.
1 - To open the canopy, pull the canopy toward the front of
the seat. To close the canopy, push it back. (12)
2 -Position the canopy visor forward or backward as
needed. When not in use, fold the canopy visor under
the canopy. (13)
3 - Open the zipper (14) on the canopy to use the dream
drape™.
4 - Pull down on the dream drape™ for extra shade. (15)
5 -To detach the canopy, pull in on the canopy mounts to
remove them. (16)
6 -Unsnap the canopy from the back of the seat and
remove the canopy. (17)
To reattach the canopy, reverse these steps.
Calf Support
The calf support has 2 use positions.
1 -To raise the calf support, lift up. (18)
2 -To lower the calf support, press the adjustment buttons
on both sides (19)-1, and push down (19)-2.
Recline
There are 2 zippers on each side of the seat back for
2 recline positions.
1 -For recline position 1, unzip the outer zippers. (20)
2 -For recline position 2, unzip the inner zippers. (21)
13 PEPP next instructions 14PEPP next instructions

Accessory
Car Seat Adaptors (sold separately)
NUNA KLIK plus infant carrier can be used with PEPP next
using the car seat adaptors.
For KLIK plus infant carrier assembly and usage, please refer
to the infant carrier instruction manual.
Before attaching the car seat adaptors, remove the canopy.
(16)
1 - Unfasten the hook and loop from the side of the seat
frame. (32)
2 - Pull and unsnap the fabric from the seat frame. (33)
3 - Unlatch and open the infant car seat adaptors, locating
the numbers on the inside. (34)
4 - Place infant car seat adaptor 1 around the left side of the
seat frame, with the arrow pointing down. The number
should be under the seat frame and the adaptor should
align with the gray lines on the top of the seat frame.
(35)
5 - Close the infant car seat adaptor over the top of the seat
frame. (36)
6 - Pull the adaptor end toward the seat frame. A “click”
sound means the car seat adaptor is attached. (37)
7 - Repeat on the right side with infant car seat adaptor 2.
Use Tether Strap
Use the tether strap to prevent the stroller inadvertently
rolling away. Check that when your hand is through the loop,
it allows you to easily control the stroller. (28)
Fold
Before folding the stroller, push the canopy to the rear of
the stroller, adjust the handle to the lowest position and
separate the storage latch from the lower storage mount.
1 -Pull up on the folding buttons (29)-1 and push the
stroller forward to fold (29)-2.
2 -Secure the storage latch to the upper storage mount.
(30)
3 - You can carry the stroller by lifting its handle. (31)
Ensure the storage latch is engaged when lifting or
carrying the stroller.
15 PEPP next instructions 16PEPP next instructions

NUNA International B.V. NUNA and all associated logos are trademarks.
Cleaning and Maintenance
Clean the frame, plastic parts, and fabric with a damp
cloth, but do not use abrasives or bleach. Do not use silicon
lubricants as they will attract dirt and grime. Do not store
your stroller in a damp place.
Clean the stroller wheels regularly with water and remove
any dirt.
To ensure long-lasting use, wipe off this product with a soft,
absorbent cloth after using it in rainy weather.
Refer to the care label attached to the fabric for washing and
drying instructions.
It is normal for fabric to color from sunlight and to show
wear and tear after a long period of use, even when used
normally.
For reasons of safety, only use original Nuna parts.
Check regularly if everything functions properly. If any parts
are torn, broken, or missing, stop using this product.
Before attaching the KLIK plus infant carrier, recline the seat
back to position 1 by unzipping the outer zippers.
8 - To attach the infant carrier, place the infant carrier on
the infant car seat adaptors. A “click” sound means the
infant carrier is attached. (38)
9 - To remove the infant carrier, push the stroller release
buttons on the infant carrier (39)-1 and lift up (39)-2.
Remove the infant carrier before folding.
To remove the infant car seat adaptors, unlatch the infant
car seat adaptors from the seat frame. Then reattach the
fabric to the seat frame and secure the hook and loop.
PEPP next Stroller Rain Cover
To assemble the rain cover, place it over the stroller seat.
(40)
Always check ventilation, especially in hot weather
when the rain cover is on the product.
Always check that the rain cover has been cleaned and
dried before folding.
DO NOT fold the stroller after assembling the rain cover.
DO NOT place your child into the stroller assembled
with rain cover during hot weather.
17 PEPP next instructions 18PEPP next instructions

IMG-0095C
