Nuna Demi Grow User manual

IMG-0057D

Designed
around your life

EN EN
2DEMI grow stroller instructions 3DEMI grow stroller instructions
Contents
Product Information
Warranty 4
Contact 4
Child Usage Requirements 5
Warnings 6
Parts List 10
Product Set Up 12
Product Use 18
Seating Options 26
Accessoires 30
DEMI grow Stroller/Sibling Seat 30
DEMI grow Stroller/Sibling Seat Rain Cover 30
DEMI grow Bassinet 32
DEMI grow Car Seat Post Adapters 34
DEMI grow Seat & Bassinet Post Adapters 36
Cleaning and Maintenance 40
Francais (FR) 42
IMPORTANT!
KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE:
READ CAREFULLY

EN EN
Child Usage Requirements
This stroller/sibling seat is suitable for use with children who
meet the following requirements:
Weight: up to 50 lbs (22.7 kg) maximum
Height: 45 in. (114.3 cm)
When using the stroller frame with the bassinet or infant
carrier, refer to the child usage requirements listed in those
instruction manuals.
4DEMI grow stroller instructions 5DEMI grow stroller instructions
Product Information
Model Number:__________________________________________________________________
Manufactured Date: ___________________________________________________________
The model number and the manufactured in date are located
on a label on the stroller frame.
Warranty
We have purposely designed our high-quality products so
that they can grow with both your child and your family.
Because we stand by our product, our gear is covered by
a custom warranty per product, starting from the day it
was purchased. Please have the proof of purchase, model
number and manufactured in date available when you
contact us.
For warranty information please visit:
www.nuna.eu/caen/warranty
Contact
For replacement parts, service, or additional warranty
questions, please contact our customer service department.
In Canada:
[e-mail]
www.nuna.eu/caen
1.800.667-4111

EN EN
6DEMI grow stroller instructions 7DEMI grow stroller instructions
A child’s safety is your responsibility. NEVER leave
your child unattended.
To avoid any danger of suffocation, remove all plastic
covers before using this product and destroy or keep
away from babies and children!
Keep small parts away from children as they pose a
choking hazard.
Discontinue using these products should they
become damaged or broken.
Use original NUNA parts and accessories only.
Each stroller/sibling seat is intended for children up to
50 lbs (22.7 kg) maximum or a height of 45 in. (114.3
cm).
To prevent a hazardous, unstable condition, do not
place more than 10 lbs (4.5 kg) in the storage basket
before use.
Use of the stroller with more than 110 lbs (49.9 kg)
will cause excessive wear and stress on the stroller.
110 lbs (49.9 kg) = 50 lbs (22.7 kg) stroller/sibling
seat maximum + 50 lbs (22.7 kg) stroller/sibling seat
maximum + 10 lbs (4.5 kg) storage basket maximum.
Negotiate curbs and rough ground carefully.
Repeated impact could cause damage to this
product.
This stroller is to be used only at walking speed.
Stroller is not intended for use while jogging, skating,
etc.
WARNING
Failure to follow these warnings and instructions could
result in serious injury or death.
The parking brake MUST be engaged when the
stroller is stopped and when placing and removing
child.
Overloading, incorrect folding, and using accessories
other than those approved by NUNA, e.g. child seats,
bag hooks, rain covers, buggy boards, etc., may
damage or make this stroller unsafe.
Adding accessories such as purses, shopping bags, or
parcels to the handle or canopy can cause the stroller
to be unstable.
This stroller does not replace a crib or a bed. Should
your child need to sleep, they should be placed in a
crib or approved sleeping area based on your child’s
requirements.
Avoid serious injury from falling or sliding out. Always
use seat belt. After fastening buckles, adjust belts to
get a snug fit around your child.
AVOID FINGER ENTRAPMENT Use care when folding
and unfolding the stroller. Be certain the stroller is
fully erected and latched before allowing your child
near the stroller.
STRANGULATION HAZARD Do not place items with
a string around your child’s neck, suspend strings
from this product, or attach strings to toys.
ALWAYS keep your child in view while in this product.
ALWAYS allow the fabric to dry naturally away from
direct heat.
ALWAYS check that the attachments are correctly
engaged.
DO NOT let your child play with this product.

EN EN
8DEMI grow stroller instructions 9DEMI grow stroller instructions
DO NOT place any item on the canopy of this product.
DO NOT leave this product exposed in the vicinity of
a strong source of heat i.e. a radiator or open fire or
store this product in a damp place.
DO NOT make any changes or modifications to this
product, that are not specified in this manual.
DO NOT use storage basket as a child carrier.
NEVER carry more than one child in a seating position
at a time in this stroller.
NEVER use the stroller on stairs or escalators. You
may suddenly lose control of the stroller or your child
may fall out.
NEVER allow children to stand on the footrest.

EN EN
10 DEMI grow stroller instructions 11DEMI grow stroller instructions
Parts List
Make sure all parts are available before assembly.
If any part is missing, please contact NUNA (see page 4
for information). No tools are required for assembly.
CHOKING HAZARD: Remove and immediately discard
protective end caps from each wheel and wheel hub axle.
1 Front Wheel (x2)
2 Rear Wheel (x2)
3 Rear Fender
4 Car Seat Post
Adapter (x2)
5 Seat & Bassinet Post
Adaptors
6 Rain Cover
7 Dream Drape™
8 Stroller/Sibling Seat
9 Stroller Frame
10 Canopy
11 Seat Pad
12 Head Support
13 Arm Bar
14 Shoulder Harness Pads
15 Calf Support
16 Front Wheel
17 Stroller Handle
18 Arm Bar Adjustment
Button
19 Seat Release Button
20 Buckle and Crotch Cover
21 Upper Seat Mount
22 Storage Basket
23 Recline Adjustment
Button
24 Handle Adjustment
Button
25 Folding Button
26 Lower Seat Mount
27 Rear Fender
28 Custom Dual
Suspension™
Adjustment Lever (x2)
29 Brake Lever
30 Rear Wheel
x2 x2
1
4
10 17
23
24
25
27
26
28
29
30
19
18
20
21
22
11
12
13
14
15
16
2 3
6
8
9
7
x2
5

EN EN
12 DEMI grow stroller instructions 13DEMI grow stroller instructions 13DEMI grow stroller instructions
Product Set Up
Open Stroller
1 - Rotate the stroller handle up.
2 - A “click” sound means the stroller frame is open
completely.
Check the stroller frame is completely latched open
before continuing.
Rear Wheels
3 - Insert the rear wheel into the rear leg. A “click” sound
means the rear wheel is assembled completely.
Check the wheel is securely attached by pulling out.
Repeat on opposite side.
4 - To remove the rear wheel, press the release button (1)
and detach the rear wheel from the rear leg (2).
5
1
2
5421
32
click
43
click

EN EN
14 DEMI grow stroller instructions 15DEMI grow stroller instructions
1 4
52
3
14 DEMI grow stroller instructions 15DEMI grow stroller instructions
12
1 4
52
3
Front Wheels
1 - Insert the front wheel into the front leg. A “click” sound
means the wheel is assembled completely.
Check the wheel is securely attached by pulling out.
Repeat on opposite side.
2 - To remove the front wheel, press the release button (1)
and detach the front wheel from the front leg (2).
Canopy
3 - Clip the canopy mount onto the stroller/sibling seat on
each side.
4 - Zip the canopy to the stroller/sibling seat.
5 - To remove the canopy, unzip the zippers, then remove
the canopy mounts.
click

EN EN
Arm Bar
1 - Align the arm bar ends with the arm bar mounts, and
insert until it clicks into place. A “click” sound means the
arm bar is assembled completely.
2 - To remove the arm bar, press the arm bar release buttons
(1) located under seat pad, and remove the arm bar. (2)
3 - For a more compact fold, press the armbar adjustment
buttons (1) and rotate the armbar down (2) until it clicks
into place.
Only use the down/stored position for folding.
NEVER use this position with child in stroller.
Stroller/Sibling Seat
The stroller/sibling seat can be attached rear or forward facing.
4 - Align the sides of the stroller/sibling seat with the seat
mounts. Place the stroller/sibling seat directly down until
it clicks into place. A “click” sound means the stroller/
sibling seat is assembled completely.
5 - To remove the stroller/sibling seat, squeeze the seat
release buttons (1) and lift the stroller/sibling seat up (2).
Rear Fenders
Attach the rear fenders for twin and double modes.
For easier assembly, remove the rear wheels.
6 - Insert the rear fender into the rear leg. A “click” sound
means the fender is assembled completely. Check the
fender is securely attached by pulling up. Repeat on
opposite side and reattach rear wheels.
Check Set Up
Stroller frame is latched open
Rear and front wheels securely attached
Canopy mount attached to stroller frame and canopy
zipped to seat pad
Stroller/sibling seat securely attached
Rear fenders securely attached for twin/double mode
1
4
2
1
1
2
2
2
1
2
16 DEMI grow stroller instructions
click
5
16 DEMI grow stroller instructions 17DEMI grow stroller instructions
4
63

EN EN
Product Use
The parking brake MUST be engaged when the stroller
is stopped and when placing and removing child.
Securing Your Child
1 - Push the center button on the buckle to release the
buckle latch, remove the clips and place your child
in the stroller.
2 - Connect the shoulder buckle and hip buckle.
3 - Secure the shoulder buckle and hip buckle to the buckle
latch and repeat on the opposite side.
4 - Fit the harness snugly to your child by sliding the lower
adjustment buckles (located under the harness covers)
up (1). Then pull the waist adjustment straps out (2).
Shoulder Harness Position
5 - The upper shoulder harness buckles can be moved up
and down for added adjustment.
To avoid serious injury from falling or sliding out, always
secure your child with the harness.
Make sure the harness is adjusted properly and your
child is snugly secured. The space between the child and
the shoulder harness should be about the thickness of
one finger. DO NOT cross the shoulder belts. This will
cause pressure on your child’s neck.
Shoulder Harness Pad Removal
To remove the shoulder harness pads, release the buckle.
6 - Slide the shoulder harness pad down off the shoulder
buckle harness strap.
To reattach the shoulder harness pad, undo the snaps and
insert the shoulder harness buckle through the inside loop.
18 DEMI grow stroller instructions 19DEMI grow stroller instructions
11
22
1 4
5
6
2
3

EN EN
20 DEMI grow stroller instructions 21DEMI grow stroller instructions
1
2
1
2
1
5
6
1 4
2
3
Canopy
1 - To open the canopy, pull the canopy toward the front of
the seat, and to close the canopy, push it back.
2 - Open the zipper (1) on the canopy to use the dream
drape™.
3 - Pull down on the dream drape™for extra shade.
4 - For added ventilation, flip the canopy window cover up.
Handle
The handle has 3 positions.
5 - To adjust the height of the handle, press the handle
adjustment button (1) and pull the handle up or down
(2).
Calf Support
The calf support has 2 use positions.
6 - To raise the calf support, lift up. To lower the calf
support, press the adjustment button in the middle of
the calf support (1), and push down (2).
1

EN EN
Recline
1 - There are 3 recline positions for the backrest.
2 - To raise or lower the backrest, squeeze the recline
adjustment button, and pull the seat up or down.
Seat Pad
Use the winter seat pad in cold weather to provide a
comfortable seating area. The winter seat pad can be
removed to provide a mesh seating area for better ventilation
during hot weather.
3 - To remove the seat pad, unbuckle the harness, open
the zipper around the seat pad and route the harness
through the seat pad slots.
DO NOT remove the backrest tube.
Brake
4 - To lock the rear wheels, step down on the brake lever.
5 - To unlock the rear wheels, lift up on the brake lever.
Always apply the brake when the stroller is stopped.
Push the stroller slightly to ensure the brake is engaged.
Custom Dual Suspension™
The stroller has two suspension modes. Make sure there is
no weight placed on the stroller when you are adjusting the
suspension and that both adjustment levers are in the same
position.
6 - Flip the adjustment levers up (1) when on rough
terrain for a softer suspension and flip the adjustment
levers down (2) when on smooth surfaces for a stiffer
suspension.
When using as a double or twin, it is recommended to flip
the adjustment levers down.
1
2
1 4
5
6
2
3
22 DEMI grow stroller instructions 23DEMI grow stroller instructions

EN EN
24 DEMI grow stroller instructions 25DEMI grow stroller instructions
Front Swivel Locks
It is recommended to use the front swivel locks on uneven
surfaces.
1 - Pull the front swivel lock out to lock front wheel
forward facing.
2 - Push the front swivel lock in to unlock.
Fold
Before folding the stroller, adjust the handle to the 2nd
or 3rd highest position and make sure the front swivel locks
are unlocked.
The stroller can be folded with the stroller/sibling seat facing
forward or without the stroller/sibling seat.
If folding with the seat, place the seat in the most reclined
position for a more compact fold.
3 - Fold the armbar (1) and canopy (2).
4 - Lift both folding buttons.
5 - Rotate the handle down.
6 - Fold the calf support down for a more compact fold.
2
1 4
4
5
6
2
3
1

EN EN
26 DEMI grow stroller instructions 27DEMI grow stroller instructions
Seating Options
The DEMI grow stroller frame can be used with the infant carrier
(using included adapters), bassinet and stroller/sibling seat
in the following combinations. Single (1), twin (2), double (3)
1
2
3

EN EN
28 DEMI grow stroller instructions 29DEMI grow stroller instructions28 DEMI grow stroller instructions 29DEMI grow stroller instructions
12
3
Seating Option Use
When using the stroller frame with the stroller/sibling seat,
bassinet or infant carrier, close the canopy when the stroller/
sibling seat, bassinet or infant carrier is assembled on the
lower mount.
Not all accessories are included on some models and
not all modes are allowed.
1 - DO NOT use the stroller/sibling seat (1), bassinet (2) or
infant carrier (3) rear facing on the lower mount.
2 - DO NOT adjust the backrest of the stroller/sibling seat
up, when it is assembled on the lower mount and the
bassinet is assembled on the upper mount.
3 - DO NOT assemble the infant carrier on the lower mount
when the bassinet is rear facing on the upper mount
without the use of the Seat & Carry Cot Post Adaptors.
The bassinet can be assembled on the upper mount
with seat & bassinet post adaptors when the infant
carrier is assembled on the lower mount
4 - DO NOT adjust the infant carrier handle to the vertical
position when the infant carrier is assembled on the
lower mount.
Please use Seat & Bassinet Post Adaptors (Part List#5)
on upper mount when using sibling seat on the upper
mount and lower mount simultaneously and both with
front facing mode.
4
1
2
3

EN EN
30 DEMI grow stroller instructions 31DEMI grow stroller instructions
1
31DEMI grow stroller instructions
1 2
Accessories
Not all accessories are included on some models.
DEMI grow Stroller/Sibling Seat
When installing the stroller/sibling seat in the lower mount,
close the canopy, adjust the calf support to its highest
position, and fold the stroller basket rear panel forward.
1 - To attach stroller/sibling seat, align the sides of the
stroller/sibling seat with the seat mounts.
Place the stroller/sibling seat directly down until it clicks
into place. A “click” sound means the stroller/sibling seat
is attached.
Remove the stroller/sibling seat from the lower mount
before folding the stroller.
Please use seat & bassinet post adapters on upper
mount when using the upper mount and lower mount
simultaneously and both with front facing mode.
DEMI grow Stroller/Sibling Seat Rain Cover
Only use the stroller/sibling seat rain cover in the upper
mount.
2 - To assemble the rain cover, place it over the stroller/
sibling seat.
ALWAYS check ventilation, when the rain cover is
on the product.
ALWAYS check that the rain cover has been cleaned and
dried before folding.
DO NOT fold the stroller assembled with the rain cover.
DO NOT place your child into the stroller assembled with
rain cover during hot weather.

1
1
1
2
EN EN
1 3
2
32 DEMI grow stroller instructions 33DEMI grow stroller instructions
DEMI grow Bassinet
For bassinet assembly and usage, please refer to the
bassinet instruction manual.
When installing the bassinet in the lower mount, close the
canopy.
1 - To attach the bassinet, align the sides of the bassinet
with the seat mounts.
Place the bassinet directly down until it clicks into place.
A “click” sound means the bassinet is attached.
2 - The bassinet can be installed rear or forward facing in
the upper mount.
3 - To remove the bassinet, press the bassinet release
buttons (1) and lift up (2).
Remove the bassinet before folding the stroller.

EN EN
1
2
1
2
1
1
1
2 2
34 DEMI grow stroller instructions 35DEMI grow stroller instructions
1 4
52
3
34 DEMI grow stroller instructions 35DEMI grow stroller instructions
DEMI grow Car Seat Post Adapters
For infant carrier assembly and usage, please refer to the
infant carrier instruction manual. Adapters are suitable for all
NUNA infant carrier.
When installing the infant carrier in the lower mount, close
the canopy.
1 - To attach the car seat post adapters, place the car seat
post adapters on the seat mounts. A “click” sound
means the car seat post adapters are attached.
2 - To attach the infant carrier, place the infant carrier on the
car seat post adapters. A “click” sound means the infant
carrier is attached.
3 - To remove the infant carrier, push the stroller release
buttons on the infant carrier (1) and lift up (2).
4 - To remove the car seat post adapters, pull the adapter
release buttons (1) and lift up (2).
5 - The car seat post adapters and infant carrier can be
attached rear facing (1) or forward facing (2) in the upper
mount.
Remove the infant carrier before folding.

EN EN
36 DEMI grow stroller instructions 37DEMI grow stroller instructions36 DEMI grow stroller instructions 37DEMI grow stroller instructions
DEMI grow Seat & Bassinet Post Adapters
Only be able to assemble the seat & bassinet post
adaptors on the upper mount.
Please use seat & bassinet post adaptors on upper
mount when using the upper mount and lower mount
simultaneously and both with front facing mode.
1 - To attach seat & bassinet post adaptors, place them
onto mounts as shown (1). A “click” sound means the
seat & bassinet post adaptors are locked. (2)
The correctly use of seat & bassinet post adaptors are
shown as (3).
2 - To attach bassinet to the seat & bassinet post adaptors,
place bassinet onto seat & bassinet post adaptors, A
“click” sound means the bassinet is locked. (4)
Please do not use bassinet on the upper seat when the
seat back of lower seat is in vertical position.
3 - To attach seat to the seat & bassinet post adaptors,
place seat onto seat & bassinet post adaptors, A “click”
sound means the seat is locked. (5)
click
2
3
click
4
click
5
1
